Page 1: User Guide
Britain’s No.1 Range Cooker USER GUIDE & INSTALLATION INSTRUCTIONS Elite SE 110 Dual Fuel... - Page 2 We offer cookware to work perfectly with all fuel types manufactured by Rangemaster, including induction hobs. You can be assured of functionality with style, as well as the quality and meticulous attention to detail you expect from the pioneers of range cooking.
-
Page 3: Table Of Contents
Contents Before You Start... Troubleshooting Important! Installation Installation and Maintenance Dear Installer Peculiar smells Safety Requirements and Regulations If you smell gas Provision of Ventilation Ventilation Location of Cooker Personal Safety Conversion Cooker Care Positioning the Cooker Cleaning Moving the Cooker Cooker Overview Fitting the Stability Bracket or Chain Hotplate Burners... -
Page 5: Before You Start
Before You Start... Your cooker should give you many years of trouble-free • DO open doors and windows to get rid of the gas cooking if installed and operated correctly. It is important • DO keep people away from the area affected that you read this section before you start, particularly if you •... -
Page 6: Cooker Care
Foods for frying should be as dry as possible. Frost on frozen When the oven is on, DO NOT leave the oven door foods or moisture on fresh foods can cause hot fat to bubble open for longer than necessary, otherwise the up and over the sides of the pan. -
Page 7: Cooker Overview
2. Cooker Overview DocAUS.020-0004 - Overview - 110DF - Elan Fig.2.1 ArtNo.220-0001 - 110DF - Elite SE anno The 110 dual fuel cooker (Fig.2.1) has the following features: Fig.2.2 6 hotplate burners including 2 wok burners A control panel Multi-function oven Fan oven Storage drawer Hotplate Burners... -
Page 8: Wok Burners
ten seconds. Fig.2.3 ArtNo.270-0003 If, when you let go of the control knob, the burner goes out, Proplus control to low then the FSD has not been bypassed. Turn the control knob to the OFF position and wait for one minute before you try again, this time making sure to hold in the control knob for slightly longer. -
Page 9: The Wok Cradle
The Wok Cradle Fig.2.9 The wok cradle is designed to fit a 35 cm wok. If you use a different wok, make sure that it fits the cradle. Woks vary very widely in size and shape. It is important that the wok sits down on the pan support –... -
Page 10: The Ovens
The Ovens Function References to ‘left-hand’ and ‘right-hand’ ovens apply as viewed To thaw small items in the oven without Defrost from the front of the appliance. heat A full cooking function, even heat The left-hand oven is a multi-function oven, while the right- Fan oven throughout, great for baking hand oven is a fan oven. - Page 11 The combination of fan and conventional cooking (top and Multi-function Oven Functions base heat) makes this function ideal for cooking large items Defrost that need thorough cooking, such as a large meat roast. This function operates the fan to circulate cold air It is also possible to bake on two shelves at one time, only.
- Page 12 Operating the Ovens Fig.2.15 Operating the Multi-function Oven The multi-function oven has two controls: a function selector and a temperature setting knob (Fig.2.15). ArtNo.270-0026 Proplus MF oven controls (2) Turn the function selector control to a cooking function. Fig.2.16 shows the control set for conventional oven cooking. Turn the oven temperature knob to the temperature required (Fig.2.17).
-
Page 13: The Clock
The Clock ArtNo.300-0004 2-button clock annotated Fig.2.19 You can use the timer (Fig.2.19) to turn the ovens on and off. The clock must be set to the time of day before the ovens will work. Setting the Time of Day When the clock is first connected, the display flashes ( 0.00 ) ... -
Page 14: Key Lock
Use the Adjusting knob to set the ‘cook period’ you need Fig.2.25 Fig.2.26 (Fig.2.25). ArtNo.301-0010 2BC Turn the Timer knob to the [] position. The display will show ArtNo.301-0008 2BC Setting the cooking time Stopping the oven 2 the current time of day plus the ‘cook period’ you just set. Use the Adjusting knob to set the ‘stop time’... -
Page 15: Accessories
Accessories Fig.2.32 Oven Shelves Flat shelf Shelf guard In addition to the flat shelves, your cooker is supplied with a drop shelf (Fig.2.32). The drop shelf increases the possibilities for oven shelf spacing. The oven shelves can be easily removed and refitted. Front Pull the shelf forward until the back of the shelf is stopped by Shelf guard... -
Page 16: Oven Light
Other Uses Fig.2.37 The Handygrill and pan can also be used for roasting. Remove the trivet from the pan and position the rack at the height of the centre of the oven. Use the fan or conventional oven settings and follow the guide time in the cooking chart for roasting. -
Page 17: Cooking Tips
3. Cooking Tips Tips on Cooking with the Timer General Oven Tips If you want to cook more than one dish, choose dishes that The wire shelves should always be pushed firmly to the back require approximately the same cooking time. However, of the oven. -
Page 18: Cooking Table
4. Cooking Table DocNo.031-0004 - Cooking table - electric & fan single cavity The oven control settings and cooking times given in the table below are intended to be used Top (T) AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a preferred result. -
Page 19: Cleaning Your Cooker
5. Cleaning Your Cooker Essential Information Fig.5.1 Isolate the electricity supply before carrying out any thorough cleaning. Allow the cooker to cool. NEVER use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. DO NOT mix different cleaning products –... -
Page 20: Ovens
Glass Fronted Door Panels Fig.5.5 The oven door front panels can be taken off so that the glass panels can be cleaned. Move the cooker forward to gain access to the sides (see the ‘Moving the Cooker’ section under ‘Installation’). Open the oven door slightly and remove the front panel fixing screws from the door sides, two each side. -
Page 21: Cleaning Table
Cleaning Table Cleaners listed (Table 5.1) are available from supermarkets or electrical retailers as stated. For enamelled surfaces use a cleaner that is approved for use on vitreous enamel. Regular cleaning is recommended. For easier cleaning, wipe up any spillages immediately. Hotplate Part Finish... -
Page 22: Troubleshooting
6. Troubleshooting Hotplate ignition or hotplate burners faulty Food is cooking too slowly, too quickly, or burning Is the power on? Cooking times may differ from your previous oven. If not, there maybe something wrong with the power Check that you are using the recommended supply. - Page 23 An oven light is not working Fig.6.1 The bulb has probably burnt out. You can buy a replacement bulb (which is not covered under the warranty) from a good electrical shop. Ask for a 15 W – ArtNo.324-0005 Oven light bulb 230 V lamp, FOR OVENS.
-
Page 24: Installation
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. 7. Installation Dear Installer In the UK the cooker must be installed in accordance with: Before you start your installation, please complete the details below, so that, if your customer has a problem relating to •... -
Page 25: Location Of Cooker
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Checking the Parts: Location of Cooker The cooker may be installed in a kitchen/kitchen diner but 4 pan supports Wok cradle NOT in a room containing a bath or shower. This appliance is designed for domestic cooking only. -
Page 26: Positioning The Cooker
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Positioning the Cooker Fig.7.1 Fig.7.1 and Fig.7.2 shows the minimum recommended distance from the cooker to nearby surfaces. 75 mm 75 mm 650 mm The cooker should not be placed on a base. The hotplate surround should be level with, or above, any adjacent work surface. -
Page 27: Moving The Cooker
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Moving the Cooker Fig.7.4 On no account try and move the cooker while it is plugged into the electricity supply. The cooker is very heavy, so take great care. We recommend that two people manoeuvre the cooker. -
Page 28: Fitting The Stability Bracket Or Chain
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Fitting the Stability Bracket or Chain Fig.7.7 Unless otherwise stated, a cooker using a flexible gas connector must be secured with a suitable stability device. Stability chain Suitable stability devices are shown in Fig.7.7, Fig.7.8 and Fig.7.9. -
Page 29: Gas Connection
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Gas Connection Fig.7.10 This must be in accordance with the relevant standards. The flexible hose (not supplied with the cooker) must be in accordance with the relevant standards. Hoses may be purchased at most builders’... -
Page 30: Electrical Connection
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Electrical Connection Current Operated Earth Leakage Breakers The cooker must be installed by a qualified electrician, in The combined use of your cooker and other domestic accordance with all relevant British Standards/Codes of appliances may cause nuisance tripping, so we Practice (in particular BS 7671), or with the relevant national... -
Page 31: Conversion To Lp Gas
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 8. Conversion to LP Gas Check the ‘Technical Data’ section at the back of the book Fig.8.1 that the hob is convertible to the gas you want to use. -
Page 32: Pressure Testing
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Pressure Testing Connect the appliance to the gas supply. The gas pressure can be measured at one of the hotplate burner jets (not a wok burner). -
Page 33: Circuit Diagram
9. Circuit Diagram P033458 P028728 The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Description Code Description Code Colour Left-hand multi-function oven Right-hand fan oven thermostat Blue thermostat Right-hand fan oven control Brown Left-hand multi-function oven function Right-hand fan oven element... -
Page 34: Technical Data
10. Technical Data ArtNo.105-0008 - Technical data - 90 induction - Elan THE COOKER IS CATEGORY: Cat II 2H3+. It is supplied set for group H natural gas. A conversion kit from NG to LP is available for the cooker. INSTALLER: Please leave these instructions with the User. - Page 35 0800 804 6261 or depending on your mobile network tariff you can call free on 0370 789 5107. For a competitive quote and to arrange for a Rangemaster approved engineer to attend, call Consumer Services on: 0800 804 6261 or...
- Page 36 Registered in England and Wales. Registration No. 354715 Registered Office: Juno Drive, Leamington Spa, Warwickshire, CV31 3RG Rangemaster continuously seeks improvements in specification, design and production of products and thus, alterations take place peri- odically. Whilst every effort is made to produce up-to-date literature, this booklet should not be regarded as an infallible guide to current...
