  • Page 1 LS 2104 Product Reference Guide...
  • Page 2 LS 2104 Product Reference Guide 70-32820-01 Revision C — June 2001 Symbol Technologies, Inc. One Symbol Plaza, Holtsville N.Y. 11742-1300 http://www.symbol.com/manuals...
  • Page 3 LS 2104 RS-232/Synapse Scanner Product Reference Guide 70-32820-01 Revision C June 2001...
  • Page 4 The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed basis. Symbol grants to the user a non-transferable and non-exclusive license to use each software or firmware program delivered hereunder (licensed program).

  • Page 5: Table Of Contents

    Scanning with the LS 2104 ........
  • Page 6 LS 2104 Signal Descriptions ........
  • Page 7 Enable/Disable Interleaved 2 of 5 ..........4-36 Set Lengths for Interleaved 2 of 5 .
  • Page 8 LS 2104 Product Reference Guide viii...

  • Page 9: About This Guide

    About This Guide The LS 2104 Product Reference Guide provides general instructions for setup, programming, operation, troubleshooting, and maintenance of the LS 2104 scanner. Notational Conventions The following conventions are used in this document: Bullets ( ) indicate: " action items "...

  • Page 10: Service Information

    Call the Support Center from a phone near the scanning equipment so that the service person can try to talk you through your problem. If the equipment is found to be working properly and the problem is symbol readability, the Support Center will request samples of your bar codes for analysis at our plant.
  • Page 11 About This Guide Australia Austria/Österreich Symbol Technologies Pty. Ltd. Symbol Technologies Austria GmbH 432 St. Kilda Road Prinz-Eugen Strasse 70 Melbourne, Victoria 3004 Suite 3 1-800-672-906 (Inside Australia) 2.Haus, 5.Stock +61-3-9866-6044 (Outside Australia) 1040 Vienna, Austria 1-505-5794 (Inside Austria) +43-1-505-5794 (Outside Austria)
  • Page 12 +46 84452900 (Outside Sweden) Customer support is available 24 hours a day, 7 days a week. If you purchased your Symbol product from a Symbol Business Partner, contact that Business Partner for service. For the latest version of this guide go to:http://www.symbol.com/manuals.

  • Page 13: Chapter 1. Setting Up The Ls 2104

    This state of the art technology gives the scanner a wider decode zone, greater depth of field, and a visible scan beam. This model reads color bar codes and symbols printed on all substrates. See the LS 2104 Decode Zone on page 2-4.

  • Page 14: Audience

    LS 2104 scanners. Unpacking Remove the LS 2104 from its packing and inspect it for damage. If the scanner was damaged in transit, call the Symbol Support Center at one of the telephone numbers listed on page x.

  • Page 15: Setting Up The Ls 2104

    Setting Up the LS 2104 Setting Up the LS 2104 Installing the Cable Insert the cable into the receptacle on the bottom of the scanner, as shown below: Figure 1-2. Installing the Cable Switching Cables Different cables are required for different hosts. To change the scanner cable: 1.

  • Page 16: Connecting To A Host

    LS 2104 Product Reference Guide Connecting to a Host Plug the connector at the end of the LS 2104 cable into the appropriate port on the Symbol interface controller or portable terminal. Refer to the controller user documentation for full details.

  • Page 17: Chapter 2. Scanning With The Ls 2104

    Before you can use the scanner, it should have already been installed and programmed. If not, see Chapter 4, Parameter Menus for instructions on programming your scanner. If you need assistance, contact your local supplier or Symbol Technologies. 1. Before you use the scanner, make sure all cable connections are secure.

  • Page 18: Aiming The Scanner

    LS 2104 Product Reference Guide Figure 2-1. Holding the Scanner Aiming the Scanner Hold the scanner at an angle. Do not hold the scanner directly over the bar code. Laser light reflecting directly back into the scanner from the bar code is known as specular reflection.
  • Page 19 Scanning with the LS 2104 Scan the Entire Symbol " The scan beam must cross every bar and space on the symbol (as in the left bar code below). " The larger the symbol, the farther away you should hold the scanner.

  • Page 20: Ls 2104 Decode Zone

    LS 2104 Product Reference Guide LS 2104 Decode Zone...

  • Page 21: Chapter 3. Maintenance And Specifications

    Chapter 3 Maintenance and Specifications Introduction This chapter covers the appropriate methods for maintaining and the technical specifications for the scanner. Maintenance Cleaning the exit window is the only maintenance required. A dirty window may affect scanning accuracy. Do not allow any abrasive material to touch the window. Remove any dirt particles with a damp cloth.
  • Page 22 Make sure the symbol is not defaced. Try scanning test symbols of the same code type. If after performing these checks the symbol still does not scan, contact your distributor or call the Symbol Support Center. See page x for the telephone number.

  • Page 23: Accessories

    Maintenance and Specifications Accessories Standard Accessories: Description Part Number LS 21xx Series Quick 70-32817-xx Reference Guide LS 2104 Product 70-32820-xx Reference Guide Shipping Box 50-01400-184 Cables Description Part Number Power Supply Operation: Straight Cable (6ft - 183cm): Female, 9-pin, TxD on Pin 2...

  • Page 24: Optional Accessories

    LS 2104 Product Reference Guide Optional Accessories Optional accessories, supplied at extra cost, include additional units of any item listed above and the following items: Description Part Number Hands-Free Stand-free 21-33324-01 standing Desk-Mount Stand 21-33323-01 Technical Specifications Item Description Power Requirements 4.75 to 5.25 VDC;...
  • Page 25 Maintenance and Specifications Item Description Storage Temperature -40° to 140° (-40° to 60°C) Straight Cable Length 6 ft (183 cm) Weight (without cable) 5.5 oz. (170 gm) Dimensions: Height 6.7 in (167 mm) Width 2.8 in (70 mm) Depth 3.4 in (85 mm)

  • Page 26: Ls 2104 Signal Descriptions

    LS 2104 Product Reference Guide LS 2104 Signal Descriptions The following signal descriptions apply to the connection between the scanner and the cable, and are for reference only. Table 3-1. Signal Descriptions Signal Name Function Data Terminal Ready. This signal is hardwired active.
  • Page 27 Maintenance and Specifications PIN 10 PIN 1 Figure 3-1. 10-pin Connector...

  • Page 28: Beeper Indications

    4 Beeps - long low tone A transmission error has been detected in a scanned symbol. The data is ignored. This will occur if a unit is not properly configured. Check option settings. 5 Beeps - low tone Convert or format error...

  • Page 29: Chapter 4. Parameter Menus

    Parameter Menus Introduction The LS 2104 is shipped with the settings shown in the Default Parameters beginning on page 4-2. These default values are stored in non-volatile memory and are preserved even when the scanner is powered down. You can change these default values by scanning the appropriate bar codes included in this manual.

  • Page 30: Default Parameters

    LS 2104 Product Reference Guide Default Parameters The following table lists the defaults for all parameters. If you wish to change any option, scan the appropriate bar code(s). Table 4-1. Default Parameters Parameter Default Page Number Set Default Parameter All Defaults...
  • Page 31 Parameter Menus Table 4-1. Default Parameters (Continued) Parameter Default Page Number UPC-E Preamble System 4-22 Character Convert UPC-E to A Disable 4-23 EAN-8 Zero Extend Disable 4-24 Converted EAN-8 to EAN-13 EAN-13 4-25 Code 128 Code 128 Enable 4-25 UCC/EAN-128 Enable 4-27 Code 39...
  • Page 32 LS 2104 Product Reference Guide Table 4-1. Default Parameters (Continued) Parameter Default Page Number NOTIS Editing Disable 4-43 MSI Plessey MSI Plessey Disable 4-44 MSI Plessey Check Digits 4-45 Transmit MSI Plessey Check Disable 4-46 Digit MSI Plessey Check Digit...

  • Page 33: Set Default Parameter

    Parameter Menus Set Default Parameter Scanning this bar code returns all parameters to the default values listed in Table 4-1 . SET ALL DEFAULTS...

  • Page 34: Host Type

    LS 2104 Product Reference Guide Host Type RS-232C Host Types Three RS-232C hosts are set up with their own parameter default settings (Table 4-2.). Selecting the ICL, Fujitsu, or Nixdorf RS-232C terminal sets the defaults listed below. These defaults take precedence over standard defaults. So if you select Fujitsu RS-232C, then select the standard defaults, the Fujitsu defaults still take precedence.
  • Page 35 Parameter Menus RS-232C Host Types Selecting the ICL, Fujitsu, or Nixdorf RS-232C terminal enables the transmission of Code ID Characters as listed in Table 4-3. below. These Code ID Characters are not programmable and are separate from the Transmit Code ID feature. The Transmit Code ID feature should not be enabled for these terminals.
  • Page 36 LS 2104 Product Reference Guide Host Type RS-232C Host Types To select an RS-232C Host Interface, scan one of the following bar codes. STANDARD RS-232C ICL RS-232C NIXDORF RS-232C Mode A NIXDORF RS-232C Mode B FUJITSU RS-232C...

  • Page 37: Beeper Volume

    Parameter Menus Beeper Volume To select a beeper volume, scan the LOW VOLUME or FULL VOLUME bar code. LOW VOLUME FULL VOLUME...

  • Page 38: Laser On Time

    LS 2104 Product Reference Guide Laser On Time This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds. To set a Laser On Time, scan the bar code below. Next scan two numeric bar codes beginning on page 4-68 that correspond to the desired time on.

  • Page 39: Power Mode

    Parameter Menus Power Mode This parameter determines whether or not power remains on after a decode attempt. When in low power mode, the scanner enters into a low power consumption mode to preserve battery life after each decode attempt. When in continuous power mode, power remains on after each decode attempt.

  • Page 40: Beep After Good Decode

    BEEP AFTER GOOD DECODE Do Not Beep After Good Decode Scan this symbol if you do not want the unit to beep after a good decode. The beeper still operates during parameter menu scanning and indicates error conditions. DO NOT BEEP AFTER GOOD DECODE...

  • Page 41: Transmit "No Read" Message

    Parameter Menus Transmit “No Read” Message When enabled, if a symbol does not decode, “NR” is transmitted. Any prefixes or suffixes which have been enabled are appended around this message. ENABLE NO READ Do Not Transmit “No Read” Message When disabled, if a symbol does not read, nothing is sent to the host.

  • Page 42: Decode Redundancy

    LS 2104 Product Reference Guide Decode Redundancy Use this parameter to indicate whether the scanner must read a bar code one time (level 0), two times (level 1) or three times (level 2) before decoding it. A higher level of redundancy ensures the accuracy of a decode in, for example, poor quality symbols.

  • Page 43: Autodiscriminate Response Time

    Parameter Menus Autodiscriminate Response Time This parameter extends the length of time during which the scanner tries to detect which host it is connected to on power up. Note: When connected to an LS 5700/5800, the 5-second option must be used.

  • Page 44: Enable/Disable Upc-E/Upc-A

    LS 2104 Product Reference Guide Enable/Disable UPC-E/UPC-A To enable or disable UPC-E or UPC-A, scan the appropriate bar code below. ENABLE UPC-E DISABLE UPC-E ENABLE UPC-A DISABLE UPC-A 4-16...

  • Page 45: Enable/Disable Ean-8/Ean-13

    Parameter Menus Enable/Disable EAN-8/EAN-13 To enable or disable EAN-8 or EAN-13, scan the appropriate bar code below. ENABLE EAN-8 DISABLE EAN-8 ENABLE EAN-13 DISABLE EAN-13 4-17...

  • Page 46: Enable/Disable Bookland Ean

    LS 2104 Product Reference Guide Enable/Disable Bookland EAN To enable or disable EAN Bookland, scan the appropriate bar code below. ENABLE BOOKLAND EAN DISABLE BOOKLAND EAN 4-18...

  • Page 47: Decode Upc/Ean Supplementals

    If UPC/EAN with supplemental characters is selected, UPC/EAN symbols without supplemental characters are not decoded. If UPC/EAN without supplemental characters is selected, and the LS 2104 is presented with a UPC/EAN plus supplemental symbol, the UPC/EAN is decoded and the supplemental characters ignored.

  • Page 48: Transmit Upc-A/Upc-E Check Digit

    LS 2104 Product Reference Guide Transmit UPC-A/UPC-E Check Digit Scan the appropriate bar code below to transmit the symbol with or without the UPC-A or UPC-E check digit. TRANSMIT UPC-A CHECK DIGIT DO NOT TRANSMIT UPC-A CHECK DIGIT TRANSMIT UPC-E CHECK DIGIT...

  • Page 49: Upc-A Preamble

    Three options are given for lead-in characters for UPC-A symbols transmitted to the host device: transmit system character only, transmit system character and country code (“0” for USA), and no preamble transmitted. The lead-in characters are considered part of the symbol. NO PREAMBLE (<DATA>)

  • Page 50: Upc-E Preamble

    Three options are given for lead-in characters for UPC-E symbols transmitted to the host device: transmit system character only, transmit system character and country code (“0” for USA), and no preamble transmitted. The lead-in characters are considered part of the symbol. NO PREAMBLE (<DATA>)

  • Page 51: Convert Upc-E To Upc-A

    Parameter Menus Convert UPC-E to UPC-A This parameter converts UPC-E (zero suppressed) decoded data to UPC-A format before transmission. After conversion, data follows UPC-A format and be affected by UPC-A programming selections (e.g., Preamble, Check Digit). Scanning DO NOT CONVERT UPC-E TO UPC-A allows you to transmit UPC-E (zero suppressed) decoded data.

  • Page 52: Ean Zero Extend

    LS 2104 Product Reference Guide EAN Zero Extend If this parameter is enabled, five leading zeros are added to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Disabling this parameter returns EAN-8 symbols to their normal format.

  • Page 53: Converted Ean-8 To Ean-13

    Parameter Menus Converted EAN-8 to EAN-13 This parameter allows a decoded EAN-8 symbol that has been converted to EAN-13 to be transmitted with either an EAN-13 code type or an EAN-8 code type. TYPE IS EAN-13 TYPE IS EAN-8 4-25...

  • Page 54: Enable/Disable Code 128

    LS 2104 Product Reference Guide Enable/Disable Code 128 To enable or disable Code 128, scan the appropriate bar code below. ENABLE CODE 128 DISABLE CODE 128 4-26...

  • Page 55: Enable/Disable Ucc/Ean-128

    Parameter Menus Enable/Disable UCC/EAN-128 To enable or disable UCC/EAN-128, scan the appropriate bar code below. ENABLE UCC/EAN-128 DISABLE UCC/EAN-128 4-27...

  • Page 56: Enable/Disable Code 39

    LS 2104 Product Reference Guide Enable/Disable Code 39 To enable or disable Code 39, scan the appropriate bar code below. ENABLE CODE 39 DISABLE CODE 39 4-28...

  • Page 57: Code 39 Check Digit Verification

    Parameter Menus Code 39 Check Digit Verification When enabled, this parameter checks the integrity of a Code 39 symbol to ensure it complies with specified algorithms. Only those code 39 symbols which include a modulo 43 check digit are decoded when this parameter is enabled.

  • Page 58: Transmit Code 39 Check Digit

    LS 2104 Product Reference Guide Transmit Code 39 Check Digit Scan this symbol if you want to transmit the check digit with the data. TRANSMIT CODE 39 CHECK DIGIT (ENABLE) Do Not Transmit Code 39 Check Digit Scan this symbol if you want to transmit the data without the check digit.

  • Page 59: Enable/Disable Code 39 Full Ascii

    Parameter Menus Enable/Disable Code 39 Full ASCII To enable or disable Code 39 Full ASCII, scan the appropriate bar code below. When enabled, the ASCII character set assigns a code to letters, punctuation marks, numerals, and most control keystrokes on the keyboard. The first 32 codes are non-printable and are assigned to keyboard control characters such as BACKSPACE and RETURN.

  • Page 60: Code 39 Buffering (Scan & Store)

    The leading space is not buffered. Decode of a valid Code 39 symbol with no leading space causes transmission in sequence of all buffered data in a first-in first-out format, plus transmission of the “triggering” symbol.

  • Page 61: Buffer Data

    Parameter Menus Buffer Data To buffer data, Code 39 buffering must be enabled, and a symbol must be read with a space immediately following the start pattern. Unless symbol overflows the transmission buffer, the unit gives a lo/hi beep to indicate successful decode and buffering.

  • Page 62: Transmit Buffer

    " No transmission occurs. Data in buffer is not affected. Attempt to Transmit an Empty Buffer If the symbol just read was the transmit buffer symbol and the Code 39 buffer is empty: " A short lo/hi/lo beep signals that the buffer is empty.

  • Page 63: Enable/Disable Code 93

    Parameter Menus Enable/Disable Code 93 To enable or disable Code 93, scan the appropriate bar code below. ENABLE CODE 93 DISABLE CODE 93 4-35...

  • Page 64: Enable/Disable Interleaved 2 Of 5

    LS 2104 Product Reference Guide Enable/Disable Interleaved 2 of 5 To enable or disable Interleaved 2 of 5, scan the appropriate bar code below. ENABLE INTERLEAVED 2 OF 5 DISABLE INTERLEAVED 2 OF 5 4-36...

  • Page 65: Set Lengths For Interleaved 2 Of 5

    Parameter Menus Set Lengths for Interleaved 2 of 5 Lengths for I 2 of 5 may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits.

  • Page 66: Convert I 2 Of 5 To Ean-13

    LS 2104 Product Reference Guide Convert I 2 of 5 to EAN-13 This parameter converts a 14 character I 2 of 5 code into EAN-13, and transmits to the host as EAN-13. In order to accomplish this, the I 2 of 5 code must be enabled, one length must be set to 14, and the code must have a leading zero and a valid EAN-13 check digit.

  • Page 67: Enable/Disable Discrete 2 Of 5

    Parameter Menus Enable/Disable Discrete 2 of 5 To enable or disable Discrete 2 of 5, scan the appropriate bar code below. ENABLE DISCRETE 2 OF 5 DISABLE DISCRETE 2 OF 5 4-39...

  • Page 68: Set Lengths For Discrete 2 Of 5

    LS 2104 Product Reference Guide Set Lengths for Discrete 2 of 5 Lengths for D 2 of 5 may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits.

  • Page 69: Enable/Disable Codabar

    Parameter Menus Enable/Disable Codabar To enable or disable Codabar, scan the appropriate bar code below. ENABLE CODABAR DISABLE CODABAR 4-41...

  • Page 70: Clsi Editing

    CLSI Editing When enabled, this parameter strips the start and stop characters and inserts a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Note: Symbol length does not include start and stop characters. ENABLE CLSI EDITING...

  • Page 71: Notis Editing

    Parameter Menus NOTIS Editing When enabled, this parameter strips the start and stop characters from decoded Codabar symbol. ENABLE NOTIS EDITING DISABLE NOTIS EDITING 4-43...

  • Page 72: Enable/Disable Msi Plessey

    LS 2104 Product Reference Guide Enable/Disable MSI Plessey To enable or disable MSI Plessey, scan the appropriate bar code below. ENABLE MSI PLESSEY DISABLE MSI PLESSEY 4-44...

  • Page 73: Msi Plessey Check Digits

    Parameter Menus MSI Plessey Check Digits These check digits, at the end of the bar code verify the integrity of the data. At least one check digit is always required. Check digits are not automatically transmitted with the data. ONE MSI Plessey CHECK DIGIT TWO MSI Plessey CHECK DIGIT 4-45...

  • Page 74: Transmit Msi Plessey Check Digit

    LS 2104 Product Reference Guide Transmit MSI Plessey Check Digit Scan this symbol if you want to transmit the check digit with the data. TRANSMIT MSI Plessey CHECK DIGIT (ENABLE) Do Not Transmit MSI Plessey Check Digit Scan this symbol if you want to transmit the data without the check digit.

  • Page 75: Msi Plessey Check Digit Algorithm

    Parameter Menus MSI Plessey Check Digit Algorithm When the two MSI Plessey check digits option is selected, an additional verification is required to ensure integrity. Either of the two following algorithms may be selected. MOD 11/MOD 10 MOD 10/MOD 10 4-47...

  • Page 76: Transmit Code Id Character

    ID character is inserted between the prefix and the decoded symbol. The user may select no code ID character, a Symbol Code ID character, or an AIM Code ID character. The Symbol Code ID characters are listed below.
  • Page 77 Parameter Menus Transmit Code ID Character (cont’d) SYMBOL CODE ID CHARACTER AIM CODE ID CHARACTER NONE 4-49...

  • Page 78: Prefix/Suffix Values

    LS 2104 Product Reference Guide Prefix/Suffix Values A prefix/suffix may be appended to scan data for use in data editing. These values are set by scanning a four-digit number (i.e. four bar codes) that corresponds to key codes for various terminals.

  • Page 79: Scan Data Transmission Format

    Parameter Menus Scan Data Transmission Format To change the Scan Data Transmission Format, scan the SCAN OPTIONS bar code below. Then select one of four options. When you have made your selection, scan the ENTER bar code on the next page. If you make a mistake, scan the DATA FORMAT CANCEL bar code on the next page.
  • Page 80 LS 2104 Product Reference Guide Scan Data Transmission Format (cont’d) <DATA> <SUFFIX 2> <DATA> <SUFFIX 1><SUFFIX 2> <PREFIX> <DATA> <PREFIX><DATA><SUFFIX 1> 4-52...
  • Page 81 Parameter Menus Scan Data Transmission Format (cont’d) <PREFIX><DATA><SUFFIX 2> <PREFIX><DATA><SUFFIX 1><SUFFIX 2> 4-53...

  • Page 82: Rs-232C Parameters

    LS 2104 Product Reference Guide RS-232C Parameters Baud Rate Baud rate is the number of bits of data transmitted per second. The scanner's baud rate setting should match the data rate setting of the host device. If not, data may not reach the host device or may reach it in distorted form.
  • Page 83 Parameter Menus Baud Rate (cont’d) BAUD RATE 4800 BAUD RATE 9600 BAUD RATE 19,200 4-55...

  • Page 84: Parity

    LS 2104 Product Reference Guide Parity A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. If you select ODD parity, the parity bit has a value 0 or 1, based on data, to ensure than an odd number of 1 bits are contained in the coded character.
  • Page 85 Parameter Menus Select SPACE parity and the parity bit is always 0. SPACE If no parity is required, select NONE. NONE 4-57...

  • Page 86: Hardware Handshaking

    LS 2104 Product Reference Guide Hardware Handshaking The data interface consists of an RS-232C port. The port has been designed to operate either with or without the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS). If Standard RTS/CTS handshaking is selected, scan data is transmitted according to the following sequence: The controller reads the CTS line for activity.
  • Page 87 Parameter Menus Scan the bar code below if no Hardware Handshaking is desired. NONE Scan the bar code below to select Standard RTS/CTS Hardware Handshaking. STANDARD RTS/CTS When RTS/CTS Option 1 is selected, the scanner asserts RTS before transmitting and ignores the state of CTS.
  • Page 88 LS 2104 Product Reference Guide When Option 2 is selected, RTS is always high or low (user-programmed logic level). However, the scanner waits for CTS to be asserted before transmitting data. If CTS is not asserted within 2 seconds (default), the scanner issues an error indication and discards the data.

  • Page 89: Software Handshaking

    Parameter Menus Software Handshaking This parameter offers control of the data transmission process in addition to, or instead of, that offered by hardware handshaking. There are five options. If Software Handshaking and Hardware Handshaking are both enabled, Hardware Handshaking takes precedence. None When this option is selected, data is transmitted immediately.
  • Page 90 LS 2104 Product Reference Guide indication and discards the data. The host must transmit an ENQ character at least every 2 seconds to prevent transmission errors. ACK/NAK with ENQ This combines the two previous options. ACK/NAK with ENQ 4-62...

  • Page 91: Host Serial Response Time-Out

    Parameter Menus Host Serial Response Time-out This parameter specifies how long the scanner waits for an ACK, NAK, or CTS before determining that a transmission error has occurred. This only applies when in one of the ACK/NAK Software Handshaking modes, or RTS/CTS Hardware Handshaking option. The delay period can range from 0.0 to 9.9 seconds in 0.1-second increments.

  • Page 92: Stop Bit Select

    LS 2104 Product Reference Guide Stop Bit Select The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream.

  • Page 93: Ascii Format

    Parameter Menus ASCII Format This parameter allows the scanner to interface with devices requiring a 7-bit or 8-bit ASCII protocol. 7-BIT 8-BIT 4-65...

  • Page 94: Beep On

    LS 2104 Product Reference Guide Beep on <BEL> When this parameter is enabled, the scanner issues a beep when a <BEL> character is detected on the RS-232C serial line. <BEL> is issued to gain a user's attention to indicate an illegal entry or other important event.

  • Page 95: Intercharacter Delay

    Parameter Menus Intercharacter Delay Select the intercharacter delay option matching host requirements. The intercharacter delay gives the host system time to service its receiver and perform other tasks between characters. The delay period can range from no delay to 99 msec in 1-msec increments. After scanning the bar code below, scan two bar codes beginning on page 4-68 to set the desired time-out.

  • Page 96: Numeric Bar Codes

    LS 2104 Product Reference Guide Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriately numbered bar code(s). 4-68...
  • Page 97 Parameter Menus Numeric Bar Codes (cont’d) 4-69...

  • Page 98: Cancel

    LS 2104 Product Reference Guide Numeric Bar Codes (cont’d) Cancel If you make an error or wish to change your selection, scan the bar code below. CANCEL 4-70...

  • Page 99: Ascii Character Set

    Appendix A ASCII Character Set Table A-1. ASCII Character Set ASCII Value Full ASCII Keystroke Code 39 Encode Char. 1000 CTRL 2 1001 CTRL A 1002 CTRL B 1003 CTRL C 1004 CTRL D 1005 CTRL E 1006 CTRL F 1007 CTRL G 1008...
  • Page 100 LS 2104 Product Reference Guide Table A-1. ASCII Character Set (Continued) 1014 CTRL N 1015 CTRL O 1016 CTRL P 1017 CTRL Q 1018 CTRL R 1019 CTRL S 1020 CTRL T 1021 CTRL U 1022 CTRL V 1023 CTRL W...
  • Page 101 ASCII Character Set Table A-1. ASCII Character Set (Continued) 1041 1042 1043 1044 1045 1046 1047 1048 1047 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065 1066 1067...
  • Page 102 LS 2104 Product Reference Guide Table A-1. ASCII Character Set (Continued) 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094...
  • Page 103 ASCII Character Set Table A-1. ASCII Character Set (Continued) 1095 1096 ‘ 1097 1098 1099 1100 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121...
  • Page 104 LS 2104 Product Reference Guide Table A-1. ASCII Character Set (Continued) 1122 1123 1124 1125 1126 1127 Undefined 1128 ALT Keys Keystroke 2064 ALT 2 2065 ALT A 2066 ALT B 2067 ALT C 2068 ALT D 2069 ALT E...
  • Page 105 ASCII Character Set Table A-1. ASCII Character Set (Continued) 2083 ALT S 2084 ALT T 2085 ALT U 2086 ALT V 2087 ALT W 2088 ALT X 2089 ALT Y 2090 ALT Z 2091 ALT [ 2092 ALT \ 2093 ALT ] 2094 ALT 6...
  • Page 106 LS 2104 Product Reference Guide Table A-1. ASCII Character Set (Continued) 3014 £ 3015 ¤ 3016 ¬ 3017 ° 3018 3019 ¶ 3020 § 3021 3022 0/00 PF Keys Keystrokes 4001 PF 1 4002 PF 2 4003 PF 3 4004...
  • Page 107 ASCII Character Set Table A-1. ASCII Character Set (Continued) 4018 PF 18 4019 PF 19 4020 PF 20 4021 PF 21 4022 PF 22 4023 PF 23 4024 PF 24 F Keys Keystroke 5001 5002 5003 5004 5005 5006 5007 5008 5009 5010...
  • Page 108 LS 2104 Product Reference Guide Table A-1. ASCII Character Set (Continued) 5020 5021 5022 5023 5024 5025 5026 5027 5028 5029 5030 5031 5032 5033 5034 5035 5036 5037 5038 5039 5040 Numeric Keystroke Keypad 6042 6043 6044 undefined 6045...
  • Page 109 ASCII Character Set Table A-1. ASCII Character Set (Continued) 6046 6047 6048 6049 6050 6051 6052 6053 6054 6055 6056 6057 6058 Enter 6059 Num Lock 6060 Extended Keystroke Keypad 7001 Break 7002 Delete 7003 Pg Up 7004 7005 Pg Dn 7006 Pause 7007...
  • Page 110 LS 2104 Product Reference Guide Table A-1. ASCII Character Set (Continued) 7012 Home 7013 Enter 7014 Escape 7015 Up Arrow 7016 Dn Arrow 7017 Left Arrow 7018 Right Arrow 7019 Back Tab A-12...
  • Page 111 (e.g., characters per inch). Bar Height The dimension of a bar measured perpendicular to the bar width. Thickness of a bar measured from the edge closest to the symbol start Bar Width character to the trailing edge of the same bar.
  • Page 112 Character Set Those characters available for encodation in a particular bar code symbology. A digit used to verify a correct symbol decode. The scanner inserts the Check Digit decoded data into an arithmetic formula and checks that the resulting number matches the encoded check digit. Check digits are required for UPC but are optional for other symbologies.
  • Page 113 Continuous Code A bar code or symbol in which all spaces within the symbol are parts of characters. There are no intercharacter gaps in a continuous code. The absence of gaps allows for greater information density.
  • Page 114 The exact (or ideal) intended value for a specified parameter. Tolerances are specified as positive and negative deviations from this value. Nominal Size Standard size for a bar code symbol. Most UPC/EAN codes can be used over a range of magnifications (e.g., from 0.80 to 2.00 of nominal). Parameter A variable that can have different values assigned to it.
  • Page 115 A minimum PCS value is needed for a bar code symbol to be scannable. PCS = (RL - RD) / RL, where RL is the reflectance factor of the background and RD the reflectance factor of the dark bars.
  • Page 116 A scannable unit that encodes data within the conventions of a certain symbology, usually including start/stop characters, quiet zones, data characters, and check characters. Symbol Aspect Ratio The ratio of symbol height to symbol width. Symbol Height The distance between the outside edges of the quiet zones of the first row and the last row.

  • Page 117: Tell Us What You Think
