Note: At the end of the service mode, press the Power button. To protect the media sensor from being
dislocated during transportation, the paper lifting plate of the sheet feeder unit will be raised.
<Service mode operation procedures>
1) With the printer power turned off, while pressing the Resume/Cancel button, press and hold the
Power button. (DO NOT release the buttons. The Power LED lights in green to indicate that a
function is selectable.)
2) While holding the Power button, release the Resume/Cancel button. (DO NOT release the Power
button.)
3) While holding the Power button, press the Resume/Cancel button 2 times, and then release both the
Power and Resume/Cancel buttons. (Each time the Resume/Cancel button is pressed, the Alarm and
Power LEDs light alternately, Alarm in orange and Power in green, starting with Alarm LED.)
4) When the Power LED lights in green, press the Resume/Cancel button the specified number of time
(s) according to the function listed in the table below. (Each time the Resume/Cancel button is
pressed, the Alarm and Power LEDs light alternately, Alarm in orange and Power in green, starting
with Alarm LED.)
Time(s) LED indication
0 times Green (Power) Power off
1 time Orange (Alarm) Service test print
2 times Green (Power) EEPROM information
3 times Orange (Alarm) EEPROM initialization
4 times Green (Power) Waste ink counter
5 times Orange (Alarm) Destination settings
6 times Green (Power) Print head deep
7 times Orange (Alarm) LF correction
8 times Green (Power) CD / DVD check
9 times Orange (Alarm) CD / DVD print
10 times Green (Power) CD / DVD print
11 to 13 Orange, Green,
times Orange
(Alarm, Power,
Alarm)
14 times Green (Power) Left margin correction Not used in servicing.
Download Service Manual And Resetter Printer at http://printer1.blogspot.com
Function
When the print head is not installed, the
carriage returns and locks in the home
position capped.
See 3-4. Verification Items, (1) Service
test print.
See 3-4. Verification Items, (2) EEPROM
print information print.
resetting
After entering the destination settings
mode, press the Resume/Cancel button
the specified number of time(s) to select
the destination. For detail, see
"Destination settings procedures" below.
(Cleaning of both black and color)
cleaning
Not used in servicing.
pattern print
position correction
Not used in servicing.
(horizontal: X
direction)
position correction
Not used in servicing.
(vertical: Y direction)
Return to the menu
selection
1-26
Remarks
