1.
Scan/swipe license (magnetic stripe, all tracks or barcode-1D and 2D
2.
Display errors or license holder name and age.
3.
User license expiration date option (automatically computed at download)
4.
Duplicate entry option
5.
Tagged entry option
6.
Receipt print/no print option
7.
Reprint receipt (whether receipt print option is on or off
8.
Save transactions options
9.
Save tagged transactions
10.
Print/Display ID batch
11.
Print/Display tagged batch
12.
Optional check transactions
13.
Optional check batch
14.
Restaurant/retail option, where restaurant implies clerk number and name
entry, clerk # required for transaction and batch includes clerk number, name
and count of transactions
15.
Transmit batch direct connect or remotely
16.
Diagnostics that display terminal id and display card data upon swipe or scan
17.
Copyright Information display
18.
Optional swipe/scan count
19.
Manual entry
20.
* Charge Back - Credit card option – swipe cc, display name, account number
and expiration date, Print to have Customer sign or save to batch.
21.
Check transactions
22.
Check batch
23.
Password protected download, Edit mode and Report Mode
24.
Ultra-violet light scanner option where program will turn UV leds on in
scanner if license has hologram. Also an option to alert merchant if the license
being swiped/scanned has micro printing.
25.
Edit mode to change:
a. Date/Time
b. Program model (UV ID mode or normal scanner mode)
c. Optional program mode to indicate to user that license also has micro
printing
d. Merchant name, address, city, state, zip, phone #
TriCom
The ID-eOmni Program
Feature List
Advertisement
Table of Contents
Related Manuals for VeriFone Omni 3730
Summary of Contents for VeriFone Omni 3730
- Page 1 TriCom The ID-eOmni Program Feature List Scan/swipe license (magnetic stripe, all tracks or barcode-1D and 2D Display errors or license holder name and age. User license expiration date option (automatically computed at download) Duplicate entry option Tagged entry option Receipt print/no print option...
- Page 2 Page 2 of 2 The ID-eOmni Program Feature List (continued) e. Change manager password f. Change report password g. Receipt print h. Save transactions i. Duplicate entry warning option j. Tag option k. Discount age l. “Check License” option for ages under 30 m.
- Page 3 ID-eOmni ID-eOmni Omni 3730/30LE Omni 3740/50 USER’S GUIDE...
-
Page 4: Table Of Contents
CONTENTS MAIN MENU..............3 MAG CARD TRANSACTION........4 BARCODE TRANSACTION........5 ID MENU..............5 MANUAL ENTRY TRANSACTION......5 REPORT..............6 REPRINT RECEIPT...........6 EDIT FUNCTION............7 EDIT FUNCTION SELECTIONS........8 XMIT.................11 DIAGS................11 MORE................11 SAMPLE REPORTS..........12 MAIN MENU THE ID-EOMNI MINIMUM DOB FOR:... -
Page 5: Mag Card Transaction
ALCOHOL-01/01/2002 TOBACCO-01/01/1999 MENU COUNT CHECK The ID-eOmni main menu displays today’s required date of birth for the purchase of alcohol and tobacco. Depressing the purple key directly below ID MENU, COUNT and CHECK(optional) will cause those functions to be performed (described separately herein). Depressing the F2 key directly across from CC will cause the credit card i.d. -
Page 6: Barcode Transaction
audible alarm. The same display will appear if the license holder is under 18 (with 18 replacing 21 above.) INVALID XXX YYY - The ID-eOmni analyzes the details of the data contained on a license. This display is shown if any one of those analyses finds something invalid on the license. -
Page 7: Manual Entry Transaction
MANUAL ENTRY TRANSACTION This transaction is used in the event that the barcode or magnetic stripe on the license in not readable or available. If the F1 key to the right of this display is depressed, the following is displayed: LICENSE # ? Enter the license number utilizing the ID3200 keypad. -
Page 8: Reprint Receipt
If DISPLAY is selected each saved record is displayed as follows: name address city, state license # expiration date date of birth EXIT NEXT Depressing the key below NEXT will cause the next saved record to be displayed. Depressing of the EXIT key will cause the following to be displayed: ‘BATCH DELETE?’... -
Page 9: Edit Function Selections
ENTER PASSWORD The manager must enter the correct six-digit password followed by the ENTER key to continue. If the correct password is entered, the information below will appear (The default password shipped with The ID-eOmni is “111111”.). In each case, if there is an option to change information, depression of the blue key directly below YES will allow new data entry. That information is entered from the keypad followed by the ENTER key which will cause the next item to be displayed. - Page 10 (merchant phone #) Change? YES NO CANCEL Merchant phone entry/change CHANGE MANAGER PASSWORD? CANCEL This allows the manager to change the EDIT mode password from the default “111111” to something more personal and private. CHANGE REPORT PASSWORD? CANCEL The batch report function requires a password which may be different from the EDIT mode password. It’s default value when The ID-eOmni is shipped is “111111”...
-
Page 11: Xmit
CANCEL This allows the manager to set the age for senior discounts (usually applies to restaurants, etc.). If this feature is not desired, set the age to 99 (default from factory). CHANGE DATE/TIME? CANCEL This function allows the manager to set the date and time in The ID-eOmni. This is only necessary if, for some reason, the date/time gets corrupted in the terminal. - Page 12 Depressing the key below YES causes the ID-eOmni to dial a remote host computer for a new download of The ID-eOmni program. Please ensure that a telephone line is connected to the back of the ID-eOmni in the second telephone check from the left as you look at the back of the terminal.
-
Page 13: Sample Reports
If this option is enabled, depressing the key directly across from CC sets the ID-eOmni into Credit Card mode, meaning the very next swipe is assumed to be a credit card and the name and account number encoded on the card are displayed. This feature provides a merchant with a second form of validation of identity. - Page 14 Date of Birth: 07/17/1972 Jane Doe is 25 years of age. Optionally prints the following lines if applicable: ****HAPPY BIRTHDAY**** ****SENIOR DISCOUNT**** ******MINOR******* BATCH REPORT EXAMPLE _______________________ ****BATCH REPORT**** THE ID-EOMNI JOE’S MARKET 123 ANYSTREET ANYTOWN, CA 99999 555-1221 12345678 DATE/TIME: 199703051327 JANE DOE 444 ELM STREET...
- Page 15 (proceeds the same for each record in the batch) _______________________ TOTAL COUNT = 10 UNDER 21 COUNT = 2 UNDER 18 COUNT = 5 ****END OF BATCH**** 3. Check License Feature – If this feature is enabled and a license swipe license swipe results in an age less than thirty, The ID- eOmni will display “CHECK LICENSE PHOTO”.
