Six 1U vertical mounting brackets in the rear post flanges, which can be used
for power distribution units, switches, or other 1U devices, as shown in
Figure 5-8.
Cable
openings
Figure 5-8 1U Power distribution unit mounted in 1U pocket on flange of rear post
M6 clip nuts
Chapter 5. Rack planning
129
