Slide Mount Holder Sh-P1 - Minolta DiMAGE DiMAGE Scan Multi PRO Instruction Manual

LOADING THE FILM HOLDER

SLIDE MOUNT HOLDER SH-P1

• The slide mount holder SH-P1 can hold up to 4 mounted
slides (35mm).
• Slide mounts must be thicker than 1mm and thinner than
2mm to fit properly into the holder.
• Blow dust off the slide before placing it into the film holder.
1. Position the slide mount holder
SH-P1 so the white arrow is on the
top-left side, then open the slide
mount.
• Open the slide holder by pushing up
the tab from underneath.
2. Place the slides within the
indentations, making sure they lie
flat.
• Insert the slides emulsion side down.
3. Press the cover firmly closed until
it clicks.
• With the fourth frame of the slide mount
holder, you can change slides without
removing the slide mount holder from the
scanner. A prescan should be made with
each new slide when using the AF and AE
function (page 29).
NOTE:
• Do not scan glass mounted slides. Glass
mounts bend the light from the line
scanner, causing bad results.
32
