Vertical position
Raise the spool pin to the vertical position. Slide
on the large spool cap and place a felt pad under
the thread spool. This is to prevent the thread from
reeling off too fast.
Do not place a spool cap on top of the spool pin as
that would prevent the spool from rotating.
Auxiliary spool pin
The auxiliary spool pin is used when winding a
bobbin thread from a second spool of thread or for
a second spool when sewing with a twin needle.
Raise the auxiliary spool pin. Slide on a large spool
cap and place a felt pad under the thread spool.
Threading the machine
Make sure that the presser foot is raised and the
needle is in the up position.
1.
Place the thread on the spool pin and t a spool
cap of the right size.
2.
Pull the thread into the thread guide (A) from
the front to the back. Pull the thread from the
right underneath the bobbin winder thread
guide (B) on the pre-tension disc (C).
3.
Thread down through the right-hand
threading slot and then upwards through the
left-hand threading slot.
4.
Bring the thread from the right into the take-up
lever (D) and down in the left-hand threading
slot to the needle thread guide (E).
5.
Thread the needle.
C
12 - Preparations
B
Main spool pin in vertical position
Auxiliary spool pin and main spool pin in vertical
position.
D
E
C
B
4
3
2
1
A
