- Page 1 PPHSS 670 2002...
- Page 2 Operating instructions Page 4 - 7...
- Page 3 PARKSIDE...
-
Page 4: Technical Data
For sawing wood, plastic and metal Dear Customer! We are delighted that you have decided to purchase our high quality PPHSS 670 pendulum action jigsaw. Please make sure you familiarise yourself fully with the way the equipment works before you use it for the first time and that you understand how to handle electrical power tools correctly. -
Page 5: Installing The Sawblade
INSTALLING THE SAWBLADE Push the saw blade shaft as far as the stop into the blade holder. Take the Allan key (from its holder in the case) and tighten both bolts. To release saw blade unscrew both bolts (counter clockwise). -
Page 6: Setting The Pendulum Action
3. Switch the machine on and plunge the oscillating saw carefully into the material. USE OF THE PARALLEL GUIDE The PPHSS 670 pendulum action jigsaw is equipped with a parallel guide . This allows you to make accurate parallel cuts using the mm scale. - Page 7 Adjust the speed and the pendulum action settings to suit the material to be sawn. We always recommend that you carry out a test cut first. To use the jig saw put the front end of the base plate on the material and turn the machine on. Press the machine from above on to the material and guide the jigsaw along the cutting line.
-
Page 8: Warranty
This piece of equipment is covered by a 36-month warranty as of the date of purchase. The equipment was produced with the greatest of care and underwent thorough testing before delivery. In the unlikely event of detecting a functional defect, please return the equipment in its original packaging with the proof of purchase (if available) to the closest service address. - Page 10 Electromagnetic compatibility: (89/336 EWG), (92/31 EWG), (93/68 EWG) Applicable harmonised standards: EN 50144-1:1998, EN 50144-2-10:1996, EN 55014:1993+A1:1997 EN 60555-2/1987, EN 61000-3-3:1995, EN 55014-2:1997 Description / Model type: PARKSIDE PPHSS 670 PENDULUM ACTION JIGSAW Bochum, 31.10.2002 Hans Kompernaß - Managing Director -...
