Epson TM-C3400 Technical Reference Manual page 41

Paper type
Form
Backing paper width
Label width
Label length
Gap between labels
Edge cutoff on left/right side
Label edge R
Black mark width
Black mark length
Black mark centering position
Black mark interval
Paper thickness
Perforated line pitch:
Perforated line form:
Number of folds:
• Do not use the paper with a hole or cutout.
• When using fanfold paper, the black marks must be at least 2 mm from the perforated
lines.
• when using this type of paper, the label end and the black mark end of the black mark
position on the die-cut label must be matched.
• Make sure to keep the same position of the black marks to the perforated lines (position
that can be detected by black mark sensor) when inserting the paper from either side in
order to use the paper inserting from reverse direction.
Plain Media Label, Fine Media Label
Fanfold paper
50 to 112 mm
46 to 108 mm
15 to 1117.6 mm
5 mm or more
2 ± 0.5 mm
2 mm or less
13 mm or more
9 mm or more
8.5 ± 1 mm
15 mm or more
0.145 to 0.161 mm
203.2 to 304.8 mm
Plain media label : 1 mm uncut, 5 mm cut
Fine media label : 1 mm uncut, 5 mm cut
Synthetic media label :
500 or less
