Installing the Metal Junction Box or Mud Ring

Cutting an Opening in the Mounting Surface

1.
2.
4.
5.
6.
Install the mud ring or metal junction box in the mounting surface (see
Mud Ring on page 6 or Installing a UL Listed Metal Junction Box
Route and connect cables to the rear panel connectors (see
on page 8).
Mount the XTP T HWP 101 to the mud ring or metal junction box (see
XTP T HWP 101 on page 9).
Connect an HDMI input to the front panel connector (see
page 10).
Supply power to all connected devices.
Using an appropriate template or the mounting enclosure as a guide, mark the area
of the wall that will be cut with a soft pencil (for the provided mud ring, see
Template on page 34).
NOTE: Check with the manufacturer of the metal junction box for specific
installation requirements.
Use a jigsaw or small hand saw to carefully cut away the material within the guidelines
drawn in step 1.
NOTE: If using a template or the mud ring as a guide for cutting the hole in drywall,
cut inside the guidelines to maximize the contact the mud ring makes with the
drywall.
If using a mud ring in a wall with insulation inside, remove at least 6 inches of the
insulation in all directions around the cutout.
NOTE: If a wall stud interferes with removing 6 inches of insulation around the
cutout, remove the insulation between the cutout and wall stud.
Check the size of the opening by laying the mud ring or metal junction box against it.
The mounting device should fit snugly in the opening.
If needed, use a saw, file, or sandpaper to enlarge the hole.
CAUTION: Risk of personal injury. Smooth the edges of the opening to avoid
personal injury during installation.
ATTENTION : Risque de blessure. Lissez les bords de l'ouverture afin d'éviter
toute blessure lors de l'installation.
Smooth the edges of the opening to avoid damage to the mounting
ATTENTION:
device or the cables.
ATTENTION : Lissez les bords de l'ouverture afin d'éviter d'endommager l'appareil
de montage ou les câbles.
Front Panel Connectors
XTP T HWP 101 Wallplate Transmitter • Installation
Installing the
on page 7).
Rear Panel Connectors
Mounting the
on
Mounting
5
