Parts List; S-Logic Board - Icom IC-7400 Service Manual

SECTION 6
[FRONT UNIT]
REF ORDER
NO. NO.
W19 8900009270 CABLE
W20 8900009310 CABLE
W21 8900009270 CABLE
W22 8900009270 CABLE
W24 8900009230 CABLE
W25 8900009660 CABLE
W26 8900009230 CABLE
W27 8900009230 CABLE
EP1 0880000950 UNIT BOARD
EP2 6450001230 E.OTHER
EP3 6450001230 E.OTHER

[S-LOGIC BOARD]

REF ORDER
NO. NO.
IC101 1130008650 S.IC
IC102 1130002660 S.IC
IC401 1110004200 S.IC
IC571 1130004170 S.IC
Q301 1530002060 S.TRANSISTOR
Q302 1520000650 S.TRANSISTOR
Q303 1530003300 S.TRANSISTOR
Q304 1530003300 S.TRANSISTOR
D301 1730000590 S.ZENER
D402 1790001470 S.DIODE
D573 1750000370 S.DIODE
L301 6180000990 COIL
L302 6190001190 S.COIL
L303 6190001180 S.COIL
L401 6190001200 S.COIL
L402 6190001210 S.COIL
L403 6190001200 S.COIL
L601 6200007030 S.COIL
R1 7210002890 VARIABLE
R2 7030003440 S.RESISTOR
R3 7030003440 S.RESISTOR
R4 7210002890 VARIABLE
R5 7030003440 S.RESISTOR
R6 7030003440 S.RESISTOR
R7 7210002630 VARIABLE
R8 7030003440 S.RESISTOR
R9 7210002630 VARIABLE
R10 7030003440 S.RESISTOR
R11 7210002630 VARIABLE
R12 7030003440 S.RESISTOR
R13 7210002630 VARIABLE
R14 7030003440 S.RESISTOR
R15 7030003540 S.RESISTOR
R16 7030003480 S.RESISTOR
R17 7030003520 S.RESISTOR
R18 7030003580 S.RESISTOR
R101 7030003680 S.RESISTOR
R102 7030003720 S.RESISTOR
R103 7030003680 S.RESISTOR
R104 7030003800 S.RESISTOR
R105 7030003680 S.RESISTOR
R106 7030003720 S.RESISTOR
R107 7030003680 S.RESISTOR
R108 7030003800 S.RESISTOR
R111 7030003580 S.RESISTOR
R112 7030003640 S.RESISTOR

PARTS LIST

DESCRIPTION
OPC-912 (P=1 N=22 L=70)
OPC-916 (P=1 N=22 L=120)
OPC-912 (P=1 N=22 L=70)
OPC-912 (P=1 N=22 L=70)
OPC-908 (P=1 N=10 L=60)
OPC-964 (P=1 N=10 L=60)
OPC-908 (P=1 N=10 L=60)
OPC-908 (P=1 N=10 L=60)
EX-2500 #01 (SENSOR UNIT)
HLJ0999-01-480
HLJ0999-01-480
DESCRIPTION
MC14071BF-EL
µPD4030BG-T1
NJM2360M-TE3
TC4S01F (TE85R)
2SC4081 T107 R
2SB1201-S-TL
2SC3647S-TD
2SC3647S-TD
RD3.0M-T2B2
SB10-05PCP-TD
DA221 TL
LAL 04NA 101K
D10F-A814AY-101K=P3
BLC13H-D818HN-1107
D10F-A814AY-681K=P3
D10F-A814AY-221K=P3
D10F-A814AY-681K=P3
SLF7032T-101MR45-2
RV-308 (RK1612210 10KB/10KB)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
RV-308 (RK1612210 10KB/10KB)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
EVU-FLAE02 B14 (10KB)
ERJ3GEYJ 102 V (1 kΩ)
EVU-FLAE02 B14 (10KB)
ERJ3GEYJ 102 V (1 kΩ)
EVU-FLAE02 B14 (10KB)
ERJ3GEYJ 102 V (1 kΩ)
EVU-FLAE02 B14 (10KB)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
[S-LOGIC BOARD]
REF ORDER
NO. NO.
R113 7030003580 S.RESISTOR
R301 7030003540 S.RESISTOR
R302 7030003620 S.RESISTOR
R303 7030000300 S.RESISTOR
R304 7030003500 S.RESISTOR
R305 7030003500 S.RESISTOR
R306 7510000731 S.THERMISTOR
R401 7030004050 S.RESISTOR
R402 7030004050 S.RESISTOR
R403 7030006091 S.RESISTOR
R404 7030006461 S.RESISTOR
R571 7030003600 S.RESISTOR
R576 7030003680 S.RESISTOR
C1 4030006880 S.CERAMIC
C2 4030006880 S.CERAMIC
C3 4030006880 S.CERAMIC
C4 4030006880 S.CERAMIC
C5 4030006880 S.CERAMIC
C6 4030006880 S.CERAMIC
C7 4030006880 S.CERAMIC
C8 4030006880 S.CERAMIC
C9 4030011600 S.CERAMIC
C101 4030006860 S.CERAMIC
C102 4030006860 S.CERAMIC
C111 4030011600 S.CERAMIC
C112 4030006860 S.CERAMIC
C113 4030006860 S.CERAMIC
C114 4030006860 S.CERAMIC
C115 4030011600 S.CERAMIC
C302 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C303 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C304 4310001140 MYLER
C305 4030013860 S.CERAMIC
C306 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C307 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C401 4030011600 S.CERAMIC
C402 4510004590 ELECTROLYTIC
C403 4030011600 S.CERAMIC
C404 4510005000 ELECTROLYTIC
C405 4030011280 S.CERAMIC
C406 4510006240 S.ELECTROLYTIC ECEV1CA221P
C407 4030011600 S.CERAMIC
C408 4030011600 S.CERAMIC
C409 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C571 4510005810 S.ELECTROLYTIC ECEV1HAR47R
C572 4030011600 S.CERAMIC
J301 6510019990 S.CONNECTOR
J302 6510019990 S.CONNECTOR
J303 6510003400 CONNECTOR
J501 6510019970 S.CONNECTOR
J502 6510019970 S.CONNECTOR
J507 6510019970 S.CONNECTOR
J508 6510019970 S.CONNECTOR
J601 6510019990 S.CONNECTOR
J604 6510003400 CONNECTOR
S1 2260001890 S.SWITCH
S2 2260001890 S.SWITCH
S3 2260001890 S.SWITCH
S4 2260001890 S.SWITCH
S5 2260001890 S.SWITCH
S6 2260001890 S.SWITCH
S7 2260001890 S.SWITCH
S8 2260001890 S.SWITCH
S9 2260001890 S.SWITCH
S10 2260001890 S.SWITCH
S11 2260001890 S.SWITCH
S601 2260001890 S.SWITCH
EP1 0910054542 PCB
6 - 1
DESCRIPTION
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
MCR10EZHJ 220 Ω (221)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
NTCCM2012 3JH 472KC-T
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 1R0 V (1 Ω)
ERA3YED 822V
ERA3YED 152V
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 104K-T-N
250 MMW 473K EF
GHM1038 SL 120J 3K
C1608 JB 1E 104K-T-N
16 MV 470 HC
C1608 JB 1E 104K-T-N
16 MV 220 HC
C1608 CH 1H 271J-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
52808-2291
52808-2291
B04B-EH-S
52808-1091
52808-1091
52808-1091
52808-1091
52808-2291
B04B-EH-S
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
B 5690B
S.=Surface mount
