INSTALLATION INSTRUCTIONS
HB0091
EC62 SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 12 AND 13.
Broan-NuTone Canada Inc.; Mississauga, Ontario www.broan.ca
877-896-1119
www.broan.ca
REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register
SV08970 rev. B

Advertisement

Table of Contents
loading

Related Manuals for Broan EC62 SERIES

Summary of Contents for Broan EC62 SERIES

  • Page 1 INSTALLATION INSTRUCTIONS HB0091 EC62 SERIES INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 12 AND 13. Broan-NuTone Canada Inc.; Mississauga, Ontario www.broan.ca 877-896-1119 www.broan.ca REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register...

  • Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following

    To reduce the risk of fire and electrical shock, the Broan Elite EC62 Series models must be installed only with their own built-in blower(s). Other blowers cannot be substituted.
  • Page 3 - EC62 SERIES POWER PACK SYSTEM - ODEL ODEL ODEL ODEL 8” R 10” R OUND APACITY OUND NOT INCLUDED NOT INCLUDED NOT INCLUDED NOT INCLUDED ODEL 8” R OUND 10” R OUND DJUSTABLE LBOW DJUSTABLE LBOW NOT INCLUDED NOT INCLUDED...

  • Page 4: Prepare The Installation

    1. PREPARE THE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. Make sure that the following items are included: - Power Pack - Accessories: • 2 Filters • 2 Filter knobs with screws, taped inside the hood •...

  • Page 5: Custom Hood Preparation

    3. CUSTOM HOOD PREPARATION WARNING When building a custom hood, always follow all applicable construction codes and standards. The custom hood must be positively secured to wall studs or other wooden framework behind the drywall. Make sure it is capable of supporting its own weight and the weight of the power pack. Failure to do so may cause personal injury or damage to countertop or cooktop.

  • Page 6: Remove Filter

    4. INSTALL CUSTOM HOOD LINER (OPTIONAL) The liners are specially designed to protect the exterior base of the custom hood. To order, refer to the table below to find the right liner model number according to the width of the custom hood nominal width. To view specific model information, including depths for each liner models, visit www.broan.ca or contact Technical Support (phone number listed on front cover).
  • Page 7 7. UNPLUG THE BLOWER(S) Unplug the blower(s) (one or two, depending on model) from the front panel. HE01105 8. REMOVE WIRING COVER AND FRONT PANEL Using a Robertson or a Phillips no. 2 screwdriver, remove both wiring cover retaining screws (A). Detach it from the power pack and set aside with its screws. Then, remove both sides screws (B) retaining the front panel to the power pack.

  • Page 8: Install The Adapter/Damper

    11. INSTALL THE ADAPTER/DAMPER (SINGLE BLOWER MODEL ONLY) ERTICAL ISCHARGE NSTALLATION Using two (2) no. 8 x 3/8’’ screws provided in parts bag, secure the adapter/damper to the top of the power pack. Remove tape from damper flap. Seal the adapter to the power pack using metal foil duct tape. HO0137 ORIZONTAL ISCHARGE...

  • Page 9: Connect Wiring

    13. CONNECT WIRING (ALL MODELS) WARNING Risk of electrical shock. Electrical wiring must be done by qualified personnel in accordance with all applicable codes and standards. Before connecting wires, switch power off at service panel and lock service disconnecting means to prevent power from being switched on accidentally. Position the power pack below the installed custom hood.
  • Page 10 15. INSTALL THE POWER PACK CAUTION Take care not to kink ducting or pinch electrical cable when installing the power pack. LASPING PRINGS Lift the power pack in custom hood until the bottom of the clasping springs (2 per side) rests on the top of the custom hood base (grey zone in illustration beside). HD0370 From inside the power pack, using provided no.

  • Page 11: Reinstall The Blower

    17. REINSTALL THE BLOWER (SINGLE BLOWER MODEL, HORIZONTAL DISCHARGE INSTALLATION ONLY) The single blower power pack is factory shipped for a vertical discharge installation. For a horizontal discharge installation, the blower must be flipped. IGHT Using a 5/16” socket, or a Phillips no. 2 or a OUNTING CREW OUNTING...

  • Page 12: Light Bulbs

    19. REINSTALL FILTER (CONTINUED) Rest rear filters edge on filter springs (A) in the power pack. Using knob, tilt up the filters into position. Make sure filter tabs (B) are securely engaged in power pack front edge after installation. HD0373 20.

  • Page 13: Operation

    ONE YEAR LIMITED WARRANTY FOR BROAN ELITE PRODUCTS Broan-NuTone Canada (Broan-NuTone) warrants to the original consumer purchaser of Broan Elite products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

  • Page 14: Service Parts

    24.SERVICE PARTS EC621306SS EC622309SS & EC622301SS HL0135 . (P OWER ODEL ART NO ESCRIPTION EC621306SS EC622309SS EC622301SS SV13296 3¼” 10” DAPTER AMPER SV08543 8” R DAPTER AMPER OUND SV08541 10” R DAPTER OUND SV08342 25 µF APACITOR SV08964 LECTRONIC ONTROL WITH HROMED UTTONS AND SV16569...
