Summary of Contents for Canon Pixma iP5200
-
Page 1: Table Of Contents
Printing with Macintosh Printing Photographs Directly from a PictBridge Compliant Device Connecting to a PictBridge Compliant Device Printing Photographs Directly from a PictBridge Compliant Device Printing Photographs Directly from a Canon Bubble Jet Direct Compatible Digital Camera Replacing an Ink Tank QA7-3504-V01... -
Page 2: Exif Print
® International ENERGY STAR Program ® As an ENERGY STAR Partner, Canon Inc. has determined that this product meets the ENERGY STAR guidelines for efficiency. ® The International ENERGY STAR Office Equipment Program is a global program that promotes energy saving through the use of computer and other office equipment. -
Page 3: Introduction
Introduction Thank you for purchasing a Canon Inkjet Printer. This Quick Start Guide uses the following symbols to indicate important information. Always observe the instructions indicated by these symbols. Instructions that, if ignored, could result in death or serious personal injury caused by incorrect operation of the equipment. -
Page 4: Installing The Print Head
Installing the Print Head • Never attempt to plug the power cord into the power outlet or unplug the power cord when your hands are wet. • Never damage, modify, stretch, or excessively bend or twist the power cord. Do not place heavy objects on the power cord. -
Page 5: Installing The Ink Tanks
Remove the Print Head from its package, then remove the orange protective cap from the Print Head. There might be some transparent or light blue ink on the inside of the bag the print head comes in, or the inside of the protective cap - this has no effect on print quality. - Page 6 Unpack the cyan ink tank. Pull the orange tape (A) completely off in the direction of the arrow and remove the clear film. Then, remove the film (B). Hold the ink tank as shown in the diagram and remove the orange protective cap protective cap located on the bottom of the ink tank.
-
Page 7: Loading Paper
Loading Paper This section describes how to load A4 (Letter) size plain paper in the Auto Sheet Feeder. When performing the print head alignment, you need to load paper in the Auto Sheet Feeder. • Always load paper in portrait orientation. Loading paper in landscape orientation can cause the paper to be jammed. -
Page 8: Installing The Printer Driver
Installing the Printer Driver Installing the Printer Driver – Windows • The screens below refer to Windows XP Service Pack 2 installation. Screens may differ depending on the operating system you are using. • When installing the printer driver in Windows XP or Windows 2000, log on to the system as a member of the Administrators group. -
Page 9: The Screen
Follow the instructions displayed on screen. When the screen shown on the left is displayed, click Easy Install. • When you select Easy Install, the items included in the CD-ROM are installed automatically. To select particular items to install, click Custom Install and follow the instruction on the screen. - Page 10 Restart. • To view the On-screen Manual, double-click the iP5200 On-screen Manual shortcut icon on the desktop, or click Start and select All Programs (or Programs), Canon iP5200 Manual and iP5200 On-screen Manual. ®...
-
Page 11: Installing The Printer Driver - Macintosh
® Installing the Printer Driver – Macintosh • Do not remove or insert the USB cable during installation, as this may result in the computer or printer not operating normally. • Before installing the driver, disable all anti-virus programs and automatically loading programs or remove them from your system folder. - Page 12 Add to add the printer. For details, refer to the Printer Setup Utility Help in the Mac Help. When using Mac OS X v.10.2, select your printer from the Name list and click Configure. Select your printer from the Product list and click Maintenance. Canon IJ Printer Utility appears.
- Page 13 • To view the On-screen Manual, double-click the iP5200 On-screen Manual alias on the desktop. • To install the User’s Guide in other language than the installed one, double-click the Manual folder in Setup Software & User’s Guide CD-ROM, Canon folder, and then copy a language folder to your hard disk.
-
Page 14: Basic Operations
• If you detect smoke, unusual smells or strange noises around the printer, immediately switch the printer off and always unplug the printer. Contact your local Canon service representative. • To avoid injury, never put your hand or fingers inside the printer while it is printing. -
Page 15: Printing With Macintosh
Printing with Macintosh From your application’s File menu, select Page Setup. Select your printer name from Format for. Select the paper size to be used. Click OK. From your application’s File menu, select Print. Select Quality & Media from the pop- up menu. -
Page 16: Printing Photographs Directly From A Pictbridge Compliant Device
• Canon Bubble Jet Direct allows you to print photos from a Canon Bubble Jet Direct compatible (PictBridge incompatible) digital camera or digital video camcorder without a computer by simply connecting the digital camera or digital video camcorder to this printer. - Page 17 * The power-on sequence may differ depending on the model or brand of the device. Either of the following icons will appear on the LCD display of the device when the printer is correctly connected. A PictBridge compliant device. A Canon Bubble Jet Direct compatible digital camera.
-
Page 18: Printing Photographs Directly From A Pictbridge Compliant
The settings explained on the following pages cannot be made on some devices. If any setting cannot be made, the default setting explained above is used. Names of settings that are displayed on Canon PictBridge compliant device are used in the description given below. - Page 19 This paper is exclusively used to print photo stickers. When printing on sticker paper, select 10 x 15 cm / 4" x 6" in Paper size. This size can be selected only for Canon PictBridge compliant devices (note that it cannot be selected for some models).
- Page 20 Checking or Changing PictBridge Print Settings From the Printer Connecting this printer to a computer and using the Canon Setup Utility enables you to change items such as the paper type, paper size, and the standard PictBridge print settings. For details,...
-
Page 21: Printing Photographs Directly From A Canon Bubble Jet Direct Compatible Digital Camera
Canon Bubble Jet Direct Compatible Digital Camera The following is a list of media types that can be set on a Canon Bubble Jet Direct compatible digital camera along with their limitations when connected to this printer. Media Types for Digital Camera... -
Page 22: Replacing An Ink Tank
Replacing an Ink Tank When the printer runs out of ink, replace the empty ink tank with a new one. Specify the following ink tanks when purchasing. Black : CLI-8BK Black : PGI-5BK Yellow : CLI-8Y Magenta : CLI-8M Cyan : CLI-8C If the Top Cover is opened more than ten minutes, the Print Head Holder moves to the right side. -
Page 23: Regulatory Information
Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you could be required to stop operation of the equipment. Canon U.S.A., Inc. One Canon Plaza... - Page 24 The following ink tanks are compatible with this printer. For details on ink tank replacement, refer to “Replacing an Ink Tank” in this guide. QA7-3504-V01 XXXXXXXX ©CANON INC.2005 PRINTED IN THAILAND...
