Summary of Contents for Humminbird 1100 Series

  • Page 2: Thank You

    Always operate the boat at very slow speeds if you suspect shallow water or submerged objects. WARNING! The electronic chart in your Humminbird® unit is an aid to navigation designed to facilitate the use of authorized government charts, not to replace them. Only official government charts and notices to mariners contain all of the current information needed for the safety of navigation, and the captain is responsible for their prudent use.
  • Page 3 Humminbird® international units purchased through our authorized international distributors. To obtain a list of authorized international distributors, please visit our Web site at humminbird.com or contact our Customer Resource Center at (334) 687-6613.

  • Page 4: Table Of Contents

    Table of Contents 1100 Series™ Introduction How Sonar Works ............................1 High Definition Side Imaging® Sonar (1199ci HD SI models only)..............3 DualBeam PLUS™ Sonar (1159ci HD, 1199ci HD SI) ..................3 Down Imaging® Sonar (1159ci HD DI only) ....................4 Xtreme Depth Sonar (Xtreme Depth Series™...
  • Page 5 Table of Contents Sonar Colors and Bottom View ........................ 23 SwitchFire® ..............................25 Freeze Frame and Active Cursor........................ 25 Instant Image Update..........................25 What’s on the Side Imaging® Display (Side Imaging® models only [1199ci HD SI]) Understanding the Side Imaging® Display ....................28 Side Imaging®...
  • Page 6 Table of Contents View Orientation ............................76 Viewing Cartography Introduction to Navigation Waypoints, Routes, and Tracks ........................ 79 Open the Waypoint Management Dialog Box..................81 What’s on the Waypoint Management Dialog Box ................82 Save, Edit, or Delete a Waypoint ......................83 Navigate to a Waypoint or Position ......................
  • Page 7 Table of Contents Quad Layout (with optional-purchase QuadraBeam PLUS™ Transducer, Side Beam View only) ....108 Bottom Lock (Sonar Zoom View only) ......................108 Bottom Range (Sonar Zoom View only, when Bottom Lock is On) .............. 108 Side Imaging® X-Press™ Menu (Side Imaging®...
  • Page 8 Table of Contents Save Current Route (only when Navigating) .................... 120 Reset XTE (only when Navigating) ......................120 Remove Target (only if a Target is Active) ....................120 Remove Grid (only if a Grid is Active) ......................120 Waypoint [Name] (Most recently-created waypoint).................. 121 Snapshot and Recording X-Press™...
  • Page 9 Table of Contents Fish ID+™ ..............................135 Fish ID Sensitivity ............................ 136 Real Time Sonar (RTS™) Window ......................136 Sonar Colors ............................137 Bottom View ............................137 Zoom Width (Sonar Zoom View only) ...................... 137 50 kHz Sensitivity (Advanced, XD Sonar only [1159ci HD XD]) ..............137 83 kHz Sensitivity (Advanced, DualBeam PLUS™...
  • Page 10 Table of Contents Track Min Distance (Advanced) ........................ 148 Track Color Range ............................ 148 Map Datum (Advanced) ..........................149 North-Up Indicator ..........................149 Course Projection Line ..........................149 3D View Outline ............................149 Continuous Navigation Mode ........................ 149 GPS Receiver Override (Advanced) ......................150 SI Navigation (Side Imaging®...
  • Page 11 Screen Snapshot (optional-purchase SD Cards only) ................171 AIS (optional-purchase AIS equipment only) ....................171 Maintenance Troubleshooting 1100 Series™ Doesn’t Power Up ......................176 1100 Series™ Defaults to Simulator with a Transducer Attached ............176 Display Problems ............................177 Finding the Cause of Noise ........................178 viii...
  • Page 12 NOTE: Entries in this Table of Contents which list (with Speed Input) or (with Temperature Input) may require the purchase of separate accessories. You can visit our Web site at humminbird.com to order these accessories online or contact our Customer Resource Center at 1-800-633-1468.

  • Page 13: 1100 Series™ Introduction

    Imaging® sonar, DualBeam PLUS™ sonar, Down Imaging® sonar, chartplotting, and an internal GPS receiver. How Sonar Works Sonar technology is based on sound waves. The 1100 Series™ Fishing System uses sonar to locate and define structure, bottom contour and composition, as well as depth directly below the transducer.

  • Page 14: Universal Sonar

    When all the echoes are viewed side by side, an easy to interpret “graph” of the bottom, fish, and structure appears. The sound pulses are transmitted at various frequencies depending on the application. Very high frequencies (455 kHz) are used for greatest definition but the operating depth is limited. High frequencies (200 kHz) are commonly used on consumer sonar and provide a good balance between depth performance and resolution.

  • Page 15: High Definition Side Imaging® Sonar (1199Ci Hd Si Models Only)

    High Definition Side Imaging® Sonar 86° 86° (1199ci HD SI Combo models only) 455kHz 455kHz Your 1199ci HD SI Combo Fishing System uses Side Imaging® sonar to provide a wide yet precise 20° 200kHz survey of a large area of water, including detailed 60°...

  • Page 16: Down Imaging® Sonar (1159Ci Hd Di Only)

    Down Imaging® Sonar (1159ci HD DI only) Your 1159ci HD DI Fishing System uses Down 45° 800kHz Imaging® technology. The Down Imaging® 75° 455kHz transducer scans the water with razor-thin, high- 16° definition beams. The beams are wide (side to side) 455kHz 28°...

  • Page 17: Quadrabeam Plus™ Sonar (With Optional-Purchase Quadrabeam Plus™ Transducer Only)

    NOTE: Contact our Customer Resource Center to determine which accessory transducers are compatible with your Humminbird® Fishing System, or visit our Web site at humminbird.com. Introduction...

  • Page 18: Universal Sonar 2

    Universal Sonar 2 (compatible w/optional-purchase Minn Kota® trolling motors) Your 1100 Series™ Fishing System supports Universal Sonar 2, a state-of-the-art, integrated and protected transducer that is built into the lower unit of Minn Kota® trolling motors. With Universal Sonar 2, all wiring is concealed inside the indestructible composite shaft—out of sight and out of harm’s way, with no clamps, ties, or exposed wires.

  • Page 19: Fishing System Configuration

    Please read all instructions that are relevant for your configuration before beginning the installation process. See the Humminbird® installation guide for details. The 1100 Series™ has a wide variety of configurations. Power GPS Receiver...

  • Page 20: Rs 232 Connector

    Your unit has a built-in dual RS 232 connector, which can be used with optional-purchase equipment such as AIS (Automatic Identification System). NOTE: To purchase a connection cable for an optional-purchase AIS, visit our Web site at humminbird.com or contact our Customer Resource Center at 1-800-633-1468.

  • Page 21: Power On

    Power On Follow the instructions below to power on your Humminbird® control head. 1100 Series™ Title Screen 1. Press the POWER/LIGHT key. 2. When the Title screen is displayed, press the MENU key to access the Start-Up Options Menu. 3. If a functioning transducer is connected, Normal operation will be selected automatically, and your Fishing System can be used on the water.

  • Page 22: What's On The Control Head

    What’s on the Control Head Your 1100 Series™ user interface is easy to use. A combination of keys, different views, and situation-specific, customizable menus allows you to control what you see on the color display. Refer to the following illustration and see Key Functions, Views, and The Menu System for more information.

  • Page 23: Key Functions

    Key Functions Your Fishing System has a set of easy to use keys that give you flexibility and control over your fishing experience. POWER/LIGHT Key The POWER/LIGHT key is used to power the Fishing System on and off. You can also use the POWER/LIGHT key to adjust the backlight and contrast of the display.

  • Page 24: Menu Key

    MENU Key The MENU key is used to access the menu system. See The Menu System for more information. Start-Up Options Menu: Press the MENU key during the power up sequence to view the Start-Up Options menu. X-Press™ Menu: Press the MENU key once in any view to access the X-Press™ Menu, which provides frequently-used menu settings that correspond with the current view or navigation mode.

  • Page 25: Exit Key

    EXIT Key The EXIT key has multiple functions, which depend on the situation. • If an alarm is sounding, press the EXIT key to cancel the alarm. • If a menu tab is selected, press the EXIT key to exit the menu mode and return to the view. •...

  • Page 26: Goto Key

    GOTO Key The GOTO key has multiple functions, which depend on the situation. • Active Cursor: Press the GOTO key while in any view to create a waypoint and start navigation towards that waypoint. • Without Active Cursor: Press the GOTO key to display the saved waypoints list, and then highlight a waypoint.

  • Page 27: Sd Memory Card Slots

    Card Slot NOTE: The SD Memory Cards require a separate purchase. For more information, visit our Web site at humminbird.com or contact our Customer Resource Center at 1-800-633-1468. To insert an SD memory card: 1. Remove the SD memory card slot cover.

  • Page 28: Add Maps To Your Fishing System

    You can also purchase SD memory cards with additional chart information for a particular location. NOTE: The 1100 Series™ supports LakeMaster®, Navionics® Cartography, Navionics® Gold, HotMaps™, HotMaps™ Premium, and Platinum™ Cartography on SD card media. The 1100 Series™ does not support Navionics® Classic Charts. NOTE: The SD Memory Cards require a separate purchase.

  • Page 29: Import Navigation Data

    Review the following information before importing navigation data (waypoints, routes, tracks, or groups) into your Humminbird® unit. • Import Humminbird® Navigation Data: Insert a loaded SD memory card into the control head card slot, and follow the on-screen prompts to import the waypoints, routes, tracks, and groups.
  • Page 30 NOTE: The SD memory cards and USB Memory Card Reader require separate purchases. The USB Memory Card Reader accessory can be used in conjunction with your personal computer to view and organize your exported navigation data. Visit our Web site at humminbird.com or contact our Customer Resource Center at 1-800-633-1468 for more information.

  • Page 31: Update Software

    Update Software Set up an online account at humminbird.com so that you will receive the latest Humminbird® news and software upgrades for your Fishing System. You can also download HumminbirdPC™ from your account, which allows you to manage your waypoints, routes, and tracks on your personal computer.

  • Page 32: What's On The Sonar Display

    Temperature - Water surface temperature Speed - If a Speed accessory or GPS Receiver is connected, the 1100 Series™ can display the speed of the boat and can keep a triplog of nautical or statute miles traveled.
  • Page 33 to your boat, including the following items: What’s on the Sonar Display...

  • Page 34: Understanding The Sonar Display

    Understanding the Sonar Display It is important to understand the significance of the display. The display does NOT show a literal 3-dimensional representation of what is under the water. Each vertical band of data received by the control head and plotted on the display represents something that was detected by a sonar return at a particular time.

  • Page 35: Sonar Colors And Bottom View

    Sonar Colors and Bottom View Sonar Colors: Original Palette As the boat moves, the unit charts the changes in depth on HIGH the display to create a profile of the Bottom Contour. The Intensity Return Sonar View displays the sonar return intensity with different colors.
  • Page 36 Structure ID™ represents weak returns in blue and strong returns in red when Sonar Colors is set to Original. If the Sonar Colors palette is changed, the Structure ID™ will display the strongest return as specified by the palette. See Sonar Menu Tab: Sonar Colors for more information.

  • Page 37: Switchfire

    SwitchFire® SwitchFire® controls how the sonar returns are displayed in the Sonar Views. SwitchFire® settings are available in the Sonar Menu Tab. To see the maximum sonar information available within the transducer beam so more fish arches and better jig tracking are shown, choose Max Mode. To see less clutter and more fish size accuracy interpreted from the transducer beam, choose Clear Mode.

  • Page 38: What's On The Side Imaging® Display

    Temperature - Water surface temperature Speed - If a Speed accessory or GPS Receiver is connected, the 1100 Series™ can display the speed of the boat and can keep a triplog of nautical or statute miles traveled.
  • Page 39 (Side Imaging® models only [1199ci HD SI]) of bottom contour and structure. For Side Imaging®, the bottom composition determines the and sand because of their relative density. Upward slopes that face the transducer reflect sonar recognizable features on the Side Imaging® display that allow for accurate interpretation of bottom Clouded Area - May indicate a bait ball and White Streaks may indicate fish.

  • Page 40: Understanding The Side Imaging® Display

    Understanding the Side Imaging® Display It is important to understand how Side Imaging® technology produces the display. The images you see on the display are produced using sonar technology. The special transducer projects three distinct beams – one beam facing down and two beams pointing out to the side. Down Beam is aimed directly below the boat and provides conical coverage.

  • Page 41: Side Imaging® Frequencies And Coverage

    The main benefit of Side Imaging® sonar to anglers is that it provides an overall survey of a large area of water. This gives you a better understanding of the bottom topography and how structure is oriented for more efficient fishing. Saltwater anglers pick up precise details of popular fishing structure like wrecks, reefs, humps and drop-offs, as well as being able to spot bait balls in open water.

  • Page 42: For Best Performance

    See Submerged Bridge: Creek Channel and New Bridge Pilings and the Submerged Bridge: Alternative Perspective illustrations for examples of this. See humminbird.com for a side imaging sonar tutorial and additional information. What’s on the Side Imaging® Display...

  • Page 43: On The Water Interpretation

    On the Water Interpretation Submerged Bridge, Creek Channel and New Bridge Pilings New Bridge Pilings Submerged Bridge Creek Channel Submerged Ravine with Timber Submerged Timber Submerged Ravine Submerged Tree Possible Drop Off What’s on the Side Imaging® Display...
  • Page 44 Submerged Bridge, Alternative Perspective Submerged Bridge Submerged Standing and Fallen Timber, plus Bait Fish Bait Fish Standing and Fallen Timber What’s on the Side Imaging® Display...
  • Page 45 Submerged Swimming Pool Swimming Pool Submerged Barge with Dumped Logs Dumped Logs Submerged Barge What’s on the Side Imaging® Display...

  • Page 46: What's On The Down Imaging® Display

    What’s on the Down Imaging® Display Down Imaging® uses unique sonar technology to provide information about the area directly that you see on the display. Down Imaging® reveals a variety of recognizable features so that you Bottom Return - Use the appearance of the bottom return to determine bottom hardness.
  • Page 47 NOTE: Entries in this view that list (with Temp/Speed or GPS Receiver) are available if either device is connected to the 1100 Series™ Fishing System. If both devices are connected, then only the information from the GPS receiver will be displayed on the view.

  • Page 48: Understanding The Down Imaging® Display

    Understanding the Down Imaging® Display The images you see on the Down Imaging® display are produced using sonar technology. Each time the unit pings, a strip of data representing all the echoes received by the transducer are put together on the display to form the image that you see.

  • Page 49: Down Imaging® Sensitivity

    Down Imaging® Sensitivity Use Down Sensitivity to control how the sonar returns appear on the display. Increase the sensitivity to reveal weaker returns that may be of interest, especially in very clear water or greater depths. Decrease the sensitivity to eliminate the clutter from the display that is sometimes present in murky or muddy water.

  • Page 50: Views

    1159ci HD XD: Sonar/Chart Combo View 1199ci HD SI: Chart/Side Combo View • Available Views: The available Views on your Humminbird® unit will vary with the model and the transducer attached to your control head. See Views Menu Tab and the following pages for more information.
  • Page 51 To customize your view rotation: You can choose which views are hidden or visible in your view rotation. 1. Press the MENU key twice to access the tabbed Main Menu, then press the RIGHT Cursor key until the Views tab is selected. 2.

  • Page 52: Sonar View

    Sonar View Sonar View presents a historical log of sonar returns. The most recent sonar returns are charted on the right side of the display. As new information is received, the historical information scrolls left across the display. • Upper and Lower Depth Range numbers indicate the distance from the surface of the water to a depth range sufficient to show the bottom.
  • Page 53 Sonar View Upper Depth Range Structure Temperature Graph Depth Depth Lines Temp: Water Surface Temperature RTS Window™ Speed: Speed of Boat Sonar Color Bar Course: the current direction the boat is traveling measured in degrees from North Lower Depth Range VLT: Voltage NOTE: If the Depth number is flashing, it means that the unit is having trouble locating the bottom.

  • Page 54: Sonar Zoom View

    Sonar Zoom View Sonar Zoom View provides a magnified view of the bottom and structure. The Sonar Zoom View makes it easier to see separate sonar returns that would usually be displayed close together, such as those caused by fish suspended close to the bottom or within structure. •...
  • Page 55 Sonar Zoom View Depth Upper Depth Range, Zoom View Temp: water surface temperature Upper Depth Range, Full Range View Speed: speed of boat Zoom Preview Box Course: the current direction the boat is traveling measured in degrees from North Full Range View VLT: Voltage Lower Depth Range, Zoom View Zoomed View...

  • Page 56: Split Sonar View

    Split Sonar View Split Sonar View displays sonar returns from each down beam frequency on separate sides of the screen. You can use the Split Sonar View to make side by side comparisons between the sonar returns from both beams. •...
  • Page 57 Split Sonar (1159ci HD and 1199ci HD SI) Depth Lower Depth Range Temp: water surface temperature Depth Lines Speed: speed of boat Upper Depth Range Course: the current direction the boat is traveling measured in degrees from North 83 kHz Sonar History Window VLT: Voltage 200 kHz Sonar History Window Views...

  • Page 58: Down Imaging® View (1159Ci Hd Di And 1199Ci Hd Si Only)

    Down Imaging® View (1159ci HD DI and 1199ci HD SI only) Down Imaging® models (1159ci HD DI) use the razor-thin, high-definition profiling beams to produce the detailed sonar data that you see on the display. Side Imaging® models (1199ci HD SI) display the down beam portion of the data from the Side Imaging®...
  • Page 59 Down Imaging® View Depth: water depth Bottom Return Boat Position: Latitude/Longitude Topography Changes Speed: speed of boat Upper Range Lower Range Course: the current direction the boat is traveling measured in degrees from North. 10 11 VLT: Voltage 10 12 Views...
  • Page 60 Down Imaging® View, with Active Cursor and Zoom Cursor Info Box Depth Depth of Cursor Boat Position: Latitude/Longitude Depth Below Cursor Speed: speed of boat Distance to Cursor Course: the current direction the boat is traveling measured in degrees from North Bearing to Cursor VLT: Voltage Zoom Level...

  • Page 61: Side Imaging® View (1199Ci Hd Si Only)

    Side Imaging® View (1199ci HD SI only) Side Imaging® View shows a shadowed right- and left-looking view from the boat as the boat passes over the bottom. See Understanding the Side Imaging® Display for more information about interpreting the Side Imaging® View. •...
  • Page 62 Side Imaging® View (while Navigating) Depth: water depth Submerged Tree XTE: Cross Track Error. Distance of Boat from Route Standing and Fallen Timber Speed: speed of boat Side Beam Range Water Column Course: the current direction the boat is traveling measured in degrees from North. Bottom Return Bearing of boat with respect to true North Orange Boat Icon (Navigating)
  • Page 63 Side Imaging® View, with Active Cursor and Zoom Cursor Info Box Depth Depth of Cursor Temp: water surface temperature Depth Below Cursor Speed: speed of boat Distance to Cursor Course: the current direction the boat is traveling measured in degrees from North Bearing to Cursor VLT: Voltage Zoom Level...

  • Page 64: Snapshot And Recording View (Optional-Purchase Sd Memory Card Required)

    Snapshot and Recording View (optional-purchase SD memory card required) Snapshot and Recording View displays the screen snapshots and recordings that are saved on the optional-purchase SD memory card installed in the control head. Use this view to review the snapshot and recording file details, start recording, and adjust the recording settings. •...
  • Page 65 Screen Snapshots Screen Snapshots are saved pictures of the view on the screen. The screen snapshot will include the menus, dialog boxes, warnings, and messages that were active when the screen snapshot was taken. Saved Screen Snapshots can be viewed from the Snapshot and Recording View or Chart View.
  • Page 66 • Use an optional-purchase SD card reader connected to a PC to view the saved screen snapshot data files on your optional-purchase SD card (see humminbird.com for details). You will notice that a .DAT (or a .TXT) file is created for every .PNG screen snapshot.
  • Page 67 Recording and Playback The Recording feature records active sonar information. When the recording is played back, the views that were active during the recording are available in Playback. The Recording and Playback feature is available when an optional-purchase SD card is installed and Screen Snapshot is On (see Accessories Menu Tab: Screen Snapshot).
  • Page 68 Playback a Recording: 1. From the Snapshot and Recording View, press the UP or DOWN Cursor keys to scroll through the saved files and highlight a saved Recording. 2. Press the RIGHT Cursor key. Recording File Information Highlighted Recording File Change Playback Settings: 1.
  • Page 69 Notes about Playback: • “Playback” will flash periodically on the screen to indicate that the control head is playing a saved recording and not a “live” view. • Navigation is not affected by the Sonar Recording feature, but any active navigation is cancelled and thumbnails and icons disappear when Playback begins or ends.

  • Page 70: Side Beam View (With Optional-Purchase Quadrabeam Plus™ Transducer)

    Side Beam View (with optional-purchase QuadraBeam PLUS™ transducer) Side Beam View displays sonar data from the left and right 455 kHz beams and the 200 kHz down-looking beam in one view. This view is available if an optional-purchase QuadraBeam PLUS™ transducer accessory is connected and Connected Transducer is set to Quad Beam (see Sonar Menu Tab: Connected Transducer).
  • Page 71 Default layout: The top portion of the display presents a historical log of sonar returns from the 200 kHz down-looking sonar beam. New information in the down beam panel scrolls from right to left. The bottom portion of the display presents a historical log of sonar returns from the 455 kHz right- and left-looking sonar beams.
  • Page 72 Classic layout: The top portion of the display presents a historical log of sonar returns from the 200 kHz down-looking sonar beam. New information in the down beam panel scrolls from right to left. The bottom portion of the display presents a historical log of sonar returns from the 455 kHz right- and left-looking sonar beams.
  • Page 73 Slanted layout: This layout is presented as three slanted panels representing the two 455 kHz side sonar beams and the 200 kHz down-looking sonar beam. New information appears on the right and scrolls to the left. Side Beam View, Slanted Layout Depth 200 kHz Sonar History Window Temp: water surface temperature...

  • Page 74: Bird's Eye View

    Bird’s Eye View Bird’s Eye View shows a 3D perspective view of the track and the chart’s land contour from a point above and behind the boat (the eye point). As the boat turns, the eye point moves to follow the boat.
  • Page 75 Bird’s Eye View (Navigating) Bearing: Direction to Destination Waypoint Next Waypoint measured in degrees from North Depth Boat Icon XTE (Cross Track Error): Distance of Boat from Route Route Speed: the measurement of the boat’s progress across a given Off Course Limits distance, and is the speed measurement provided by GPS Cartography Course: the current direction the boat is traveling measured...

  • Page 76: Chart View

    Chart View Chart View shows cartography from the built-in Contour XD™, built-in UniMap™, or an optional SD map for the area surrounding your current position. The cartography is applied to any standard Chart View or Combo view that displays a chart. The current track (also known as the position history or breadcrumb trail) showing where the boat has been, along with saved tracks, waypoints, and the current route (when navigating), are overlaid on the chart.
  • Page 77 Chart View (with Cursor) with optional-purchase Navionics® Cartography Cursor Info Box Track Latitude and Longitude Position of Cursor Boat Icon Distance to Cursor Waypoint Bearing to Cursor Course Projection Line Depth Active Cursor Temp: Water Surface Temperature Decluttered Waypoint icons Speed: Speed of Boat Cartography Course: the current direction the boat is traveling measured in degrees from North...

  • Page 78: Combo Views

    Combo Views Combo Views display two views (or more) on the screen at the same time. You can perform functions for either side of the view, access the X-Press™ Menu, and change the left view display size. The available combo views are shown on the following pages. Combo Views: Functions The Combo Views allow you to observe and control two views at once.

  • Page 79: Side Imaging®/Sonar Combo View (1199Ci Hd Si Only)

    Side Imaging®/Sonar Combo View (1199ci HD SI only) Side/Sonar Combo View shows sonar information and Side Imaging® sonar information in a combination split screen, where the Sonar View is displayed on the left and the Side Imaging® View is displayed on the right. Select an Active Side, and you can adjust the sensitivity, the side beam range, the chart scrolling speed, and the color scheme of the display.

  • Page 80: Chart/Bird's Eye Combo View

    Chart/Bird’s Eye Combo View Chart/Bird’s Eye Combo View shows the Chart and Bird’s Eye views in a combination split screen, where the Bird’s Eye View is displayed on the left and the Chart View is displayed on the right. For more information about each side of this combo view, see Chart View and Bird’s Eye View.

  • Page 81: Chart/Chart Combo View

    Chart/Chart Combo View Chart/Chart Combo View shows two versions of the Chart view in a combination split screen so that you can see the position of the boat on one side while you zoom in or perform other functions on the other. See Chart View for more information. Chart/Chart Combo View (Navigating) Cartography Next Waypoint...

  • Page 82: Chart/Sonar Combo View

    Chart/Sonar Combo View Chart/Sonar Combo View shows both the Chart and Sonar views in a combination split screen, where the Sonar View is displayed on the left and the Chart View is displayed on the right. For more information about each side of this combo view, see Chart View and Sonar View. Chart/Sonar Combo View Depth Cartography...

  • Page 83: Chart/Side Imaging® Combo View (1199Ci Hd Si Only)

    Chart/Side Imaging® Combo View (1199ci HD SI only) Chart/Side Combo View shows chart information and Side Imaging® sonar information in a combination split screen, where the Side Imaging® View is displayed on the left and the Chart View is displayed on the right. For more information about each side of this combo view, see Chart View and Side Imaging®...

  • Page 84: Down Imaging®/Side Imaging® Combo View (1199Ci Hd Si Only)

    Down Imaging®/Side Imaging® Combo View (1199ci HD SI only) Down/Side Combo View shows Down Imaging® and Side Imaging® sonar information in a combination split screen, where the Down Imaging® View is displayed on the left and the Side Imaging® View is displayed on the right. For more information about each side of this combo view, see Down Imaging®...

  • Page 85: Chart/Down Imaging® Combo View (1159Ci Hd Di And 1199Ci Hd Si Only)

    Chart/Down Imaging® Combo View (1159ci HD DI and 1199ci HD SI only) Chart/Down Combo View shows Chart and Down Imaging® information in a combination split screen, where the Down Imaging® View is displayed on the left and the Chart View is displayed on the right.

  • Page 86: Down Imaging®/Sonar Combo View (1159Ci Hd Di And 1199Ci Hd Si Only)

    Down Imaging®/Sonar Combo View (1159ci HD DI and 1199ci HD SI only) Down/Sonar Combo View shows traditional Sonar information on the left and Down Imaging® sonar information on the right. For more information about each side of this combo view, see Down Imaging®...

  • Page 87: Down Imaging®/Side Imaging®/Sonar Combo View (1199Ci Hd Si Only)

    Down Imaging®/Side Imaging®/Sonar Combo View (1199ci HD SI only) Down/Side/Sonar Combo View shows Down Imaging® and traditional Sonar information on the left side of the screen, and Side Imaging® on the right side of the screen. If you use the active cursor on the left side of the screen, a cursor will appear in both the Sonar and Down Imaging®...

  • Page 88: View Orientation

    View Orientation Both Chart and Chart Combo Views allow you to choose the orientation of the view (see Navigation Menu Tab: Chart Orientation). In each orientation, the view pans automatically so that the boat is always centered on the display. To see more of the view when the boat is traveling at the speed you set, see Chart Menu Tab: Vessel Offset and Offset Speed.

  • Page 89: Viewing Cartography

    Viewing Cartography In the Chart and Chart Combo Views, there are several cartography-related functions that you can access using various keys. Panning: Use the 4-WAY Cursor Control key to move the chart around on the display in the direction of the key being pressed. When you do this, a bull’s eye cursor is drawn at the center of the screen and is linked to the boat by a yellow line, even if the boat is off the screen.
  • Page 90 Screen Snapshots and Recording Icons: When a waypoint is created while Screen Snapshot and Recording is active, the waypoint will appear as a snapshot icon or recording icon in chart views. See Views: Snapshot and Recording View for more information. Chart Info: Press the INFO key to get detailed information about the chart.

  • Page 91: Introduction To Navigation

    You can also use the Waypoint Management dialog box to create new waypoints and routes from scratch. You can edit your navigation data and organize it too. This section will get you started. See your Humminbird® Waypoint Management Guide for complete details. Waypoints, Routes, and Tracks...
  • Page 92 Routes link two or more waypoints together to create a path for navigation, and are used in trip planning. You can link individual waypoints together by using the GOTO key. Your Fishing System can store up to 45 routes that can each contain up to 50 waypoints. A route represents your intended navigation and shows the shortest path from each waypoint to the next.

  • Page 93: Open The Waypoint Management Dialog Box

    Open the Waypoint Management Dialog Box The Waypoint Management dialog box allows you to organize your waypoints, routes, and tracks on your Humminbird® control head. Open the Waypoint Management Dialog Box 1. Press the MENU key twice to open the Main Menu.

  • Page 94: What's On The Waypoint Management Dialog Box

    What’s on the Waypoint Management Dialog Box Use the Waypoint Management dialog box to manage your waypoints, routes, and tracks. Use the 4-WAY Cursor Control key to select a waypoint, route, track, group, or menu option. To scroll through the list, press the UP or DOWN Cursor keys. To open a submenu, press the RIGHT Cursor key.

  • Page 95: Save, Edit, Or Delete A Waypoint

    Information: Displays the default group where all new waypoints, routes, and tracks will be saved. In this illustration, Home is the default group. This field also changes to display instructions. Directory: Shows the directory structure and the currently selected group. The illustration shows group GP001 as the selected group.

  • Page 96: Navigate To A Waypoint Or Position

    Delete a Waypoint: Open the Waypoint Management dialog box. Select a Waypoint, and press the RIGHT Cursor key to open the Waypoint submenu. Select Delete, and press the RIGHT Cursor key. To remove the Waypoint from the group, choose Selected. To delete the waypoint from all groups, choose All Instances.
  • Page 97 NOTE: The spacing of the rings on the waypoint target and the spacing of the grid lines on the trolling grid are the same as the length of the scale bar on the left edge of the display. Zooming in or out will decrease or increase the spacing, respectively.
  • Page 98 Chart View with Grid Depth Waypoint Trolling Grid Temp: water surface temperature Waypoint for Grid Speed: speed of boat Course Projection Line Course: the current direction the boat is traveling measured in degrees from North Boat Icon VLT: Voltage Map Scale Cartography Introduction to Navigation...

  • Page 99: Routes

    Routes Save the Current Route: While you are navigating, the current route can be saved. From the Navigation X-Press™ Menu, select Save Current Route, and press the RIGHT Cursor key. Navigation will continue. Create a New Route: Open the Waypoint Management dialog box. Select Options > New > New Route.

  • Page 100: Tracks

    • Choose a Waypoint in a Route, and press the RIGHT Cursor key. Select Reorder, and press the RIGHT Cursor key. To move the waypoint up or down in the route order, press the UP or DOWN Cursor keys. Press the EXIT key to select Save. Press the RIGHT Cursor key to confirm your changes. Changing the Waypoint Order in a Route (two options) Select Reverse OR Select a Waypoint>...

  • Page 101: Edit Your Waypoints, Routes, Tracks, And Groups

    NOTE: The Edit Waypoint dialog box is also available when you select a waypoint from the Navigation X-Press™ Menu. NOTE: See your Humminbird® Waypoint Management Guide for more information about groups and the other great features of the Waypoint Management dialog box.
  • Page 102 Edit a Waypoint, Route, Track, or Group 1. Open the Waypoint Management dialog box. 2. Open the Submenu: Use the 4-WAY Cursor Control key to select a waypoint, route, track, or group. Press the RIGHT Cursor key to open the submenu. 3.

  • Page 103: Man Overboard (Mob) Navigation

    Man Overboard (MOB) Navigation As soon as you know that you have a man overboard (MOB), you should activate MOB navigation to maximize the chances for a successful rescue. MOB navigation allows you to create an MOB waypoint to locate the point at which your man went overboard and the relation of the boat to that point.
  • Page 104 MOB Navigation Depth Position where Man Overboard was activated XTE (Cross Track Error): Distance of Boat from Route Elapsed Time since MOB was activated Speed: speed of boat MOB Waypoint Course: the current direction the boat is traveling measured Target surrounding MOB Waypoint in degrees from North Course Projection Line Bearing: Direction to Destination Waypoint measured in...

  • Page 105: The Menu System

    The Menu System The Menu System is divided into easy-to-use menu modules as follows: • Start-Up Options Menu: Press the MENU key during the power on sequence to view the Start-Up Options Menu. From the Start-Up Options Menu, you can choose the following Fishfinder Modes: Normal, Simulator, and System Status.

  • Page 106: Start-Up Options Menu

    Start-Up Options Menu Press the MENU key during the power on sequence to view the Start-Up Options Menu, and select one of the modes described on the following pages. Also, see Power On for more information. Start-Up Options Menu Normal Use Normal for on-the-water operation with a transducer connected.

  • Page 107: Simulator

    Simulator Use Simulator to learn how to use your Fishing System before taking your boat on the water. The Simulator is a very powerful tool that provides a randomly-updated display which simulates on the water operation. Simulator We recommend going through this manual while using the Simulator, since all of the menus function and affect the display in the same way as they would in Normal operation.

  • Page 108: System Status

    System Status Use System Status to view system connections and to conduct a unit self-test. After you select System Status from the Start-Up Options Menu, press the VIEW key to display the following options: • Self Test • Accessory Test •...

  • Page 109: Accessory Test

    Accessory Test lists the accessories connected to the system. Accessory Test Screen NOTE: The speed accessory will be detected only if the paddlewheel has moved since your Fishing System was powered up. Start-Up Options Menu...

  • Page 110: Gps Diagnostic View

    GPS Diagnostic View shows a sky chart and numerical data from the GPS receiver. The sky chart shows the location of each visible GPS satellite with its satellite number and a signal strength bar. A dark gray bar indicates that the satellite is being used to determine your current position. A light gray bar indicates that the satellite is being monitored, but is not yet being used.

  • Page 111: X-Press™ Menu

    X-Press™ Menu The X-Press™ Menu provides a shortcut to your most frequently-used settings. The options provided on the X-Press™ Menu correspond with the current view. For example, if you are in a Sonar View and press the MENU key once, the Sonar X-Press™ Menu will display. X-Press™...

  • Page 112: Main Menu

    Main Menu The Main Menu provides the standard set of menu options, including the settings that are changed less frequently. The Main Menu is organized under the following tabs to help you find a specific menu item quickly: Alarms, Sonar, Navigation, Chart, Setup, Views, and Accessories.

  • Page 113: Quick Tips For The Main Menu

    Quick Tips for the Main Menu • From any menu option on a menu tab, press the EXIT key to jump directly to the top of the tab. • From the bottom of a menu tab, press the DOWN Cursor key to jump directly to the top of the tab.

  • Page 114: User Mode (Normal Or Advanced)

    Advanced Mode is provided for users who want the highest level of control over the Fishing System. Several menu settings are added to the Main Menu when the User Mode is changed to Advanced. Advanced mode is the default setting when you first power on your Humminbird® Fishing System.
  • Page 115 1199ci HD SI Sonar Tab, Normal Mode 1199ci HD SI Sonar Tab, Advanced Mode Menu Quick Tips...

  • Page 116: Sonar X-Press™ Menu

    NOTE: The selected transducer also influences the menu options. See Sonar Menu Tab: Connected Transducer for more information. NOTE: Menu options are determined by your Humminbird® model. See the following pages for full menu descriptions. Sonar X-Press™ Menu Sonar X-Press™ Menu...

  • Page 117: Cancel Navigation (Only When Navigating)

    Cancel Navigation (only when Navigating) Settings: Press the RIGHT Cursor key and follow screen instructions. Cancel Navigation discards the current route and exits Navigation Mode. This menu option will only appear when you are currently navigating a route. This will not delete a previously-saved route.

  • Page 118: Sensitivity

    Sensitivity Settings: Low = 1, High = 20; Default = 10 Sensitivity controls how much detail is shown on the display and will adjust the sensitivity of all sonar frequencies. Decrease the sensitivity to eliminate the clutter from the display that is sometimes present in murky or muddy water. If Sensitivity is adjusted too low, the display may not show many sonar returns that could be fish.

  • Page 119: Lower Range

    The available Upper Range settings are determined by your Humminbird® model as follows: • 1159ci HD: 0 to 1490 ft, 0 to 497 m (International Models only); Default = 0 • 1159ci HD DI: 0 to 1490 ft, 0 to 497 m (International Models only); Default = 0 •...

  • Page 120: Quad Layout (With Optional-Purchase Quadrabeam Plus™ Transducer, Side Beam View Only)

    Quad Layout (with optional-purchase QuadraBeam PLUS™ Transducer, Side Beam View only) Settings: Default, Classic, Slanted; Default = Default Quad Layout allows you to choose how sonar information is displayed in the Side Beam View. The Side Beam View displays sonar data from the left and right 455 kHz beams, as well as the 200 kHz down-looking beam.

  • Page 121: Side Imaging® X-Press™ Menu (Side Imaging® Views Only [1199Ci Hd Si])

    Side Imaging® X-Press™ Menu (Side Imaging® Views only [1199ci HD SI]) The Side Imaging® X-Press™ Menu provides a shortcut to your most frequently-used settings. Press the MENU key once while in any of the Side Imaging® Views to access the Side Imaging®...

  • Page 122: Cancel Navigation (Only When Navigating)

    Cancel Navigation (only when Navigating) Settings: Press the RIGHT Cursor key and follow screen instructions. Cancel Navigation discards the current route and exits Navigation Mode. This menu option will only appear when you are currently navigating a route. This will not delete a previously-saved route.

  • Page 123: Si Enhance

    Decrease the SI Sensitivity to eliminate the clutter from the display that is sometimes present in murky or muddy water. If SI Sensitivity is adjusted too low, the display may not show many sonar returns that could be fish. SI Enhance Settings: Press the RIGHT Cursor key.

  • Page 124: Si Range

    SI Range Settings: Auto, 6 to 360 feet, or 2 to 120 meters [International Models only]; Default = 150 feet, 50 meters SI Range sets the deepest range that will be displayed in the Side Imaging® views. The range must be set manually. Choose a low range number to focus on a shorter distance of the water column and see greater detail on the screen.

  • Page 125: Down Imaging® X-Press™ Menu (Down Imaging® Views Only [1159Ci Hd Di And 1199Ci Hd Si])

    NOTE: Menu options can be expanded or simplified by setting the User Mode to Advanced or Normal. See Main Menu: User Mode for details. NOTE: Menu options are determined by your Humminbird® model. See the following pages for full menu descriptions. Down Imaging® X-Press™ Menu...

  • Page 126: Cancel Navigation (Only When Navigating)

    Cancel Navigation (only when Navigating) Settings: Press the RIGHT Cursor key and follow screen instructions. Cancel Navigation discards the current route and exits Navigation Mode. This menu option will only appear when you are currently navigating a route. This will not delete a previously-saved route.

  • Page 127: Di Enhance

    DI Enhance Settings: Press the RIGHT Cursor key. DI Enhance allows you to adjust your Down Imaging® View in the following categories: Sensitivity, Contrast, and Sharpness. Whether you’re searching the Down Imaging® data for fish or certain bottom contour, the most effective settings will vary with the situation.

  • Page 128: Lower Range

    Lower Range Settings: Auto to 1500 feet, Auto to 500 meters [International Models only]; Default = Auto Lower Range sets the deepest depth range that will be displayed by the unit. Auto: The Lower Range will be adjusted by the unit to follow the bottom automatically. Auto is the default setting.

  • Page 129: Navigation X-Press™ Menu

    NOTE: To see the Navigation X-Press™ Menu in a Combo View, change the Active Side setting to the side you want to adjust. Navigation X-Press™ Menu See Introduction to Navigation and the Humminbird® Waypoint Management Guide for more information. Navigation X-Press™ Menu...

  • Page 130: Cancel Navigation (Only When Navigating)

    Cancel Navigation (only when Navigating) Settings: Press the RIGHT Cursor key and follow screen instructions. Cancel Navigation discards the current route and exits Navigation Mode. This menu option will only appear when you are currently navigating a route. This will not delete a previously-saved route.

  • Page 131: Waypoint [Name] (Only With An Active Cursor On A Waypoint)

    You can move the cursor onto an existing waypoint and press the MENU key once, or use Cursor to Waypoint to select a waypoint from the saved waypoints list. NOTE: See Introduction to Navigation and the Humminbird® Waypoint Management Guide for more information.

  • Page 132: Clear Current Track

    Clear Current Track Settings: Press the RIGHT Cursor key and follow screen instructions. Clear Current Track allows you to clear the current track on the display and start a new track at the present position. Save Current Route (only when Navigating) Settings: Press the RIGHT Cursor key and follow screen instructions.

  • Page 133: Waypoint [Name] (Most Recently-Created Waypoint)

    You must have pressed the MARK key at least once since you last powered up the Fishfinder for this menu option to appear. NOTE: See Introduction to Navigation and the Humminbird® Waypoint Management Guide for more information. The Waypoint Submenu includes the following menu options: Edit opens the Edit Waypoint dialog box so that you can edit the selected waypoint.

  • Page 134: Snapshot And Recording X-Press™ Menu (Snapshot And Recording View Only)

    Snapshot and Recording X-Press™ Menu (Snapshot and Recording View only) The Snapshot and Recording X-Press™ Menu provides access to the snapshot management and sonar recording functions. Press the MENU key once while in the Snapshot and Recording View to access the Snapshot and Recording X-Press™...

  • Page 135: Cancel Navigation (Only When Navigating)

    Cancel Navigation (only when Navigating) Settings: Press the RIGHT Cursor key and follow screen instructions. Cancel Navigation discards the current route and exits Navigation Mode. This menu option will only appear when you are currently navigating a route. This will not delete a previously-saved route.

  • Page 136: Delete All Recordings (Optional-Purchase Sd Memory Card, Snapshot And Recording View Only)

    Delete All Recordings (optional-purchase SD Memory Card, Snapshot and Recording View only) Settings: Press the RIGHT Cursor key and follow screen instructions. Delete All Recordings allows you to delete all the recordings at once. This menu option is only available when an optional-purchase SD memory card is installed and Snapshot and Recording View is on the screen.

  • Page 137: Stop Playback (Optional-Purchase Sd Memory Card Only)

    NOTE: Sonar chart speed is increased during Fast Forward and reversed during Rewind. This may result in a reduced quality sonar image, since at higher speeds, not every sonar return can be processed. Stop Playback (optional-purchase SD Memory Card only) Settings: Press the RIGHT Cursor key to activate.

  • Page 138: Alarms Menu Tab

    Alarms Menu Tab From any view, press the MENU key twice to access the Main Menu System. The Alarms tab will be the default selection. NOTE: When an alarm is triggered, you can silence it by pressing any key. The alarm will be silenced, and will not be triggered again until a new instance of the alarm condition is detected.

  • Page 139: Depth Alarm

    Depth Alarm Settings: Off, 1 to 100 feet, or 0.5 to 30 meters [International Models only]; Default = Off Depth Alarm sounds when the depth becomes equal to or less than the menu setting. Fish ID Alarm Settings: Off, All, Large/Medium, Large; Default = Off Fish ID Alarm sounds when the Fishfinder detects fish that correspond to the alarm setting.

  • Page 140: Aux. Temp Alarm (With Optional-Purchase Temp. Probe Or Temp/Speed Only)

    Aux. Temp Alarm (with optional-purchase Temp. probe or Temp/Speed only) Settings: Off, 33-120 [Fahrenheit], 0-50 [Celsius]; Default = Off Aux Temp Alarm sounds when the water temperature from the Paddlewheel/Temperature Probe detected by the Fishing System reaches the Aux Temp Alarm setting, which is set in degrees Fahrenheit or Celsius [International Models only].

  • Page 141: Arrival Alarm

    Arrival Alarm Settings: Off, 25 to 3000 feet, 10 to 1000 meters [International Models only]; Default = 150 feet, 50 meters Arrival Alarm sounds when the boat has either exceeded the distance to the destination waypoint, or has entered the Arrival Alarm Circle, based on the menu setting when navigating. Arrival Alarm allows you to set how close the boat must be to the destination waypoint before the Arrival Alarm will sound.

  • Page 142: Timer Setup

    Timer Setup Settings: Press the RIGHT Cursor key to open the dialog box. Timer Setup allows you to open a dialog box to create settings for the Timer. You can also start the countdown from this dialog box. When the Timer is started, the clock counts down from the amount of time set in the dialog box.

  • Page 143: Sonar Menu Tab

    NOTE: Menu options can be expanded or simplified by setting the User Mode to Advanced or Normal. See Main Menu: User Mode for details. NOTE: Menu options are determined by your Humminbird® model. See the following pages for full menu descriptions. NOTE: The selected transducer also influences the menu options.

  • Page 144: Beam Select

    Settings: Various, see below. Beam Select sets which sonar returns from the transducer will be displayed on the screen. The available beam frequencies are determined by your Humminbird® model. DualBeam PLUS™ models (1159ci HD) and Side Imaging® models (1199ci HD SI) allow you to choose 200/83 kHz, 200 kHz, or 83 kHz (Default = 200 kHz).

  • Page 145: Imaging Frequency (1159Ci Hd Di And 1199Ci Hd Si Only)

    • When set to 200 kHz, only the returns from the 200 kHz narrow beam will be displayed in the Sonar View and the Sonar Zoom View. The Split Sonar View will continue to display returns from both beams in their respective windows. The RTS Window™ in the Sonar View will display the returns from the 200 kHz narrow beam.

  • Page 146: Surface Clutter

    Surface Clutter Settings: Low = 1 to High = 10; Default = 5 Surface Clutter adjusts the filter that removes surface clutter noise caused by algae and aeration. The lower the setting, the less surface clutter will be displayed. Surface Clutter SwitchFire®...

  • Page 147: Fish Id

    Fish ID+™ Settings: Off, On; Default = Off Fish ID+™ uses advanced signal processing to interpret sonar returns and will display a Fish Symbol when very selective requirements are met. When a fish is detected, a fish icon and its depth are displayed above the return that has been classified as being a fish.

  • Page 148: Fish Id Sensitivity

    Fish ID Sensitivity Settings: Low = 1, High = 10; Default = 5 Fish ID Sensitivity adjusts the threshold of the Fish ID+™ detection algorithms. Selecting a higher setting allows weaker returns to be displayed as fish. This is useful for identifying smaller fish species or baitfish.

  • Page 149: Sonar Colors

    Sonar Colors Settings: Gray, Green, Inverse, Original Palette, Palette 1, Palette 2, Palette 3; Default = Palette 1 Sonar Colors allows you to select which color palette you would like to use for the display. The palette you choose will be applied to the Sonar Views. •...

  • Page 150: 83 Khz Sensitivity (Advanced, Dualbeam Plus™ Sonar Only [1159Ci Hd And 1199Ci Hd Si])

    Fishing System, User Mode is set to Advanced (see Setup Menu Tab: User Mode), and Connected Transducer is set to Quad Beam (see Sonar Menu Tab: Connected Transducer). NOTE: Visit our Web site at humminbird.com to order this accessory online or contact our Customer Resource Center at 1-800-633-1468. Sonar Menu Tab...

  • Page 151: Depth Lines (Advanced)

    Depth Lines (Advanced) Settings: Off, On; Default = On Depth Lines divide the display into four equal sections which are separated by three horizontal depth lines. The depth of each line is displayed along the depth scale. You can turn Depth Lines On or Off.

  • Page 152: Noise Filter (Advanced)

    SI Range Lines (with Contour Mode On) SI Range Lines Noise Filter (Advanced) Settings: Off, Low, Medium, High 1, High 2, High 3; Default = Low Noise Filter adjusts the sonar Noise Filter to limit interference on the display from sources such as your boat engine, turbulence, or other sonar devices.

  • Page 153: Water Type (Advanced)

    2D Element in order to display depth in the digital readout window. The 2D Element setting should not be used with a Down Imaging® transducer. NOTE: Visit our Web site at humminbird.com to determine which accessory transducers are compatible with your Humminbird® Fishing System, or contact our Customer Resource Center.

  • Page 154: Connected Transducer

    • 1199ci HD SI: Hi-Def Sidescan is the default selection. The Compact Sidescan, Sidescan, QuadraBeam PLUS™, Dual Beam, Dual 50/200 kHz, and Universal Sonar require a separate purchase. NOTE: To purchase transducers, visit our Web site at humminbird.com or call our Customer Resource Center at 1-800-633-1468. DI Pings (Advanced, Down Imaging®...

  • Page 155: Color Bar

    DI Pings Down Imaging® beams 45° 800kHz 75° 455kHz 16° 455kHz 28° Sonar 200kHz beams 75 Degree Total Coverage NOTE: See How Sonar Works: Down Imaging® Sonar for more information. Color Bar Settings: Off, On; Default = On Color Bar allows you to display or suppress the display of the color bar shown in the full screen Sonar View.

  • Page 156: Navigation Menu Tab

    NOTE: Menu options can be expanded or simplified by setting the User Mode to Advanced or Normal. See Main Menu: User Mode for details. NOTE: Menu options are determined by your Humminbird® model. See the following pages for full menu descriptions. Navigation Menu (Advanced)

  • Page 157: Current Track

    You can also edit waypoint, route, and track information. Your navigation data can be saved into groups, sorted, copied, and exported to HumminbirdPC™. See Introduction to Navigation and the Humminbird® Waypoint Management Guide for more information. Navigation Menu Tab...

  • Page 158: Waypoint Settings

    Settings dialog box to set the waypoint icon category and the waypoint icon for all new waypoints. See Introduction to Navigation: Edit your Waypoints, Routes, Tracks, and Groups and the Humminbird® Waypoint Management Guide for details. The Waypoint Settings dialog box includes the following options: Icon Category allows you to select a waypoint icon category (All, Geometry, Alerts, Supplies, Navigation, Recreation, Fish, Environment).

  • Page 159: Casting Rings

    Casting Rings Settings: Off to 150 feet, 0 to 50 meters; Default = Off Casting Rings allows you to display a circle around each waypoint on the Chart View. This menu option sets the distance that the Casting Ring will be displayed from the waypoint. Select Off to hide the Casting Rings.

  • Page 160: Trolling Grid Rotation

    Trolling Grid Rotation Settings: 0° to 89°, Default = 0° Trolling Grid Rotation allows you to set the orientation of the trolling grid in degrees, where a setting of 0° displays a standard North, South, East, West alignment. See Introduction to Navigation: Add a Waypoint Target or Trolling Grid for information.

  • Page 161: Map Datum (Advanced)

    Map Datum (Advanced) Settings: Various, Default = WGS 84 Map Datum allows you to change the map coordinate system used by the Fishing System to match those of a paper map. North-Up Indicator Settings: On, Off; Default = Off North-Up allows you to display the North-Up icon on the screen to indicate the direction of True North.

  • Page 162: Gps Receiver Override (Advanced)

    GPS Receiver Override (Advanced) Settings: Internal, External, Auto; Default = Auto GPS Receiver Override allows you to set which GPS receiver to use if you have multiple GPS receivers plugged into the system. These multiple GPS receivers may be internal or external. If you select Auto, your unit will select a GPS receiver automatically.

  • Page 163: Chart Menu Tab

    Chart Menu Tab Press the MENU key twice to access the Main Menu and then press the RIGHT Cursor key until the Chart tab is selected. NOTE: Menu options can be expanded or simplified by setting the User Mode to Advanced or Normal. See Main Menu: User Mode for details.

  • Page 164: Lat/Lon Grid

    (see SD Memory Card Slots: Add Maps to Your Fishing System). NOTE: The SD Memory Cards require a separate purchase. For more information, visit our Web site at humminbird.com or contact our Customer Resource Center at 1-800-633-1468. Set Simulation Position...

  • Page 165: Clear Map Offset (Advanced)

    NOTE: The cursor must be active in order for this procedure to work. If the cursor was not active before you began this procedure, an error message will appear. Exit the menu, set the cursor, then try again. NOTE: This feature does not apply to LakeMaster® charts. Clear Map Offset (Advanced) Settings: Follow screen instructions to activate.

  • Page 166: Map Borders

    Map Borders, shown with optional-purchase Navionics® Cartography with Custom Chart Layers Map Borders Isolated Dangers: Boat Ramps Bridge Coastline Anchorage Area Recom. Route Restricted Area Drying Lines Navaids Map Borders Settings: Hidden, MMC/SD Only, All Visible; Default = MMC/SD Only Map Borders allows you to display or hide map borders.

  • Page 167: Auto Range (Advanced)

    Auto Range (Advanced) Settings: On, Off; Default = Off Auto Range, when turned on, sets the chart scale to the lowest range so that only the boat icon and the next waypoint in the route are displayed. See Views: Viewing Cartography for more information.

  • Page 168: Depth Colors (Optional-Purchase Lakemaster® Charts Only)

    Depth Colors (optional-purchase LakeMaster® charts only) Settings: Off, 1 - 10; Default = Off Depth Color sets the depth shading in the Chart views to Off or Shaded. Depth Highlight (optional-purchase LakeMaster® charts only) Settings: Off, 1 to 180 feet, 1 to 30 fathoms, 1 to 60 meters (International Models only);...

  • Page 169: Shallow Water Highlight (Optional-Purchase Lakemaster® Charts Only)

    Shallow Water Highlight (optional-purchase LakeMaster® charts only) Settings: 0 to 30 feet, 0 to 5 fathoms, 0 to 10 meters (International Models only); Default = 0 Shallow Water Highlight allows you to select a minimum shallow depth setting so that the depth is highlighted in red in the Chart Views.

  • Page 170: Setup Menu Tab

    Setup Menu Tab From any view, press the MENU key twice to access the tabbed Main Menu, then press the RIGHT Cursor key until the Setup tab is selected. NOTE: Menu options will vary depending on which accessories are attached to the unit. NOTE: Menu options can be expanded or simplified by setting the User Mode to Advanced or Normal.

  • Page 171: Units - Depth

    Units - Depth Settings: Domestic Models: Feet, Fathoms; International Models: Meters, Feet, Fathoms; Default = Feet/Meters Units - Depth selects the units of measure for all depth-related readouts. Units - Temp (International Models only) Settings: Celsius, Fahrenheit; Default = Celsius Units - Temp selects the units of measure for all temperature-related readouts.

  • Page 172: Triplog Reset (With Speed Input Only)

    NOTE: It is important to back up your control head’s data files periodically. Data files should also be saved to your PC before restoring the unit’s defaults or updating the software. See your Humminbird® online account at humminbird.com and the Waypoint Management guide.

  • Page 173: Select Readouts (Advanced, Non-Navigation Mode)

    Select Readouts (Advanced, Non-navigation Mode) Select Readouts sets individual digital readouts on all the views that can display readouts. This feature allows you to select what information will be displayed in each of a variable number of fixed-position readouts arranged at the bottom of the screen. To leave the data window blank, select Off.
  • Page 174 Each readout position can be empty or contain one of the following: 5 Selectable Readouts; Non-Navigation Mode Aux. Temp The current detected water temperature from an optional-purchase Temperature Probe or Temp/Speed accessory. Course Course is the current direction the boat is traveling measured in degrees from North (i.e. 321°, where 000° is North, 090°...

  • Page 175: Select Nav Readouts (Advanced, Navigation Mode)

    Select Nav Readouts (Advanced, Navigation Mode) Select Nav Readouts sets the individual digital readouts that will be used only during navigation. This feature allows you to select what information will be displayed in each of a variable number of fixed-position readouts arranged at the bottom of the screen on various views.
  • Page 176 Each readout position can either be empty or contain one of the items from the following table: 5 Selectable Readouts; Navigation Mode Bearing Bearing is the direction to a destination waypoint measured in degrees from North (i.e. 321°, where 000° is North, 090°...

  • Page 177: Depth Offset (Advanced)

    5 Selectable Readouts; Navigation Mode WPTnext/TTG/DTG Waypoint Next/Time To Go/Distance to Go. Waypoint Next is the next waypoint on the route. Time To Go is the estimated time required to reach the next waypoint on the route. TTG is calculated using the SOG and DTG. Distance To Go is the distance between the current position of the boat and the next waypoint on the route.

  • Page 178: Local Time Zone (Advanced)

    Local Time Zone (Advanced) Settings: Various; Default = EST [UTC-5] - Eastern Standard Time Local Time Zone selects your time zone in reference to the time reported by the GPS receiver when Time+Date is selected as a Digital Readout (see Setup Menu Tab: Select Readouts). Daylight Saving Time (Advanced) Settings: Off, On;...

  • Page 179: Digits Format (Advanced)

    Digits Format (Advanced) Settings: Small tenths, Large tenths, No tenths; Default = Large tenths Digits Format adds a tenth decimal place to the readouts such as Temperature and Depth. Use the settings to change the display of the decimal place or remove it from the digital readouts. Examples of the different settings are displayed below.

  • Page 180: Demonstration

    Demonstration Settings: Off, Visible; Default = Visible Demonstration controls whether the Demonstration Mode is visible or off. The Demonstration Mode appears on the screen if you don’t press any keys during the warning screen at power up. Menu settings cannot be saved in Demonstration (see Power On and Start-Up Options Menu). Sound Control Settings: No Sounds, Alarms Only, All Sounds;...

  • Page 181: Views Menu Tab

    Views Menu Tab From any view, press the MENU key twice to access the tabbed Main Menu, then press the RIGHT Cursor key until the Views tab is selected. This menu tab allows you to set the available views to hidden or visible in the view rotation.

  • Page 182: Accessories Menu Tab

    See the Operations Manual that comes with your accessory for detailed information. Accessories Menu (no accessories attached) Accessories Menu (with accessories attached) NOTE: To purchase accessories or any additional equipment for your control head configuration, go to humminbird.com or contact our Customer Resource Center at 1-800-633-1468. Accessories Menu Tab...

  • Page 183: Screen Snapshot (Optional-Purchase Sd Cards Only)

    Screen Snapshot (optional-purchase SD Cards only) Settings: Off, On; Default = Off Screen Snapshot activates the screen snapshot function. When Screen Snapshot is enabled, pressing the MARK key creates a saved screen snapshot on the optional-purchase SD card installed in your unit’s card slot. All active menus, dialog boxes, warnings and messages are captured and saved automatically.
  • Page 184 As target information is received, the information is displayed in the Chart Views. In Bird’s Eye View, only the target position is displayed. • Vessel Icons identify the type of target. • Alarm & Red Vessel Icon identify a target that has exceeded the CPA (Closest Point of Approach) setting.
  • Page 185 AIS Submenu: The AIS submenu allows you to track targets, receive alerts when targets are within the distance you set, and display targets in Chart Views. In Bird’s Eye View, only the position will be displayed. To change settings in the AIS Submenu: Highlight AIS is in the Accessories MENU Tab, and press the RIGHT Cursor key to access the AIS Submenu.
  • Page 186 AIS Target List Accessories Menu Tab...

  • Page 187: Maintenance

    Maintenance Your Humminbird® fishfinder is designed to provide years of trouble free operation with very little maintenance. Use the following procedures to ensure your Humminbird® continues to deliver top performance. Control Head Maintenance It is important to consider the following precautions when using your Humminbird® control head: •...

  • Page 188: Troubleshooting

    1100 Series™ Doesn’t Power Up If your 1100 Series™ doesn’t power up, use the Installation section of this manual for specific confirmation details, making sure that: • the power cable is properly connected to the 1100 Series™ control head •...

  • Page 189: Display Problems

    Display Problems There are several main conditions or sources of possible interference that may cause problems with the quality of the information displayed on the control head. Look in the following table for some symptoms of display problems and possible solutions: Problem Possible Cause The control head loses...

  • Page 190: Finding The Cause Of Noise

    Finding the Cause of Noise Electrical noise usually affects the display with many black dots at high speeds, and high sensitivity readings. One or more of the following sources can cause noise or interference: Possible Source of Noise Isolation Other electronic devices Turn off any nearby electronic devices to see if the problem goes away, then turn them on one at a time to see if the noise re-appears.

  • Page 191: Operating Frequency

    IPX Rating ....IP67 Waterproof/Submersible @ 1m for 30 minutes and dust tight NOTE: Product specifications and features are subject to change without notice. NOTE: Humminbird® verifies maximum stated depth in saltwater conditions, however actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition and slope.
  • Page 192 IPX Rating ....IP67 Waterproof/Submersible @ 1m for 30 minutes and dust tight NOTE: Product specifications and features are subject to change without notice. NOTE: Humminbird® verifies maximum stated depth in saltwater conditions, however actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition and slope.
  • Page 193 IPX Rating ....IP67 Waterproof/Submersible @ 1m for 30 minutes and dust tight NOTE: Product specifications and features are subject to change without notice. NOTE: Humminbird® verifies maximum stated depth in saltwater conditions, however actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition and slope.
  • Page 194 IPX Rating ....IP67 Waterproof/Submersible @ 1m for 30 minutes and dust tight NOTE: Product specifications and features are subject to change without notice. NOTE: Humminbird® verifies maximum stated depth in saltwater conditions, however actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition and slope.
  • Page 195 Mailing Address Humminbird® serial number (Your Humminbird ® unit must be registered at humminbird.com/support/productregistration.aspx.) Shipping and Handling: We can only accept requests that include a money order in the amount of $9.99 to cover shipping and handling. Please allow 4-6 weeks for processing.
  • Page 196 *NOTE: A copy of the Linux operating system is not required to upgrade your fishing system. The Humminbird® application software and control head include a separate service warranty. Please see humminbird.com and the separate warranty card included with your unit for details.
  • Page 197 The unintentional, external sound waves that interfere with the optimal operation of sonar. Noise appears as random “dots“ on the display and is caused by a variety of sources. Many Humminbird® products have a Noise Filter menu setting that allows the user to clear the screen of noise that is difficult to eliminate (also, see Troubleshooting).
  • Page 198 A very fast sonar update rate collects more information and provides a more detailed image of the bottom, fish, and structure. Many Humminbird® units operate at up to 40 times per second when in single frequency operation. Due to the limitation of the speed of sound in water, the update rate begins to slow as depth increases to deeper than 50 feet.
  • Page 199 (i.e. two fish hanging very close, or a fish hanging very close to structure). Humminbird® fishfinders provide a very good 2 1/2 inches of target separation in shallower than 100 feet of depth. Target separation decreases as depth increases due to the need for longer Pulse Pulse Width Width to achieve greater depth.
  • Page 200 Acquisition Time The length of time that a GPS receiver typically takes to determine a position from at least three satellites. Humminbird® GPS receivers provide very fast acquisition times (under one minute), permitting users to get out on the water faster.
  • Page 201 Speed Over Ground is optimal for navigation because accurate destination times can be derived from this measurement. Humminbird® products allow for input and display of both speed measurements.
  • Page 202 This can include a marker buoy, dock, fishing hole, or anywhere else the user may want to return to. Humminbird® products offer the ability to name and assign a symbol to the saved location. Depth, Date, and Time of Day when the waypoint was created is also saved.

  • Page 203: Transducer Installation

    Appendix A Transducer Mounting Template: XHS 9 HDSI 180 T Remove and use for Transducer Installation Use 5/32” drill bit. Drill Drill Drill PLACE EITHER CORNER ON DEADRISE ANGLE NOTE: If you are reproducing or printing this template from an electronic file, start with the following print settings: Scale = None, Paper = 8.5 x 11 inches, Layout = Portrait.

  • Page 204: Contact Humminbird

    Contact Humminbird® Contact the Humminbird® Customer Resource Center in any of the following ways: By Telephone (Monday - Friday 8:00 a.m. to 4:30 p.m. Central Standard Time): 1-800-633-1468 By e-mail (typically we respond to your e-mail within three business days): service@humminbird.com...
