- Page 1 INSTALLATION INSTRUCTIONS HB0073 E60000 SERIES INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14.
-
Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following
10. To reduce the risk of fire and electric shock, the Broan Elite E60E Series hood must be installed with one Broan exterior blower model 331H, 332H, 335 or 336; or one Broan in-line blower model HLB3, HLB6, HLB9 ou HLB11. - Page 3 E60000 SERIES RANGE HOOD SYSTEM - INTERNAL BLOWERS ODEL ODEL ODEL ODEL ODEL (10" R (7" R (8" R APACITY OUND ALL CAP OUND ALL CAP OUND ALL CAP ODEL 8" R ODEL OUND (10" R OUND (7" R OUND DJUSTABLE DJUSTABLE LBOW...
- Page 4 E60000 SERIES RANGE HOOD SYSTEM - IN-LINE AND EXTERIOR BLOWERS ODEL (10" R ODEL OUND HLB9 (800 IGH CAPACITY ODEL HLB11 (1100 335 (1200 ODEL LINE LOWER 331H (600 336 (1500 ODEL 8" 12" INCLUDES TWO 332H (900 XTERIOR BLOWER 10"...
- Page 5 The Broan Elite E60000 Series range hood includes many configurations: Hoods with single or double internal blowers(included with the hood), or hoods using external blowers. For this last category, the Broan Elite E60000 Series must be installed with in-line blower models HLB3, HLB6, HLB9 or HLB11, or exterior blower model 331H, 332H, 335 or 336 only.
-
Page 6: Measure Installation
2. MEASURE INSTALLATION Dimensions for the most common installation are illustrated at right. Ceiling The minimum hood distance above cooktop must not be less than 24". Cabinet, soffit, Top of wood A maximum of 30" above cooktop is highly recommended for best capture decorative flue or mounting strip of cooking impurities. -
Page 7: Install Backsplash
3. PREPARE THE INSTALLATION ( CONT’D UCTED NSTALLATIONS Cut-out the openings for duct (A) and power cable (B), in cabinet or wall, according to the direction of discharge chosen. See figures below. NOTE: For all internal blower hoods, the cut-out opening for house wiring can be made in cabinet bottom OR wall, no matter the discharge chosen (vertical or horizontal). -
Page 8: Remove The Adapter
5. CHOOSE THE OPENING(S) (INTERNAL BLOWER(S) HOOD ONLY) Remove the knockout(s) for the chosen opening(s) (horizontal at the back of the hood or vertical on top). See illustrations below. ERTICAL DISCHARGE ORIZONTAL DISCHARGE NOTE: For ducted installation only. HR0021 Punch out the appropriate electrical knockout hole on top (A) or back (B) of the hood. -
Page 9: Horizontal Discharge Installation
8. HORIZONTAL DISCHARGE INSTALLATION (INTERNAL BLOWER(S) HOOD ONLY) All internal blower hoods are factory shipped with the blower(s) mounted for a vertical discharge configuration. For a horizontal discharge configuration, disassemble the blower(s) from the inner top of the hood and mount it (them) to the inner back panel of the hood. The procedure below applies for one or two blowers. -
Page 10: Install Wood Mounting Strip
9. INSTALL THE ADAPTER AND THE TRANSITION (IF NEED BE) (INTERNAL BLOWER(S) HOOD ONLY) Using standard 3/8" screws provided, secure the adapter to the top (or back) of the hood (2 screws for a 3¼" x 10" adapter/damper and 4 screws for a 4½"... -
Page 11: Install The Hood
13. INSTALL THE HOOD CAUTION Hold the hood until it is completely secured to the wood mounting strip. OUNTING SCREWS LOCATION NTERNAL BLOWER ONLY Run power cable to installation location. Remove the electrical compartment cover. Insert the cable in the hood and tighten the wire clamp to secure the cable. HD0264 LL INSTALLATIONS ALL ANCHORS LOCATION... -
Page 12: Install The Blower
16. INSTALL THE BLOWER (EXTERIOR OR IN-LINE BLOWER) Refer to instructions included with blower. Plug the 3-prong plug cord from rough-in plate to the 3-prong male connector inside the hood (A) and the 2-prong male connector cord from rough-in plate to the 2-prong plug inside the hood (B). -
Page 13: Operation
19. USE AND CARE Baffle Filters The baffle filters should be cleaned frequently. Use a warm detergent solution. Wash more often if your cooking style generates greater grease—like frying foods or wok cooking. Remove baffle filters by pushing them towards the back of hood and rotating filters downward. Baffle filters are dishwasher safe. Allow filters to dry completely before reinstalling them in the hood. - Page 14 20. OPERATION (CONT'D) HC0034 1) Halogen light knob 2) Blower speed control knob HC0035 1) Halogen light knob 2) Blower operation indicator 3) ON/OFF blower switch 4) Blower speed control knob COOKTOP LIGHTING (HALOGEN) A rotary 3-position knob (1) controls the halogen lights (OFF - low intensity - high intensity). BLOWER The blower is operated using two controls.
-
Page 15: Wiring Diagrams
22. WIRING DIAGRAMS Broan Elite E60000 Series NEON Internal blower(s) hoods SPEED SWITCH CONTROL On 3 Off 2 USE ONLY WITH APPROPRIATE MAKE-UP AIR SYSTEM THERMOSTAT LINE NEUTRAL GROUND LAMP SWITCH COLOR CODE BLACK BLUE BROWN ORANGE WHITE LAMP LAMP... -
Page 16: Service Parts
CREWS NO REPLACEMENT PARTS AND REPAIRS . 8-32 1/4", In order to ensure your unit remains in good working condition, you must use Broan-NuTone genuine ECHANICAL CREWS NO . 10-2" replacement parts only. Broan-NuTone genuine replacement parts are specially designed for each...
