SPECIFICATIONS
Usable Film Type
35 mm film, Advanced Photo System film
Effective Scanning Area
35 mm: 24.2 x 36.3 mm
Advanced Photo System film: 17.28 x 29.95 mm
Scan System
Single-pass
Optical Resolution
2,820 dpi
Image Sensor
RGB 3-line CCD
Scan Time*
35 mm film
Preview
Final Scan (2,820 dpi)
A/D Conversion
12 bits
Output Data
8 bits or 16 bits per colour channel
Dynamic Range
3.6
Focus
Focus free
Light Source
Fluorescent lamp
SCSI - II ( SCSI Ports: D-Sub 25 pin, Centronics 50 )
Interface
Power Requirements
220 – 240 Volts AC, 50 / 60 Hz
Power Consumption
Max. 30 W
Dimensions (WxHxD)
90.5 x 162 x 272 mm
Weight
2.0 kg
Standard Accessories
Driver software: Windows TWAIN 32 / Utility / ICC Profile, Macintosh Adobe Photoshop Plug-in / Utility / ColorSync Profile /
ICC Profile, 35 mm Film Holder FH-D1, Slide Mount Holder SH-D1, Power Cord PW-D1, SCSI Cable SC-11 ( D-Sub 25 pin, Centronics 50 ) ,
Adobe Photoshop LE, CD-ROM for Dimâge Scan Elite
Optional Accessory
Advanced Photo System Adapter AD-10
* Measurement Conditions
Windows
CPU: Pentium III 600MHz, RAM: 384MB, Operating System: Windows 98, Application: Adobe Photoshop 5.0.2,
Driver Software: TWAIN 32 source, ASPI Version: 4.57, SCSI Board: Adaptec AHA-2940AU, Memory Size of Application: 265MB
Macintosh
CPU: PowerPC G3 450MHz, RAM: 320MB, Operating System: MacOS 8.6, Application: Adobe Photoshop 5.0.2,
Driver Software: Photoshop Plug-in, Virtual Memory: Off, Memory Size of Application: 150MB
35mm Film Holder
PC SYSTEM REQUIREMENTS
CPU
Operating system
RAM
Screen size
No. of colours
Required space on HD
Others
Recommended SCSI board: Adaptec AVA-1505AE / 2902E, AHA-1510B / 1520B / 1540CP / 2910B / 2910C / 2920C / 2940 / 2940AU / 2940U / 2940UW / 2940W, APA- 1460D, SCSI card 19160 / 29160 / 29160N / 2930U / 2930U2.
1
*
Dimâge is a trademark or registered trademark of Minolta Co., Ltd.
Digital ICE is a trademark of Applied Science Fiction, Inc.
Windows is a trademark or registered trademark of Microsoft Corp.
Macintosh is a trademark or registered trademark of Apple Computer Inc.
Adobe Photoshop is a trademark or registered trademark of Adobe Systems Inc.
All other brand and product names are trademarks or registered trademarks of their respective owners.
Minolta Co., Ltd.
Minolta Europe GmbH
Minolta (UK) Ltd.
(Photo Operations)
Photopak Sales
Minolta Portugal Limitada
Windows
approx. 10 s
approx. 35 s
Slide Mount Holder
Specifications and accessories are based on the latest information available at the time of printing and are subject to change without notice.
1
IBM PC / AT compatible *
Intel Pentium or higher
Windows NT 4.0 / Windows 95, 98 /
Windows 2000 Professional / Windows Me
Windows 2000 Professional and Windows Me: 40MB or larger
Others: 32MB or larger
XGA (1024 x 768 pixels) or larger, VGA can be also used.
16-bit high colour, minimum
Approx. 90MB or larger
(For 16-bit depth: approx. 200MB or larger)
Adobe Photoshop 3.0.5 / 4.0.1 / 5.5, Photoshop 5.0LE,
Paintshop Pro 5.0 and Corel Photopaint 8 have been fully
tested with the TWAIN driver software.
Recommended SCSI board (for New Power Macintosh G3 series – BLUE and WHITE): Adaptec PowerDomain 2940UW / 2940U2W / 2930U / 29160N, SCSI card 2906.
2
*
3-13, 2-Chome, Azuchi-Machi, Chuo-Ku, Osaka 541-8556, Japan
Minoltaring 11, D-30855 Langenhagen, Germany
Rooksley Park, Precedent Drive, Rooksley, Milton Keynes, MK13 8HF, England
241 Western Industrial Estate, Naas Road, Dublin 12, Ireland
Av. do Brasil 33-A, P-1700 Lisboa, Portugal
Advanced Photo System film
Macintosh
approx. 6 s
Index
approx. 30 s
Preview
Final Scan (2,820 dpi)
Advanced Photo System
Adapter (optional)
Macintosh *
PowerPC only (68K not supported)
System 7.5 – Mac OS 9
Free memory of 16MB or larger
19-inch (1024 x 768 pixels) recommended, 13-inch possible
32,000 minimum
Approx. 90MB or larger
(For 16-bit depth: approx. 200MB or larger)
Adobe Photoshop 3.0.5 / 4.0.1 / 5.5 and Photoshop 5.0LE
have been fully tested for use with the plug-in software.
©1999 Minolta Co., Ltd.
Windows
approx. 8 s / frame
approx. 10 s
approx. 25 s
2
Minolta homepage address: www.dimage.minolta.com
www.minoltaeurope.com
9242-4903-11
M0301 (MH-E)-A4
Macintosh
approx. 6 s / frame
approx. 6 s
approx. 25 s
