Digicast Media Router S2 Receiver CMR-5995 (MR-S2-ASI)
Installation & Initial Configuration
the router for proper operation.
•
Test
Comtech EF Data Customer Support if the shipment is:
•
Contact
Incomplete
Physically damaged
Inoperable
2.3
Installation
The CMR-5995 is designed for ease of installation and configuration. Once the unit has
been removed from the packing container, please follow these instructions:
Step
Procedure
1
Place the unit on a flat surface with free airflow, where the LEDs can be clearly observed
and with unrestricted access to the rear panel of the unit.
2
Until the unit has been fully configured, the coaxial connection to the Low Noise Block (LNB)
should NOT be connected to the unit . If the unit will not be powering the LNB, it is
recommended that 'Polarity' (on the 'Tuner' configuration page) be set to 'Off'
3
Connect the DC power connection from the SPU30-102 (external power supply) to the
connection labeled PWR on the back of the unit and tighten the restraining nut to ensure
secure operation.
4
Connect an RJ-45 Ethernet cable (patch cord) to the port labeled ETHERNET and to an
Ethernet concentrator (hub) or switch.
5
Connect a terminal cable P/N CA-TERMINAL (supplied) to the port labeled TERM and to a
PC's serial port (DB-9), to initially configure the CMR-5995.
6
Connect the AC power (via the IEC power cord) between a standard wall outlet and the
power supply. The Blue LED will illuminate.
7
Upon startup, the LEDs on the front panel may illuminate as follows:
Color
Blue
Green
Red
Green
Green
Amber
Green
Green
Green
Label
PWR
Illuminates if power is properly applied
RED
Redundancy indicator
ALARM
May illuminate if the unit is not yet configured
LOCK
Illuminates if the tuner is locked
E-SPD
Ethernet speed indicator
E-COL
Ethernet collision indicator
E-RX
Flashes if there is Ethernet traffic/activity
E-TX
Illuminates if the Ethernet connection to the Hub/Switch is
E-LINK
operational
2-2
MN-CMR5995-IOM
Description
Revision 1
