Directed Electronics PS-4461TWE-FM User Manual

Two-way 6-button lcd automatic/manual transmission remote starter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
T W O - W A Y
6 - B U T T O N
L C D
T R A N S M I S S I O N
A U T O M A T I C / M A N U A L
R E M O T E
S T A R T E R
PS-4461TWE-FM
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle is
parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL position and
the parking brake is engaged in order to avoid accidents upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to avoid
accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled or put
into valet mode before servicing.
A note concerning the battery inside the transmitter:
Depending on your usage of the transmitter, the battery can last anywhere between 3 to 6 months. When the
battery is low, the transmitter will produce two beeps in a repetitive cycle. At that point you should replace
your battery with a new one. That is why we recommend that you keep a spare battery somewhere handy
such as the glove compartment.
Designed & engineered in Canada
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of
the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (EIRP) is not more than that required for successful
communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the
equipment
Doc#: 100825
Rev:2.1
© 2010
WARNING
- PS-4461TWE-FM -
- FcN -
Canada

Advertisement

Table of Contents
loading

Related Manuals for Directed Electronics PS-4461TWE-FM

Summary of Contents for Directed Electronics PS-4461TWE-FM

  • Page 1 NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment Doc#: 100825 Rev:2.1 © 2010 - PS-4461TWE-FM - - FcN - Canada...
  • Page 2 What is EncryptR™ Technology? EncryptR™ employs proprietary encryption software that sends unique codes from the remote starter to the ADS-TB or ADS-AL-CA bypass module that cannot be replicated or reversed with hi-tech equipment. The EncryptR™ communication exchanged between the remote starter and the ADS bypass module is best described as a “secret handshake”...

  • Page 3: Table Of Contents

    Table of Contents AUX 1 ............16 Introduction .......... 4 Horn Chirp Timing ........16 Multi-car Operation ........16 Vehicle Presets ..........4 OEM-Style Alarm........16 Heater ............4 Intrusion Codes via horn ......17 Windshield Wipers, Radio & Headlights ..4 Missing a Start or a Stop Confirmation ..

  • Page 4: Introduction

    Introduction This is a state-of-the-art remote car starter system. The system is packed with advanced features such as priority access to the driver’s door (commodity features), the Safe Start children safety feature and SmartStart™. SmartStart™ is a groundbreaking technology that enables your remote starter features to be accessed by your smartphone.

  • Page 5: Using The Transmitter

    Using the Transmitter Your remote starter is equipped with a 6-button multi-channel remote control. It can operate two independent vehicles equipped with identical remote starters (see Multi-car operation section on page 16). LCD Remote Functions The transmitter offers several command-confirmation and timer features. This section explains some of the key functions available.

  • Page 6: Backlight

    See Valet mode section Remote valet 1 beep (page-12) See Panic Mode section Panic None 1 beep (page-12) Backlight Three different ways to use the backlight: Turning the backlight on for 3 seconds, press the for at least 1 second and release. If the button is pressed and held for more than 5 seconds the backlight will stay ON as long as the button is held.
  • Page 7 To SAVE modifications and EXIT remote’s MENU, do not touch any button for approximately 5 to 10 seconds. Remote’s advanced functions and MENU Display Description Parking meter countdown This version of the countdown feature is particularly useful for keeping track of parking meter time: the user may quickly set up the countdown using the Parking .
  • Page 8 The transmitter keypad can also be locked as follows: a. Press to select MENU. b. Within 3 seconds, press c. The LCD will display “Security” to confirm locking of the keypad. Press for about 1sec to unlock the transmitter’s keypad. Backlight color The backlight can be set to 8 different colors.

  • Page 9: Remote-Starting Your Vehicle

    F Button Function FBPRO Function Button Programming Menu 1 2 3 M Level 1, level 2, level 3, MENU 2 3 1 M Level 2, level 3, level 1, MENU Function Button 3 1 2 M Level 3, level 1, level 2, MENU programming 2 1 3 M Level 2, level 1, level 3, MENU...

  • Page 10: Driving Off

    If your vehicle has an automatic transmission and it does not start at the first attempt, the system will shut down, wait a few seconds and try to start the engine again. There will be 3 start attempts before the system gives up. Driving Off With the vehicle running under remote control, press the button to disarm and unlock the...

  • Page 11: Remote Starter Features

    Remote Starter Features Remote Door Locks If your system was installed with the Remote Door Locks option, you will have the convenience of remote keyless entry. To lock your doors and arm the starter kill (if installed): Press and hold the button for approx.

  • Page 12: Valet Modes

    Valet Modes When the vehicle is in Valet Mode, the remote starter functionalities and alarm (if configured) are disabled. If the vehicle needs to be serviced, or if you park it indoors, the Valet Mode will prevent the engine from being remote-started accidentally. Any of the following features will put your remote car starter into Valet Mode: Ignition Valet: This feature allows you to put your system into Valet Mode by...

  • Page 13: Quick Lockout Tm

    (this will lock your doors and deactivate panic mode), or (this will unlock your doors and deactivate panic mode). Furthermore, the panic mode can be stopped by activating Valet Mode (page- 12) * Panic Mode will automatically shut down after 30 sec. Quick Lockout (Also called Secure Panic.) For fast protection in emergency situations, the system will LOCK all doors when you press the brake pedal while you hear the sound signal.

  • Page 14: Temperature Request (If Acc-Temp-100 Installed)

    To Enable the LED: Press and hold simultaneously until the remote beeps once, pause for 2 seconds, then beeps once again. Release the buttons. The parking light will flash 1 time. Temperature Request (If ACC Temp 100 installed) The user can request the temperature in the vehicle if a Temperature Sensor Module (ACC-Temp- 100) is installed: Through advance function remote’s menu (page-6), select L-01.

  • Page 15: Turbo Mode

    Turbo Mode If Turbo Mode is configured at installation, it will allow a turbocharger to idle down after the user leaves the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it is shut down by remote control), then shut down the engine.

  • Page 16: Aux 1

    AUX 1 Note: This 500 mA negative Aux 1 output can be used for many different applications Priority door: This great feature allows the user to unlock solely the driver’s door with a single press of the button on the transmitter, and to unlock the other doors, if desired, by pressing the button for a second time.

  • Page 17: Intrusion Codes Via Horn

    - The LED on the antenna will flash slowly to indicate that the OEM-style alarm is now armed. To disarm the OEM-style alarm, press the button on the transmitter. To stop the horn from sounding if the OEM-style alarm is triggered, press the button, or put the system in and out of Valet Mode (page-12) Intrusion Codes via horn The system monitors the following:...

  • Page 18: Troubleshooting Transmitting Range

    Customized feature: Your installer can add customized features such as turning on the radio, opening sliding doors, etc. To control the Multi level features, refer to the tables below: FBPRO setting 1 *default FBPRO setting 2 FBPRO FBPRO Features Levels Features Levels setting...

  • Page 19: Diagnostics – Parking Light Flash Table

    in relation to the remote control can affect the range. Straight on – standing in front of the vehicle – generally gives you the greatest range; the second best performance is from the back. Using the remote control from either side of the vehicle will usually give the lowest range. x The range will be significantly lower in a crowded parking lot than in open space.
