2. THE PARAMETER OF THE OUTDOOR COIL AND OUTDOOR SENSOR： （R
T(℃) R(KΩ) V(v)
-30 67.94 0.3235
-29 64.25 0.3408
-28 60.79 0.3588
-27 57.53 0.3776
-26 54.48 0.3971
-25 51.6 0.4174
-24 48.9 0.4384
-23 46.35 0.4603
-22 43.96 0.4829
-21 41.7 0.5065
-20 39.58 0.5307
-19 37.58 0.5558
-18 35.69 0.5818
-17 33.91 0.6087
-16 32.23 0.6363
-15 30.65 0.6648
-14 29.15 0.6942
-13 27.74 0.7244
-12 26.4 0.7556
-11 25.14 0.7875
-10 23.95 0.8202
-9 22.82 0.8539
-8 21.75 0.8885
-7 20.74 0.9237
-6 19.79 0.9596
-5 18.88 0.9966
-4 18.02 1.0343
-3 17.2 1.0731
-2 16.43 1.1122
-1 15.7 1.1520
0 15 1.1929
1 14.34 1.2342
2 13.71 1.2765
3 13.11 1.3195
4 12.55 1.3623
5 12.01 1.4063
6 11.5 1.4506
7 11.01 1.4959
8 10.55 1.5410
9 10.1 1.5878
10 9.684 1.6338
11 9.284 1.6805
12 8.903 1.7276
13 8.54 1.7749
14 8.194 1.8226
15 7.864 1.8704
16 7.549 1.9185
17 7.249 1.9667
D A T A
D A T A
DEC HEX T(℃)
16 10 18
17 11 19
18 12 20
19 13 21
20 14 22
21 15 23
22 16 24
23 17 25
25 19 26
26 1A 27
27 1B 28
28 1C 29
30 1E 30
31 1F 31
32 20 32
34 22 33
35 23 34
37 25 35
39 27 36
40 28 37
42 2A 38
44 2C 39
45 2D 40
47 2F 41
49 31 42
51 33 43
53 35 44
55 37 45
57 39 46
59 3B 47
61 3D 48
63 3F 49
65 41 50
67 43 51
69 45 52
72 48 53
74 4A 54
76 4C 55
79 4F 56
81 51 57
83 53 58
86 56 59
88 58 60
91 5B 61
93 5D 62
95 5F 63
98 62 64
100 64 65
R(KΩ) V(v) DEC HEX
6.962 2.0151 103 67
6.688 2.0636 105 69
6.427 2.1120 108 6C
6.178 2.1603 110 6E
5.939 2.2089 113 71
5.712 2.2570 115 73
5.494 2.3053 118 76
5.286 2.3533 120 78
5.086 2.4014 122 7A
4.896 2.4489 125 7D
4.714 2.4963 127 7F
4.539 2.5436 130 82
4.372 2.5904 132 84
4.212 2.6369 134 86
4.059 2.6830 137 89
3.912 2.7288 139 8B
3.772 2.7738 141 8D
3.637 2.8188 144 90
3.508 2.8631 146 92
3.384 2.9070 148 94
3.265 2.9504 150 96
3.151 2.9932 153 99
3.041 3.0358 155 9B
2.936 3.0775 157 9D
2.835 3.1188 159 9F
2.739 3.1590 161 A1
2.646 3.1990 163 A3
2.556 3.2387 165 A5
2.471 3.2771 167 A7
2.388 3.3155 169 A9
2.309 3.3528 171 AB
2.233 3.3896 173 AD
2.159 3.4262 175 AF
2.089 3.4615 177 B1
2.021 3.4965 178 B2
1.956 3.5306 180 B4
1.893 3.5644 182 B6
1.832 3.5977 183 B7
1.774 3.6299 185 B9
1.718 3.6616 187 BB
1.664 3.6926 188 BC
1.612 3.7231 190 BE
1.562 3.7528 191 BF
1.513 3.7824 193 C1
1.467 3.8106 194 C2
1.422 3.8386 196 C4
1.379 3.8658 197 C5
1.337 3.8927 199 C7
=15K±2%；B=3450±2%）
0
T(℃) R(KΩ) V(v)
66 1.297 3.9186
67 1.258 3.9443
68 1.22 3.9696
69 1.184 3.9939
70 1.149 4.0178
71 1.116 4.0406
72 1.083 4.0636
73 1.051 4.0862
74 1.021 4.1077
75 0.9914 4.1290
76 0.963 4.1497
77 0.9354 4.1701
78 0.9088 4.1898
79 0.8831 4.2091
80 0.8582 4.2280
81 0.8342 4.2463
82 0.8109 4.2643
83 0.7884 4.2818
84 0.7666 4.2988
85 0.7455 4.3155
86 0.725 4.3318
87 0.7053 4.3476
88 0.6861 4.3631
89 0.6676 4.3781
90 0.6496 4.3929
91 0.6323 4.4071
92 0.6156 4.4209
93 0.5993 4.4345
94 0.5836 4.4477
95 0.5683 4.4606
96 0.5535 4.4732
97 0.5391 4.4855
98 0.5251 4.4975
99 0.5115 4.5093
100 0.4983 4.5207
101 0.4855 4.5319
102 0.4731 4.5427
103 0.461 4.5534
104 0.4492 4.5638
105 0.4378 4.5739
106 0.4268 4.5838
107 0.416 4.5934
108 0.4055 4.6029
109 0.3953 4.6121
110 0.3854 4.6211
DEC HEX
200 C8
201 C9
202 CA
204 CC
205 CD
206 CE
207 CF
208 D0
209 D1
211 D3
212 D4
213 D5
214 D6
215 D7
216 D8
217 D9
217 D9
218 DA
219 DB
220 DC
221 DD
222 DE
223 DF
223 DF
224 E0
225 E1
225 E1
226 E2
227 E3
227 E3
228 E4
229 E5
229 E5
230 E6
231 E7
231 E7
232 E8
232 E8
233 E9
233 E9
234 EA
234 EA
235 EB
235 EB
236 EC
