"Streamline Closed Circuit"
SOLAR STORAGE
SOLAR WATER HEATER
OWNER'S MANUAL
AND
WARRANTY / INSTALLATION INFORMATION
WARNING: Plumber – Be Aware
Use copper pipe ONLY. Plastic pipe MUST NOT be used.
It is a requirement of a solar water heater installation that all
pipe work be in copper and not plastic, due to the effects of
high water temperatures.
Solahart Industries Pty Ltd
ABN 45 064 945 848
This water heater must be installed and serviced by an authorised person.
Please leave this guide with the householder.

Advertisement

Table of Contents
loading

Related Manuals for Solahart Streamline Closed Circuit

Summary of Contents for Solahart Streamline Closed Circuit

  • Page 1 “Streamline Closed Circuit” SOLAR STORAGE SOLAR WATER HEATER OWNER’S MANUAL WARRANTY / INSTALLATION INFORMATION WARNING: Plumber – Be Aware Use copper pipe ONLY. Plastic pipe MUST NOT be used. It is a requirement of a solar water heater installation that all pipe work be in copper and not plastic, due to the effects of high water temperatures.
  • Page 2 PATENTS This water heater may be protected by one or more patents or registered designs. ® Registered trademark of Solahart Industries Pty Ltd or Rheem Australia Pty Ltd. ™ Trademark of Solahart Industries Pty Ltd or Rheem Australia Pty Ltd.

  • Page 3: Table Of Contents

    Installation – Solar Storage Tank ................14 Installation – Solar Collectors ................... 22 Connections – Plumbing.................... 26 Connections – Electrical .................... 29 Auxiliary Pump......................31 Commissioning......................34 Draining The Water Heater..................48 Water Supplies......................52 Warranty ........................53 Solahart Offices ......................56...

  • Page 4: Introduction

    It is with the above in mind that we at Solahart Industries Pty Ltd are confident that your purchase of the “STREAMLINE CLOSED CIRCUIT SOLAR PREHEAT” solar water heater will provide you reliable hot water with quality after sales service back up.

  • Page 5: About Your Water Heater

    The solar storage tank is suitable for installation either outdoor or indoor and with either Solahart ‘J’, ‘KF’, ‘LC’, ‘LCS’ or ‘BT’ solar collectors. The system is suitable for installation in areas subject to frost or freeze conditions. Freeze conditions occur below 6°C.
  • Page 6 If the power supply cord or plug to the solar storage tank is damaged, it must be replaced by an authorised person in order to avoid a hazard. The power supply cord and plug must be replaced with a genuine replacement part available from Solahart. Phone your nearest Solahart Dealer to arrange for an inspection.
  • Page 7 There are a number of factors that will affect the length of service the water heater will provide. These include the water quality, the water pressure, temperature (inlet and outlet) and the water usage pattern. However, your Solahart water heater is supported by a comprehensive warranty (refer to page 54).

  • Page 8: How Your Water Heater Works

    HOW YOUR WATER HEATER WORKS SOLAR OPERATION The Solahart Streamline closed circuit solar water heater has its vitreous enamel lined solar storage tank installed at ground or floor level, remotely from the solar collectors. This water heater is an indirect solar hot water system with a heat exchanger in the solar storage tank.
  • Page 9 If the power supply to the water heater is on and the green LED is off or the red LED is flashing, this indicates there is a fault with the water heater. The red LED may emit up to five flashes in each series of flashes. Count the number of flashes and phone your nearest Solahart Dealer to arrange for an inspection.

  • Page 10: Regular Care

    If water does not flow freely from the drain line when the lever is heater lifted, then the water heater should be checked by your nearest Solahart Dealer. The temperature pressure relief valve should be checked for lift until water...

  • Page 11: Save A Service Call

    • Collector area is too small For most installations, the number of solar collectors recommended in Solahart literature has been proven to provide the required solar energy to meet the average family needs. However, in some circumstances, it may be necessary to install an additional solar collector.
  • Page 12 Warning: Collector glass must not be replaced whilst the solar collector is on the roof. The collector glass is not offered as a replacement part and no attempt should be made to remove it. Should the solar collector require replacement, contact your nearest Solahart Dealer. TEMPERATURE PRESSURE RELIEF VALVE RUNNING •...
  • Page 13 Consider recent changes to your hot water usage pattern and check if there has been any increase in tariffs since your previous account. IF YOU HAVE CHECKED ALL THE FOREGOING AND STILL BELIEVE YOU NEED ASSISTANCE, CALL YOUR NEAREST SOLAHART DEALER.

  • Page 14: Installation - Solar Storage Tank

    THIS WATER HEATER IS NOT SUITABLE FOR POOL HEATING. The system is suitable for installation with Solahart ‘J’, ‘KF’, ‘LC’, ‘LCS’ or ‘BT’ solar collectors. The solar circuit must be installed with a continuous fall of a minimum 5° in the pipe work from the solar...
  • Page 15 INSTALLATION – SOLAR STORAGE TANK SAFE TRAY It is a requirement of AS/NZS 3500.4 that for a new installation, a water heater be installed in a safe tray where in the event of a leak, property may otherwise be damaged. Construction, installation and draining of a safe tray must comply with the above mentioned Standard.
  • Page 16 INSTALLATION – SOLAR STORAGE TANK RAIN WATER TANK If the solar collectors and solar pipe work are to be installed on a section of roof which is part of a rain water runoff collection system, then it is recommended this section of roof and its gutter be isolated from the rain water collection system.
  • Page 17 INSTALLATION – SOLAR STORAGE TANK HOT WATER DELIVERY This water heater can deliver water at temperatures which can cause scalding. It is necessary and we recommend that a temperature limiting device be fitted between the in-series booster water heater and the hot water outlets in any ablution area such as a bathroom or ensuite, to reduce the risk of scalding.
  • Page 18 INSTALLATION – SOLAR STORAGE TANK CIRCULATED HOT WATER FLOW AND RETURN SYSTEM A solar water heater should not be installed as part of a circulated hot water flow and return system in a building. The benefits of solar gain will be significantly reduced and energy gained from the sun lost through the pipe work.
  • Page 19 INSTALLATION – SOLAR STORAGE TANK REDUCING HEAT LOSSES The cold water line to and the hot water lines from the water heater must be insulated in accordance with the requirements of AS/NZS 3500.4. The insulation must be weatherproof and UV resistant if exposed.
  • Page 20 INSTALLATION – SOLAR STORAGE TANK DIMENSIONS AND TECHNICAL DATA Model DBV 270 00 Capacity 270 litres Mass 145 kg (empty) 415 kg (full) Specifications are subject to change with ongoing product improvements.
  • Page 21 INSTALLATION – SOLAR STORAGE TANK TYPICAL INSTALLATION – OUTDOOR LOCATION TYPICAL INSTALLATION – INDOOR LOCATION...

  • Page 22: Installation - Solar Collectors

    INSTALLATION – SOLAR COLLECTORS SOLAR COLLECTOR LOCATION Consideration must be given to the position of the solar collectors in relation to the solar storage tank. There are limitations on both the maximum length of the solar hot and solar cold pipes and the maximum height between the solar storage tank and the solar collectors.
  • Page 23 INSTALLATION – SOLAR COLLECTORS PIPE LENGTHS The solar hot and solar cold pipes between the solar storage tank and the solar collectors shall: • be of DN15 hard drawn copper pipe. • have a continuous fall from the solar collectors to the solar storage tank of a minimum 5° (1 in 10 grade).
  • Page 24 INSTALLATION – SOLAR COLLECTORS Maximum Height To Collectors The solar collectors must be the highest point of the system. The maximum height of the solar installation, from the base of the solar storage tank to the top of the solar collectors, is 9 m. The pump supplied with the solar storage tank will not circulate closed circuit fluid through heights greater than 9 m and solar gain will not be achieved.
  • Page 25 INSTALLATION – SOLAR COLLECTORS WARNING: Plumber – Be Aware • The solar hot and solar cold pipes between the solar storage tank and the solar collectors MUST BE of copper and fully insulated with closed cell polymer insulation or similar (minimum thickness 13 mm).

  • Page 26: Connections - Plumbing

    CONNECTIONS – PLUMBING CONNECTION SIZES • Hot water connection: RP¾/20. • Cold water connection: RP¾/20. • Solar hot (from collector) connection: DN15 compression fitting. • Solar cold (to collector) connection: DN15 compression fitting. • Temperature Pressure Relief valve connection: RP½/15. •...
  • Page 27 CONNECTIONS – PLUMBING RELIEF VALVE The temperature pressure relief valve is shipped behind the lower front cover of the water heater. The temperature pressure relief valve must be fitted before the water heater is operated. Before fitting the relief valve, make sure the probe has not been bent. Seal the thread with Teflon tape - never hemp. Make sure the tape does not hang over the end of the thread.
  • Page 28 CONNECTIONS – PLUMBING SOLAR INLET AND OUTLET All pipe work must be cleared of foreign matter before connection and purged before attempting to operate the water heater. All olive compression fittings must use brass or copper olives. Use thread sealing tape or approved thread sealant on all fittings. The solar cold outlet and solar hot inlet connections are located at the top of the solar storage tank.

  • Page 29: Connections - Electrical

    CONNECTIONS – ELECTRICAL The power supply to the water heater must not be switched on until the solar storage tank is filled with water. MEGGER READING It is not mandatory to conduct a megger test on a plug in appliance, however if a megger test is conducted on this water heater, then the following should be noted.
  • Page 30 For reasons of safety and economy, we advise the thermostat of the in-series booster water heater be set at the lowest temperature that will provide sufficient hot water during periods when boosting is required. Solahart recommends the thermostat is set at 60°C to maximise solar contribution. Discuss the thermostat setting requirements with the householder.

  • Page 31: Auxiliary Pump

    AUXILIARY PUMP The solar collectors must be the highest point of the system. The maximum height of the solar installation from the base of the solar storage tank to the top of the solar collectors is 9 m. The pump supplied with the solar storage tank will not circulate closed circuit fluid through heights greater than 9 m and solar gain will not be achieved.
  • Page 32 AUXILIARY PUMP Auxiliary Pump Typical Installation...
  • Page 33 AUXILIARY PUMP AUXILIARY PUMP – ELECTRICAL CONNECTION The auxiliary pump, if installed, must be wired to the control board. The flexible cord supplied with the pump must be housed in a 20 mm flexible conduit. The flexible conduit should be secured to the insulated pipe work with the cable ties provided, to the side of the solar storage tank using the adhesive backed cable tie mounts and cable ties provided and to the penetration in the solar storage tank jacket using the cable gland provided.

  • Page 34: Commissioning

    COMMISSIONING TO FILL AND TURN ON THE WATER HEATER The power supply to the water heater must not be switched on until the solar storage tank is filled with water. To fill the solar storage tank with water and turn on the water heater: •...
  • Page 35 COMMISSIONING SOLAR CIRCUIT It is necessary to commission and check the operation of the solar circuit. The commissioning procedure includes: • checking the circulation of closed circuit fluid through the solar circuit. • checking the drain back function of the solar circuit. •...
  • Page 36 COMMISSIONING Warning: Although non-toxic, the following first aid advice and procedures should be followed if the closed circuit fluid concentrate comes into human contact or is spilt: • Swallowed - give milk or water and seek medical attention. • Eyes - wash with running water. •...
  • Page 37 COMMISSIONING Commissioning the Solar Circuit To commission and check the solar circuit: Switch off the electrical supply at the power outlet to the solar storage tank. If the pump has been operating, wait five minutes to allow the drain back of the closed circuit fluid in the solar circuit.
  • Page 38 COMMISSIONING Disconnect the drain line from the solar circuit relief valve at the top of the solar storage tank. Remove the spring clip from the solar circuit relief valve and remove the valve. Warning: The solar circuit may be under disconnect pressure.
  • Page 39 COMMISSIONING 11. Check the closed circuit fluid is circulating around the solar circuit. To check circulation: Listen for the trickling sound of the closed circuit fluid returning into the heat exchanger by placing your ear against the side toward the top of the solar storage tank. If the fluid is circulating around the solar circuit, a trickling sound will be heard as the fluid returns back into the heat exchanger.
  • Page 40 COMMISSIONING Drain Back Function 14. Switch off the electrical supply at the power outlet to the solar storage tank. The red LED on the solar monitor label will stop flashing. The pump will deactivate. The closed circuit fluid will drain back down to the heat exchanger and the level of the closed circuit fluid in the clear hose will rise.
  • Page 41 COMMISSIONING Closed Circuit Fluid Level 16. Measure the distance from the text marking “MINIMUM FLUID LEVEL WITH PUMP OPERATING” to the closed circuit fluid dynamic level marked on the side of the solar storage tank during step 12. The correct closed circuit fluid dynamic level for efficient operation of the system when the pump is operating is between the “MINIMUM FLUID LEVEL WITH PUMP OPERATING”...
  • Page 42 COMMISSIONING 17. Determine the correct amount of water to be added to or closed circuit fluid to be drained from the heat exchanger if the dynamic level is either below the text marking “MINIMUM FLUID LEVEL WITH PUMP OPERATING” or more than 150 mm above this mark. Each 100 mm of fluid level height is equivalent to three (3) litres of closed circuit fluid.
  • Page 43 COMMISSIONING 18. Add water to top up the level of the closed circuit fluid in the heat exchanger if required. To add water to the closed circuit fluid: If not already removed, disconnect the drain line and remove the spring clip from the solar circuit relief valve at the top of the solar storage tank and remove the valve (refer to step Warning: The solar circuit may be under pressure.
  • Page 44 COMMISSIONING Pressure Testing the Solar Circuit 21. Close the heat exchanger drain valve. heat exchanger 22. Refit the solar circuit relief valve, orientating the valve drain valve closed outlet to the rear of the solar storage tank. Secure with the spring clip. Reconnect the drain pipe to the valve.
  • Page 45 COMMISSIONING Remove Closed Circuit Fluid Level Hose 29. Remove the clear hose from the solar storage tank when satisfied the commissioning procedure is complete. To remove the hose: Ensure the heat exchanger drain valve is closed. heat exchanger Remove the hose from the side of the storage tank drain valve and place the end into a container to collect the closed...
  • Page 46 COMMISSIONING DIAGNOSTIC FEATURES OF THE SOLAR CONTROLLER The solar storage tank incorporates a solar monitor which is connected to the solar control module by a ribbon cable. The solar monitor is located on the lower front cover and houses both a green and a red LED.
  • Page 47 COMMISSIONING TO TURN OFF THE WATER HEATER If it is necessary to turn off the water heater on completion of the installation, such as on a building site or where the premises is vacant, then: • Switch off the electrical supply at the power outlet to the water heater. •...

  • Page 48: Draining The Water Heater

    DRAINING THE WATER HEATER Solar Storage Tank To drain the solar storage tank: • Turn off the water heater (refer to “To Turn Off The Water Heater” on page 47). • Close all hot water taps. • Operate the relief valve release lever - do not let the lever snap back or you will damage the valve seat.
  • Page 49 This page is intentionally blank...
  • Page 50 This page is intentionally blank...
  • Page 51 This page is intentionally blank...

  • Page 52: Water Supplies

    WATER SUPPLIES Your water heater is manufactured to suit the water conditions of most Australian metropolitan supplies. However, there are some known water supplies which can have detrimental effects on the water heater and its operation and/or life expectancy. If you are unsure of your water quality, you can obtain information from your local water supply authority.

  • Page 53: Warranty

    WARRANTY EXCLUSIONS 1. REPAIR AND REPLACEMENT WORK WILL BE CARRIED OUT AS SET OUT IN THE SOLAHART WATER HEATER WARRANTY, HOWEVER THE FOLLOWING EXCLUSIONS MAY CAUSE THE WATER HEATER WARRANTY TO BECOME VOID AND MAY INCUR A SERVICE CHARGE AND / OR COST OF PARTS.
  • Page 54 Receiver/Drier, Evaporator and associated pipe work. Solahart reserves the right to transfer fully functional components from the defective water heater to the replacement water heater if required. The term “water heater” used in the Warranty, Warranty Conditions and Warranty Exclusions means the Solahart supplied water heater(s), solar storage tank(s), solar collector(s), kit(s) and components.
  • Page 55 If a Solahart unit Tank Serial No Date of manufacture Collector Serial No’s Comments Installer Certification – I certify this installation has been installed and tested in accordance with Solahart Industries Pty Ltd specifications Signature: Installer Customer Date White Copy: Head Office...

  • Page 56: Solahart Offices

    + 31 492 579 694 Facsimile International: + 1 334 260 1514 Australia For SERVICE Telephone - 1800 638 011 For Sales Telephone - 1300 769 475 or your nearest Solahart Dealer or your nearest Solahart Dealer Revision Date: 2007 September 126538C...
