Num ber of LED flashes be tween pauses
2 flashes
3 flashes
4 flashes
5 flashes
6 flashes
7 flashes
8 flashes
9 flashes
10 flashes
5. If a sensor is often activated, decrease that sensor's sensitivity (or reposition the sensor, if necessary). If a certain trigger is often
activated, check pin switch operation, verify that the pin switch is not exposed to moisture and check the trigger wire for possible
shorting.
IntelliGuard 7000 comes from the factory with its features preprogrammed as noted in bold text in the tables on pages 10 and 11.
Some features can be programmed by the installer or the user, others can only be programmed only by the installer.
Using the CliffNet Wizard Pro
The CliffNet Wizard Pro provides an intuitive access to all installer and user-programmable features through a user-friendly, graphical
user interface. Because CliffNet Wizard Pro is Windows™-compatible, most operations can be accomplished by simply pointing and
clicking a mouse. CliffNet Wizard Pro totally eliminates complicated programming charts and lengthy button pressing sequences.
Please refer to the CliffNet Wizard Pro User's Guide for more programming information if you are using the CliffNet Wizard Pro.
Otherwise, for manual programming refer to the tables provided in the following sections.
Programming the User-Selectable Features
1. Write down the column (across) number and row (down) number of the feature(s) you wish to program.
2. Turn the ignition to the "ON" position or start the engine.
3. Enter the factory preset valet/programming code of "2" by pressing the PlainView 2 Switch's
unmarked button.
4. After entering the code, press and hold the
acknowledge program mode entry. The IntelliGuard 7000 is now in the "Feature Select" position for User-Programmable Features.
5. Select the feature column: Press the unmarked button the same number of times as the column number. Pause. You will then hear
the same number of chirps as the column number you have selected, audibly confirming your selection.
6. Within five seconds, select the feature row: Press the
chirp each time you press the unmarked side to help you count.
7. If there is a NOTE for the selected feature, perform the actions noted.
8. Pause. You will hear either one or two chirps: two chirps = ON, one chirp = OFF.
9. You can select another feature, or you can exit program mode:
a. To select another feature in that same column, repeat step 6 within the next five seconds (after five seconds, three chirps
indicate that the IntelliGuard 7000 is now back in the "Feature Select" position).
b. To select a different feature column, repeat step 5.
c. To exit program mode, turn the ignition off (you'll hear three chirps and the LED will turn off to indicate exit of program
mode), or wait 60 seconds and the IntelliGuard 7000 will automatically exit program mode.
In tel liGuard 7000/199
Eight Event TotalRecall (Continued)
valet codes were entered while the system was in BlackJax mode
Programmable Features
for about 3 seconds until you hear one siren chirp and the LED turns on to
button the same number of times as the feature's row number. You'll hear a
Trig ger/sen sor in di ca tion
Dual-Zone Piezo Sensor
Optional Sensor
Door Trigger
0Trunk Trigger
Hood Trigger
An attempt was made to turn on the
ignition or start the engine while the system was armed
More than three consecutive incorrect
BlackJax
System Power Interruption
button two times, then press the
9
