17 - Way Ford Plug
Year
Make
2002
Ford
For the vehicles listed above use the Green wire on the SWC-01 and set the CAR DIP
Switch settings as follows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Dip 7 Dip 8
Down Down Up
Up
SWC-01
Model
Pin
Location
Focus
11
Up
Up
Down
13
Wire Color
Additional Wiring Needed
white/black
Connect pin 12,
Brown/Yellow, to chassis
ground
