1. If you have already plugged your VCR, DVD
player, TV, and this receiver into the AC outlets,
unplug their AC power cords first.
2. Connect your VCR, DVD player, TV, and this
receiver as follows, using the cables with the
monaural mini-plugs (not supplied).
• See "CONNECTIONS 1" on the previous page.
3. Connect the audio input/output jacks on VCR,
DVD player, TV, and this receiver using the
cables with RCA pin plug.
• See pages 6 and 7.
4. Connect the video input/output jacks on VCR,
DVD player, TV, and this receiver, using the
cables with RCA pin plug or with
S-video plug.
• See "CONNECTIONS 2" on the previous page.
5. Plug the AC power cords of the components into
the AC outlets.
6. When turning on the TV for the first time after
the AV COMPU LINK connection, turn the TV
volume to the minimum using the TV volume
control on the TV.
7. Turn on the other connected components first,
then turn on this receiver.
• When turning on the VCR, use the remote control supplied
with this receiver (press VCR POWER).
The AV COMPU LINK remote control system allows you to use the
five basic functions listed below.
Remote Control of the TV, DVD player, and VCR
Using This Remote Control
See page 45 for details.
For the DVD player and the VCR:
• Aim the remote control directly at the remote sensor on each
component.
For the TV having AV COMPU LINK terminal "RECEIVER/
AMP":
• Aim the remote control directly at the remote sensor on the
receiver.
For the TV having AV COMPU LINK terminal "AV COMPU
LINK EX":
• Aim the remote control directly at the remote sensor on the TV.
One-Touch Video Play
Simply by inserting a video cassette without its safety tab into the
VCR, you can enjoy the video playback without setting other
switches manually. The receiver automatically turns on and changes
the source to "VCR."
The TV automatically turns on and changes the input mode to the
position so that you can view the playback picture.
When you insert a video cassette with its safety tab, press the play
(3 3 3 3 3 ) button on the VCR or on the remote control. So, you can get the
same result.
42
One-Touch DVD Play
Simply by starting playback on the DVD player, you can enjoy the
DVD playback without setting other switches manually.
• When the DVD player is connected through the analog input jacks
on this receiver (and analog input is selected), the receiver
automatically turns on and changes the source to "DVD" or
"DVD MULTI."
• When the DVD player is connected through the digital input
terminal on this receiver (and digital input is selected), the
receiver automatically turns on and changes the source to "DVD
DIGITAL."
The TV automatically turns on and changes the input mode to the
position so that you can view the playback picture.
Automatic Selection of TV's Input Mode
• When you select "TV SOUND" (or "TV DIGITAL") as the source
to play on the receiver, the TV automatically changes the input
mode to the TV tuner so that you can watch TV.
• When you select "DVD" (or "DVD DIGITAL"), "DVD MULTI,"
"VCR," or "DBS" (or "DBS DIGITAL") as the source to play on
the receiver, the TV automatically changes the input mode to the
appropriate position (either Video Input 1 or Video Input 2) so that
you can view the playback picture.
Note:
When you select "TV SOUND" (or "TV DIGITAL") as the source on the
receiver, you cannot see the menu on the TV screen since the AV
COMPU LINK remote control system automatically changes the TV's
input mode to the TV tuner.
If you do not mind stopping listening to the TV sounds, you can then
show the on-screen displays after changing the TV's input mode to
the appropriate position (either Video Input 1 or Video Input 2) the
receiver is connected to.
Automatic Power On/Off
The TV, VCR, and DVD player turn on and off along with the
receiver.
When you turn on the receiver;
• If the previously selected source is "VCR," the TV and VCR will
turn on automatically.
• If the previously selected source is "TV SOUND" (or "TV
DIGITAL") or "DBS" (or "DBS DIGITAL"), only the TV will
turn on automatically.
• If the previously selected source is "DVD" (or "DVD DIGITAL")
or "DVD MULTI," the TV and DVD player will turn on
automatically.
When you turn off the receiver, the TV, VCR and the DVD player
will turn off.
Note:
If you turn off the receiver while recording on the VCR, the VCR will
not turn off, but continue recording.
