EWM-COPPER, EWM-SS, EWM-SS-BLK
If the unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.

TO REPLACE THE POWER CORD

1. Unplug the unit from the outlet.
2. Remove the two mounting screws from the bottom front of the heater assembly.
3. Loosen but do not remove the four heater / light assembly mounting screws
located on the bottom sides of the wall mounted electric fireplace.
4. Slide the heater and light assembly forward to release it from the bottom of the
wall mounted electric fireplace.
5. Place heater and light assembly on a flat surface and remove the six screws from
the upper sides and back of the assembly.
6. Separate the flicker motor and light assembly from the lower assembly.
7. Locate and disconnect the power cord wiring connections noting their original
locations.
8. With needle nose pliers grasp the power cord strain relief grommet from inside
the lower cover and push while twisting to remove.
9. Pull the power cord out through the hole in the lower cover.
10. Install the new power cord through the hole in the lower cover and connect all of
the wiring connections in their original locations.
11. Install the power cord retaining grommet on the power cord and insert into the
hole in the lower cover.
12. Reassemble in the reverse order as above.
