And 20 - Way Vw Plugs - Metra Electronics SWC-01 Installation Instructions Manual

16 and 20 - Way VW Plugs

7 5
6
8
7 5
8 6
Year Make
2003-05 Cadillac
2004-05 Cadillac
For the vehicles listed above use the Green wire on the SWC-01 and set the CAR DIP
Switch settings as follows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Dip 7 Dip 8
Down Down Up Up
Year Make
2004-05 Pontiac
For the vehicles listed above use the Green wire on the SWC-01 and set the CAR DIP
Switch settings as follows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Dip 7 Dip 8
Down Down Up Up
SWC-01
3 1
C2
4 2
3 1
4 2
Model Pin
Location
CTS C1 pin 13
SRX C1 pin 13
Up Down Up
Model Pin
Location
GTO C1 pin 11
Down Down Up
14
8 11
2 5 6 15
3
1 4 9 7 10 12
Wire Color Additional Wiring Needed
Dk.Blue Connect pin 2 on C3,Purple,
to chassis ground
Dk.Blue Connect pin 2 on C3,Purple,
to chassis ground
Up
Wire Color Additional Wiring Needed
Brown Connect pin 12 on C1,
Black/Yellow, to chassis
ground
Up
14 17 20
18
13 16 19
