Page 1 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R User’s Manual WGSW-24040 / WGSW-24040R 24-Port 10/100/1000Mbps Layer 2 Managed Switch SGSW-24040 / SGSW-24040R 24-Port 10/100/1000Mbps Layer 2 Managed Stackable Switch SGSW-24040P / SGSW-24040P4 24G PoE Managed Stackable Switch SGSW-24240 / SGSW-24240R...
Page 2: Fcc Warning
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.
Page 3: Table Of Contents
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R TABLE OF CONETNTS 1. INTRODUTION ........................13 1.1 Packet Contents ............................13 1.2 Product Description ...........................14 1.3 How to Use This Manual ..........................16 1.4 Product Features............................17 1.5 Product Specification ..........................19 2. INSTALLATION ........................24 2.1 Hardware Description ..........................24...
Page 4 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4. WEB CONFIGURATION ...................... 50 4.1 Main WEB PAGE ............................53 4.2 System.................................55 4.2.1 System Information..............................56 4.2.2 IP Configuration ..............................58 4.2.3 User Authentication .............................59 4.2.4 SNTP Configuration.............................60 4.2.5 WEB Firmware Upgrade............................61 4.2.6 TFTP Firmware Upgrade .............................62 4.2.7 Configuration Save ..............................64...
Page 5 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.6 VLAN................................96 4.6.1 VLAN Overview ..............................96 4.6.2 IEEE 802.1Q VLAN .............................97 4.6.3 VLAN Basic Information.............................101 4.6.4 VLAN Port Configuration ...........................102 4.6.5 VLAN Membership Configuration ........................106 4.6.6 Private VLAN Configuration..........................107 4.7 Rapid Spanning Tree Protocol ........................109 4.7.1 Theory ................................109...
Page 6 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.10.4 802.1X Port Status............................153 4.10.5 802.1X and MAC-Based Authentication Statistics ...................154 4.10.6 Windows Platform RADIUS Server Configuration ...................158 4.10.7 802.1X Client Configuration..........................160 4.11 Access Control Lists ..........................163 4.11.1 Access Control List Configuration ........................163 4.11.2 ACE Configuration ............................165...
Page 7 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.16.3 Stack Information .............................206 4.16.4 Stack Port State Ovewview..........................208 4.16.5 Stack Example..............................209 4.17 Power over Ethernet (SGSW-24040P / SGSW-24040P4)..............212 4.17.1 Power over Ethernet Powered Device ......................213 4.17.2 Power Configuration ............................213 4.17.3 PoE Status...............................218 5.
Page 8 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Port VeriPHY ...............................237 Port Numbers ..............................238 Mirror Configuration.............................239 Mirror Port ................................239 Mirror SID ................................239 Mirror Mode .................................240 6.3 Link Aggregation Command ........................241 Aggregation Configuration...........................241 Aggregation Add..............................241 Aggregation Delete..............................242 Aggregation Lookup ............................242 Aggregation Mode ...............................243...
Page 9 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R RSTP Cost ................................259 RSTP Priority...............................259 RSTP Edge .................................260 RSTP P2P ................................260 RSTP Status ................................261 RSTP Statistics..............................262 RSTP mCheck..............................262 6.6 Multicast Configuration Command ......................263 IGMP Configuration .............................263 IGMP Mode .................................263 IGMP State ................................264 IGMP State ................................264...
Page 10 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Dot1x Secret................................279 Dot1x Authenticate ..............................279 Dot1x Re-authentication ............................280 Dot1x Period................................280 Dot1x Timeout ..............................281 Dot1x Statistics..............................281 Dot1x Clients ...............................282 Dot1x Agetime ..............................282 Dot1x Holdtime ..............................283 6.9 Access Control List Command .......................284 ACL Configuration ...............................284 ACL Action................................284...
Page 11 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.12 Stack Management Command ......................298 Stack List ................................298 Stack List ................................298 Stack Master Reelect............................298 Stack Select.................................298 Stack SID Swap..............................299 Stack SID Delect ..............................299 Stack SID Asign..............................299 6.13 Power over Ethernet Command......................300 PoE Configuration ...............................300...
Page 12 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R APPENDEX A ........................313 A.1 Switch's RJ-45 Pin Assignments ......................313 A.2 10/100Mbps, 10/100Base-TX ........................313 APPENDEX B : GLOSSARY....................315...
Page 13: Introdution
24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch SGSW-24240R 24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch / Redundant Power Terms of “Managed Switch” means the Switches mentioned titled in the cover page of this User’s manual, i.e.WGSW-24040 and SGSW-24040. 1.1 Packet Contents Open the box of the Managed Switch and carefully unpack it.
Page 14: Product Description
VLAN, Spanning Tree protocol, QoS, bandwidth control and IGMP Snooping. The WGSW-24040 provides 802.1Q Tagged VLAN, Q-in-Q VLAN trunning and private VLAN, the VLAN groups allowed on the WGSW-24040 will be maximally up to 255. Via supporting port aggregation, the Managed Switch allows the operation of a high-speed trunk combining multiple ports, up to eight groups of maximum to 8-ports for trunking, and it supports fail-over as well.
Page 15 Advanced Features and Centralized Power Management for Enterprise and Campus PoE Networking (PoE Model) The PLANET SGSW-24040P series PoE Switch provides 24 10/100/1000Mbps Power-over-Ethernet (PoE, IEEE 802.3af compliant) ports which optimize the installation and power management of network devices such as wireless access points (AP), Voice over IP (VoIP) phones, and security video cameras.
Page 16: How To Use This Manual
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 1.3 How to Use This Manual This User Manual is structured as follows: Section 2, INSTALLATION The section explains the functions of the Switch and how to physically install the Managed Switch.
Page 17: Product Features
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 1.4 Product Features Physical Port WGSW-24040 / WGSW-24040R 24-Port 10/100/1000Base-T Gigabit Ethernet RJ-45 4 mini-GBIC/SFP slots, shared with Port-21 to Port-24 RS-232 DB9 console interface for Switch basic management and setup...
Page 18 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R − Private VLAN Edge (PVE) ■ Support Spanning Tree Protocol − STP, IEEE 802.1d (Spanning Tree Protocol) − RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol) ■ Support Link Aggregation − 802.3ad Link Aggregation Control Protocol (LACP) −...
Page 19: Product Specification
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R ■ Mirror across stack ■ Link Aggregation groups spanning multiple switches in a stack ■ Hardware learning with MAC table synchronization across stack Redundant Power System (WGSW-24040R / SGSW-24040R) ■ 100~240V AC / 48V DC Dual power redundant ■...
Page 20 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Jumbo Frame 10Kbytes Power, Link/Act and speed per Gigabit port Power Consumption Max. 30 watts / 102 BTU Power Requirement – AC AC 100~240V, 50/60Hz AC : 100~240V, 50/60Hz -48V DC @ 0.6A Power Requirement –...
Page 21 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R SGSW Stackable PoE models Product SGSW-24040P SGSW-24040P4 Hardware Specification Copper Ports 24 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports SFP/mini-GBIC Slots 4 SFP interfaces, shared with Port-21 to Port-24 Stacking Ports 2 5GbE / Cross-HDMI interface...
Page 22 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R WGSW / SGSW all models Product All Models Layer 2 function System Configuration Console, Telnet, Web Browser, SNMPv1, v2c and v3 Port disable/enable. Auto-negotiation 10/100/1000Mbps full and half duplex mode selection.
Page 23 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX/100BASE-FX IEEE 802.3z Gigabit SX/LX IEEE 802.3ab Gigabit 1000T IEEE 802.3x Flow Control and Back pressure IEEE 802.3ad Port trunk with LACP Standards Compliance IEEE 802.1d Spanning tree protocol IEEE 802.1w Rapid spanning tree protocol...
Page 24: Installation
Figure 2-1 show the front panel of the Managed Switches. WGSW-24040 / WGSW-24040RFront Panel Figure 2-1 WGSW-24040 / WGSW-24040R front panel. SGSW-24040 / SGSW-24040R Front Panel Figure 2-2 SGSW-24040 / SGSW-24040R front panel. SGSW-24040P / SGSW-24040P4 Front Panel Figure 2-3 SGSW-24040P / SGSW-24040P4 front panel.
Page 25 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R ■ Gigabit TP interface 10/100/1000Base-T Copper, RJ-45 Twist-Pair: Up to 100 meters. ■ Gigabit SFP slots 1000Base-SX/LX mini-GBIC slot, SFP (Small Factor Pluggable) transceiver module: From 550 meters (Multi-mode fiber), up to 10/30/50/70/120 kilometers (Single-mode fiber).
Page 26: Led Indications
The front panel LEDs indicates instant status of port links, data activity, system operation, Stack status and system power, helps monitor and troubleshoot when needed. WGSW-24040 / WGSW-24040R LED indication Figure 2-5 WGSW-24040 / WGSW-24040R LED panel ■ System Color Function Lights to indicate that the Switch is powered on.
Page 27 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R ■ 1000Base-SX/LX SFP interfaces (Shared Port-21~Port-24) Color Function Lights: To indicate the link through that SFP port is successfully established with 1000 speed 1000Mbps Green To indicate that the SFP port is link down...
Page 28 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Lights: To indicate the link through that port is successfully established with speed 10Mbps or 100Mbps 10/100 Blink: To indicate that the switch is actively sending or receiving data over that port.
Page 29 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R FAN1 Alert Green Lights to indicate that the FAN1 failure FAN2 Alert Green Lights to indicate that the FAN2 failure FAN3 Alert Green Lights to indicate that the FAN3 failure ■ 10/100/1000Base-T interfaces...
Page 30 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R ■ System Color Function Lights to indicate that the Switch is powered on. Green Blink to indicate the System is running under booting procedure. Master Green Lights to indicate that the Switch is the Master of the stack group...
Page 31: Switch Rear Panel
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R ■ 7-Segment LED Display Stack ID (1~9, A~F, 0): To indicate the Switch ID of each SGSW Managed Switch. Switch IDs are used to uniquely identify the Managed Switches within a stack. The Switch ID of each Managed Switch is shown on the display on the front of the Managed Switch and is used widely in the web pages as well as in the CLI commands of the Stack group.
Page 32 • When stacked, the STX1 / Cascade Down port should connect to the other switch’s STX2 / Cascade UP port and the STX2 / Cascade UP port should connect to other switch’s STX1 / Cascade Down out. • You can just use attached PLANET CB-STX50 or longer stack cable CB-STX200 connector to stack.
Page 33 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • The CB-STX50 and CB-STX200 are Cross-Overed HDMI cables, only attached PLANET stack cable can be used. • Plug-and-play connection. Figure 2-16 SGSW-24040 / SGSW-24040R Stack Ports ■ DC Power Connector The rear panel of the WGSW-24040R and SGSW-24040R contains a power switch and a DC power connector, which accepts DC power input voltage from -30V to -60V DC.
Page 34: Install The Switch
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 2.2 Install the Switch This section describes how to install your Managed Switch and make connections to the Managed Switch. Please read the following topics and perform the procedures in the order being presented. To install your Managed Switch on a desktop or shelf, simply complete the following steps.
Page 35: Rack Mounting
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Step5: Supply power to the Managed Switch. Connect one end of the power cable to the Managed Switch. Connect the power plug of the power cable to a standard wall outlet.
Page 36: Installing The Sfp Transceiver
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 2-20 Mounting SGSW-24040 in a Rack Step6: Proceeds with the steps 4 and steps 5 of session 2.2.1 Desktop Installation to connect the network cabling and supply power to the Managed Switch.
Page 37 SGSW-24040 / SGSW-24040R Approved PLANET SFP Transceivers PLANET Managed Switch supports both Single mode and Multi-mode SFP transceiver. The following list of approved PLANET SFP transceivers is correct at the time of publication: ■ MGB-SX SFP (1000BASE-SX SFP transceiver / Multi-mode / 850nm / 220m~550m) ■...
Page 38 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 2-22 Pull out the SFP transceiver Never pull out the module without pull the handle or the push bolts on the module. Direct pull out the module with violent could damage the module and SFP module slot of the Managed...
Page 39: Connecting Dc Power Supply
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 2.2.4 Connecting DC Power Supply – WGSW-24040R / SGSW-24040R The WGSW-24040R and SGSW-24040R support -48VDC power input, connect the power cable to the switch at the input terminal block. The size of the two screws in the terminal block is M3.5.
Page 40: Stack Installation
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 2.3 Stack Installation SGSW-24040 / SGSW-24040R The SGSW-24040 series Managed Switch provides a switch stacking function to manage up to 16 switches using a single IP address. And up to 384 Gigabit Ethernet ports can be managed by a stacking group and you can add ports and functionality as needed.
Page 41: Connecting Stacking Cable
There are two high-performance HDMI-like Stack ports on the rear panel for proprietary management stack. Only attached PLANET CB-STX50 and CB-STX200 cross-overed HDMI cable can be used. STEP-1: Plug one end of the cable in the “STX1 / Cascade Down” port and the other end to the ”STX2 / Cascade UP” port of next device.
Page 42 STEP-7: Connect the RS-232 serial cable to the console port on the front of the stack master, then loin the SGSW Switch to start the switch management. Or you can use the PLANET Smart Discovery Utility to displayt the IP address of the stack and Web login the stack with this IP address.
Page 43 (console, telnet, web and SNMP) is accessible. It’s allow to build a stack of up to 16 PLANET SGSW Switches. If there is the space limitation or power issue and you wish to stack all the switches in different racks, use long stack cables “CB-STX200” to connect two stacks.
Page 44: Switch Management
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 3. SWITCH MANAGEMENT This chapter explains the methods that you can use to configure management access to the Managed Switch. It describes the types of management applications and the communication and management protocols that deliver data between your management device (workstation or personal computer) and the system.
Page 45: Management Access Overview
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 3.2 Management Access Overview The Managed Switch gives you the flexibility to access and manage it using any or all of the following methods: An administration console Web browser interface An external SNMP-based network management application The administration console and Web browser interface support are embedded in the Managed Switch software and are available for immediate use.
Page 46: Direct Access
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 3-1 Console management Direct Access Direct access to the administration console is achieved by directly connecting a terminal or a PC equipped with a terminal-emulation program (such as HyperTerminal) to the Managed Switch console (serial) port.
Page 47: Web Management
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 3.4 Web Management The Managed Switch offers management features that allow users to manage the Managed Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer. After you set up your IP address for the switch, you can access the Managed Switch's Web interface applications directly in your Web browser by entering the IP address of the Managed Switch.
Page 48: Snmp-Based Network Management
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 3.5 SNMP-Based Network Management You can use an external SNMP-based application to configure and manage the Managed Switch, such as SNMPc Network Manager, HP Openview Network Node Management (NNM) or What’s Up Gold. This management method requires the SNMP agent on the switch and the SNMP Network Management Station to use the same community string.
Page 49: Snmp Protocol
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Start the Telnet program on a PC and connect to the Managed Switch. The management interface is exactly the same with RS-232 console management. 3.6.2 SNMP Protocol Simple Network Management Protocol (SNMP) is the standard management protocol for multi-vendor IP networks. SNMP supports transaction-based queries that allow the protocol to format messages and to transmit information between reporting devices and data-collection programs.
Page 50: Web Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4. WEB CONFIGURATION This section introduces the configuration and functions of the Web-Based management. About Web-based Management The Managed Switch offers management features that allow users to manage the Managed Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.
Page 51 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Logging on the switch Use Internet Explorer 6.0 or above Web browser. Enter the factory-default IP address to access the Web interface. The factory-default IP Address as following: http://192.168.0.100 When the following login screen appears, please enter the default username "admin" with password “admin” (or the username/password you have changed via console) to login the main screen of Managed Switch.
Page 52 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-1-3 Default main page Now, you can use the Web management interface to continue the switch management or manage the Managed Switch by Web interface. The Switch Menu on the left of the web page let you access all the commands and statistics the Managed Switch provides.
Page 53: Main Web Page
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.1 Main WEB PAGE The WGSW / SGSW Managed Switch provides a Web-based browser interface for configuring and managing it. This interface allows you to access the Managed Switch using the Web browser of your choice. This chapter describes how to use the Managed Switch’s Web browser interface to configure and manage it.
Page 54 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Main Menu Using the onboard web agent, you can define system parameters, manage and control the Managed Switch, and all its ports, or monitor network conditions. Via the Web-Management, the administrator can setup the Managed Switch by select the functions those listed in the Main Function.
Page 55: System
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2 System Use the System menu items to display and configure basic administrative details of the Managed Switch. Under System the following topics are provided to configure and view the system information: This section has the following items: ■...
Page 56: System Information
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.1 System Information The System Info page provides information for the current device information. System Info page helps a switch administrator to identify the hardware MAC address, software version and system uptime. The screen in Figure 4-2-1 appears.
Page 57 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R : Click to refresh the page; any changes made locally will be undone. For the SGSW series stackable switch, the System Information page add additional column to identify the current switch ID of...
Page 58: Ip Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.2 IP Configuration The IP Configuration includes the IP Address, Subnet Mask and Gateway. The Configured column is used to view or change the IP configuration.Fill up the IP Address, Subnet Mask and Gateway for the device. The screen in Figure 4-2-2 appears.
Page 59: User Authentication
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R : Click to save changes. : Click to undo any changes made locally and revert to previously saved values. 4.2.3 User Authentication This page allows you to configure the system password required to access the web pages or log in from CLI. After setup completed, please press “Save”...
Page 60: Sntp Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.4 SNTP Configuration In the System sub-function menu, you can see the SNTP Configuration (see Figure 4-4), by which you can configure the time settings for the Managed Switch. You can specify SNTP Servers and set GMT Timezone. The SNTP Configuration screen in Figure 4-2-4 appears.
Page 61: Web Firmware Upgrade
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R It is recommended that you research any time server selection to ensure that it can meet your specific time server requirements. Any NTP time server selection should be evaluated to determine if the server in question meets your specific time server requirements.
Page 62: Tftp Firmware Upgrade
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.6 TFTP Firmware Upgrade The Firmware Upgrade page provides the functions to allow a user to update the Managed Switch firmware from the TFTP server in the network. Before updating, make sure you have your TFTP server ready and the firmware image is on the TFTP server.
Page 63 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-2-8 TFTP Firmware upgrade pop-up message Figure 4-2-9 Firmware Upgrade pop-up message Click “OK”, the Switch will start the TFTP upgrade procedure. Please check your TFTP server application to confirm the TFTP file is well transmit to the Switch.
Page 64: Configuration Save
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.7 Configuration Save This function allows backup and reload the current configuration of the Managed Switch to the local management station. The screen in Figure 4-2-10 appears. Figure 4-2-10 Configuration Save page screenshot You can save/view or load the switch configuration.
Page 65 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-2-11 File Download screen Chose the file save path in management workstation. Figure 4-2-12 File save screen...
Page 66: Configuration Upload
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.8 Configuration Upload This function allows backup and reload the current configuration of the Managed Switch to the local management station. The screen in Figure 4-2-13 appears. Figure 4-2-13 Configuration Upload page screenshot Configuration Upload Click the “Browse”...
Page 67: Factory Default
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.9 Factory Default The Factory Reset button can reset the Managed Switch back to the factory default mode. Be aware that the entire configuration will be reset; include the IP address of the Managed Switch. Once the Factory Reset item is pressed, the screen in...
Page 68: System Reboot
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.2.10 System Reboot The Reboot page enables the device to be rebooted from a remote location. Once the Reboot button is pressed, user have to re-login the WEB interface about 60 seconds later, the screen in Figure 4-2-16 appears.
Page 69: Simple Network Management Protocol
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.3 Simple Network Management Protocol 4.3.1 SNMP Overview The Simple Network Management Protocol (SNMP) is an application layer protocol that facilitates the exchange of management information between network devices. It is part of the Transmission Control Protocol/Internet Protocol (TCP/IP) protocol suite.
Page 70: Snmp System Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.3.2 SNMP System Configuration Configure SNMP on this page. The SNMP System Configuration screen in Figure 4-3-1 appears. Figure 4-3-1 SNMP System Configuration page screenshot Object Description • Indicates the SNMP mode operation. Possible modes are: Mode Enabled: Enable SNMP mode operation.
Page 71: Snmp System Information Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.3.3 SNMP System Information Configuration The switch system information is provided here. The System Information Configuration screen in Figure 4-3-2 appears. Figure 4-3-2 System Information Configuration page screenshot The page includes the following fields:...
Page 72 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-3-3 SNMP Trap Configuration page screenshot The page includes the following fields: Object Description • Indicates the SNMP trap mode operation. Possible modes are: Trap Mode • Enabled: Enable SNMP trap mode operation.
Page 73: Snmpv3 Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Trap Probe Security Indicates the SNMP trap probe security engine ID mode of operation. Possible Engine ID values are: • Enabled: Enable SNMP trap probe security engine ID mode of operation.
Page 74: Snmpv3 Communities Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Security Model Indicates the security model that this entry should belong to. Possible security models are: • any: Accepted any security model (v1|v2c|usm). • v1: Reserved for SNMPv1. v2c: Reserved for SNMPv2c.
Page 75: Snmpv3 Groups Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R from 33 to 126. • Source IP Indicates the SNMP access source address. • Source Mask Indicates the SNMP access source address mask. 4.3.5.3 SNMPv3 Groups Configuration Configure SNMPv3 groups table on this page. The entry index key are Security Model and Security Name.
Page 76: Snmpv3 Users Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.3.5.4 SNMPv3 Users Configuration Configure SNMPv3 users table on this page. The entry index key are Engine ID and User Name. The SNMPv3 Users Configuration screen in Figure 4-3-7 appears. Figure 4-3-7 SNMPv3 Users Configuration page screenshot...
Page 77: Snmpv3 Views Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Authentication A string identifying the authentication pass phrase. For MD5 authentication Password protocol, the allowed string length is 8 to 32. For SHA authentication protocol, the allowed string length is 8 to 40. The allowed content is the ASCII characters from 33 to 126.
Page 78 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R General, if a view entry's view type is 'excluded', it should be exist another view entry which view type is 'included' and it's OID subtree overstep the 'excluded' view entry. •...
Page 79: Port Management
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.4 Port Management Use the Port Menu to display or configure the Managed Switch's ports. This section has the following items: Port Configuration Configures port connection settings Port Statistics Lists Ethernet and RMON port statistics...
Page 80 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The page includes the following fields: Object Description • Port This is the logical port number for this row. • Link The current link state is displayed graphically. Green indicates the link is up and red that it is down.
Page 81: Port Statistics Overview
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Enabled: Link up and link down power savings enabled. • Total Power Usage Total power usage in board, measured in percent. When set each port to run at 100M Full, 100M Half, 10M Full, and 10M Half-speed modes. The Auto-MDIX function will disable.
Page 82: Detailed Port Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The displayed counters are: Object Description • The logical port for the settings contained in the same row. Port • Packets The number of received and transmitted packets per port. •...
Page 83 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The page includes the following fields: Receive Total and Transmit Total Object Description • Rx and Tx Packets The number of received and transmitted (good and bad) packets • Rx and Tx Octets The number of received and transmitted (good and bad) bytes.
Page 84: Port Mirroring Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Transmit Error Counters Object Description • Tx Drops The number of frames dropped due to output buffer congestion. • Tx Late/Exc. Coll. The number of frames dropped due to excessive or late collisions.
Page 85 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Mirror Port Configuration The Port Mirror Configuration screen in Figure 4-4-5 Figure 4-4-6 appears. WGSW Standalone Switch Figure 4-4-5 Port Mirror Configuration page screenshot The page includes the following fields: Object Description •...
Page 86: Sfp Module Information
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R SGSW Stackable Switch The SGSW Stackable switch supports port mirror function over stack switch. Figure 4-4-6 Port Mirror Configuration page screenshot The page includes the following fields: Object Description • Frames from ports that have either source or destination mirroring enabled are Switch to mirror to mirrored to this switch.
Page 87 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-4-7 SFP Module Information page screenshot The page includes the following fields: Object Description • Type Display the type of current SFP module, the possible types are: • 1000Base-SX • 1000Base-LX •...
Page 88: Link Aggregation
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.5 Link Aggregation Port Aggregation optimizes port usage by linking a group of ports together to form a single Link Aggregated Groups (LAGs). Port Aggregation multiplies the bandwidth between the devices, increases port flexibility, and provides link redundancy.
Page 89 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems that require high speed redundant links. Link aggregation lets you group up to eight consecutive ports into a single dedicated connection.
Page 90: Static Aggregation Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.5.1 Static Aggregation Configuration This page is used to configure the Aggregation hash mode and the aggregation group. The aggregation hash mode settings are global, whereas the aggregation group relate to the currently selected stack unit, as reflected by the page header.
Page 91 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-5-3 Aggregation Group Configuration page screenshot The page includes the following fields: Object Description • Locality Indicates the aggregation group type. This field is only valid for stackable switches. •...
Page 92: Lacp Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.5.2 LACP Configuration Link Aggregation Control Protocol (LACP) - LACP LAG negotiate Aggregated Port links with other LACP ports located on a different device. LACP allows switches connected to each other to discover automatically whether any ports are member of the same LAG.
Page 93: Lacp System Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R each second, while Passive will wait for a LACP packet from a partner (speak if spoken to). 4.5.3 LACP System Status This page provides a status overview for all LACP instances. The LACP Status page display the current LACP aggregation Groups and LACP Port status .
Page 94 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-5-6 LACP Port Status page screenshot The page includes the following fields: Object Description • The switch port number. Port • LACP 'Yes' means that LACP is enabled and the port link is up. 'No' means that LACP is not enabled or that the port link is down.
Page 95: Lacp Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.5.5 LACP statistics This page provides an overview for LACP statistics for all ports. The LACP statistics screen in Figure 4-5-7 appears. Figure 4-5-7 LACP Port statistics page screenshot The page includes the following fields:...
Page 96: Vlan
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.6 VLAN 4.6.1 VLAN Overview A Virtual Local Area Network (VLAN) is a network topology configured according to a logical scheme rather than the physical layout. VLAN can be used to combine any collection of LAN segments into an autonomous user group that appears as a single LAN.
Page 97: Ieee 802.1Q Vlan
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.6.2 IEEE 802.1Q VLAN In large networks, routers are used to isolate broadcast traffic for each subnet into separate domains. This Managed Switch provides a similar service at Layer 2 by using VLANs to organize any group of network nodes into separate broadcast domains.
Page 98 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R normally. Some relevant terms: Tagging - The act of putting 802.1Q VLAN information into the header of a packet. Untagging - The act of stripping 802.1Q VLAN information out of the packet header.
Page 99: Port Vlan Id
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Adding an IEEE802.1Q Tag Original Ethernet Dest. Addr. Src. Addr. Length/E. type Data Old CRC Dest. Addr. Src. Addr. E. type Length/E. type Data New CRC New Tagged Packet Priority VLAN ID ■...
Page 100: Vlan Classification
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R VLANs, and any intermediate network devices or the host at the other end of the connection supports VLANs. Then assign ports on the other VLAN-aware network devices along the path that will carry this traffic to the same VLAN(s), either manually or dynamically using GVRP.
Page 101: Vlan Basic Information
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.6.3 VLAN Basic Information The VLAN Basic Information page displays basic information on the VLAN type supported by the Managed Switch. The VLAN Basic Information screen in Figure 4-6-1 appears. Figure 4-6-1 VLAN Basic Information page screenshot...
Page 102: Vlan Port Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.6.4 VLAN Port Configuration This page is used for configuring the Managed Switch port VLAN. The VLAN per Port Configuration page contains fields for managing ports that are part of a VLAN. The port default VLAN ID (PVID) is configured on the VLAN Port Configuration page. All untagged packets arriving to the device are tagged by the ports PVID.
Page 103 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The Managed Switch supports multiple VLAN tags and can therefore be used in MAN applications as a provider bridge, aggregating traffic from numerous independent customer LANs into the MAN (Metro Access Network) space. One of the purposes of the provider bridge is to recognize and use VLAN tags so that the VLANs in the MAN space can be used independent of the customers’...
Page 104 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-6-2 VLAN Port Configuration page screenshot The page includes the following fields: Object Description • This is the logical port number for this row. Port • PVID Allow assign PVID for selected port. The range for the PVID is 1-4094.
Page 105 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Q-in-Q Mode Sets the Managed Switch to QinQ mode, and allows the QinQ tunnel port to be configured. The default is for the Managed Switch to function in Disable mode.
Page 106: Vlan Membership Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.6.5 VLAN Membership Configuration Adding Static Members to VLANs (VLAN Index) Use the VLAN Static Table to configure port members for the selected VLAN index. Assign ports as tagged if they are connected to 802.1Q VLAN compliant devices, or untagged they are not connected to any VLAN-aware devices.
Page 107: Private Vlan Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.6.6 Private VLAN Configuration Overview When a VLAN is configured to be a private VLAN, communication between ports within that VLAN can be prevented. Two application examples are provided in this section: •...
Page 108 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The port settings relate to the currently selected stack unit, as reflected by the page header. This feature works across the stack. Figure 4-6-4 Private VLAN Configuration page screenshot The page includes the following fields:...
Page 109: Rapid Spanning Tree Protocol
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.7 Rapid Spanning Tree Protocol 4.7.1 Theory The Spanning Tree protocol can be used to detect and disable network loops, and to provide backup links between switches, bridges or routers. This allows the switch to interact with other bridging devices in your network to ensure that only one route exists between any two stations on the network, and provide backup links which automatically take over when a primary link goes down.
Page 110 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The switch sends BPDUs to communicate and construct the spanning-tree topology. All switches connected to the LAN on which the packet is transmitted will receive the BPDU. BPDUs are not directly forwarded by the switch, but the receiving switch uses the information in the frame to calculate a BPDU, and, if the topology changes, initiates a BPDU transmission.
Page 111 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Switch Blocking Listening Disable Learning Forwarding Figure 4-7-1 STP Port State Transitions You can modify each port state by using management software. When you enable STP, every port on every switch in the network goes through the blocking state and then transitions through the states of listening and learning at power up.
Page 112 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Priority A relative priority for each switch – lower 32768 numbers give a higher priority and a greater chance of a given switch being elected as the root bridge Hello Time...
Page 113 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R the Root Bridge, the set Hello Time will be used if and when your Switch becomes the Root Bridge. The Hello Time cannot be longer than the Max. Age. Otherwise, a configuration error will occur.
Page 114 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R LAN 1 Portcast = 19 Port 3 Bridge ID = 15 Port 1 Port 2 Portcast = 4 Portcast = 4 Portcast = 4 Portcast = 4 Port 1 Port 1...
Page 115: Rstp System Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.7.2 RSTP System Configuration This page allows you to configure RSTP system settings. The settings are used by all RSTP Bridge instances in the Switch or switch Stack. The Managed Switch support the following Spanning Tree protocols: ‧...
Page 116: Rstp Bridge Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Compatible – Classis STP (802.1d): Provides a single path between end stations, avoiding and eliminating loops. The Gigabit Ethernet Switch implement the Rapid Spanning Protocol as the default spanning tree protocol. While select “Compatibles” mode, the system use the RSTP (802.1w) to compatible and co work with another STP (802.1d)’s BPDU control packets.
Page 117: Rstp Port Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.7.4 RSTP Port Configuration This page allows the user to inspect the current RSTP port configurations, and possibly change them as well. This page contain settings for aggregations and physical ports. The aggregation settings are stack global.
Page 118 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R path cost ports are chosen as forwarding ports in favor of higher path cost ports. Valid values are in the range 1 to 200000000. • Controls the port priority. This can be used to control priority of ports having Priority identical port cost.
Page 119 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Port Type Link Type IEEE 802.1w-2001 Ethernet Half Duplex 2,000,000 Full Duplex 1,000,000 Trunk 500,000 Fast Ethernet Half Duplex 200,000 Full Duplex 100,000 Trunk 50,000 Gigabit Ethernet Full Duplex 10,000 Trunk...
Page 120: Rstp Port Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.7.5 RSTP Port Status This page displays the RSTP port status for port physical ports in the currently selected switch. The RSTP Port Status screen in Figure 4-7-10 appears. Figure 4-7-10 RSTP Port Status page screenshot...
Page 121: Rstp Port Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • State The current RSTP port state. The port state can be one of the following values: • Disabled • Blocking • Learning Forwarding • Non-STP. • • The RSTP Bridge instance (VLAN ID). This is also a link to the RSTP Detailed Bridge Bridge Status, if the port is RSTP enabled.
Page 122: Quality Of Service
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8 Quality of Service 4.8.1 Understand QOS Quality of Service (QoS) is an advanced traffic prioritization feature that allows you to establish control over network traffic. QoS enables you to assign various grades of network service to different types of traffic, such as multi-media, video, protocol-specific, time critical, and file-backup traffic.
Page 123: Qos Control List Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Create a QoS profile which associates a service level and a classifier. Apply a QoS profile to a port(s). 4.8.2 QoS Control List Configuration This page lists the QCEs for a given QCL.
Page 124: Qos Control Entry Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Type Value Indicates the value according to its QCE type. • Ethernet Type: The field shows the Ethernet Type value. • VLAN ID: The field shows the VLAN ID. •...
Page 125: Port Qos Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The page includes the following fields: Object Description • QCE Type Select the available type for the specific QCE. • Ethernet Type: Matches the received frame's EtherType against the QCE Key.
Page 126 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-8-3 Port QoS Configuration page screenshot The page includes the following fields: Object Description • Number of Classes Configure the number of traffic classes as "1", "2", or "4". The default value is "4".
Page 127: Qcl Configuration Wizard
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8.4 QCL Configuration Wizard This handy wizard helps you set up a QCL quickly. The QCL Configuration Wizard screen in Figure 4-8-5 appears. Figure 4-8-5 Welcome to the QCL Configuration Wizard page screenshot...
Page 128 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-8-6 Set up Policy Rules page screenshot The page includes the folling fileds: Object Description • Frames that hit this QCE are set to match this specific QCL. QCL ID •...
Page 129: Set Up Typical Network Application Rules
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8.4.2 Set up Typical Network Application Rules Set up the specific QCL for different typical network application quality control. STEP-1 Set up the specific QCL for different typical network application quality control by selecting the network application type for your...
Page 130 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • User Definition Indicates the user definition that applies to the specific QCE. The user definitions are: • Ethernet Type: Specify the Ethernet Type filter for this QCE. The allowed range is 0x600 to 0xFFFF.
Page 131: Set Up Tos Precedence Mapping
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8.4.3 Set up ToS Precedence Mapping Set up the traffic class mapping to the precedence part of ToS (3 bits) when receiving IPv4/IPv6 packets. The screen in Figure 4-8-10 appears. Figure 4-8-10 Set up ToS Precedence Mapping page screenshot...
Page 132: Set Up Vlan Tag Priority Mapping
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8.4.4 Set up VLAN Tag Priority Mapping Set up the traffic class mapping to the User Priority value (3 bits) when receiving VLAN tagged packets. The screen in Figure 4-8-11 appears.
Page 133: Qos Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8.5 QoS Statistics This page provides statistics for the different queues for all switch ports. The ports belong to the currently selected stack unit, as reflected by the page header. The QoS Statistics screen in Figure 4-8-12 appears.
Page 134: Bandwidth Control
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8.6 Bandwidth Control Configure the switch port rate limit for Policers and Shapers on this page. The settings relate to the currently selected stack unit, as reflected by the page header. The screen Bandwidth Control in Figure 4-8-13 appears.
Page 135: Storm Control Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.8.7 Storm Control Configuration Storm control for the switch is configured on this page. There three types of storm rate control: Unicast storm rate control Multicast storm rate control Broadcast storm rate control.
Page 136: Multicast
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.9 Multicast 4.9.1 IGMP Snooping The Internet Group Management Protocol (IGMP) lets host and routers share information about multicast groups memberships. IGMP snooping is a switch feature that monitors the exchange of IGMP messages and copies them to the CPU for feature processing.
Page 137 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-9-2 Multicast flooding Figure 4-9-3 IGMP Snooping multicast stream control...
Page 138 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R IGMP Versions 1 and 2 Multicast groups allow members to join or leave at any time. IGMP provides the method for members and multicast routers to communicate when joining or leaving a multicast group.
Page 139 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R message, and query messages that are specific to a given group. The states a computer will go through to join or to leave a multicast group are shown below: Non-Member Leave Group...
Page 140: Igmp Snooping Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.9.2 IGMP Snooping Configuration This page provides IGMP Snooping related configuration. Most of the settings are global, whereas the Router Port configuration is related to the currently selected stack unit, as reflected by the page header.
Page 141: Igmp Port Related Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.9.3 IGMP Port Related Configuration This page provides IGMP Snooping related configuration. Most of the settings are global, whereas the Router Port configuration is related to the currently selected stack unit, as reflected by the page header.
Page 142: Igmp Snooping Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.9.4 IGMP Snooping Status This page provides IGMP Snooping status. The status relate to the currently selected stack unit, as reflected by the page header. The IGMP Snooping status screen in Figure 4-9-7 appears.
Page 143: Multicast Address Table
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.9.5 Multicast Address Table The Multicast Address Table screen in Figure 4-9-8 appears. Figure 4-9-8 Multicast Address Table page screenshot The page includes the following fields: Object Description • Delete Check to delete the entry. It will be deleted during the next save.
Page 144: Ieee 802.1X Network Access Control
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.10 IEEE 802.1X Network Access Control Overview of 802.1X (Port-Based) Authentication In the 802.1X-world, the user is called the supplicant, the switch is the authenticator, and the RADIUS server is the authentication server.
Page 145: Understanding Ieee 802.1X Port-Based Authentication
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.10.1 Understanding IEEE 802.1X Port-Based Authentication The IEEE 802.1X standard defines a client-server-based access control and authentication protocol that restricts unauthorized clients from connecting to a LAN through publicly accessible ports. The authentication server authenticates each client connected to a switch port before making available any services offered by the switch or the LAN.
Page 146 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Switch (802.1X device)—controls the physical access to the network based on the authentication status of the client. The switch acts as an intermediary (proxy) between the client and the authentication server, requesting identity information from the client, verifying that information with the authentication server, and relaying a response to the client.
Page 147 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-10-2 EAP message exchange Ports in Authorized and Unauthorized States The switch port state determines whether or not the client is granted access to the network. The port starts in the unauthorized state.
Page 148: System Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.10.2 802.1X System Configuration This page allows you to configure the IEEE 802.1X and MAC-based authentication system and port settings. The IEEE 802.1X standard defines a port-based access control procedure that prevents unauthorized access to a network by requiring users to first submit credentials for authentication.
Page 149 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Reauthentication If checked, clients are reauthenticated after the interval specified by the Enabled Reauthentication Period. Reauthentication for 802.1X-enabled ports can be used to detect if a new device is plugged into a switch port.
Page 150: And Mac-Based Authentication Port Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.10.3 802.1X and MAC-Based Authentication Port Configuration When 802.1X is enabled, you need to configure the parameters for the authentication process that runs between the client and the switch (i.e., authenticator), as well as the client identity lookup process that runs between the switch and authentication server.
Page 151 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Object Description • Port The port number for which the configuration below applies. • Admin State Sets the authentication mode to one of the following options (only used when 802.1X or MAC-based authentication is...
Page 152 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R the value "Specific" from the list-box opens up for entering a specific number of maximum clients on the port (1 to 104). The stackswitch is "born" with a pool of state-machines, from which all ports draw whenever a new client is seen on the port.
Page 153: Port Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.10.4 802.1X Port Status This page provides an overview of the current IEEE 802.1X port states for the selected switch. The 802.1X Port Status screen in Figure 4-10-5 appears. Figure 4-10-5 802.1X Status page screenshot...
Page 154: And Mac-Based Authentication Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R EAPOL frame for port-based authentication, and the source MAC address from the most recently received frame from a new client for MAC-based authentication. 4.10.5 802.1X and MAC-Based Authentication Statistics This page provides detailed IEEE 802.1X statistics for a specific switch port running port-based authentication. For MAC-based ports, it shows selected RADIUS statistics, only.
Page 155 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The selected port belongs to the currently selected stack unit as reflected by the table header. EAPOL Counters These counters are not available for MAC-based ports. Supplicant frame counter statistics. There are seven receive frame counters and three transmit frame counters.
Page 156 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R RADIUS Counters RADIUS Server frame counter statistics. For MAC-based ports there are two tables containing RADIUS counters. The left-most shows a summary of all RADIUS counters on this port. The right-most shows RADIUS counters for the currently selected client, or dashes if no client is selected or available.
Page 157 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R MAC-based: Counts all the RADIUS packets sent from the switch towards the RADIUS server for a given port (left-most table) or client (right-most table). Possible retransmissions are not counted. Last Supplicant/Client Info For MAC-based ports, this section is embedded in the RADIUS counter's section.
Page 158: Windows Platform Radius Server Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.10.6 Windows Platform RADIUS Server Configuration Setup the RADIUS server and assign the client IP address to the Managed switch. In this case, field in the default IP Address of the Managed Switch with 192.168.0.100. And also make sure the shared secret key is as same as the one you had set at the switch RADIUS server –...
Page 159 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-10-9 Windows Server RADIUS Server setting path Enter ” Active Directory Users and Computers”, create legal user data, the next, right-click a user what you created to enter properties, and what to be noticed:...
Page 160: Client Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Set the Ports Authenticate Status to “Force Authorized” if the port is connected to the RADIUS server or the port is a uplink port that is connected to another switch. Or once the 802.1X stat to work, the switch might not be able to access the RADIUS server.
Page 161 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-10-12 Click “OK”. When client has associated with the Managed Switch, a user authentication notice appears in system tray. Click on the notice to continue. Figure 4-10-13...
Page 162 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Enter the user name, password and the logon domain that your account belongs. 10. Click “OK” to complete the validation process. Figure 4-10-14...
Page 163: Access Control Lists
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.11 Access Control Lists ACL is an acronym for Access Control List. It is the list table of ACEs, containing access control entries that specify individual users or groups permitted or denied to specific traffic objects, such as a process or a program.
Page 164 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Policy: The ACE will match ingress ports with a specific policy. • Port: The ACE will match a specific ingress port. • Frame Type Indicates the frame type of the ACE. Possible values are: Any: The ACE will match any frame type.
Page 165: Ace Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.11.2 ACE Configuration Configure an ACE (Access Control Entry) on this page. An ACE consists of several parameters. These parameters vary according to the frame type that you select. First select the ingress port for the ACE, and then select the frame type.
Page 166 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R MAC Parameters Object Description • SMAC Filter (Only displayed when the frame type is Ethernet Type or ARP.) Specify the source MAC filter for this ACE. Any: No SMAC filter is specified. (SMAC filter status is "don't-care".) Specific: If you want to filter a specific source MAC address with this ACE, choose this value.
Page 167 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R ARP Parameters The ARP parameters can be configured when Frame Type "ARP" is selected. Object Description • ARP/RARP Specify the available ARP/RARP opcode (OP) flag for this ACE. • Any: No ARP/RARP OP flag is specified. (OP is "don't-care".) •...
Page 168 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R address field (THA) settings. 0: RARP frames where THA is not equal to the SMAC address. 1: RARP frames where THA is equal to the SMAC address. Any: Any value is allowed ("don't-care").
Page 169 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R TCP parameters will appear. These fields are explained later in this help file. • IP Protocol Value When "Specific" is selected for the IP protocol value, you can enter a specific value..
Page 170 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R address and destination IP mask in the DIP Address and DIP Mask fields that appear. • DIP Address When "Host" or "Network" is selected for the destination IP filter, you can enter a specific DIP address in dotted decimal notation.
Page 171 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R hits this ACE matches this TCP/UDP source value. • TCP/UDP Source When "Range" is selected for the TCP/UDP source filter, you can enter a specific TCP/UDP source range value. The allowed range is 0 to 65535. A frame that hits Range this ACE matches this TCP/UDP source value.
Page 172: Acl Configuration Wizard
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Ethernet Type Parameters The Ethernet Type parameters can be configured when Frame Type "Ethernet Type" is selected. Object Description • EtherType Filter Specify the Ethernet type filter for this ACE. Any: No EtherType filter is specified (EtherType filter status is "don't-care").
Page 173: Set Up Policy Rules
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The page includes the following fields: Object Description • Set up Policy Rules Set up the default policy rules for Client ports, Server ports, Network ports and Guest ports. • Group ports into several types according to different ACL policies.
Page 174: Set Up Port Policies
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.11.3.2 Set up Port Policies Group ports into several types according to different ACL policies. The settings relate to the currently selected stack unit, as reflected by the page header. The screen in Figure 4-11-4 appears.
Page 175: Set Up Typical Network Application Rules
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.11.3.3 Set up Typical Network Application Rules Set up the specific for different typical network application access control. The screen in Figure 4-11-5 appears. STEP-1: Selecting the Network Application Type: Figure 4-11-5 Set up Typical network Application Rules page screenshot...
Page 176 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R range is 0 to 65535. • Others Indicates the other application that applies to the specific ACE. The other applications are: HTTPS, ICMP, Multicast IP Stream, NetBIOS, PING Request, Ping Reply, SNMP, SNMP Traps.
Page 177 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R through 8. • Switch Select the switch to which this ACE applies. • Any: The ACE applies to any port. • Switch n: The ACE applies to this switch number, where n is the number of the switch.
Page 178: Set Up Source Mac And Source Ip Binding
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.11.3.4 Set up Source MAC and Source IP Binding Strictly control the network traffic by only allowing incoming frames that match the source IP and source MAC on specific port. The settings relate to the currently selected stack unit, as reflected by the page header.
Page 179: Set Up Dos Attack Detection Rules
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-11-9 4.11.3.5 Set up Attack Detection Rules Set up the specific ACL for different typical network application access control. The screen in Figure 4-11-10 appears. Figure 4-11-10 Set up DoS Attack Detection Rules page screenshot...
Page 180: Set Up Dos Attack Detection Rules
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R packet of destination unreachable to the spoofed source address. Eventually leading it to be unreachable by other clients and the system will go down. • A malicious attacker sending a malformed ICMP request packet larger than the...
Page 181 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The page includes the following fields: Object Description • Ingress Port Select the ingress port to which this ACE applies. • Any: The ACE applies to any port. • Port n: The ACE applies to this port number, where n is the number of the switch port.
Page 182: Acl Rate Limiter Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.11.4 ACL Rate Limiter Configuration Configure the rate limiter for the ACL of the switch. The ACL Rate Limiter Configuration screen in Figure 4-11-13 appears. Figure 4-11-13 ACL Rate Limiter Configuration page screenshot...
Page 183: Acl Ports Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.11.5 ACL Ports Configuration Configure the ACL parameters (ACE) of each switch port. These parameters will affect frames received on a port unless the frame matches a specific ACE. The settings relate to the currently selected stack unit, as reflected by the page header.
Page 184 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Select the policy to apply to this port. The allowed values are 1 through 8. The Policy ID default value is 1. • Select whether forwarding is permitted ("Permit") or denied ("Deny"). The default Action value is "Permit".
Page 185: Address Table
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.12 Address Table Switching of frames is based upon the DMAC address contained in the frame. The Managed Switch builds up a table that maps MAC addresses to switch ports for knowing which ports the frames should go to ( based upon the DMAC address in the frame ).
Page 186: Static Mac Table Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.12.2 Static MAC Table Configuration The static entries in the MAC table are shown in this table. The static MAC table can contain 64 entries. The maximum of 64 entries is for the whole stack, and not per switch.
Page 187: Mac Address Table Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.12.3 MAC Address Table Status Dynamic MAC Table Entries in the MAC Table are shown on this page. The MAC Table contains up to 8192 entries, and is sorted first by VLAN ID, then by MAC address.
Page 188 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Buttons Auto-refresh □ : Check this box to enable an automatic refresh of the page at regular intervals. Refreshe: Refreshes the displayed table starting from the "Start from MAC address" and "VLAN" input fields.
Page 189: Port Security
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.13 Port Security (To be Continued) Port security is a feature that allows you to configure a switch port with one or more device MAC addresses that are authorized to access the network through that port.
Page 190 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Make sure that the link used for managing the switch is added to the Static Mac Table before changing to secure learning mode, otherwise the management link is lost and can only be restored by using another non-secure port or by connecting to the switch via the serial interface.
Page 191: Lldp
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.14 LLDP 4.14.1 Link Layer Discovery Protocol Link Layer Discovery Protocol (LLDP) is used to discover basic information about neighboring devices on the local broadcast domain. LLDP is a Layer 2 protocol that uses periodic broadcasts to advertise information about the sending device. Advertised information is represented in Type Length Value (TLV) format according to the IEEE 802.1ab standard, and can include details...
Page 192: Lldp Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.14.2 LLDP Configuration This page allows the user to inspect and configure the current LLDP port settings. The LLDP Configuration screen in Figure 4-14-1 appears. Figure 4-14-1 LLDP Configuration page screenshot...
Page 193 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R This attribute must comply with the following rule: (Transmission Interval * Hold Time Multiplier) ≤65536, and Transmission Interval >= (4 * Delay Interval) • Each LLDP frame contains information about how long the information in the Tx Hold LLDP frame shall be considered valid.
Page 194 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Port Descr Optional TLV: When checked the "port description" is included in LLDP information transmitted. • Optional TLV: When checked the "system name" is included in LLDP information Sys Name transmitted.
Page 195: Lldp Neighbor
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.14.3 LLDP Neighbor This page provides a status overview for all LLDP neighbors. The displayed table contains a row for each port on which an LLDP neighbor is detected. The LLDP Neighbor screen in Figure 4-14-3 appears.
Page 196: Lldp Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.14.4 LLDP Statistics This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to the whole stack, switch, while local counters refers to counters for the currently selected switch. The LLDP Statistics screen in Figure 4-14-4 appears.
Page 197 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Total Neighbors Shows the number of LLDP frames dropped due to that the entry table was full. Entries Dropped • Shows the number of entries deleted due to Time-To-Live expiring.
Page 198: Network Diagnastics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.15 Network Diagnastics 4.15.1 Cable Diagnostics This page is used for running the Cable Diagnostics. Press to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds.
Page 199: Ping
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.15.2 Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press , 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply.
Page 200: Stacking
Chain topology (same as a disconnected ring) Multiple PLANET SGSW-24040 / SGSW-24040R devices may be connected together to constitute a ring or chain stack topology using the STX / 5Gbps ports as interconnect links. Dedicated stacking features built into SGSW-24040 / SGSW-24040R makes all devices in the stack operate together as a single, much larger switch.
Page 201 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Chain Stack: A chain of switches, that is, no redundant forwarding paths. Figure 4-16-1 Chain Stack topology Ring Stack: A ring of switches, thereby providing redundant forwarding paths. Figure 4-16-2 Ring Stack topology Back-to-Back Stack : Two switches interconnected on both stacking ports.
Page 202: Stack
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.16.1 Stack This section provides information for understand stacking architecture, include the below items: Switch IDs • Assigning and Swapping Switch IDs • Removing a Switch From the Stack • Replacing a Switch •...
Page 203: Master Election
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R "Save". The new hardware has now taken over the configuration of the failing hardware. General Switch ID Assignment Rules When assigning Switch IDs to the devices in the stack, you must note the following: Switches with assigned IDs can be changed to use any other switch ID (possibly by swapping Switch ID with another active switch).
Page 204: Shortest Path Forwarding
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-16-4 Remove or Replace a switch from the stack 4.16.1.4 Shortest Path Forwarding The SGSW Swtich supports shortest path forwarding technology to optimal data flow across the stack. The advantage of shortest path forwarding as below: Automatic Loop Prevention –...
Page 205: Stack Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.16.2 Stack Configuration This page is used for configure the stack, include assign Switch ID, master priority and display the current stack member information. The screen in Figure 4-16-6appears. Figure 4-16-6 Stack Configuration page screenshot...
Page 206: Stack Information
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.16.3 Stack Information This page provides an overview of the stack topology, as detected by SPROUT. Stack Topology The Stack Topology screen in Figure 4-16-7 appears. Figure 4-16-7 Stack Information page screenshot - Stack Topology...
Page 207 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-16-8 Stack Information page screenshot - Stack List The page includes the following fields: Object Description • Delete Deletes this switch from the stack configuration. • Stack Member The MAC address of the switch.
Page 208: Stack Port State Ovewview
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-16-9 Stack Information page screenshot - Master Forwarding Table 4.16.4 Stack Port State Ovewview This page provides an overview of the current switch port states. Clicking on the image of a port opens the Port Statistics page.The port states are illustrated as follows:...
Page 209: Stack Example
Step 3: Use the Web browser such as IE 6.0 to login the Master Switch, the default IP address is 192.168.0.100. Or you can use the PLANET Smart Discovery Utility to find out the IP address of the stack group.
Page 210 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 4-16-12 Stack Configuration Step 5: We wish to make the SGSW switch with MAC “00-30-4f-24-04-76” / Switch ID=2 to become the Stack Master and swap the Switch ID to 1.
Page 211 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Reflash the web browser, the switch with MAC address “00-30-4f-24-04-76” become the stack master now. Figure 4-16-14 The result after master election Step 6: After the Stack Master and Members have been configured, any switch in the stack can be managed from the web agent by choosing the desired Member ID from the Switch drop down menu.
Page 212: Power Over Ethernet (Sgsw-24040P / Sgsw-24040P4)
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.17 Power over Ethernet (SGSW-24040P / SGSW-24040P4) Providing up to 24 PoE, in-line power interface, the SGSW-24040P / SGSW-24040P PoE Switch can easily build a power central-controlled IP phone system, IP Camera system, AP group for the enterprise. For instance, 24 camera / AP can be easily installed around the corner in the company for surveillance demands or build a wireless roaming environment in the office.
Page 213: Power Over Ethernet Powered Device
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.17.1 Power over Ethernet Powered Device Voice over IP phones Enterprise can install POE VoIP Phone, ATA and other Ethernet/non-Ethernet end-devices to the central where UPS is installed for un-interrupt power system and power control system.
Page 214 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Classification mode In this mode each port automatic determines how much power to reserve according to the class the connected PD belongs to, and reserves the power accordingly. Three different port classes exist and one for 4, 7 and 15.4 Watts.
Page 215 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Ethernet Port Configuration This section allows the user to inspect and configure the current PoE port settings , screen in Figure 4-17-2 appears. Figure 4-17-2 PoE Configuration screenshot The page includes the following fields:...
Page 216 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Allocation mode Auto mode • Port class, if available • Power allocation, if available • Port power consumption. Consumption Priority mode The default PoE management mode is “Auto mode”. • Power Supply Set limit value of the total PoE port provided power to the PDs.
Page 217 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R A PD shall return Class 0 to 3 in accordance with the maximum power draw as specified by Table 4-17-1. Class Usage Range of maximum power used by the PD Default 0.44 to 12.95 Watts...
Page 218: Poe Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 4.17.3 PoE Status This page allows the user to inspect the total power consumption, total power reserved and current status for all PoE ports. The page includes the following fields: Object Description •...
Page 219 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R • Total Power Reserved Shows how much the total power be reserved for all PDs. • PoE Temperature Unit 1 Display the current operating temperature of PoE chip unit 1. The unit 1 is in charge of PoE Port-1~Port-12 •...
Page 220: Command Line Interface
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 5. COMMAND LINE INTERFACE 5.1 Accessing the CLI When accessing the management interface for the switch over a direct connection to the server’s console port, or via a Telnet connection, the switch can be managed by entering command keywords and parameters at the prompt. Using the switch's command-line interface (CLI) is very similar to entering commands on a UNIX system.
Page 221: Configure Ip Address
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R For security reason, please change and memorize the new password after this first setup. Only accept command in lowercase letter under console interface. Configure IP address The WGSW / SGSW Managed Switch is shipped with default IP address as following.
Page 222 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R On “Switch/> ” prompt, enter the following command and press <Enter>. As show in Figure 5-3. Switch/> ip setup 192.168.1.100 255.255.255.0 192.168.1.1 The previous command would apply the follow settings for the Switch.
Page 223: Telnet Login
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R terminal-emulation program for connecting to the terminal serial port. A workstation attachment under UNIX can use an emulator such as TIP 5.2 Telnet login The Managed Switch also supports telnet for remote management. The switch asks for user name and password for remote...
Page 224: Command Line Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6. Command Line Mode The CLI groups all the commands in appropriate modes according to the nature of the command. A sample of the CLI command modes are described below. Each of the command modes supports specific software commands.
Page 225: System Reboot
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R : Show all switch configuration, default: Show system configuration <port_list>: Port list or 'all', default: All ports Example: To display system information: Switch/>system configuration System Name : SGSW-24040 System Password: admin...
Page 226: System Name
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: keep_ip: Keep IP configuration, default: Restore full configuration Example: To restore default value but not reset IP address: Switch/>system restore default keep_ip System Name Description: Set or show the system name.
Page 227: System Password
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <prompt>: CLI prompt string Default Setting: SWITCH Example: To change CLI title: Switch/>system prompt SGSW-24040 SGSW-24040/> System Password Description: Set or show the system password. Syntax: System Password [<password>] Parameters: <password>: System password or 'clear' to clear...
Page 228: System Timezone
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <ip_addr>: IP address (a.b.c.d), default: Show IP address Default Setting: 0.0.0.0 Example: Set SNTP server: SWITCH/>system sntp 220.130.158.52 System Timezone Description: Set or show the system timezone offset. Syntax: System Timezone [<offset>] Parameters: <offset>: Time zone offset in minutes (-720 to 720) relative to UTC...
Page 229 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <ip_server>: TFTP server IP address (a.b.c.d) <file_name>: Firmware file name...
Page 230: Ip Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R IP Configuration Description: Show IP configuration. Syntax: IP Configuration Example: Show IP configuration: Switch/>ip configuration DHCP Client: Disabled IP Address : 192.168.100.105 IP Mask : 255.255.255.0 IP Router : 192.168.100.1 VLAN ID SNTP Server: 0.0.0.0...
Page 231: Ip Setup
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R IP Setup Description: Set or show the IP setup. Syntax: IP Setup [<ip_addr>] [<ip_mask>] [<ip_router>] [<vid>] Parameters: <ip_addr> : IP address (a.b.c.d), default: Show IP address <ip_mask> : IP subnet mask (a.b.c.d), default: Show IP mask <ip_router>: IP router (a.b.c.d), default: Show IP router...
Page 232 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R SWITCH/>ip ping 192.168.0.51 PING server 192.168.0.51 60 bytes from 192.168.0.51: icmp_seq=0, time=0ms 60 bytes from 192.168.0.51: icmp_seq=1, time=0ms 60 bytes from 192.168.0.51: icmp_seq=2, time=10ms 60 bytes from 192.168.0.51: icmp_seq=3, time=0ms 60 bytes from 192.168.0.51: icmp_seq=4, time=0ms...
Page 233: Port Management Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.2 Port Management Command Port Configuration Description: Show port configuration. Syntax: Port Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Example: Display port1~4 status SWITCH/>port configuration 1-4 Port State...
Page 234: Port Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Default Setting: Enable Example: Disable port1 SWITCH/>port state 1 disable Port Mode Description: Set or show the port speed and duplex mode. Syntax: Port Mode [<port_list>] [10hdx|10fdx|100hdx|100fdx|1000fdx|auto] Parameters: <port_list>: Port list or 'all', default: All ports...
Page 235: Port Maximum Frame
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Syntax: Port Flow Control [<port_list>] [enable|disable] Parameters: <port_list>: Port list or 'all', default: All ports enable : Enable flow control disable : Disable flow control (default: Show flow control mode) Default Setting:...
Page 236: Port Power
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Port Power Description: Set or show the port PHY power mode. Syntax: Port Power [<port_list>] [enable|disable|actiphy|dynamic] Parameters: <port_list>: Port list or 'all', default: All ports enable : Enable all power control...
Page 237: Port Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Example: SWITCH/>port excessive 1 restart Port Statistics Description: Show port statistics. Syntax: Port Statistics [<port_list>] [<command>] Parameters: <port_list> : Port list or 'all', default: All ports <command> : The command parameter takes the following values:...
Page 238: Port Numbers
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Port Numbers Description: Show port numbering. Syntax: Port Numbers...
Page 239: Mirror Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Mirror Configuration Description: Show mirror configuration. Syntax: Mirror Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Mirror Port Description: Set or show the mirror port. Syntax: Mirror Port [<port>|disable] Parameters: <port>|disable: Mirror port or 'disable', default: Show port...
Page 240: Mirror Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Default Setting: Example: Set mirror SID 2 for switch SWITCH/>mirror sid 2 Mirror Mode Description: Set or show the mirror mode. Syntax: Mirror Mode [<port_list>] [enable|disable|rx|tx] Parameters: <port_list>: Port list or 'all', default: All ports...
Page 241: Link Aggregation Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.3 Link Aggregation Command Aggregation Configuration Description: Show link aggregation configuration. Syntax: Aggr Configuration Example: SWITCH/>aggr configuration Aggregation Mode: SMAC : Enabled DMAC : Disabled : Enabled Port : Enabled Aggregation Add Description: Add or modify link aggregation.
Page 242: Aggregation Delete
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Aggregation Delete Description: Delete link aggregation. Syntax: Aggr Delete <aggr_id> Parameters: <aggr_id>: Aggregation ID, global: 1-2, local: 3-14 Example: Delete Group2 SWITCH/>aggr delete 2 Aggregation Lookup Description: Lookup link aggregation. Syntax: Aggr Lookup [<aggr_id>]...
Page 243: Aggregation Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Aggregation Mode Description: Set or show the link aggregation traffic distribution mode. Syntax: Aggr Mode [smac|dmac|ip|port] [enable|disable] Parameters: smac : Source MAC address dmac : Destination MAC address : Source and destination IP address...
Page 244: Lacp Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R LACP Configuration Description: Show LACP configuration. Syntax: LACP Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Example: Show LACP configuration SWITCH/>lacp configuration Port Mode Role ---- -------- ---- ------...
Page 245: Lacp Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Disabled Auto Active Disabled Auto Active Disabled Auto Active Disabled Auto Active LACP Mode Description: Set or show LACP mode. Syntax: LACP Mode [<port_list>] [enable|disable] Parameters: <port_list>: Port list or 'all', default: All ports...
Page 246: Lacp Role
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Default Setting: Auto Example: Set key1 for port1~4 SWITCH/>lacp key 1-4 1 LACP Role Description: Set or show the LACP role. Syntax: LACP Role [<port_list>] [active|passive] Parameters: <port_list>: Port list or 'all', default: All ports...
Page 247: Lacp Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <port_list>: Port list or 'all', default: All ports Example: Show LACP status of port1~4 SWITCH/>lacp status 1-4 Port Mode Aggr ID Partner System ID Partner Port ------ ------------ ----- -------...
Page 248 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R...
Page 249: Vlan Configuration Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.4 VLAN Configuration Command VLAN Configuration Description: Show VLAN configuration. Syntax: VLAN Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Example: Show VLAN status of port1 SWITCH/>vlan configuration 1 Mode : IEEE 802.1Q...
Page 250: Vlav Pvid
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Dot1q Example: Set VLAN mode in port base SWITCH/>vlan mode portbased VLAV PVID Description: Set or show the port VLAN ID. Syntax: VLAN PVID [<port_list>] [<vid>|none] Parameters: <port_list>: Port list or 'all', default: All ports <vid>|none : Port VLAN ID (1-4095) or 'none', default: Show port VLAN ID...
Page 251: Vlan Ingress Filter
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R (default: Show accepted frame types) Default Setting: Example: Set port20 that allow tagged frames only SWITCH/>vlan frametype 20 tagged VLAN Ingress Filter Description: Set or show the port VLAN ingress filter.
Page 252: Vlan Q-In-Q Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <port_list>: Port list or 'all', default: All ports untagged : VLAN Link Type Tagged tagged : VLAN Link Type Untagged Default Setting: Un-tagged Example: Enable tagged frame for port2 SWITCH/>vlan linktype 2 tagged...
Page 253: Vlan Add
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R dot1q : Set out layer VLAN tag ether type : 802.1Q Default Setting: Example: SWITCH/>vlan ethtype 10 man VLAN Add Description: Add or modify VLAN entry. Syntax: VLAN Add <vid> [<port_list>] Parameters: <vid>...
Page 254: Vlan Lookup
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <vid>: VLAN ID (1-4095) Example: Delete port17 to port24 in VLAN10 SWITCH/>vlan delete 10 17-24 VLAN Lookup Description: Lookup VLAN entry. Syntax: VLAN Lookup [<vid>] Parameters: <vid>: VLAN ID (1-4095), default: Show all VLANs...
Page 255: Pvlan Configuration
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R PVLAN Configuration Description: Show Private VLAN configuration. Syntax: PVLAN Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports PVLAN Isolate Description: Set or show the port isolation mode. Syntax: PVLAN Isolate [<port_list>] [enable|disable]...
Page 256: Spanning Tree Protocol Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.5 Spanning Tree Protocol Command RSTP Configuration Description: Show RSTP configuration. Syntax: RSTP Configuration [<port_list>] Parameters: <port_list>: Port list or 'all'. Port zero means aggregations. Default Setting: Disable Example: Show RSTP status of port1 SWITCH/>rstp configuration 1...
Page 257: Rstp Age
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Default Setting: 32768 Example: Set RSTP system priority value in 4096 SWITCH/>rstp sysprio 4096 RSTP Age Description: Set or show the RSTP maximum age. Syntax: RSTP Age [<max_age>] Parameters: <max_age>: RSTP maximum age time (6-200)
Page 258: Rstp Version
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Example: Set RSTP forward delay value in 25 SWITCH/>rstp delay 25 RSTP Version Description: Set or show the RSTP protocol version. Syntax: RSTP Version [compatible|normal] Parameters: compatible: Compatible with STP normal...
Page 259: Rstp Cost
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Default Setting: Disable Example: Enable rstp mode for port1 SWITCH/>rstp mode 1 enable RSTP Cost Description: Set or show the RSTP path cost. Syntax: RSTP Cost [<port_list>] [<path_cost>] Parameters: <port_list>: Port list or 'all'. Port zero means aggregations.
Page 260: Rstp Edge
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <priority> : RSTP priority (0/16/32/48/.../224/240) Default Setting: Example: Set RSTP priority value in 16 for port1 SWITCH/>rstp priority 1 16 RSTP Edge Description: Set or show the RSTP edge parameter. Syntax: RSTP Edge [<port_list>] [enable|disable]...
Page 261: Rstp Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <port_list>: Port list or 'all', default: All ports enable : Enable RSTP point2point disable: Disable RSTP point2point auto : Automatic RSTP point2point detection Default Setting: Auto Example: Enable RSTP P2P mode for port1 SWITCH/>rstp p2p 1 enable...
Page 262: Rstp Statistics
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R RSTP Statistics Description: Show RSTP statistics. Syntax: RSTP Statistics [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports RSTP mCheck Description: Set the RSTP mCheck (Migration Check) variable for ports.
Page 263: Multicast Configuration Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.6 Multicast Configuration Command IGMP Configuration Description: Show IGMP snooping configuration. Syntax: IGMP Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Default Setting: IGMP Mode: Disabled Flooding : Disabled...
Page 264: Igmp State
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Enable IGMP mode SWITCH/>igmp mode enable IGMP State Description: Set or show the IGMP snooping state for VLAN. Syntax: IGMP State [<vid>] [enable|disable] Parameters: <vid>: VLAN ID (1-4095), default: Show all VLANs...
Page 265: Igmp Querier
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R disable: Disable IGMP snooping (default: Show IGMP snooping mode) Default Setting: Enable Example: Disable VID 1 SWITCH/>igmp state 1 disable IGMP Querier Description: Set or show the IGMP snooping querier mode for VLAN.
Page 266: Igmp Router
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R IGMP Fastleave [<port_list>] [enable|disable] Parameters: <port_list>: Port list or 'all', default: All ports enable : Enable IGMP fast leave disable : Disable IGMP fast leave (default: Show IGMP fast leave mode)
Page 267: Igmp Flooding
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R IGMP Flooding Description: Set or show the IGMP snooping unregistered flood operation. Syntax: IGMP Flooding [enable|disable] Parameters: enable : Enable IGMP flooding disable: Disable IGMP flooding (default: Show IGMP flood mode)
Page 268 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <vid>: VLAN ID (1-4095) Default Setting: Disable Example: Enable IGMP flooding function SWITCH/>igmp status 1 Switch 1: --------- Querier Status Queries Queries V1 Reports V2 Reports V3 Reports V2 Leave...
Page 269: Quality Of Service Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.7 Quality of Service Command QoS Configuration Description: Show QoS Configuration. Syntax: QoS Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports QoS Classes Description: Set or show the number of traffic classes.
Page 270: Qos Tag Priority
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <port_list>: Port list or 'all', default: All ports <class> : Traffic class low/normal/medium/high or 1/2/3/4 Default Setting: Example: Set high priority for port5 SWITCH/>qos default 5 high QoS Tag Priority Description: Set or show the port VLAN tag priority.
Page 271: Qos Qcl Add
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R QoS QCL Port [<port_list>] [<qcl_id>] Parameters: <port_list>: Port list or 'all', default: All ports <qcl_id> : QCL ID Default Setting: Example: Set QCL ID5 for port10 SWITCH/>qos qcl port 10 5...
Page 272: Qos Qcl Delete
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <etype> : Ethernet Type : VLAN ID keyword <vid> : VLAN ID (1-4095) port : UDP/TCP port keyword <udp_tcp_port> : Source or destination UDP/TCP port (0-65535) dscp : IP DSCP keyword <dscp>...
Page 273: Qos Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R QoS Mode Description: Set or show the port egress scheduler mode. Syntax: QoS Mode [<port_list>] [strict|weighted] Parameters: <port_list>: Port list or 'all', default: All ports strict : Strict mode weighted: Weighted mode...
Page 274: Qos Shaper
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Syntax: QoS Rate Limiter [<port_list>] [enable|disable] [<bit_rate>] Parameters: <port_list>: Port list or 'all', default: All ports enable : Enable rate limiter disable : Disable rate limiter (default: Show rate limiter mode) <bit_rate>...
Page 275: Qos Unicast
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R SWITCH/>qos shaper 9-16 enable 1000 QoS Unicast Description: Set or show the unicast storm rate limiter. Syntax: QoS Storm Unicast [enable|disable] [<packet_rate>] Parameters: enable : Enable unicast storm control disable : Disable unicast storm control <packet_rate>: Rate in pps (1, 2, 4, ..., 512, 1k, 2k, 4k, ..., 1024k)
Page 276: Qos Broadcast
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Example: Enable multicast storm rate limiter in 1kpps SWITCH/>qos storm multicast enable 1k QoS Broadcast Description: Set or show the multicast storm rate limiter. Syntax: QoS Storm Broadcast [enable|disable] [<packet_rate>] Parameters:...
Page 277: Port Access Control Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.8 802.1x Port Access Control Command Dot1x Configuration Description: Show 802.1X configuration. Syntax: Dot1x Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Example: Show IEEE802.1x status of port1 SWITCH/>dot1x configuration 1...
Page 278: Dot1X Status
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R disable: Disable 802.1X (default: Show 802.1X mode) Default Setting: Disable Example: Enable IEEE802.1x founction for port1 SWITCH/>dot1x mode enable Dot1x Status Description: Set or show the 802.1X port state. Syntax: Dot1x State [<port_list>] [macbased|auto|authorized|unauthorized] Parameters: <port_list>: Port list or 'all', default: All ports...
Page 279: Dot1X Secret
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Syntax: Dot1x Server [<ip_addr>] Parameters: ip_addr: RADIUS server IP address (a.b.c.d) (default: Show IP address) Default Setting: 0.0.0.0 Example: Set RADIUS server IP address for switch. RADIUS server IP address is 192.168.0.254.
Page 280: Dot1X Re-Authentication
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Refresh (restart) 802.1X authentication process. Syntax: Dot1x Authenticate [<port_list>] [now] Parameters: <port_list>: Port list or 'all', default: All ports : Force reauthentication immediately Dot1x Re-authentication Description: Set or show Reauthentication mode.
Page 281: Dot1X Timeout
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <reauth_period>: Period between reauthentications (1-3600 seconds) (default: Show reauthentication period) Default Setting: 3600 Example: Set period re-authentication time in 3000 seconds SWITCH/>dot1x period 3000 Dot1x Timeout Description: Set or show the time between EAPOL retransmissions.
Page 282: Dot1X Clients
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Parameters: <port_list>: Port list or 'all', default: All ports clear : Clear statistics eapol : Show EAPOL statistics radius : Show RADIUS statistics (default: Show all statistics) Dot1x Clients Description: Set or show the maximum number of allowed clients for MAC-based ports.
Page 283: Dot1X Holdtime
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Example: Set age time in 100 seconds SWITCH/>dot1x agetime 100 Dot1x Holdtime Description: Time in seconds before a MAC-address that failed authentication gets a new authentication chance. Syntax: Dot1x Holdtime [<hold_time>] Parameters: <hold_time>: Hold time before MAC addresses that failed authentication expire...
Page 284: Access Control List Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.9 Access Control List Command ACL Configuration Description: Show ACL Configuration. Syntax: ACL Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Default Setting: Example: Set age time in 100 seconds SWITCH/>dot1x agetime 100...
Page 285: Acl Policy
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Rate Limiter: Disable Port Copy: Disable Loading: Disable Shut down: Disable Example: ???? SWITCH/>acl action 17-24 deny 1 24 log shut ACL Policy Description: Set or show the ACL port policy.
Page 286: Acl Add
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <rate_limiter_list>: Rate limiter list (1-15), default: All rate limiters <packet_rate> : Rate in pps (1, 2, 4, ..., 512, 1k, 2k, 4k, ..., 1024k) Default Setting: Example: SWITCH/>acl rate 15 1024k...
Page 287: Acl Delete
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <smac> : Source MAC address (xx-xx-xx-xx-xx-xx) or 'any' <dmac> : Destination MAC address (xx-xx-xx-xx-xx-xx) or 'any' : ARP keyword <sip> : Source IP address (a.b.c.d/n) or 'any' <dip> : Destination IP address (a.b.c.d/n) or 'any' <arp_opcode>...
Page 288: Acl Lookup
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R ACL Lookup Description: Show ACE, default: All ACEs. Syntax: ACL Lookup [<ace_id>] Parameters: <ace_id>: ACE ID (1-1024) ACL Lookup Description: Clear all ACL counters. Syntax: ACL Clear...
Page 289: Mac Address Table Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.10 MAC Address Table Command MAC Configuration Description: Show MAC address table configuration. Syntax: MAC Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports Example: Show port1 Mac state SWITCH/>mac configuration 1...
Page 290: Mac Delete
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Example: Add Mac address 00-30-4F-01-01-02 in port1 and vid1 SWITCH/>mac add 00-30-4f-01-01-02 1 1 MAC Delete Description: Delete MAC address entry. Syntax: MAC Delete <mac_addr> [<vid>] Parameters: <mac_addr>: MAC address (xx-xx-xx-xx-xx-xx) <vid>...
Page 291: Mac Age Time
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R MAC Age Time Description: Set or show the MAC address age timer. Syntax: MAC Agetime [<age_time>] Parameters: <age_time>: MAC address age time (10-1000000), default: Show age time Default Setting: Example: Set agetime value in 30 SWITCH/>mac agetime 30...
Page 292: Mac Dump
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R SWITCH/>mac learning 1 secure MAC Dump Description: Show sorted list of MAC address entries. Syntax: MAC Dump [<mac_max>] [<mac_addr>] [<vid>] Parameters: <mac_max> : Maximum number of MAC addresses 1-8192, default: Show all addresses <mac_addr>: First MAC address (xx-xx-xx-xx-xx-xx), default: MAC address zero...
Page 293: Mac Flash
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R MAC Flash Description: Flush all learned entries. Syntax: MAC Flush...
Page 294: Lldp Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.11 LLDP Command LLDP Configuration Description: Show LLDP configuration. Syntax: LLDP Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports LLDP Mode Description: Set or show LLDP mode. Syntax: LLDP Mode [<port_list>] [enable|disable|rx|tx]...
Page 295: Lldp Optional Tlv
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R LLDP Optional TLV Description: Show / Set LLDP Optional TLVs. Syntax: LLDP Optional_TLV [<port_list>] [port_descr|sys_name|sys_descr|sys_capa|mgmt_addr] [enable|disable] Parameters: <port_list>: Port list or 'all', default: All ports port_descr : Description of the port...
Page 296: Lldp Hold
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Example: Set transmission interval in 10 SWITCH/>lldp interval 10 LLDP Hold Description: Set or show LLDP Tx hold value. Syntax: LLDP Hold [<hold>] Parameters: <hold>: LLDP hold value (2-10) Default Setting:...
Page 297: Lldp Information
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Syntax: LLDP Reinit [<reinit>] Parameters: <reinit>: LLDP reinit delay (1-10) Default Setting: Example: Set LLDP reinit delay value in 3 SWITCH/>lldp reinit 3 LLDP Information Description: Show LLDP neighbor device information.
Page 298: Stack Management Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 6.12 Stack Management Command Stack List Description: Show the list of switches in stack. Syntax: Stack List [detailed|productinfo] Parameters: detailed: Show detailed information Stack List Description: Set the master election priority.
Page 299: Stack Sid Swap
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R <sid>: Switch ID (1-16), default: Show SID Example: Select switch2 to management switch2 SWITCH/>stack select 2 Stack SID Swap Description: Swap SID values used to identify two switches. Syntax: Stack SID Swap <sid> <sid>...
Page 300: Power Over Ethernet Command
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Example: Assign SID2 for switch that use MAC address 00-30-4f-24-04-76 SWITCH/>stack sid assign 2 00-30-4f-24-04-76 6.13 Power over Ethernet Command PoE Configuration Description: Show PoE configuration. Syntax: PoE Configuration Example: SWITCH/>poe configuration Port Mode Priority Max.Power[W]...
Page 301: Poe Mode
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R PoE Mode Description: Set or show PoE mode. Syntax: PoE Mode [<port_list>] [enable|disable] Parameters: <port_list>: Port list or 'all', default: All ports enable : Enables PoE disable : Disable PoE (default: Show PoE's mode)
Page 302: Poe Maximum_Power
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R SWITCH/> poe mgmt_mode Power management mode ------------------------------------- Power management mode : automode PoE Maximum_Power Description: Set or show PoE maximum power per port (0-15.4, with one digit). Syntax: PoE Maximum_Power [<port_list>] [<port_power>] Parameters: <port_list>...
Page 303 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R PoE Status Example: SWITCH/> poe status Port Port Status PD Class Power Used [W] Current Used [mA] ---- ------------------- -------- --------------------- -------------------------- PoE ON PoE OFF PoE OFF PoE OFF PoE OFF...
Page 304: Switch Operation
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 7. SWITCH OPERATION 7.1 Address Table The Switch is implemented with an address table. This address table composed of many entries. Each entry is used to store the address information of some node in network, including MAC address, port no, etc. This in-formation comes from the learning process of Ethernet Switch.
Page 305: Auto-Negotiation
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 7.5 Auto-Negotiation The STP ports on the Switch have built-in "Auto-negotiation". This technology automatically sets the best possible bandwidth when a connection is established with another network device (usually at Power On or Reset). This is done by detect the modes and speeds at the second of both device is connected and capable of, both 10Base-T and 100Base-TX devices can connect with the port in either Half- or Full-Duplex mode.
Page 306: Power Over Ethernet Overview
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 8. POWER OVER ETHERNET OVERVIEW What is PoE? Based on the global standard IEEE 802.3af, PoE is a technology for wired Ethernet, the most widely installed local area network technology adopted today. PoE allows the electrical power necessary for the operation of each end-device to be carried by data cables rather than by separate power cords.
Page 307 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Figure 1 - Power Supplied over the Spare Pins The data pairs are used. Since Ethernet pairs are transformer coupled at each end, it is possible to apply DC power to the center tap of the isolation transformer without upsetting the data transfer.
Page 308: The Poe Provision Process
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R References: IEEE Std 802.3af-2003 (Amendment to IEEE Std 802.3-2002, including IEEE Std 802.3ae-2002), 2003 Page(s):0_1-121 White Paper on Power over Ethernet (IEEE802.3af) http://www.poweroverethernet.com/articles.php?article_id=52 Microsemi /PowerDsine http://www.microsemi.com/PowerDsine/ Linear Tech http://www.linear.com/ The PoE Provision Process While adding PoE support to networked devices is relatively painless, it should be realized that power cannot simply be transferred over existing CAT-5 cables.
Page 309: Classification
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The signature resistor lies in the PD's PoE front-end, isolated from the rest of the the PD's circuitries till detection is certified. Classification Once a PD is detected, the PSE may optionally perform classification, to determine the maximal power a PD is to consume. The PSE induces 15.5-20.5 VDC, limited to 100 mA, for a period of 10 to 75 ms responded by a certain current consumption by the...
Page 310 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R functionality - the PSE shutdowns power to a disconnected port within 300 to 400ms. The upper boundary is a physical human limit for disconnecting one PD and reconnecting another. DC Disconnect DC Disconnect detection involves measurement of current.
Page 311: Trouble Shooting
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R 9. TROUBLE SHOOTING This chapter contains information to help you solve problems. If the Ethernet Switch is not functioning properly, make sure the Ethernet Switch was set up according to instructions in this manual.
Page 312 Solution: Check that modules are installed correctly PLANET CB-STX50 or CB-STX200 cables not installed correctly (LEDs on front panel STX1 or STX2 do not light) Check that the cables are inserted correctly The stack cable is PLANET proprietary stack cable, the stack cable is cross-overed HDMI-like cable, the normal HDMI cable can’t be used for the SGSW series.
Page 313: Appendex A
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R APPENDEX A A.1 Switch's RJ-45 Pin Assignments 1000Mbps, 1000Base T Contact MDI-X BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA- BI_DD+ BI_DC+ BI_DD- BI_DC- Implicit implementation of the crossover function within a twisted-pair cable, or at a wiring panel, while not expressly forbidden, is beyond the scope of this standard.
Page 314 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R The standard cable, RJ-45 pin assignment The standard RJ-45 receptacle/connector There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color...
Page 315: Appendex B : Glossary
User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R APPENDEX B : GLOSSARY ACE is an acronym for Access Control Entry. It describes access permission associated with a particular ACE ID. There are three ACE frame types (Ethernet Type, ARP, and IPv4) and two ACE actions (permit and deny). The ACE also contains many detailed, different parameter options that are available for individual application.
Page 316 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Auto-negotiation is the process where two different devices establish the mode of operation and the speed settings that can be shared by those devices for a link. DES is an acronym for Data Encryption Standard. It provides a complete description of a mathematical algorithm for encrypting (enciphering) and decrypting (deciphering) binary coded information.
Page 317 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R between octets. An IPv4 dotted decimal address has the form x.y.z.w, where x, y, z, and w are decimal numbers between 0 and 255. DSCP DSCP is an acronym for Differentiated Services Code Point. It is a field in the header of IP packets for packet classification purposes.
Page 318 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R HTTPS HTTPS is an acronym for Hypertext Transfer Protocol over Secure Socket Layer. It is used to indicate a secure HTTP connection. HTTPS provide authentication and encrypted communication and is widely used on the World Wide Web for security-sensitive communication such as payment transactions and corporate logons.
Page 319 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R IMAP is the protocol that IMAP clients use to communicate with the servers, and SMTP is the protocol used to transport mail to an IMAP server. The current version of the Internet Message Access Protocol is IMAP4. It is similar to Post Office Protocol version 3 (POP3), but offers additional and more complex features.
Page 320 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R MAC addresses to switch ports for knowing which ports the frames should go to ( based upon the DMAC address in the frame ). This table contains both static and dynamic entries. The static entries are configured by the network administrator if the administrator wants to do a fixed mapping between the DMAC address and switch ports.
Page 321 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Optional TLVs. A LLDP frame contains multiple TLVs For some TLVs it is configurable if the switch shall include the TLV in the LLDP frame. These TLVs are known as optional TLVs. If an optional TLVs is disabled the corresponding information is not included in the LLDP frame.
Page 322 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R QCE is an acronym for QoS Control Entry. It describes QoS class associated with a particular QCE ID. There are six QCE frame types: Ethernet Type, VLAN, UDP/TCP Port, DSCP, TOS, and Tag Priority. Frames can be classified by one of 4 different QoS classes: "Low", "Normal", "Medium", and "High"...
Page 323 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Samba is a program running under UNIX-like operating systems that provides seamless integration between UNIX and Microsoft Windows machines. Samba acts as file and print servers for Microsoft Windows, IBM OS/2, and other SMB client machines.
Page 324 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Switch ID Switch IDs (1-16) are used to uniquely identify the switches within a stack. The Switch ID of each switch is shown on the display on the front of the switch and is used widely in the web pages as well as in the CLI commands.
Page 325 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R decoded into 64 possibilities, and the singular code that results is compared against the corresponding bit in the IPv4 ToS priority control bit (0~63). A LLDP frame can contain multiple pieces of information. Each of these pieces of information is known as TLV (TLV is short for "Type Length Value").
Page 326 User’s Manual of WGSW-24040 / WGSW-24040R SGSW-24040 / SGSW-24040R Provider switching: This is also known as Q-in-Q switching. Ports connected to subscribers are VLAN unaware, members of one VLAN, and set up with this unique Port VLAN ID. Ports connected to the service provider are VLAN aware, members of multiple VLANs, and set up to tag all frames.
Page 327: Ec Declaration Of Conformity
EC Declaration of Conformity For the following equipment: *Type of Product: 24-Port 10/100/1000Mbps with 4 Shared SFP Managed Gigabit Switch *Model Number: WGSW-24040 / WGSW-24040R / SGSW-24040 / SGSW-24040R * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C.
Page 328 *Model Number: SGSW-24240 / SGSW-24240R * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive on (89/336/EEC).

This manual is also suitable for:

Wgsw-24040r Sgsw-24040p4 Sgsw-24240 Sgsw-24040 Sgsw-24240r Sgsw-24040r ... Show all

Planet WGSW-24040 User Manual

1 Introdution

2 Installation

3 Switch Management

4 Web Configuration

5 Command Line Interface

6 Command Line Mode

Quick Links

Related Manuals for Planet WGSW-24040

Summary of Contents for Planet WGSW-24040
