Technical Specification
Model Number
Storage capacity (litres)
depth (mm)
width (mm)
Overall height incl t&p valve
Height excl t&p valve
Weight when full (kg)
Cold feed/hot draw off connections (mm)
Maximum water supply pressure (bar)
System operating pressure (pre-set) (bar)
Expansion vessel charge pressure (bar)
Expansion relief valve set pressure (bar)
Temperature and pressure relief valve settings:
Lift pressure (bar)
Lift temperature (ºC)
Package includes*:
Expansion vessel ltr
3bar pressure reducing valve, non return valve, 6 bar expansion relief valve,
tundish
T/P valve 7bar 90degC factory fitted
15mm to 22mm Tundish
Cylinder with 3kW immersion, thermostat, and manual reset thermal cut-out
Installation Manual
Performance:
Heat up time 15 to 65 ºC (min)
Reheat time for 70% of contents (min)
2. Component Check List
The SUTP water heater comes complete with all necessary safety equipment, please check through the
components supplied and ensure that all parts are present:
a. Water Heater
b. 5 litre Expansion Vessel
c. Pressure reducing valve
d. Expansion relief valve
e. Isolation valve
f. Tundish
g. Expansion vessel bracket
Please contact our customer service department immediately should any part be missing.
3. General requirements
3.1. The "SUTP Mid Range" domestic hot water cylinder MUST be installed by a competent person
in accordance with section G3 of the current Building Regulations.
3.2. Important - It is important that the installer reads and understands these instructions, unpacks and
familiarises themselves with the equipment before commencing the installation. Failure to observe
these installation instructions could invalidate the warranty.
SUTP30
SUTP50
SUTP75
30
50
400
400
400
400
665
860
586
781
47
71
22
22
12
12
3
3
3
3
6
6
7
7
90
90
5
5
•
•
•
•
•
•
•
•
•
•
36
55
25
38
75
400
400
1175
1093
100
22
12
3
3
6
7
90
5
•
•
•
•
•
85
60
3
