Page 1: Assembly Instructions
662101 GLUTE/SQUAT OPTION ASSEMBLY INSTRUCTIONS Part # 7046901 Revision: 07/31/01 Rev B... -
Page 2: Tools Required For Assembly
WELCOME TO THE WORLD OF Please note: * Thank you for purchasing the Parabody 662101 Glute/Squat Option. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. -
Page 3: Parts List
PART # DESCRIPTION 6748802 FOOT PLATE 6748702 SQUAT BAR 6740002 GLUTE KICK 6016401 ROLLER PAD PRESS BASE FIGURE 1 STEP 1 • Swing the PRESS SEAT over 90° to install FOOT PLATE (1). See FIGURE 1. • SECURELY attach the FOOT PLATE (1) to the PRESS BASE using two 1/2 X 3-1/4” BOLTS (6) and two 1/2” LOCK NUTS (7) as shown in FIGURE 1. - Page 4 FIGURE 2 STEP 2 • Slide two ROLLER PADS (4) over the SQUAT BAR (2). See FIGURE 2. Space PADS out equally to support back of neck. (Optional : SQUAT BAR may be used without ROLLER PADS.) • Insert SQUAT BAR (4) into the hole on the PRESS ARM as shown. PRESS FIGURE 3 STEP 3...
- Page 5 • Rotate GLUTE KICK (3) 90° to hold GLUTE KICK (3) in PRESS ARM. See FIGURE 5. Thank you for purchasing the PARABODY 662101 GLUTE/SQUAT OPTION. If unsure of proper use of equipment refer to the 662101 OPERATION GUIDE or call your local PARABODY distributor or call the PARABODY customer service department at (800) 328-9714.
