Timer cleaning - 6
If 720 to 1,080 hours have elapsed
(All in sequence) since the previous Black/Color
cleaning till the start of the next
printing.
Timer cleaning - 7
If 1,080 to 2,160 hours have elapsed
(All in sequence) since the previous Black/Color
cleaning till the start of the next
printing.
If 2,160 to 4,320 hours have elapsed
Timer cleaning - 8
since the previous Black/Color
(All in sequence)
cleaning till the start of the next
printing.
Timer cleaning - 9
If 4,320 to 8,640 hours have elapsed
(All in sequence)
since the previous Black/Color
cleaning till the start of the next
printing.
Timer cleaning -
If 8,640 or longer hours have elapsed
10
since the previous Black/Color
(All in sequence)
cleaning till the start of the next
printing.
At print head
When the print head is removed and
replacement
installed.
(All in sequence)
At ink tank When an ink tank is replaced (without
*3
the print head removal or re-
replacement
installation)
(Black/Color/All in
sequence)
Manual cleaning - Via the operation panel (All at the
same time only)
(Black/Color/All at
the same time) - Via the printer driver (Selectable
from Black, Color, or All at the
same time)
Deep cleaning Via the printer driver (Selectable from
Black, Color, or All at the same time)
(Black/Color/All at
the same time)
If the print head
has not been
capped before
power-on
(All in sequence)
*1: When 24 to 60 hours have elapsed since the previous Black cleaning, timer cleaning - 0 is
performed. However, this cleaning will be conducted up to 5 times from the printer installation,
and no further timer cleaning - 0 will be performed.
*2: The period of time since the previous cleaning is counted by Black and Color separately. For
this reason, the cleaning mode may differ according to Black or Color.
*3: When only the black ink tank is replaced, Black cleaning is performed. One of the color ink
Download Service Manual And Resetter Printer at http://printer1.blogspot.com
1.27 (Black)
1.06 (Color)
1.95 (Black)
1.06 (Color)
1.95 (Black)
1.06 (Color)
0.57 (Black)
2.25 (Color)
0.38 (Black)
1.06 (Color)
0.20 (Black)
0.65 (Color)
1.95 (Black)
1.06 (Color)
0.38 (Black)
1.06 (Color)
2-3
80
85
90
90
90
100
80 (All in
sequence)
40 (Black)
65 (Color)
45 (All at the
same time)
35 (Black)
40 (Color)
90 (All at the
same time)
45 (Black)
65 (Color)
80 (All in
sequence)
