User Guide for the Polycom VVX 1500 Phone

Phone Icons

1 - 22
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Feature
10 Picture-in-Picture window
(PIP)
The following table describes the icons that display on the touch screen.
Call counters only display when the icon appears next to the Line Key.
Note
Icon
Description
The small window in the corner of the
touch screen that displays video. By
default, the PIP displays the near site.
You can toggle the PIP to display the
near site or the far site. For more
information, see
on page 3-3.
Description
Buddy Status (Online)
Busy Lamp Field (BLF) indicator (line is idle)
Buddy Status (Busy, Do Not Disturb)
Buddy Status (Be Right Back, Away, Out to Lunch)
Buddy Status (Offline)
Busy Lamp Field (BLF) indicator (line is busy)
Call (audio-only)
Call with Polycom HD Voice
Call (video)
Call (video) with Polycom HD Voice
Handling Video Calls
