Pro-Form PFEVEL75108.0 User Manual page 9

9. Orient the Transport Handle (116) as shown, and
attach it to the Upright (3) with four Transport
Handle Screws (97).
Identify the Left and Right Upright Covers (17, 110),
which are marked with "Left" and "Right" stickers.
Attach each Upright Cover (17, 110) to the Upright
(3) with two M4 x 16mm Round Head Screws (101).
10. Identify the Left Handlebar (8) and the Left Upper
Body Arm (11), which are marked with "Left" stickers.
Orient the Left Handlebar (8) and the Left Upper
Body Arm (11) as shown. Insert the Left Handlebar
into the Left Upper Body Arm. Attach the Left
Handlebar with two M8 x 41mm Button Bolts (78)
and two M8 Jamnuts (79). Make sure that the
Jamnuts are in the hexagonal holes.
Attach the Right Handlebar (9) to the Right Upper
Body Arm (12) in the same way.
9
116
97
17
101
10
8
Hexagonal
Holes
79
11
9
97
101
110
3
9
79
78
78
12
