SECTION 5 PARTS LIST
[FRONT UNIT]
REF ORDER
NO. NO.
S2801 2260001580 SWITCH
SP2801 2510000441 SPEAKER
W2807 8900005340 CABLE
W2808 8900005340 CABLE
W2809 8900005370 CABLE
W2810 8900005340 CABLE
W2811 8900005340 CABLE
WS1 8600034520 M.OTHER
WS2 8600034530 M.OTHER
[LOGIC BOARD]
REF ORDER
NO. NO.
IC2001 1140006930 S.IC
IC2002 1140005130 S.IC
IC2003 1110005710 S.IC
IC2005 1180001460 S.IC
IC2006 1180001450 S.IC
IC2007 1110002550 IC
IC2008 1110000960 S.IC
IC2009 1180000420 S.IC
Q2002 1530001970 S.TRANSISTOR
Q2003 1520000290 TRANSISTOR
Q2005 1530001970 S.TRANSISTOR
Q2006 1530001970 S.TRANSISTOR
Q2007 1590001380 S.TRANSISTOR
Q2008 1590001380 S.TRANSISTOR
Q2009 1530001970 S.TRANSISTOR
Q2011 1590001380 S.TRANSISTOR
Q2012 1590001380 S.TRANSISTOR
Q2013 1590001380 S.TRANSISTOR
D2001 1750000020 S.DIODE
D2002 1730000830 S.ZENER
D2003 1750000020 S.DIODE
D2004 1750000020 S.DIODE
D2005 1750000020 S.DIODE
D2006 1750000020 S.DIODE
D2007 1750000020 S.DIODE
D2008 1750000020 S.DIODE
D2009 1750000020 S.DIODE
D2010 1750000020 S.DIODE
X2001 6050009450 XTAL
L2002 6910000670 COIL
L2003 6910000670 COIL
L2004 6200003260 S.COIL
L2005 6910000670 COIL
L2006 6200003260 S.COIL
L2007 6200003260 S.COIL
L2008 6200003260 S.COIL
L2009 6200003260 S.COIL
L2010 6170000140 COIL
R2003 7030000520 S.RESISTOR
R2005 7030000400 S.RESISTOR
[GEN]: [GEN-21], [GEN-22], [GEN-23]
[GMDSS]: [GEN-23], [EUR-22]
DESCRIPTION
JPZ2120-0101 (TV-3)
F77G08-6205
OPC-522 (N:6 L:100)
OPC-522 (N:6 L:100)
OPC-524 (N:10 L:150)
OPC-522 (N:6 L:100)
OPC-522 (N:6 L:100)
SX1632 P2801FR
SX1632 P2802FR
DESCRIPTION
HD6433834A95F SX-1632SA
HD66100F
S-80842CLUA-B63-T2
µPC78L05T-E1
µPC78L08T-E1
TA7252AP
NJM4558M-TE1
TA78L05F (TE12R) [GMDSS]
2SC1623-T2B-L6
2SB1015-Y
2SC1623-T2B-L6
2SC1623-T2B-L6
DTC114EKA T146
DTC114EKA T146
2SC1623-T2B-L6
DTC114EKA T146
DTC114EKA T146
DTC114EKA T146
1SS184 (TE85R)
RD9.1M-T2B1
1SS184 (TE85R)
1SS184 (TE85R)
1SS184 (TE85R)
1SS184 (TE85R)
1SS184 (TE85R)
1SS184 (TE85R)
1SS184 (TE85R)
1SS184 (TE85R)
CR-513 (9.8304 MHz)
BL01RN1A1D2B
BL01RN1A1D2B
NL 322522T-101J
BL01RN1A1D2B
NL 322522T-101J
NL 322522T-101J
NL 322522T-101J
NL 322522T-101J
LW-15
Ω
MCR10EZHJ 15 k
Ω
MCR10EZHJ 1.5 k
[EUR]: [EUR-21], [EUR-22]
[Others]: [GEN-21], [GEN-22], [EUR-21]
[LOGIC BOARD]
REF ORDER
NO. NO.
R2007 7030000430 S.RESISTOR
R2009 7030000580 S.RESISTOR
R2011 7030000580 S.RESISTOR
R2012 7030000740 S.RESISTOR
R2013 7030000580 S.RESISTOR
R2014 7030000580 S.RESISTOR
R2015 7030000380 S.RESISTOR
R2016 7030000380 S.RESISTOR
R2017 7030000620 S.RESISTOR
R2018 7030000380 S.RESISTOR
R2019 7030000700 S.RESISTOR
R2020 7030000660 S.RESISTOR
R2021 7030000660 S.RESISTOR
R2022 7030000620 S.RESISTOR
R2024 7030000010 S.RESISTOR
R2039 7030000580 S.RESISTOR
R2040 7030000560 S.RESISTOR
R2041 7030000460 S.RESISTOR
R2042 7030000580 S.RESISTOR
R2043 7030000520 S.RESISTOR
R2044 7030000500 S.RESISTOR
R2045 7030000500 S.RESISTOR
R2046 7030000500 S.RESISTOR
R2047 7030000470 S.RESISTOR
R2048 7030000380 S.RESISTOR
R2049 7030000580 S.RESISTOR
R2054 7010003241 RESISTOR
R2055 7030000500 S.RESISTOR
R2056 7030000020 S.RESISTOR
R2057 7030000380 S.RESISTOR
R2058 7010003101 RESISTOR
R2061 7030000260 S.RESISTOR
R2062 7030000440 S.RESISTOR
R2063 7030000300 S.RESISTOR
R2064 7030000610 S.RESISTOR
R2065 7030000620 S.RESISTOR
R2066 7310004980 TRIMMER
R2067 7030000540 S.RESISTOR
R2068 7030000610 S.RESISTOR
R2069 7030000380 S.RESISTOR
R2070 7310004960 TRIMMER
R2071 7030000400 S.RESISTOR
R2072 7030000360 S.RESISTOR
R2073 7030000340 S.RESISTOR
R2077 7030000530 S.RESISTOR
R2078 7030000500 S.RESISTOR
R2079 7030000530 S.RESISTOR
R2080 7030000500 S.RESISTOR
R2081 7030000530 S.RESISTOR
R2082 7030000500 S.RESISTOR
R2083 7030000530 S.RESISTOR
R2084 7030000530 S.RESISTOR
R2085 7030000580 S.RESISTOR
R2086 7030000540 S.RESISTOR
R2087 7030000520 S.RESISTOR
R2088 7030000580 S.RESISTOR
R2090 7030000240 S.RESISTOR
C2002 4030004740 S.CERAMIC
C2003 4030004740 S.CERAMIC
C2004 4030004740 S.CERAMIC
C2005 4030004880 S.CERAMIC
C2006 4030004880 S.CERAMIC
C2007 4030004750 S.CERAMIC
C2008 4310000520 MYLAR
C2009 4030004750 S.CERAMIC
C2012 4510005150 ELECTROLYTIC
C2013 4030004740 S.CERAMIC
C2014 4030004740 S.CERAMIC
C2015 4030004740 S.CERAMIC
C2016 4030004740 S.CERAMIC
C2017 4030004740 S.CERAMIC
C2018 4030004740 S.CERAMIC
C2019 4030004740 S.CERAMIC
5 - 1
DESCRIPTION
Ω
MCR10EZHJ 2.7 k
Ω
MCR10EZHJ 47 k
Ω
MCR10EZHJ 47 k
Ω
MCR10EZHJ 1 M
Ω
MCR10EZHJ 47 k
ΩΩ
MCR10EZHJ 47 k
Ω
MCR10EZHJ 1 k
Ω
MCR10EZHJ 1 k
Ω
MCR10EZHJ 100 k
Ω
MCR10EZHJ 1 k
Ω
MCR10EZHJ 470 k
Ω
MCR10EZHJ 220 k
Ω
MCR10EZHJ 220 k
Ω
MCR10EZHJ 100 k
MCR10EZHJ JPW (000)
Ω
MCR10EZHJ 47 k
Ω
MCR10EZHJ 33 k
Ω
MCR10EZHJ 4.7 k
Ω
MCR10EZHJ 47 k
Ω
MCR10EZHJ 15 k
Ω
MCR10EZHJ 10 k
Ω
MCR10EZHJ 10 k
Ω
MCR10EZHJ 10 k
Ω
MCR10EZHJ 5.6 k
Ω
MCR10EZHJ 1 k
Ω
MCR10EZHJ 47 k
Ω
PSD1/4V 47
Ω
MCR10EZHJ 10 k
Ω
MCR10EZHJ 1 (010)
Ω
MCR10EZHJ 1 k
Ω
PSD1/4V 3.3
Ω
MCR10EZHJ 100 (101)
Ω
MCR10EZHJ 3.3 k
Ω
MCR10EZHJ 220 (221)
Ω
MCR10EZHJ 82 k
Ω
MCR10EZHJ 100 k
Ω
KVSF639AC 103 10 k
Ω
MCR10EZHJ 22 k
Ω
MCR10EZHJ 82 k
Ω
MCR10EZHJ 1 k
Ω
KVSF639AC 104 100 k
Ω
MCR10EZHJ 1.5 k
Ω
MCR10EZHJ 680 (681)
Ω
MCR10EZHJ 470 (471)
Ω
MCR10EZHJ 18 k
Ω
MCR10EZHJ 10 k
Ω
MCR10EZHJ 18 k
Ω
MCR10EZHJ 10 k
Ω
MCR10EZHJ 18 k
Ω
MCR10EZHJ 10 k
Ω
MCR10EZHJ 18 k
Ω
MCR10EZHJ 18 k
Ω
MCR10EZHJ 47 k
Ω
MCR10EZHJ 22 k
Ω
MCR10EZHJ 15 k
Ω
MCR10EZHJ 47 k
Ω
MCR10EZHJ 68 (680) [Others]
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 CH 1H 120J-T
C2012 CH 1H 120J-T
C2012 JB 1H 103K-T
50 F2D 224J
C2012 JB 1H 103K-T
50 MV 10 HC
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
S.=Surface mount
