SECTION 6

6-1 IC-M302

[VR BOARD]
REF ORDER
NO. NO.
R1 7210003140 VARIABLE
J1 6510009490 CONNECTOR
EP1 0910056592 PCB
[SQL BOARD]
REF ORDER
NO. NO.
R1 7210003150 VARIABLE
J1 6510009470 CONNECTOR
EP1 0910056602 PCB
[FRONT UNIT]
REF ORDER
NO. NO.
MC1 0800007150 MICROPHONE
0800007160 MICROPHONE
0800007320 MICROPHONE
SP1 2510001240 SPEAKER
W1 7120000470 JUMPER
W2 7120000470 JUMPER
W3 8900012410 CABLE

[LOGIC BOARD]

REF ORDER
NO. NO.
IC1 1140011800 S.IC
IC2 1170000350 S.IC
IC3 1130007430 S.IC
IC4 1130011570 S.IC
IC5 1110006210 S.IC
IC6 1110002700 S.IC
Q2 1520000460 S.TRANSISTOR
Q3 1530002850 S.TRANSISTOR
Q4 1530002850 S.TRANSISTOR
Q6 1590001050 S.TRANSISTOR
D1 1750000550 S.DIODE
D2 1750000550 S.DIODE
D3 1750000150 S.DIODE
X1 6050011800 S.XTAL
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
PARTS LIST
DESCRIPTION M.
TP96N97N-15SK-10KA-2685
S5B-ZR
B 6017B
DESCRIPTION M.
TP96N97-15SK-10KB-2685
S3B-ZR
B 6018B
DESCRIPTION M.
HM-141B ACC <FG> [Black]
HM-141W ACC <FG> [White]
HM-141G ACC <FG> [Gray]
045P0803 <FG>
ERDS2T0
ERDS2T0
OPC-1263 (N=30,L=110)
DESCRIPTION M.
M37560MFA-303GP (FX-2685A)
PC357N6T
TC7S14FU (TE85R)
BR24L32FV-WE2
BD5242FVE-TR
NJM2904M-TE1
2SB1132 T100 R
2SC4116-BL (TE85R)
2SC4116-BL (TE85R)
DTC114TUA T106
1SS355 TE-17
1SS355 TE-17
DA204K T146
CR-769 (7.9872 MHz)
[LOGIC BOARD]
REF ORDER
NO. NO.
R1 7030003530 S.RESISTOR
R3 7030003560 S.RESISTOR
T
R4 7030003560 S.RESISTOR
R5 7030003560 S.RESISTOR
R14 7030003700 S.RESISTOR
T
R15 7030003640 S.RESISTOR
R16 7030003560 S.RESISTOR
R21 7030003250 S.RESISTOR
R22 7030003250 S.RESISTOR
R23 7030003250 S.RESISTOR
R24 7030003630 S.RESISTOR
R25 7030003640 S.RESISTOR
R26 7030003440 S.RESISTOR
R27 7030003570 S.RESISTOR
R28 7030003500 S.RESISTOR
R29 7030003440 S.RESISTOR
R30 7030003390 S.RESISTOR
R31 7030003390 S.RESISTOR
R35 7030003360 S.RESISTOR
R36 7030003540 S.RESISTOR
T
R37 7030003580 S.RESISTOR
R38 7030003440 S.RESISTOR
R40 7030003340 S.RESISTOR
T
R41 7030003560 S.RESISTOR
R42 7030003560 S.RESISTOR
R43 7030003560 S.RESISTOR
R51 7030003680 S.RESISTOR
R52 7030003800 S.RESISTOR
R53 7030003560 S.RESISTOR
R54 7030003540 S.RESISTOR
R55 7030003560 S.RESISTOR
R56 7030003560 S.RESISTOR
R61 7030003680 S.RESISTOR
R62 7030003560 S.RESISTOR
R63 7030003560 S.RESISTOR
R64 7030003560 S.RESISTOR
R65 7030003800 S.RESISTOR
C1 4030006900 S.CERAMIC
C2 4030006850 S.CERAMIC
C3 4030006900 S.CERAMIC
C4 4030006850 S.CERAMIC
C5 4030006900 S.CERAMIC
C6 4030011600 S.CERAMIC
C7 4030006900 S.CERAMIC
C11 4030006900 S.CERAMIC
C12 4030006860 S.CERAMIC
C13 4030006900 S.CERAMIC
C14 4030006860 S.CERAMIC
C16 4030006880 S.CERAMIC
C17 4030006900 S.CERAMIC
C18 4030006900 S.CERAMIC
C21 4030008880 S.CERAMIC
C22 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C23 4030006900 S.CERAMIC
C25 4030006900 S.CERAMIC
C26 4030006860 S.CERAMIC
C31 4030009650 S.CERAMIC
C32 4030007050 S.CERAMIC
T
C41 4030006850 S.CERAMIC
T
C42 4030006850 S.CERAMIC
T
C43 4030006860 S.CERAMIC
T
T
T
J1 6510021720 S.CONNECTOR
J2 6510015540 S.CONNECTOR
T
T
DS1 5030002590 LCD
T
DS2 5040002310 S.LED
T
DS3 5040002310 S.LED
DS4 5040002660 S.LED
DS5 5040002660 S.LED
T
DS6 5040002660 S.LED
T
DS7 5040002660 S.LED
T
EP1 0910057311 PCB
EP2 8930061040 LCD CONTACT
T
6 - 1
DESCRIPTION M.
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 270 V (27 Ω)
ERJ3GEYJ 270 V (27 Ω)
ERJ3GEYJ 270 V (27 Ω)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
C1608 JB 1H 103K-T
C1608 JB 1H 471K-T
C1608 JB 1H 103K-T
C1608 JB 1H 471K-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 223K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 CH 1H 240J-T
C1608 CH 1H 220J-T
C1608 JB 1H 471K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
30FLT-SM1-TB
B4B-ZR-SM3-TF
IS08251E00V0
SML-311YTT86
SML-311YTT86
FY1101F-TR (LED)
FY1101F-TR (LED)
FY1101F-TR (LED)
FY1101F-TR (LED)
B 6096A
SRCN-2685-SP-N-W
S.=Surface mount
