- Page 1 ™ Dell Dimension E520 DELL Dimension E520 Built to meet your needs Built to meet your needs Dell Confidential...
- Page 2 Dimension E520 can expand to support your productivity, collaboration, and entertainment requirements. The Dimension E520 chassis not only looks cool, but also has amazing cooling capacity because of its BTX-based design and Dell QuietCase™ technology. Available with Intel® Celeron® to Intel Core™...
- Page 3 4 years. Should the situation arise, DellConnect is a simple online access tool that allows a Dell service and support associate to access your computer through a broadband connection, diagnose your problem and repair it.
- Page 4 ™ Dell Dimension E520 Dimension C521 XPS 700 Sleek and Powerful Extreme Gaming ® NVIDIA® GeForce® 6150 LE GPU /nForce® NVIDIA nForce590 SLI X16 chipset 430 MCP chipset Intel® Pentium® D processors and Intel AMD Sempron™, Athlon™ 64, and Athlon™...
- Page 5 ™ Dell Dimension E520 WHO IS THE Dimension E520 CUSTOMER • Prefers a full-featured product to meet their productivity or entertainment needs in an accommodating size. • Demands all-around performance with multimedia capabilities and values expandability. • Expects performance features today and the ability to upgrade or add features to their PC in the future.
- Page 6 (dual channel*). • 4GB* of maximum memory Video Solutions • The new Dimension E520 offers three graphics solutions comprised of integrated graphics and a choice of two PCI Express graphics cards: 256 MB ATI X1300 Pro or the 256 MB NVIDIA® GeForce® 7300LE TurboCache* .
- Page 7 Dell Dimension E520 Audio Solutions • Integrated 7.1 high definition audio is included on every Dimension E520 • Customers can choose to upgrade to Integrated Sound Blaster® Audigy™ HD Software Edition to enhance sound for music, gaming or multimedia presentations.
- Page 8 ™ Dell Dimension E520 • Speakers: The Dimension E520 is available with a range of speakers . – Dell 5650 5.1 Surround Sound Speakers System with Subwoofer: • Awesome surround sound, great for listening to DVD-Audio, DVD-Video, or that 3D audio gaming experience.
-
Page 9: Optical Drives
700MB. Hard Disk Drives • The Dimension E520 offers a variety of Dell factory installed hard drive configurations with fast technology, Serial ATA drives. The Dimension E520 offers high levels of expandability, with support for one or two drives, each with up to 320GB* of total storage. -
Page 10: Operating Systems
Dell digital flat panel displays available for the Dimension E520 include the Dell 1707FP (17” Flat Panel), the Dell 1907FP (19” Flat Panel), the Dell 2007WFP (20.1” wide-screen Flat Panel) and the Dell 2407WFP (24” wide- screen Flat Panel). -
Page 11: Front View
™ Dell Dimension E520 FRONT VIEW: BACK VIEW: Voltage Selection Switch Power Connector Back Panel Connectors Card Slots Dell Confidential... - Page 12 ™ Dell Dimension E520 Dell Confidential...
- Page 13 ™ Dell Dimension E520 Dell Confidential...
- Page 14 ™ Dell Dimension E520 Other processors are available. For more information, see E520 Tech Specs on dell.com at http://www.dell.com/content/products/productdetails.aspx/dimen_e520?c=us&l=en&s=bsd &cs=04 Dell Confidential * See important information on Page 25.
- Page 15 ™ Dell Dimension E520 Intel Graphics Media Accelerator 3000 Other graphics solutions are available. For more information, see E520 Tech Specs on dell.com at http://www.dell.com/content/products/productdetails.aspx/dimen_e520?c=us&l=en& s=bsd&cs=04 Dell Confidential...
- Page 16 ™ Dell Dimension E520 Dell Confidential...
- Page 17 ™ Dell Dimension E520 Dell Confidential...
- Page 18 Dell has long worked to reduce or eliminate the use of environmentally sensitive materials in products. Dell’s design for recycling includes: •...
- Page 19 Dell Recycling: Dell has one of the most robust recycling programs in the industry, and recycling is free with purchase of any new Dell PC and for a nominal charge as a standalone service. Terms and conditions apply; visit www.dell.com/recycling for more information.
- Page 20 • Transfers your data to a new system* – Along with setting up your new system, Dell can transfer up to 2GB of data from your old system to your new one, includes loading up to 2 customer-supplied software CDs •...
- Page 21 Base, go to www.support.dell.com. Live Chat is becoming a preferred method of support for many computer users and is a quick way to get most technical issues resolved. To chat with a Dell technician go to www.support.dell.com/chat. E-mail: At www.support.dell.com/email, customers can send E-mail questions to Dell technicians 24 hours a day and will receive automated responses immediately or rep responses within 6 hours.
- Page 22 ™ Dell Dimension E520 ® ® Microsoft Windows XP Media Center Edition 2005 turns your office or living room into a multimedia hub Fun with Photos: • Make fewer trips to the photo lab by using built-in photo editing features •...
- Page 23 OS, device drivers and applications from CD. Dell PC Restore should be used as the last method to restore the OS and factory-installed software. Any programs or files added since the system was purchased are permanently deleted from the hard drive.
- Page 24 Dimension E520 The Dell Picture Studio™ The Dell Picture Studio is a digital photography one-stop shop for acquiring images from a digital camera or scanner; quickly improving, organizing and cataloguing photos; creating greeting cards, fliers, and Web graphics, creating presentations; to sharing photos and online photos, customers can find it all in the Dell Picture Studio.
- Page 25 Dimension E521/C521 Shared Memory: Between 64 MB and 512 MB of system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Dimension E520 Shared Memory: Up to 224 MB of system memory may be allocated to support integrated graphics, depending on system memory size and other factors.
- Page 26 Dell, the Dell logo, and Dimension are trademarks of Dell Inc. Other trademarks and trade names may be used in this document to refer to the entities claiming the marks and names or their products.
