TOPCOM Babytalker 1010
• Plug the small plug of the adapter into the charger jack
on the top of the unit and the other end in the electrical
socket.
• Make sure that the unit is switched off in order to charge
the batteries properly.
NOTE: It takes approximately 12 to 14 hours to fully
charge the batteries (with 600mAh).
10 Supporting device for wall assembly
The baby unit is wall mountable. The appropriate screw is not supplied. Turn a 3mm screw
into the wall. The screw head must be approx. 3 mm out of the wall so that the screw can be
fixed correctly into the hang hole at the back of the baby unit. Hang the baby unit with its
10
hang hole carefully to this screw.

11 Battery Charge Level

The BATTERY CHARGE LEVEL in the Parent Unit, as well as in the Baby Unit is indicated
by the number of squares present inside the BATTERY icon on the LCD Display.
• Battery Full
• Battery 2/3 charged
• Battery 1/3 charged
• Battery empty
12 Buttons
12.1 Baby unit
(See picture 1 on the folded cover page)
1 VOX sensitivity control
2 Microphone
3 On/Off switch
Menu down button: Select the previous value in the menu.
4
5 External microphone connector (microphone not included)
Menu button: Enter the setting menu
6
7 Power adapter connector
Menu up button - Select the next value in the menu.
8
9 LCD display
10 Hang hole for wall mounting
11 ON/OFF LED
8
12
TOPCOM Babytalker 1010
12
