2001 Expedition/Navigator Workshop Manual
SECTION 412-02: Heating and Ventilation
REMOVAL AND INSTALLATION
Heater Core
Removal and Installation
NOTE: If a heater core leak is suspected, the heater core must be leak tested before it is removed from the
vehicle. For additional information, refer to
1. Drain the radiator. For additional information, refer to
2. Remove the instrument panel. For additional information, refer to
3. If equipped with the 5.4L 4V engine, remove the junction block splash shield.
4. If equipped with the 5.4L 4V engine, remove the bolts and disconnect the cable ends from the starter
relay.
5. If equipped with the 5.4L 4V engine, remove the junction block bracket.
1. Disengage the wire harness connector.
2. Remove the bolts.
3. Remove the junction block bracket.
