GPS Output

Settings: 5 Hz, 10 Hz; Default = 5 Hz
GPS Output controls the frequency at which data from the GPS Receiver is
sent to the control head. Select 10 Hz to receive the most GPS updates on
the display.
Time Format
(Advanced, International Models only)
Settings: 12 hour, 24 hour; Default = 12 hour
Time Format changes the time format used by the unit. Time Format selects
a 12 hour or 24 hour format for the time of day displayed when Time + Date
is selected as a Digital Readout on the Sonar View (see Setup Menu Tab:
Select Readouts).
Date Format
(Advanced, International Models only)
Settings: mm/dd/yy, dd.mm.yy, yy.mm.dd;
Default = mm/dd/yy
Date Format changes the date format used by the unit. Date Format selects
the format for the date display when Time + Date is selected as a Digital
Readout on the Sonar View (see Setup Menu Tab: Select Readouts).
Digits Format adds a tenth decimal place to the readouts such as
Temperature and Depth. Use the settings to change the display of the
decimal place or remove it from the digital readouts. Examples of the
different settings are displayed below. Also, see Select Readouts and Views.
Small tenths
NMEA 0183 Output turns the NMEA* output on or off. NMEA Output
should be turned On if you connect the NMEA Output wires of an accessory
GPS Receiver cable to another NMEA-compatible device, such as an
autopilot.
*NMEA 0183 is a National Marine Electronics Association standard for data
communication.
NOTE: A separate purchase of accessory AS-HHGPS may be required for the
NMEA output function.
113
Digits Format
(Advanced)
Settings: Small tenths, Large tenths, No tenths;
Default = Small tenths
Large tenths No tenths
NMEA 0183 Output
(Advanced)
Settings: Off, On; Default = Off
Setup Menu Tab
