Related Manuals for EverFocus ENR 400

Summary of Contents for EverFocus ENR 400

  • Page 2: Safety Precautions

    This Product is RoHS compliant. Ihr EverFocus Produkt wurde entwickelt und Your EverFocus product is designed and manufactured hergestellt mit qualitativ hochwertigen Materialien with high quality materials and components which can und Komponenten, die recycelt und wieder be recycled and reused.

  • Page 3: Table Of Contents

    ENR 400 Installation Manual CONTENT INTRODUCTION ............................. 5 MAIN FEATURES ........................... 5 SPECIFICATIONS ..........................6 ..........................6 ECHNICAL DATA * ......................7 UPPORTED AMERA ODELS ............................8 IMENSIONS ..........................8 ELIVERY SCOPE ........................8 PTIONAL CCESSORIES HARDWARE INSTALLATION ........................ 9 ..................
  • Page 4 ENR 400 Installation Manual APPENDIX B: 3 GPP SETUP EXAMPLES ..................75 ENR ........................75 ONFIGURATION IN ......................76 ONFIGURATION OBILE HONE 7.2.1 BenQ-Siemens E81 ............................... 76 7.2.2 BenQ P50 ..................................78 APPENDIX C: INSTALLATION REMOTE DESKTOP TOOL ............... 81...

  • Page 5: Introduction

    ENR 400 Installation Manual 1 Introduction The NeVio ENR network video recorders are designed for recording and managing of IP video devices. Easy and intuitive operation, combined with intelligent search functions guarantee a fast an efficient evaluation of video records.

  • Page 6: Specifications

    ENR 400 Installation Manual 3 Specifications 3.1 Technical data Physical IP video channels 4 (expandable up to 32 with 7 x ENR U4) Recording / playback rate Up to 25 IPS / channel Total recording rate Up to 400 IPS in 4CIF resolution, up to 800 IPS in CIF resolution (depending on camera type / compression...

  • Page 7: Supported Camera Models

    ENR 400 Installation Manual 3.2 Supported Camera Models* Supported IP Cameras / Video server Status: Version 3.1.4.7 / October 20109 Manufacturer Supported Products EverFocus EAN800A*; EAN800AW*; EAN850A*; EAN900*; EDN800*; EDN850*; EZN850*; EVS100; EVS400; EAN750 ACTI SED 2100; SED 2120; SED 2140; SED 2310; SED 2320; SED 2400; SED 2420; SED 2600; SED 2610; SEM 1110; CAM 5130; CAM 5140;...

  • Page 8: Dimensions

    ENR 400 Installation Manual 3.3 Dimensions 3.4 Delivery scope  ENRxxx depending on ordered version  PC keyboard  PC mouse  DVI-VGA adaptor  CD-ROM with recovery software, remote software and documentation (software includes: Remote Live Client, Remote Playback Client, Database Maintenance Tool, Backup Software) ...

  • Page 9: Hardware Installation

    ENR 400 Installation Manual 4 Hardware installation 4.1 Front panel controls and connectors DVD-RW drive Firewire-connector (reserved) Audio out Microphone in Power switch 2 x USB 2.0 Power LED HDD Access LED Reset switch 4.2 Back panel connectors Power in socket 110/230 VAC...

  • Page 10: Status Led Gigabit Lan Port

    ENR 400 Installation Manual 4.3 Status LED Gigabit LAN port The LAN RJ45 socked has 2 integrated LED for status of the LAN connectivity: 4.4 System connections The ENR series is designed for network recording in Local Area Network (LAN).

  • Page 11: System Setup

    ENR 400 Installation Manual 5 System Setup 5.1 First Time System Start With factory default user settings the ENR will boot automatically and starts the ENR software application without requiring Windows Login and Application login. Switch on the backside power switch and push the front power switch to start the ENR.

  • Page 12: Quick Start Setup

    ENR 400 Installation Manual 5.3 Quick Start Setup This chapter describes the minimum installation steps to install IP-cameras for standard (continuous) recording. Note: Precondition for this quick start setup is that all IP cameras of the system are installed in the same network and IP address range as the ENR.
  • Page 13 ENR 400 Installation Manual +Search: Express setup for camera types supporting UPnP. (EverFocus Nevio IP camera series support UPnP). +Insert: Manual input of camera data for camera types, not supporting UPnP. Camera setup with SEARCH function Click on +SEARCH to install cameras with UPnP support, a list with all available cameras appears: Select a camera for installing and activate the checkbox at left side: Enter user name and password for this camera and if applicable the camera name.
  • Page 14 ENR 400 Installation Manual After setting the desired cameras confirm with OK to take over these cameras in the ENR camera list: Manual IP camera setup Alternative to the search function it is possible to setup cameras including IP settings manually. Click the button +INSERT to open the setup window: Enter IP parameter and user name / password.
  • Page 15 ENR 400 Installation Manual For changing frame rate and recording image quality select a camera from the list and press CAMERA SETTINGS button: The window shows current camera settings. Possible values depend on camera type. Change the setting to the recording system requirements and confirm with OK.
  • Page 16 ENR 400 Installation Manual On lower right side of camera setup screen are additional settings for On Screen Display overlay display: OSD on/off OSD of date / date adjustment OSD of time / time adjustment OSD camera number OSD camera name...
  • Page 17 ENR 400 Installation Manual If recording shall start automatically after application start, activate the checkbox SCHEDULE RECORDING SYSTEM under START-UP. Confirm all settings with OK. With these basic settings the ENR is configured already for continuous recording. For more detailed settings including schedule and event management refer to the following chapters DETAILED SETUP.

  • Page 18: Detailed Setup

    ENR 400 Installation Manual 5.4 Detailed Setup Following chapters describe the setup options of the ENR in all details. 5.4.1 Setting - General open with > CONFIG > SETTING This menu defines general parameters, display and start-up behaviour of the ENR.
  • Page 19 ENR 400 Installation Manual Live streaming server: with activated checkbox the steaming server for live view will be activated at ENR start Remote playback server: with activated checkbox the steaming server for playback view will be activated at ENR start...

  • Page 20: Setting - Camera

    ENR 400 Installation Manual Status Display - Display options for global status display (right side of main screen) Display options, displayed with activated checkbox  Current time  Current date  Free disk space (total for all recording drives)  IP camera bitrate (summarised input stream) ...
  • Page 21 After selecting the tab CAMERA the screen shows camera setup with an empty camera list. The camera setup supports 2 methods to install cameras: +Search: Express setup for camera types, which support UPnP. (EverFocus Nevio IP camera series support UPnP).
  • Page 22 Select a camera for installing and activate the checkbox at left side: Enter user name and password for this camera and if applicable the camera name. Default user name and password for EverFocus NEVIO cameras is: user name (admin level):...
  • Page 23 ENR 400 Installation Manual Manual IP camera setup Alternative to the search function it is possible to setup cameras including IP settings manually. Click the button +INSERT to open the setup window: Enter IP parameter and user name / password.
  • Page 24 ENR 400 Installation Manual For changing frame rate and recording image quality select a camera from the list and press CAMERA SETTINGS button: The window shows current camera settings. Possible values depend on camera type. Change the setting to the recording system requirements and confirm with OK.
  • Page 25 ENR 400 Installation Manual On lower right side of camera setup screen are additional settings for On Screen Display overlay display: OSD on/off OSD of date / date adjustment OSD of time / time adjustment OSD camera number OSD camera name...

  • Page 26: Setting - I/O Device

    ENR 400 Installation Manual 5.4.3 Setting - I/O Device This menu defines parameters for digital inputs and outputs of connected IP devices. The functionality depends on connected IP - devices. Device name List of available devices Input / Output list...

  • Page 27: Setting - Ptz - Config

    ENR 400 Installation Manual 5.4.4 Setting - PTZ - Config Camera list Communication settings PTZ parameter Tour settings Preset settings Camera list Available cameras in the system. Select one and activate checkbox for editing PTZ functions. Basic settings Select the device type from the drop-down menu.

  • Page 28: Setting - Hotline (Communication Settings)

    ENR 400 Installation Manual 5.4.5 Setting - Hotline (communication settings) This menu provides communication settings for mail, FTP, modem and phone. These settings are mandatory for several alarm reactions in GUARD mode (Send Snapshot to FTP, Phone call, Send SMS, Send e-mail).

  • Page 29: Setting - User Account

    ENR 400 Installation Manual 5.4.6 Setting - User Account The ENR recorders provide user right management with free assignable user rights for each user. In factory setting 1 user with administrator rights is pre-defined: user name: admin no password For user setup are 2 groups of user rights defined:...

  • Page 30: Setting - Address Book

    ENR 400 Installation Manual 5.4.7 Setting - Address book Contact person settings are required for GUARD mode event reactions "Phone call", "Send SMS" and "Send mail". Enter the required data. Already defined contact persons are listed in lower part of the window.

  • Page 31: Setting - Joystick

    ENR 400 Installation Manual Run Playback on Monitor Selection of monitor output 1 or 2 for playback window Primary / Secondary Use the arrow buttons in the middle to add / remove cameras from the list of selected monitor. Removed cameras will not be displayed at this monitor.
  • Page 32 ENR 400 Installation Manual Selectable options for key assignment of the Joystick are: 32 of 81 ENR400_ma_inst_en_rev01...

  • Page 33: Guard - Live Event / Event Action Configuration

    ENR 400 Installation Manual 5.5 GUARD - live event / event action configuration The GUARD mode allows live monitoring with automatic event reactions, triggered by intelligent video analytics functions. For the settings click on GUARD in Main screen: The menu screen shows all installed systems in the left side list, which can be used as event source.

  • Page 34: Event Types

    ENR 400 Installation Manual 5.5.1 Event types Depending on the device you will get a choice of available event types: For cameras: For input contacts: 34 of 81 ENR400_ma_inst_en_rev01...
  • Page 35 ENR 400 Installation Manual For system events: The setup options for the event types are described in following chapters 35 of 81 ENR400_ma_inst_en_rev01...
  • Page 36 ENR 400 Installation Manual 5.5.1.1 Signal lost event Indicates signal loss from this camera. Options: Life Cycle Definition, how long the message is shown Activated Period Permanent (Always Activated) or scheduled function (daily time period) 36 of 81 ENR400_ma_inst_en_rev01...
  • Page 37 ENR 400 Installation Manual 5.5.1.2 General motion event The GENERAL MOTION event allows motion detection in free definable square detection areas. ADVANCED For defining a detection area draw a window by mouse in the video window. Confirm setting with "REGION1".
  • Page 38 ENR 400 Installation Manual Sensitivity Sensitivity of motion detection, moving slider to right increases sensitivity, moving to left decreases sensitivity. Interval Filter function for motion detection. If slider is moved to right, a longer movement period is needed to trigger alarm Start / Stop With START SIMULATION you can test, if current settings are correct.
  • Page 39 ENR 400 Installation Manual 5.5.1.3 Foreign object event This event type creates an event if an unexpected object appears in a defined zone. Define detection zone Draw the detection zone by mouse in the video window and confirm wit "REGION1". You can also add and subtract areas, as described in detail under "GENERAL MOTION".
  • Page 40 ENR 400 Installation Manual Sensitivity Sensitivity of detection, moving slider to right increases sensitivity, moving to left decreases sensitivity. Interval Filter function for detection. If slider is moved to right, a longer period of object appearing in detection zone is needed to trigger alarm.
  • Page 41 ENR 400 Installation Manual Define detection zone Draw the detection zone by mouse in the video window and confirm wit "REGION1". You can also add and subtract areas, as described in detail under "GENERAL MOTION". Sensitivity Sensitivity of detection, moving slider to right increases sensitivity, moving to left decreases sensitivity.
  • Page 42 ENR 400 Installation Manual Start / Stop Simulation With START SIMULATION you can test, if current settings are correct. Detected movements are displayed in yellow, below the video window appears "Event detected". End the simulation mode with "STOP SIMULATION". BASIC...
  • Page 43 ENR 400 Installation Manual 5.5.1.5 Camera occlusion event Sensitivity Sensitivity of detection, moving slider to right increases sensitivity, moving to left decreases sensitivity. Interval Filter function for detection. If slider is moved to right, a longer period of camera occlusion is needed to trigger alarm.
  • Page 44 ENR 400 Installation Manual BASIC Options: Life Cycle Definition, how long the message is shown Activated Period Permanent (Always Activated) or scheduled function (daily time period) 44 of 81 ENR400_ma_inst_en_rev01...
  • Page 45 ENR 400 Installation Manual 5.5.1.6 Focus lost event Sensitivity Sensitivity of detection, moving slider to right increases sensitivity, moving to left decreases sensitivity. Interval Filter function for detection. If slider is moved to right, a longer period of unfocussed camera is needed to trigger alarm.

  • Page 46: Event Actions

    ENR 400 Installation Manual BASIC Options: Life Cycle Definition, how long the message is shown Activated Period Permanent (Always Activated) or scheduled function (daily time period) 5.5.2 Event actions Each defined event can be assigned to one ore more event actions.
  • Page 47 ENR 400 Installation Manual Available event actions are: The event actions are described in following chapters. 5.5.2.1 Event action: Play sound After selecting PLAY SOUND as event action and double click opens a window for selecting the sound file. Select a file and confirm with OPEN.
  • Page 48 ENR 400 Installation Manual 5.5.2.2 Event action: Send E-mail After selecting SEND E-MAIL as event action and double click opens a window with a list of available contact persons (setup in > CONFIG > SETTING > ADDRESS BOOK required): Select a contact for E-Mail notification and confirm with OK.
  • Page 49 ENR 400 Installation Manual 5.5.2.4 Event action: PTZ preset go This event requires PTZ cameras with preset function in the system. After selecting PTZ PRESET GO as event action and double click opens a window for selecting the PTZ camera, preset position and event related parameters.
  • Page 50 ENR 400 Installation Manual 5.5.2.5 Event action: Signal digital output This event action allows to switch a contact output of an installed IP-device. After selecting SIGNAL DIGITAL OUTPUT as event action and double click opens a window with all available digital output contacts in the system: Activated the checkbox at desired contact output and confirm with OK.
  • Page 51 ENR 400 Installation Manual 5.5.2.7 Event action: send top central server Reserved for future functions 5.5.2.8 Event action: Send snapshot to FTP In case of an event the system will send a snapshot to the defined FTP server. This event action requires FTP-server setup under >CONFIG > SETTING > HOTLINE > FTP.

  • Page 52: Schedule Setup

    ENR 400 Installation Manual Schedule setup The ENR allows continuous, scheduled or event controled recording. The recording behaviour is defined in the SCHEDULE menu. Open the SCHEDULE menu from MAIN console: In factory setting the system will record all cameras in continuous mode.

  • Page 53: Setup New Schedule Manually

    ENR 400 Installation Manual 5.6.1 Setup new schedule manually Step 1 Step 2 Step 3 Step 4 Step 1 Left-click and draw the bar to the time table. The scheduled time will appear as a grey bar. Step 2 Click the Insert icon and add a new schedule in the Regular Mode, i.e. to record video during the time period you set with 30 FPS, Normal video quality, and Normal resolution.

  • Page 54: Copy Schedule

    ENR 400 Installation Manual 5.6.2 Copy Schedule You may set up the schedule for each channel/camera by repeating the process above, or simply apply the setting of a single camera to all the others. Copy To 5.6.3 3.5 Week Mode Schedule the cameras for each day of the week differently.
  • Page 55 ENR 400 Installation Manual Adjust the Scheduled Setting: You can manually change the setting at any time after you insert or load a period of schedule. Option 1: Move the cursor to the Time Bar and change the length or move the bar sideway to change the start and end points.

  • Page 56: Conigure - Encoding Option Panel

    ENR 400 Installation Manual 5.6.4 Conigure - Encoding Option Panel Select Event Panel Always Record Record on Event Record on Motion Pre-record/ Post-record Always Record Select this option to record the video at all time. Record on Event Select this option to obtain the Select Event panel. From the Smart Guard list, check the box of the camera(s) that you want to trigger the recording action.

  • Page 57: E-Map

    ENR 400 Installation Manual E-Map The ENR series provides an e-map function, which allows to show location of installed IP - Devices on maps or other graphics. In GUARD mode the map can popup automatically in case of an event and show the event location including preview of the event camera.
  • Page 58 ENR 400 Installation Manual For placing a camera or contact on the map drag an item from device list and drop on the map at desired location. After finalising the layout finish the edit mode by clicking on OPERATE MODE.

  • Page 59: Counting Application

    ENR 400 Installation Manual 5.8 COUNTING APPLICATION The integrated Counting Application allows to count the number of persons, cars or other objects in one or both directions. The counting results can be shown in the camera live view. For evaluation of counting results the ENR provides a log with diagrams for definable time periods.
  • Page 60 ENR 400 Installation Manual Define Object Size Define the estimated object size by drawing in the video window. If necessary, the object size has to be adjusted again after running simulation (in case of no safe detection). Options 1 Way Counting: Application will count movements from REGION 1 to REGION 2 only.

  • Page 61: Network Services

    ENR 400 Installation Manual 5.9 Network Services For remote access to the ENR system are Server - functionalities required. The functions are managed and defined under NETWORK SERVICE. For setup go to > CONFIG > NETWORK SERVICE. 5.9.1 Network service: Live Streaming This service allows connections from other client PCs to the ENR by "REMOTE LIVE VIEWER"...
  • Page 62 ENR 400 Installation Manual Service Start / Stop By clicking on START the server function for live view is enabled. Clicking on STOP disables the service Kill Client Stops remote connection to selected connection from the list Kill All Clients...
  • Page 63 ENR 400 Installation Manual Black / White List Remote live access to ENR can be filtered by a White List (selected IPs can access) or a Black List (selected IPs are blocked for access). White List Check the “Enable White List” box to activate the white list filter. Only IP from the white list is allowed to log in.

  • Page 64: Network Service: Remote Playback

    ENR 400 Installation Manual Performance This tab shows current network streaming performance for total system and for selected live connection. Total bit rate Individual Camera bit rate 5.9.2 Network Service: Remote Playback Live Streaming Server log information 64 of 81...

  • Page 65: Network Service: Remote Playback

    ENR 400 Installation Manual 5.9.3 Network Service: Remote Playback When starting the remote playback function of your computer, you allow remote users to log on to the specific computer and withdraw data files that are stored on it. As system administrator, you are able to monitor the accounts that log on in order to maintain the system efficiency.
  • Page 66 ENR 400 Installation Manual Black / White List Remote live access to ENR can be filtered by a White List (selected IPs can access) or a Black List (selected IPs are blocked for access). White List Check the “Enable White List” box to activate the white list filter. Only IP from the white list is allowed to log in.

  • Page 67: Network Service: Remote Playback

    ENR 400 Installation Manual Performance This tab shows current network streaming performance for total system and for selected live connection. Total bit rate Individual Camera bit rate 5.9.4 Network Service: Remote Playback Plaback Streaming Server log information 67 of 81...

  • Page 68: Network Service: 3Gpp Service

    ENR 400 Installation Manual 5.9.5 Network Service: 3GPP Service When starting the 3GPP service function of your computer, you allow remote users to log on the 3GPP supported mobile phone and view cameras that are connected to it. See Appendix B for more details about 3GPP Service.

  • Page 69: Network Service: Remote Desktop

    ENR 400 Installation Manual 5.9.6 Network Service: Remote Desktop When starting the Remote Desktop option of your computer, you allow remote users to use Remote Desktop Tool to login and configuration system. See Appendix C to install and use this tool.

  • Page 70: Appendix A: Db Tool

    ENR 400 Installation Manual 6 Appendix A: DB TOOL The DB Tool Repair database files and Export configurations. NOTE : improper use of this DB Tool may cause lose of the recorded video data. Step 1: Execute DB Tool from program files.

  • Page 71: Repair Database

    ENR 400 Installation Manual 6.1 Repair Database This page has three repair method, Modify Location, Verify Only, and Repair. For modify location propose: Playback system can recognize all recording video in the folders which list on Main Console > Config >...
  • Page 72 ENR 400 Installation Manual Example of database modification: In certain case that when video data needs to be transfer from old PC to another new PC, user will need to perform the following procedure. 1. Manually copy all recorded video data from the default installation path or other user-defined storage path of the old PC.
  • Page 73 ENR 400 Installation Manual Step 4: Choose the method of “Verify Only”, and click “verify”. This method will only check the files without modify. Verify result will show how many files broken or missing. Step 5: Choose the method of “Repair(Complete)”, and click “Repair” to repair. The Repair Result will show how many files are fixed and inserted.

  • Page 74: E Xport C Onfigurations

    ENR 400 Installation Manual 6.2 Export Configurations This tool allows to export the complete configuration to a file. Step 1: Press “Export”. Step 2: Select the location you want to Export and type the name of the configurations. Step 3: Press “Save” to start to import database.

  • Page 75: Appendix B: 3 Gpp Setup Examples

    ENR 400 Installation Manual 7 Appendix B: 3 GPP setup examples How to setup 3GPP streaming connection (using BenQ-Siemens mobile phones) 7.1 Configuration in ENR Step 1 : Go to Config and select Network Service 75 of 81 ENR400_ma_inst_en_rev01...

  • Page 76: Configuration Mobile Phone

    ENR 400 Installation Manual Step 2 : Select 3GPP Service, and then click Start Note: In the Option item, the port selected here is the same port from mobile handset 7.2 Configuration Mobile Phone 7.2.1 BenQ-Siemens E81 Step 1: Goto Menu, then Internet...
  • Page 77 ENR 400 Installation Manual Step 2: Select Bookmarks Step 3: Add New Bookmark Step 4: Configure the Address setting as the following example. Ex: rtsp://61.216.97.69:554/media00.3gp 61.216.97.69:554 is the IP address of ENR system Port : port specified in 3GPP Service in ENR system...

  • Page 78: Benq P50

    ENR 400 Installation Manual 7.2.2 BenQ P50 1. Connect GPRS 2. Download and install the [PLATFORM4] software. 3. Execute Main Console. 4. Press the [Config][Network Service][Start] 78 of 81 ENR400_ma_inst_en_rev01...
  • Page 79 ENR 400 Installation Manual 5. Open [PLATFORM4], press the button framed by red into Option 6. [Open Url] enter the rtsp address of the camera (EX: rtsp://61.216.97.69/media00.3gpchannel 1 EX: rtsp://61.216.97.69/media01.3gpchannel 2 EX: rtsp://61.216.97.69/media02.3gpchannel 3) 79 of 81 ENR400_ma_inst_en_rev01...
  • Page 80 ENR 400 Installation Manual 7. [Setting I]change the setting and press “OK” [Protocol] [Buffer Size] [Connection TimeOut] [Data Recept. TimeOut] [Deblocking Filter] check 8. Go back to PLATFORM4, searching and then getting the video 80 of 81 ENR400_ma_inst_en_rev01...

  • Page 81: Appendix C: Installation Remote Desktop Tool

    ENR 400 Installation Manual 8 Appendix C: Installation Remote Desktop Tool Installation Step 1: Insert the Installation CD. Step 2: Please go to RemoteDesktopViewer directly and Run Setup.exe file. Start Remote Desktop Tool Step 1: Please point to Start > All Programes > NUUO Remote Desktop Viewer > Remote Desktop Viewer.
