Figure 4-10 shows the storage tray attached to an nx360 M4.
Figure 4-10 IBM NeXtScale Storage Native Expansion Tray attached to an nx360 M4
compute node
Ordering information is listed in Table 4-16.
Table 4-16 IBM NeXtScale System Internal Storage tray
Part number
Feature code
00Y8546
A4GD
Figure 4-11 shows the IBM NeXtScale Storage Native Expansion Tray with the
cover removed showing seven 3.5-inch drives installed.
Figure 4-11 IBM NeXtScale Storage Native Expansion Tray
Description
IBM NeXtScale Storage Native Expansion Tray
Chapter 4. IBM NeXtScale nx360 M4 compute node
87
