[LOGIC BOARD]

REF ORDER
NO. NO.
C2020 4510004600 ELECTROLYTIC
C2021 4030004740 S.CERAMIC
C2022 4510007480 ELECTROLYTIC
C2023 4030008960 S.CERAMIC
C2024 4510005120 ELECTROLYTIC
C2025 4510004990 ELECTROLYTIC
C2026 4510005120 ELECTROLYTIC
C2027 4030004740 S.CERAMIC
C2028 4510008400 ELECTROLYTIC
C2029 4510008400 ELECTROLYTIC
C2030 4030004740 S.CERAMIC
C2031 4510005490 ELECTROLYTIC
C2032 4510005480 ELECTROLYTIC
C2033 4510005480 ELECTROLYTIC
C2034 4510008410 ELECTROLYTIC
C2035 4510008410 ELECTROLYTIC
C2036 4510005120 ELECTROLYTIC
C2037 4510008410 ELECTROLYTIC
C2038 4510005500 ELECTROLYTIC
C2039 4030004740 S.CERAMIC
C2040 4510005120 ELECTROLYTIC
C2041 4030004740 S.CERAMIC
C2042 4510005120 ELECTROLYTIC
C2043 4030004740 S.CERAMIC
C2044 4510005500 ELECTROLYTIC
C2049 4030008960 S.CERAMIC
C2050 4030008960 S.CERAMIC
C2051 4510008400 ELECTROLYTIC
C2052 4030004740 S.CERAMIC
C2053 4030004740 S.CERAMIC
C2054 4510005120 ELECTROLYTIC
C2060 4310000480 MYLAR
RL2001 6330001330 RELAY
J2007 6510003390 CONNECTOR
J2008 6510018381 CONNECTOR
J2009 6510018391 CONNECTOR
J2010 6510018391 CONNECTOR
J2011 6510018391 CONNECTOR
J2012 6510018391 CONNECTOR
J2013 6510010020 CONNECTOR
J2014 6510010020 CONNECTOR
J2016 6510003400 CONNECTOR
DS2001 5080000305 LAMP
DS2002 5080000305 LAMP
DS2003 5080000305 LAMP
DS2004 5010000180 LCD
DS2005 5080000150 LAMP
S2003 2260002230 SWITCH
S2004 2260002230 SWITCH
S2005 2260002230 SWITCH
S2006 2260002230 SWITCH
S2007 2260002230 SWITCH
S2008 2260002230 SWITCH
S2009 2260002230 SWITCH
S2010 2260002230 SWITCH
S2011 2260002230 SWITCH
S2012 2260002230 SWITCH
S2013 2260002230 SWITCH
S2014 2260002230 SWITCH
S2015 2260002230 SWITCH
S2016 2260002230 SWITCH
S2017 2260002230 SWITCH
S2018 2260002230 SWITCH
S2019 2260002230 SWITCH
S2020 2260002230 SWITCH
S2021 2260002230 SWITCH
S2022 2260002230 SWITCH
S2023 2260002230 SWITCH
S2024 2260002230 SWITCH
S2025 2260002230 SWITCH
S2026 2260002230 SWITCH
S2027 2260002230 SWITCH
W2012 7030000010 S.RESISTOR
W2013 7030000010 S.RESISTOR
[GEN]: [GEN-21], [GEN-22], [GEN-23]
[GMDSS]: [GEN-23], [EUR-22]
DESCRIPTION
16 MV 1000 HC
C2012 JB 1H 472K-T
16 MV 470 CA
C2012 JB 1C 104K-T
16 MV 47 HC
16 MV 100 HC
16 MV 47 HC
C2012 JB 1H 472K-T
25 MV 22 HC
25 MV 22 HC
C2012 JB 1H 472K-T
50 MV 2R2 HC
50 MV 1 HC
50 MV 1 HC
25 MV 4R7 HC
25 MV 4R7 HC
16 MV 47 HC
25 MV 4R7 HC
16 MV 10 HC
C2012 JB 1H 472K-T
16 MV 47 HC
C2012 JB 1H 472K-T
16 MV 47 HC
C2012 JB 1H 472K-T
16 MV 10 HC
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
25 MV 22 HC [GMDSS]
C2012 JB 1H 472K-T [GMDSS]
C2012 JB 1H 472K-T [GMDSS]
16 MV 47 HC [GMDSS]
50 F2D 104J [Others]
AG 201344
B03B-EH-S
10FE-BT-VK-N
06FE-BT-VK-N
06FE-BT-VK-N
06FE-BT-VK-N
06FE-BT-VK-N
RTB-1.5-2F
RTB-1.5-2F
B04B-EH-S [GMDSS]
HRT-3290A-F
HRT-3290A-F
HRT-3290A-F
DLC-7978P
HRS-7219A [GMDSS]
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
SW-158 (SKHHPM)
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
[EUR]: [EUR-21], [EUR-22]
[Others]: [GEN-21], [GEN-22], [EUR-21]
[LOGIC BOARD]
REF ORDER
NO. NO.
W2014 7030000010 S.RESISTOR
W2015 7030000010 S.RESISTOR
W2018 7030000010 S.RESISTOR
W2019 7030000010 S.RESISTOR
WS1 8600034540 M.OTHER
WS2 8600034550 M.OTHER
WS3 8600036420 M.OTHER
8970023230 M.OTHER
EP2001 0910045067 PCB
[SENSOR1 BOARD]
REF ORDER
NO. NO.
J2601 6510018391 CONNECTOR
S2601 2250000020 ENCODER
EP2601 0910044811 PCB
[SENSOR2 BOARD]
REF ORDER
NO. NO.
J2701 6510018391 CONNECTOR
S2701 2250000020 ENCODER
EP2701 0910044811 PCB
[MAIN UNIT]
REF ORDER
NO. NO.
IC4 1160000130 S.IC
IC5 1160000130 S.IC
IC6 1160000130 S.IC
IC8 1110003140 IC
IC9 1110004840 S.IC
IC10 1110004840 S.IC
IC11 1130011190 S.IC
IC12 1140003830 S.IC
IC16 1110000960 S.IC
IC17 1110000960 S.IC
IC18 1110000960 S.IC
IC19 1110000960 S.IC
IC20 1110000960 S.IC
IC21 1110000960 S.IC
IC22 1130011170 S.IC
IC23 1110001400 S.IC
IC24 1180001250 S.IC
IC27 1170000280 S.IC
IC31 1130008630 S.IC
IC32 1130003760 S.IC
IC33 1130003760 S.IC
IC34 1130011200 S.IC
IC35 1130008650 S.IC
IC36 1110003300 S.IC
5 - 2
DESCRIPTION
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
[GMDSS]
SX1632 P2002*J2002L0
SX1632 P2003*J2003L0
SX1632 P2004L0 [GMDSS]
SX1632 LEAD SET [Others]
B 4252G
DESCRIPTION
06FE-BT-VK-N
SRB18100 25KC
B 4366A
DESCRIPTION
06FE-BT-VK-N
SRB18100 25KC
B 4366A
DESCRIPTION
TD62783AF (S,EL)
TD62783AF (S,EL)
TD62783AF (S,EL)
LA1150N
NJM1496V-TE1
NJM1496V-TE1
BU4011BF-E2
TC4W66F (TE12L)
NJM4558M-TE1
NJM4558M-TE1
NJM4558M-TE1
NJM4558M-TE1
NJM4558M-TE1
NJM4558M-TE1
BU4001BF-E2
µPC1555G2-T1
TA7808F (TE16L)
TLP121 (GB-TPL)
MC14028BF-EL
TC4S81F (TE85R)
TC4S81F (TE85R)
BU4069UBF-E2
MC14071BF-EL
M5282FP 70CD
S.=Surface mount
