Page 2: Table Of Contents
Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems How to get going AM/FM stereo with CD AM/FM stereo with in-dash six CD Auxiliary input jack (Line in) USB port Satellite radio information Navigation system SYNC Climate Controls Manual heating and air conditioning Automatic temperature control...
Page 3 Table of Contents Locks and Security Keys Locks Anti-theft system Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes AdvanceTrac...
Page 5: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 6 Introduction Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment.
Page 7 Introduction BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in.
Page 8 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 9 WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 10 Introduction Export unique (Non–United States/Canada) vehicle specific information For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this Owner’s Guide. A market unique supplement may be supplied that complements this book.
Page 11 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
Page 12 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 13: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
Page 14 Instrument Cluster WARNING: Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Powertrain malfunction/reduced power: Illuminates when a powertrain or a AWD fault has been detected.
Page 15 Instrument Cluster Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected. Contact your authorized dealer as soon as possible. Normal braking is still functional unless the brake warning light also is illuminated. Airbag readiness: If this light fails to illuminate when the ignition is turned to on, continues to flash or...
Page 16 Instrument Cluster Low tire pressure warning (if equipped): Illuminates when your tire pressure is low. If the light remains on at start up or while driving, the tire pressure should be checked. Refer to Inflating your tires in the Tires, Wheels and Loading chapter.
Page 17 Instrument Cluster Low washer fluid (if equipped): Illuminates when the windshield washer fluid is low. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on.
Page 18: Gauges
Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 19 Instrument Cluster Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the on position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. The FUEL icon and arrow indicates which side of the vehicle the fuel filler door is located.
Page 20 Instrument Cluster Trip odometer: Registers the miles (kilometers) of individual journeys. • With mini message center Tap on the TRIP/RESET stem to toggle the display between the trip and the odometer. Press the stem again to select Trip A and Trip B features.
Page 21: Entertainment Systems
Quick start — How to get going WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
Page 22 Entertainment Systems Listening to satellite radio (if equipped) 1. If the audio system is turned off, press VOL-PUSH to turn the radio on. Turn VOL-PUSH to adjust the volume. Note: The system may take a few moments to turn on. 2.
Page 23 Entertainment Systems For a single CD system, if a disc is not already loaded, insert only one, label side up into the CD slot. LOADING CD and READING DISC will appear in the display. The first track on the disc will begin playing. For an in-dash six CD system, if a disc is not already loaded, press LOAD.
Page 24 Entertainment Systems While in folder mode, press FOLDER to access the next folder on MP3 discs, if available. Press SHUFFLE to engage shuffle mode. SHUFFLE ON will appear in the display. If you wish to engage shuffle mode right away, press SEEK to begin random play. Otherwise, random play will begin when the current track is finished playing.
Page 25: Am/Fm Stereo With Cd
(if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 26 Entertainment Systems In CATEGORY MODE, press to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.). Refer to Category Mode under Menu for further information. Satellite radio is available only with a valid SIRIUS subscription. Check with your authorized dealer for availability. (Phone): If your vehicle is equipped with SYNC , press to access SYNC PHONE features.
Page 27 Entertainment Systems • DELETE SONG: Press OK to delete a song from the system’s memory. Press to cycle through the saved songs. When the song appears in the display that you would like to delete, press OK. The song will appear in the display for confirmation. Press OK again and the display will read SONG DELETED.
Page 28 Entertainment Systems To activate, press MENU repeatedly until RBDS (ON/OFF) appears in the display. Use SEEK to toggle RBDS ON/OFF. When RBDS is OFF, you will not be able to search for RBDS equipped stations or view the station name or type. Press OK to close and return to the main menu.
Page 29 Entertainment Systems TRACK/FOLDER MODE: Available only on MP3 discs in CD mode. In track mode, press SEEK, SEEK to scroll through all tracks on the disc In folder mode, press SEEK, SEEK to scroll through tracks within the selected folder. Press FOLDER, FOLDER to access the previous/next folder (if...
Page 30 Entertainment Systems In satellite radio mode (if equipped), press SEEK, SEEK seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK, SEEK to seek to the previous/next channel in the selected category. Press and hold SEEK, SEEK to fast seek through the previous /next channels.
Page 31 Entertainment Systems FOLDER: In folder mode, press FOLDER to access the previous folder on MP3 discs, if available. 10. FF (Fast forward): Press FF to manually advance in a CD/MP3 track. 11. REW (Rewind): Press REW to manually reverse in a CD/MP3 track. 12.
Page 32 Entertainment Systems In satellite radio mode (if equipped), press and hold to hear a brief sampling of the next channels. Press again to stop. In CATEGORY MODE, press SCAN to hear a brief sampling of the channels in the selected category. Press again to stop. Satellite radio is available only with a valid SIRIUS radio subscription.
Page 33: Am/Fm Stereo With In-Dash Six Cd
(if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 34 Entertainment Systems In satellite radio mode (if equipped), press to tune to the next/previous channel. In CATEGORY MODE, press to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.). Refer to Category Mode under Menu for further information. Satellite radio is available only with a valid SIRIUS radio subscription.
Page 35 Entertainment Systems • DELETE SONG: Press OK to delete a song from the system’s memory. Press to cycle through the saved songs. When the song appears in the display that you would like to delete, press OK. The song will appear in the display for confirmation. Press OK again and the display will read SONG DELETED.
Page 36 Entertainment Systems RBDS: Available only in FM mode. This feature allows you to search RBDS-equipped stations for a certain category of music format: CLASSIC, COUNTRY, INFORM, JAZZ/RB, ROCK, etc. To activate, press MENU repeatedly until RBDS (ON/OFF) appears in the display. Use to toggle RBDS ON/OFF.
Page 37 Entertainment Systems Track/Folder mode: Available only on MP3 discs in CD mode. In track mode, press SEEK, SEEK to scroll through all tracks on the disc. In folder mode, press SEEK, SEEK to scroll through tracks within the selected folder. Press FOLDER, FOLDER to access the previous/next folder (if...
Page 38 Entertainment Systems In satellite radio mode (if equipped), press SEEK, SEEK seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK, SEEK to seek to the previous/next channel in the selected category. Press and hold SEEK, SEEK to fast seek through the previous /next channels.
Page 39 Entertainment Systems 10. FF (Fast forward): Press FF to manually advance in a CD/MP3 11. REW (Rewind): Press REW to manually reverse in a CD/MP3 track. 12. Memory presets: To set a station, select the desired frequency band, AM, FM1 or FM2. Tune to the desired station.
Page 40 Entertainment Systems 14. AM/FM: Press to select AM/FM1/FM2 frequency band. 15. ON/OFF/Volume: Press to turn on/off. Turn to increase/decrease volume. Note: If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 41: Auxiliary Input Jack (Line In)
Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 42 Entertainment Systems 3. Attach one end of the audio extension cable to the headphone output of your player and the other end of the audio extension cable to the AIJ in your vehicle. 4. Turn the radio on, using either a tuned FM station or a CD loaded into the system.
Page 43: Usb Port
USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 44 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch...
Page 45 Entertainment Systems CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels.
Page 46: Satellite Radio Information
Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
Page 47 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming...
Page 48 Entertainment Systems Satellite Radio Electronic Serial Number (ESN): This 12–digit Satellite Serial Number is needed to activate, modify or track your satellite radio account. You will need this number when communicating with SIRIUS. While in Satellite Radio mode, you can view this number on the radio display by pressing AUX and Preset 1 control simultaneously.
Page 49: Navigation System
Entertainment Systems Radio Display Condition Action Required NO TEXT Song title Song title information not information not available at this time on this available. channel. The system is working properly. NO TEXT Category Category information not information not available at this time on this available.
Page 50: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the distribution of the airflow in the vehicle. See the following for a brief description on each control setting: MAX A/C: Distributes recirculated air through the instrument panel...
Page 51 Climate Controls 5. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in MAX A/C, (defrost) and (floor/defrost). 6. Fan speed adjustment: Controls the volume of air circulated in the vehicle. Operating tips •...
Page 52: Automatic Temperature Control
Climate Controls DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) SYSTEM WITH HEATED SEATS (IF EQUIPPED) Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Driver Controls chapter. MAX A/C setting: In order to achieve maximum cooling performance, press , A/C, , and set the temperature to 60°F (16°C) and the...
Page 53 Climate Controls Passenger heated seat: Press to control the passenger heated seat. Refer to Heated seats in the Seating and Safety Restraints chapter for more information. Recirculated air: Press to activate/deactive air recirculation in the vehicle. Recirculated air may reduce the amount of time needed to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle.
Page 54: Automatic Operation
Climate Controls 12. Driver side temperature control: Press to increase/decrease the temperature on the driver side of the vehicle in dual zone or the temperature of both the driver and passenger side in single zone. 13. AUTO: To engage automatic temperature control, press AUTO and select the desired temperature using the temperature control.
Page 55: Rear Window Defroster
Climate Controls • Manual operation: 1. Select 2. Select A/C and (recirculated air). Use (recirculated air) with A/C to provide colder airflow. 3. Set the temperature to 60°F (16°C). 4. Set highest fan setting initially, then adjust to maintain comfort. To aid in side window defogging/demisting in cold weather: 1.
Page 56 Climate Controls CABIN AIR FILTER (IF EQUIPPED) The cabin air filter element is designed to reduce the concentration of airborne particles such as dust, spores and pollen in the air being supplied to the interior of the vehicle. The presence of a particulate filter element provides the following benefits: •...
Page 57: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position turn on the headlamps. Rotate back to to turn the headlamps off. Autolamp control The autolamp system provides light sensitive automatic on/off control of the exterior lights normally controlled by the headlamp control.
Page 58 Lights Fog lamp control (if equipped) The headlamp control also operates the fog lamps. The fog lamps can be turned on when the headlamp control is in the positions and the high beams are not turned on. Pull the headlamp control towards you to turn the fog lamps on.
Page 59 Lights WARNING: Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate the tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 60 Lights • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground • (3) 25 feet (7.6 meters) • (4) Horizontal reference line 2. Measure the height of the headlamp bulb center from the ground and mark an 8 foot (2.4 meter) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well).
Page 61: Turn Signal Control
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Front row map lamps (if equipped) To turn on the map lamps, press the outer edge of the clear lens. The front row map lamp lights when: •...
Page 62: Bulb Replacement
Lights Map/dome lamp (if equipped) The dome lamp lights when: • any door is opened, • the instrument panel dimmer switch is rotated up until the courtesy lamps come on, and • any of the remote entry controls are pressed and the ignition is off.
Page 63 Lights Examples of unacceptable moisture (usually caused by a lamp water leak) are: • Water puddle inside the lamp • Large water droplets, drip marks or streaks present on the interior of the lens Take your vehicle to dealer for service if any of the above conditions of unacceptable moisture are present.
Page 64 Lights Replacing interior bulbs Check the operation of all bulbs frequently. Replacing exterior bulbs Check the operation of all the bulbs frequently. Replacing headlamp bulbs Check the operation of all bulbs frequently. 1. Make sure that the headlamp control is in the off position. 2.
Page 65 Lights Replacing front parking lamp/turn signal bulbs 1. Make sure that the headlamp control is in the off position. 2. Open the hood. 3. Reach over the front bolster. 4. Rotate the bulb socket counterclockwise and remove from the lamp assembly. 5.
Page 66 Lights 6. Install the bulb socket into the lamp assembly and rotate clockwise. 7. Carefully install the tail lamp assembly on the vehicle by securing the lamp assembly with two bolts. Replacing high-mount brake lamp bulbs Your vehicle is equipped with an LED center high-mount stop lamp. It is designed to last the life of the vehicle.
Page 67: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.
Page 68: Steering Wheel Adjustment
Driver Controls Rear window wiper/washer controls For rear wiper operation, rotate the rear window wiper and washer control to the desired position. Select: 2 — Normal speed operation of rear wiper. 1 — Intermittent operation of rear wiper. O (off) — Rear wiper and washer off. For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position.
Page 69 Driver Controls ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamp. Slide on rod feature The visor will slide back and forth on the rod for increased sunlight coverage. Rotate the visor towards the side window and extend it rearward for additional sunlight coverage.
Page 70 Driver Controls CENTER CONSOLE (IF EQUIPPED) Your vehicle may be equipped with a variety of console features. These include: 1. Cupholders 2. Tissue box holder (located on underside of console lid) 3. Rear power point 4. Utility compartment with a clamshell tray with coin holder and a removable divider for organizing and storing personal items including...
Page 71 Driver Controls To have full capacity usage of your power point, the engine is required to be running to avoid unintentional discharge of the battery. To prevent the battery from being discharged: • do not use the power point longer than necessary when the engine is not running, •...
Page 72: Power Windows
Driver Controls POWER WINDOWS WARNING: Do not leave children unattended in the vehicle and do not let children play with the power windows. They may seriously injure themselves. WARNING: When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.
Page 73 Driver Controls To operate one touch up: • Pull the switch completely up to the second detent and release quickly. The window will close fully. Momentarily press the switch to any position to stop the window operation. If the switch is pressed and held to the normal open or one touch down position during a one touch up cycle, the window will stop.
Page 74 Driver Controls INTERIOR MIRROR The interior rear view mirror has two pivot points on the support arm which lets you adjust the mirror up or down and from side to side. WARNING: Do not adjust the mirror while the vehicle is in motion.
Page 75: Mirrors
Driver Controls EXTERIOR MIRRORS Power side view mirrors WARNING: Do not adjust the mirror while the vehicle is in motion. To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror.
Page 76: Speed Control
Driver Controls SPEED CONTROL With speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal. WARNING: Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved. Setting speed control The controls for using your speed control are located on the steering...
Page 77 Driver Controls Disengaging the speed control will not erase previous set speed. Resuming a set speed Press the RESUME control and release it. This will automatically return the vehicle to the previously set speed. Increasing speed while using speed control There are two ways to set a higher speed: •...
Page 78 Driver Controls • Press the brake pedal until the desired vehicle speed is reached and press the SET + control. Turning off speed control There are two ways to turn off the speed control: • Press the brake pedal. This will not erase your vehicle’s previously set speed.
Page 79 Driver Controls In Radio mode: • Press to access the next/previous preset station. In CD mode: • Press to listen to the next track on the disc. In Satellite radio mode (if equipped): • Press to advance through preset channels. In any mode: •...
Page 80 Driver Controls Navigation system/SYNC hands free control features (if equipped) Press control briefly until the voice icon appears on the Navigation display to use the voice command feature. Press to activate phone mode or answer a phone call. Press and hold to exit phone mode or end a call.
Page 81 Driver Controls To open power sunshades and panoramic Vista Roof™: Press and release the control to open the sunshade. The front and rear sunshades open simultaneously. Note: Vista Roof™ will only open after power sunshades are completely open. Power sunshades will only close after Vista Roof™...
Page 82 Driver Controls HOMELINK WIRELESS CONTROL SYSTEM (IF EQUIPPED) The HomeLink Wireless Control System, located on the driver’s visor, provides a convenient way to replace up to three hand-held transmitters with a single built-in device. This feature will learn the radio frequency codes of most transmitters to operate garage doors, entry gate operators, security systems, entry door locks, and home or office lighting.
Page 83 Driver Controls 1. Position the end of your hand-held transmitter 1–3 inches (2–8 cm) away from the HomeLink button you wish to program (located on your visor) while keeping the indicator light in view. 2. Simultaneously press and hold both the chosen HomeLink and hand-held transmitter buttons until the HomeLink indicator light changes from a slow to a rapidly blinking light.
Page 84 Driver Controls Gate Operator & Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting — not allowing enough time for HomeLink to accept the signal from the hand-held transmitter. After completing Step 1 outlined in the Programming section, replace Step 2 with the following: Note: If programming a garage door opener or gate operator, it is advised to unplug the device during the “cycling”...
Page 85 Driver Controls Erasing HomeLink buttons To erase the three programmed buttons (individual buttons cannot be erased): • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.
Page 86: Message Center
Driver Controls Odometer/Trip odometer Refer to Gauges in the Instrument Cluster chapter. Note: Engine can not be running to change the state of Autolamp or Rear Park Assist (when not in Reverse). Autolamp (if equipped) This feature keeps your headlights on for up to three minutes after the ignition is switched off.
Page 87 Driver Controls Selectable features Reset Press this control to select and reset functions shown in the INFO menu and SETUP menu. Info menu This control displays the following control displays: • Odometer • Trip Odometer A or B • Distance to Empty •...
Page 88 Driver Controls Average fuel economy (AFE) Select this function from the INFO menu to display your average fuel economy in miles/gallon or liters/100 km. If you calculate your average fuel economy by dividing 100 miles traveled by gallons of fuel used (kilometers traveled by liters used), your figure may be different than displayed for the following reasons: •...
Page 89 Driver Controls Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. This variation is four degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error.
Page 90 Driver Controls 6. Release the RESET control, then slowly press RESET down again. 7. Press the SETUP control repeatedly until the correct zone setting for your geographic location is displayed on the message center. To exit the zone setting mode press and release the RESET control.
Page 91 Driver Controls • Easy entry/exit seat (if equipped) • Power Liftgate (if equipped) • Reverse sensing system (Park Assist) (if equipped) • Language System check Selecting this function from the SETUP menu causes the message center to cycle through each of the systems being monitored.
Page 92 Driver Controls 1. To disable/enable the autolamp delay feature, select this function from the SETUP control for the current display mode. 2. Press the RESET control to select the new Autolamp delay values of 0, 10, 20, 30, 60, 90, 120 or 180 seconds. Autolock This feature automatically locks all vehicle doors when the vehicle is shifted into any gear, putting the vehicle in motion.
Page 93 Driver Controls Power Liftgate (if equipped) This feature allows users to open/close the rear liftgate at the touch of a button. 1. To disable/enable the power liftgate feature, select this function from the SETUP control for the current display mode. 2.
Page 94 Driver Controls In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for several seconds. The message center will display the last selected feature if there are no more warning messages.
Page 95 Driver Controls REAR LEFT DOOR AJAR — Displayed when the rear left door is not completely closed. REAR RIGHT DOOR AJAR — Displayed when the rear right door is not completely closed. PARK BRAKE ENGAGED — Displayed when the manual park brake is set, the engine is running and the vehicle is driven more than 3 mph (5 km).
Page 96 Driver Controls POSITIVE RETENTION FLOOR MAT (IF EQUIPPED) WARNING: Do not install additional floor mats on top of the factory installed floor mats as they may interfere with the accelerator or the brake pedals. To install floor mats that have a retention post: Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to...
Page 97 Driver Controls WARNING: Make sure that the liftgate is closed to prevent exhaust fumes from being drawn into the vehicle. This will also prevent passengers and cargo from falling out. If you must drive with the liftgate door open, keep the vehicle well ventilated so outside air comes into the vehicle.
Page 98 Driver Controls If the liftgate reverses and starts to close after an open request, a fast continuous chime indicates excessive load on the gate or a possible strut failure. If any excessive load is removed and you still have a faster chime, have the system serviced immediately by your authorized dealer.
Page 99 Driver Controls To power open or close the liftgate with the integrated keyhead transmitter: Press twice within three seconds to open the liftgate. Refer to Remote entry system in the Locks and Security chapter. To power open the liftgate with outside liftgate control button: 1.
Page 100 Driver Controls Note: The liftgate movement direction can be reversed with a second press of the instrument panel, or the rear cargo area control button, or a second double press of the integrated keyhead transmitter button. To manually operate the liftgate: 1.
Page 101 Driver Controls CARGO AREA FEATURES Cargo management system (if equipped) The cargo management system consists of storage compartments located in the floor of the rear cargo area. 1. To open, lift the release handle and the lid. 2. To close, lower the lid. Cargo net (if equipped) The cargo net secures lightweight objects in the cargo area.
Page 102 Driver Controls Utility hook The utility hook can be used to hang small items such as grocery bags, etc. Do not hang more than 10 lb (4.5 kg) on the hook. LUGGAGE RACK (IF EQUIPPED) The load must be placed directly on the luggage rack. The vehicle’s roof panel is not designed to carry a load.
Page 103: Locks And Security
Locks and Security KEYS Your vehicle is equipped with two Integrated Keyhead Transmitters (IKTs). The IKT functions as both a programmed ignition key that operates all the locks and starts the vehicle, and the transmitter portion functions as the remote entry transmitter.
Page 104 Locks and Security Recommended handling of the Integrated Keyhead Transmitter (IKT) To avoid inadvertently activating the remote entry functions of your vehicle, it is recommended that the Integrated Keyhead Transmitter (IKT) be handled properly when starting and turning off your vehicle. When inserting the IKT into the ignition cylinder, place your thumb on the center thumb rest of the IKT...
Page 105: Locks
Locks and Security POWER DOOR LOCKS • Press the control to unlock all doors. • Press the control to lock all doors. Smart locks This feature helps to prevent you from locking yourself out of the vehicle if your key is still in the ignition. When you open one of the front doors or the liftgate and you lock the vehicle with the power door lock control (on the driver or passenger door trim panel), all the doors will lock, then all doors will automatically...
Page 106 Locks and Security Deactivating/activating autolock feature Your vehicle comes with the autolock features activated; there are four methods to enable/disable this feature: • Through your authorized dealer, • by using a power door unlock/lock procedure, • using a keypad procedure (if equipped), or •...
Page 107 Locks and Security Keyless entry keypad autolock enable/disable procedure 1. Turn the ignition to the off position. 2. Close all the doors. 3. Enter factory–set 5–digit entry code. 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
Page 108 Locks and Security Power door lock switch autounlock enable/disable procedure Before starting, ensure the ignition is in the off position and all vehicle doors are closed. You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, wait a minimum of 30 seconds before beginning again.
Page 109 Locks and Security CHILDPROOF DOOR LOCKS • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 110 Locks and Security There are two possible types of IKTs: • Vehicles equipped with a power liftgate • Vehicles not equipped with a power liftgate The typical operating range for your IKT is approximately 33 feet (10 meters). A decrease in operating range could be caused by: •...
Page 111 Locks and Security • remotely lock all the vehicle doors. • remotely open the power liftgate (if equipped). • activate the personal alarm. • operate the illuminated entry feature. The remote entry lock/unlock feature operates in any ignition position except while the key is held in the start position. The panic feature operates with the key in the off position.
Page 112 Locks and Security Opening the power liftgate (if equipped) Press twice within three seconds to fully unlatch and open the liftgate. WARNING: Make sure all persons are clear of the liftgate area before using power liftgate control. In order to fully lower and latch the liftgate, press the control twice. If the liftgate stops mid travel, it may have detected an obstacle, Check to ensure the liftgate swing zone is free from obstruction and reset the power assist by manually closing the liftgate.
Page 113 Locks and Security Activating the memory feature To activate this feature: 1. Position the seat and mirrors to the desired positions. 2. Press and hold either the 1 or 2 control on the driver’s door for five seconds. (A tone will be heard after ⁄...
Page 114 Locks and Security To replace the battery: 1. Twist a thin coin in the slot of the IKT near the key ring in order to remove the battery cover. Note: Do not wipe off any grease on the battery terminals on the back surface of the circuit board.
Page 115 Locks and Security The illuminated entry system will turn off the lights if: • the ignition is turned to the on position, or • the Integrated Keyhead Transmitter lock control is pressed, or • the vehicle is locked using the keyless entry keypad (if equipped), or •...
Page 116 Locks and Security 1. Place the key in the ignition and turn the ignition to the on position. 2. Press the power door unlock control on the door panel three times. 3. Turn the ignition from the on position to the off position. 4.
Page 117 Locks and Security SECURICODE™ KEYLESS ENTRY SYSTEM (IF EQUIPPED) You can use the keyless entry keypad to: • lock or unlock the doors without using a key. • recall memory seat/power mirrors positions (if equipped). The keypad can be operated with the factory set 5–digit entry code; this code is located on the owner’s wallet card in the glove box and is available from your authorized dealer.
Page 118: Anti-Theft System
Locks and Security Erasing personal code 1. Enter the factory set 5–digit code. 2. Within five seconds, press the 1 • 2 on the keypad and release. 3. Press and hold the 1 • 2 for two seconds. This must be done within five seconds of completing Step 2.
Page 119 Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 120 Locks and Security Automatic arming The vehicle is armed immediately after switching the ignition to the off position. The theft indicator will flash every two seconds to act as a theft deterrent when the vehicle is armed. Automatic disarming The vehicle is disarmed immediately after the ignition is turned to the on position.
Page 121 Locks and Security Tips: • Only use Integrated Keyhead Transmitters (IKTs) or standard SecuriLock keys. • You must have two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible. • If two previously programmed coded keys are not available, you must take your vehicle to your authorized dealer to have the spare key(s) programmed.
Page 122 Locks and Security 8. Turn the ignition from the 1 (off) position to the 3 (on) position. Keep the ignition in the 3 (on) position for at least six seconds. 9. Remove the newly programmed coded key from the ignition. If the key has been successfully programmed it will start the vehicle’s engine and will operate the remote entry system (if the new key is an Integrated Keyhead Transmitter).
Page 123: Seating And Safety Restraints
Seating and Safety Restraints SEATING WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 124 Seating and Safety Restraints To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 3. Lower the head restraint by pressing and holding the guide sleeve lock/release button and pushing down on the head restraint.
Page 125 Seating and Safety Restraints To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Insert and push a tool, such as a large paper clip, into the pin hole located on the side of the guide sleeve and press the lock/release button, then pull the head restraint...
Page 126 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Using the manual lumbar support (if equipped) The lumbar control is located on the side of the seat cushion. Lift up or down to adjust lumbar support.
Page 127 Seating and Safety Restraints Pump the handle upwards to raise the cushion and pump downward to lower the cushion to the desired location. Pull lever up to adjust seatback. Folding down the front passenger seatback (if equipped) The front passenger seatback can be folded to a horizontal position to make room for a long load.
Page 128 Seating and Safety Restraints WARNING: Cover sharp edges on the load to help prevent injury to occupants. Secure the load to help prevent shifting during sudden stops. WARNING: Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.
Page 129 Seating and Safety Restraints WARNING: To reduce the risk of possible serious injury: Do not hang objects off seat back or stow objects in the seatback map pocket (if equipped) when a child is in the front passenger seat. Do not place objects underneath the front passenger seat or between the seat and the center console (if equipped).
Page 130 Seating and Safety Restraints • To program position 2, repeat the previous procedure using control button 2. • A chime will sound confirming that a memory position has been set. A position can be recalled: • in any gearshift position if the ignition is not on. •...
Page 131 Seating and Safety Restraints Note: Do not do the following: • Place heavy objects on the seat • Operate the seat heater if water or any other liquid is spilled on the seat. Allow the seat to dry thoroughly. The heated seats will only function when the ignition is in the on position.
Page 132 Seating and Safety Restraints Press the release button to lower the head restraint. Folding down the 60/40 rear seats Note: The head restraints should be placed in the full down position before folding the seatback down. Note: Ensure that no objects such as books, purses, or briefcases are on the floor in front of, on or under the second row seat cushion before actuating the release lever to cycle the seats to the load-floor position.
Page 133 Seating and Safety Restraints 2nd row EasyFold™ seatback release (if equipped) WARNING: Ensure that the seat is unoccupied when folding it down. Folding the seat while occupied could result in damage to the seat or injury. Note: The power feature is operational when the vehicle is in park and the lifgate has been open for less than 10 minutes.
Page 134 Seating and Safety Restraints Adjusting the second row seatback WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. The second row seat reclines for additional comfort.
Page 135: Safety Restraints
Seating and Safety Restraints To access the cup holders, lift up one of the slotted areas on the cover. WARNING: Use only soft cups in the cupholder. Hard objects can injure you in a collision. Returning the 2nd row armrest to the upright position Close the cover on the cup holders.
Page 136 Seating and Safety Restraints • The electrical wiring for the airbags, crash sensor(s), safety belt pretensioners, front safety belt usage sensors, driver seat position sensor, front passenger sensing system, and indicator lights. How does the Personal Safety System work? The Personal Safety System can adapt the deployment strategy of your vehicle’s safety devices according to crash severity and occupant conditions.
Page 137 Seating and Safety Restraints Front passenger sensing system For airbags to do their job they must inflate with great force, and this force can pose a potentially deadly risk to occupants that are very close to the airbag when it begins to inflate. For some occupants, this occurs because they are initially sitting very close to the airbag.
Page 138 Seating and Safety Restraints during frontal collisions, and in rollover and side collisions when the Safety Canopy is activated. This helps increase the effectiveness of the safety belts. In frontal collisions, the safety belt pretensioners can be activated alone or, if the collision is of sufficient severity, together with the front airbags.
Page 139 Seating and Safety Restraints WARNING: To reduce the risk of injury, make sure children sit where they can be properly restrained. WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.
Page 140 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 141 Seating and Safety Restraints WARNING: Failure to inspect and replace if necessary the belt and retractor assembly after an accident could increase the risk of injury in a collision. All safety restraints in the vehicle are combination lap and shoulder belts.
Page 142 Safety seats for children later in this chapter. How to disengage the automatic locking mode WARNING: Ford Motor Company recommends that all passenger safety belt assemblies and attaching hardware should be inspected by an authorized dealer after any collision to verify that the automatic locking retractor feature for child seats is still working properly.
Page 143 Seating and Safety Restraints The safety belt pretensioner tightens the safety belts firmly against the occupant’s body at the start of the crash. WARNING: The driver and front passenger safety belt system (including retractors, buckles and height adjusters) must be replaced if the vehicle is involved in a collision that results in deployment of front airbags, seat-mounted side airbags and Safety Canopy , and safety belt pretensioners.
Page 144 Seating and Safety Restraints To adjust the comfort guide: 1. Slip the shoulder belt into the belt guide. 2. Slide the guide up or down along the webbing so that the belt is centered on the occupant’s shoulder. WARNING: Position the safety belt comfort guide so that the belt rests across the middle of your shoulder.
Page 145 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the on warning chime sounds 4-8 seconds. position...
Page 146 Seating and Safety Restraints If... Then... The driver’s and front The Belt-Minder feature will not passenger’s safety belts are activate. buckled before the ignition switch is turned to the on position or less than 1-2 minutes have elapsed since the ignition switch has been turned to on...
Page 147 Seating and Safety Restraints Reasons given... Consider... “Belts are We design our safety belts to enhance comfort. If uncomfortable” you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible; this can improve comfort.
Page 148 Seating and Safety Restraints One-time disable If at any time the driver/front passenger quickly buckles then unbuckles the safety belt for that seating position, the Belt-Minder is disabled for the current ignition cycle. The Belt-Minder feature will enable during the same ignition cycle if the occupant buckles and remains buckled for approximately 30 seconds.
Page 149: Airbags
Seating and Safety Restraints 1. Turn the ignition switch to the on position. DO NOT START THE ENGINE. 2. Wait until the safety belt warning light turns off (Approximately 1–2 minutes). • Step 3 must be completed within 50 seconds after the safety belt warning light turns off.
Page 150 Seating and Safety Restraints Important supplemental restraint system precautions Airbags DO NOT inflate slowly or gently and the risk of injury from a deploying airbag is greatest close to the trim covering the airbag module. WARNING: All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag supplemental restraint system (SRS) is provided.
Page 151 Seating and Safety Restraints WARNING: Do not put anything on or over the airbag module. Placing objects on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury. WARNING: Do not attempt to service, repair, or modify the airbag supplemental restraint system (SRS) or its fuses.
Page 152 Seating and Safety Restraints How does the safety belt pretensioner and airbag supplemental restraint system work? The safety belt pretensioner and airbag SRS are designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates pretensioner activation and airbag inflation.
Page 153 Seating and Safety Restraints WARNING: Several air bag system components get hot after inflation. Do not touch them after inflation. WARNING: If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 154 Seating and Safety Restraints The front passenger sensing system will disable (will not inflate) the front passenger’s frontal airbag if: • the front passenger seat is unoccupied, or has small/medium objects in the front seat. • the system determines that an infant is present in a rear-facing infant seat that is installed according to the manufacturer’s instructions.
Page 155 Seating and Safety Restraints The front passenger sensing system is designed to enable (may inflate) the front passenger’s frontal airbag anytime the system senses that a person of adult size is sitting properly in the front passenger seat. • When the front passenger sensing system enables the front passenger frontal airbag (may inflate), the indicator lamp will be unlit and stay unlit.
Page 156 Seating and Safety Restraints leans forward or sideways, or puts one or both feet up, the chance of injury during a crash is greatly increased. WARNING: Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the front passenger sensing system, resulting in serious injury or death in a crash.
Page 157 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide.
Page 158 Seating and Safety Restraints WARNING: Any alteration/modification to the front passenger seat may affect the performance of the front passenger sensing system. Determining if the system is operational The supplemental restraint system uses a warning indicator light in the instrument cluster or a back-up tone to indicate the condition of the system.
Page 159 Seating and Safety Restraints WARNING: Do not attempt to service, repair, or modify the airbag SRS, its fuses or the seat cover on a seat containing an airbag. Contact your authorized dealer as soon as possible. WARNING: All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided.
Page 160 Seating and Safety Restraints The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side airbags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration.
Page 161 Seating and Safety Restraints Safety Canopy system WARNING: Do not place objects or mount equipment on or near the headliner at the siderail that may come into contact with a deploying Safety Canopy . Failure to follow these instructions may increase the risk of personal injury in the event of a collision.
Page 162 Seating and Safety Restraints How does the Safety Canopy system work? The design and development of the Safety Canopy system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 163 Seating and Safety Restraints Children 12 years old and under should always be properly restrained in the second or third row seats. The Safety Canopy will not interfere with children restrained using a properly installed child or booster seat because it is designed to inflate downward from the headliner above the doors along the side window opening.
Page 164 Seating and Safety Restraints Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system. Refer to the Airbag readiness section in the Instrument Cluster chapter. Routine maintenance of the airbag is not required.
Page 165: Child Restraints
Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 166 Seating and Safety Restraints Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Infants or Children weighing 40 lb (18 kg) or Use a child safety toddlers less (generally age four or younger) seat (sometimes called an infant carrier, convertible seat, or toddler seat).
Page 167 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated be- low by “X” LATCH LATCH Safety Safety Safety (lower (lower belt belt and belt anchors LATCH only Child straint chors only) (lower Weight Type...
Page 168 Seating and Safety Restraints WARNING: Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by the vehicle manufacturer.
Page 169 Seating and Safety Restraints training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
Page 170 Seating and Safety Restraints Children 12 and under should be properly restrained in a rear seating position whenever possible. If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat. Installing child safety seats with combination lap and shoulder belts Check to make sure the child seat is properly secured before each use.
Page 171 Seating and Safety Restraints 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat...
Page 172 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 173 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 174 Seating and Safety Restraints Your vehicle has LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol. The LATCH anchors are located at the rear section of the rear seat between the cushion and seat back, below the locator symbols on the seat back.
Page 175 Seating and Safety Restraints Use of inboard lower anchors from the outboard seating positions (center seating use) The lower anchors at the center of the second row rear seat are spaced 460 mm (18 inches) apart. The standardized spacing for LATCH lower anchors is 280 mm (11 inches) center to center.
Page 176 Seating and Safety Restraints Attaching child safety seats with tether straps Many forward-facing child safety seats include a tether strap which extends from the back of the child safety seat and hooks to an anchoring point called the top tether anchor. Tether straps are available as an accessory for many older safety seats.
Page 177 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster.
Page 178 Seating and Safety Restraints Booster seats position a child so that vehicle lap/shoulder safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably at the edge of the cushion, while minimizing slouching.
Page 179 Seating and Safety Restraints Types of booster seats There are generally two types of belt-positioning booster seats: backless and high back. Always use booster seats in conjunction with the vehicle lap/shoulder belt. • Backless booster seats If your backless booster seat has a removable shield, remove the shield.
Page 180 Seating and Safety Restraints Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 181 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 182: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO CROSSOVER VEHICLE OWNERS Crossover vehicles handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Crossover vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 183 Tires, Wheels and Loading driving surfaces are relatively level, obstruction-free and otherwise similar to normal on-road driving conditions. Operating your vehicle under other than those conditions could subject the vehicle to excessive stress which might result in damage which is not covered under your warranty.
Page 184: Tire Information
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 185 Tires, Wheels and Loading WARNING: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 186: Tire Inflation
Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 187 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 188 Tires, Wheels and Loading Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump. It is normal for tires to heat up and the air pressure inside to go up as you drive.
Page 189 Tires, Wheels and Loading Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
Page 190 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
Page 191 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System.
Page 192 Tires, Wheels and Loading WARNING: If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion. A tire can explode in as little as three to five seconds.
Page 193 Tires, Wheels and Loading • Front Wheel Drive (FWD)/All Wheel Drive (AWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 194 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 195 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
Page 196 Tires, Wheels and Loading 10. Tire Ply Composition and Material Used: Indicates the number of plies or the number of layers of rubber-coated fabric in the tire tread and sidewall. Tire manufacturers also must indicate the ply materials in the tire and the sidewall, which include steel, nylon, polyester, and others.
Page 197 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below. Note: Tire Quality Grades do not apply to this type of tire. 1.
Page 198 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 199: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 200 Tires, Wheels and Loading The Tire Pressure Monitoring System complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 201 Tires, Wheels and Loading Understanding your Tire Pressure Monitoring System (TPMS) The Tire Pressure Monitoring System measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The Low Tire Pressure Warning Lamp will turn ON if the tire pressure is significantly low.
Page 202 Tires, Wheels and Loading When you believe your system is not operating properly The main function of the Tire Pressure Monitoring System is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
Page 203 Tires, Wheels and Loading Low Tire Pressure Possible cause Customer Action Required Warning Light Flashing Warning Spare tire in use Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.
Page 204 SNOW TIRES AND CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 205: Vehicle Loading
Tires, Wheels and Loading VEHICLE LOADING – WITH AND WITHOUT A TRAILER This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 206 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 207 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 208 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 209 Tires, Wheels and Loading WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury. GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer.
Page 210 Tires, Wheels and Loading WARNING: Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 211: Trailer Towing
Tires, Wheels and Loading to transport the cement to your home? If you and your friend each weigh 220 lb. (99 kg), the calculation would be: 1,400 - (2 x 220) - (12 x 100) = 1,400 - 440 - 1,200 = - 240 lb. No, you do not have enough cargo capacity to carry that much weight.
Page 212 Tires, Wheels and Loading Do not exceed the maximum loads listed on the Safety Compliance Certification label. For load specification terms found on the label, refer to Vehicle loading–with and without a trailer in this chapter. Remember to figure in the tongue load of your loaded vehicle when figuring the total weight.
Page 213 Tires, Wheels and Loading Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle. Contact your authorized dealer or a reliable trailer dealer as soon as possible if you require assistance. Hitches Do not use hitches that clamp onto the vehicle’s bumper or attach to the axle.
Page 214 Tires, Wheels and Loading cause them not to function properly. Your lamp outage feature may also be disabled or provide incorrect information. Trailer tow connector (equipped on vehicles with a Class II trailer tow/prep package) The trailer tow connector is located under the rear bumper, on the driver’s side of the vehicle.
Page 215: Recreational Towing
Tires, Wheels and Loading Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
Page 216 Tires, Wheels and Loading All Wheel Drive (AWD) vehicles: Tow your All Wheel Drive vehicle with all four wheels on the ground or with all four wheels off the ground using a vehicle transport trailer. Do not tow your All Wheel Drive vehicle with the front wheels off the ground (by using a tow dolly) and the rear wheels on the ground.
Page 217: Driving
Driving STARTING Positions of the ignition 1. Off— locks the automatic transmission gearshift lever and allows key removal. This position also shuts the engine and all electrical accessories off without locking the steering wheel. To lock the steering wheel, remove the key then turn the steering wheel.
Page 218 Driving WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. WARNING: Do not start your vehicle in a closed garage or in other enclosed areas.
Page 219 Driving • Make sure the gearshift is in P (Park). 3. Turn the key to 3 (on) without turning the key to 4 (start). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
Page 220 Driving that assists in starting the engine. After releasing the key from the 4 (start) position, the engine may continue cranking for up to 10 seconds or until the vehicle starts. Note: Cranking may be stopped at any time by turning the key to the off position 3.
Page 221 Driving WARNING: To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. Prior to using the engine block heater, follow these recommendations for proper and safe operation: • For your safety, use an outdoor extension cord that is product certified by Underwriter’s Laboratory (UL) or Canadian Standards Association (CSA).
Page 222: Brakes
Driving How to use the engine block heater Ensure the receptacle terminals are clean and dry prior to use. To clean them, use a dry cloth. Depending on the type of factory installed equipment, your engine block heater will use .4 to 1.0 kilowatt-hours of energy per hour of use. Your factory installed block heater system does not have a thermostat;...
Page 223 Driving ABS warning lamp The ABS lamp in the instrument cluster momentarily illuminates when the ignition is turned on. If the light does not illuminate during start up, remains on or flashes, the ABS may be disabled and may need to be serviced. Even when the ABS is disabled, normal braking is still effective.
Page 224: Advancetrac
Driving Press the parking brake pedal downward again to release the parking brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. Note: If the vehicle is driven with the parking brake applied, a chime will sound.
Page 225 Driving WARNING: If a failure has been detected within the AdvanceTrac with RSC system, the sliding car icon will illuminate steadily. Verify that the AdvanceTrac with RSC system is not manually disabled (push the AdvanceTrac with RSC “Off “ button located on the center of the instrument panel). If the sliding car icon still illuminates steadily, have the system serviced by an authorized dealer immediately.
Page 226 Driving When AdvanceTrac with RSC performs a normal system self-check, some drivers may notice a slight movement of the brake, and/or a rumble, grunting, or grinding noise after startup and when driving off. When an event occurs that activates AdvanceTrac with RSC you may experience the following: •...
Page 227 Driving Electronic Stability Control (ESC) Electronic Stability Control (ESC) may enhance your vehicle’s directional stability during adverse maneuvers, for example when cornering severely or avoiding objects in the roadway. ESC operates by applying brakes to one or more of the wheels individually and, if necessary, reducing engine power if the system detects that the vehicle is about to skid or slide laterally.
Page 228 Driving The Roll Stability Control system may be deactivated in certain situations. See the Switching Off AdvanceTrac with RSC section following. Switching Off AdvanceTrac with RSC If the vehicle is stuck in snow, mud or sand, and seems to lose engine power, switching off certain features of the AdvanceTrac with RSC system may be beneficial because the wheels are allowed to spin.
Page 229: Transmission Operation
Driving STEERING To help prevent damage to the power steering system: • Never hold the steering wheel at its furthest turning points (until it stops) for more than a few seconds when the engine is running. • Do not operate the vehicle with a low power steering fluid level (below the MIN mark on the reservoir).
Page 230 Driving If you cannot move the gearshift lever out of P (Park) with ignition in the on position and the brake pedal pressed: 1. Apply the parking brake, turn ignition key to off, then remove the key. 2. Using a screwdriver (or similar tool), remove the protective cover to the interlock release access hole on the console.
Page 231 Driving Automatic Transmission Adaptive Learning Your transmission is equipped with an adaptive learning strategy found in the vehicle computer. This feature is designed to increase durability and provide consistent shift feel over the life of the vehicle. A new vehicle or transmission may have firm and/or soft shifts.
Page 232 Driving N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. D (Drive) with Overdrive The normal driving position for the best fuel economy. Transmission operates in gears one through six.
Page 233: Reverse Sensing System
Driving Overdrive Cancel with Grade Assist is designed to provide optimal gear selection in hilly terrain or mountainous areas. It is recommended that you return to O/D (overdrive mode) on flat terrain to provide the best fuel economy and transmission function. To return to O/D (overdrive mode), press the transmission control switch again.
Page 234 Driving WARNING: To help avoid personal injury, always use caution when in R (Reverse) and when using the RSS. WARNING: This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 235 Driving While receiving a warning the radio volume will be reduced to a predetermined level. After the warning goes away, the radio will return to the previous value. The RSS automatically turns on when the gearshift lever is placed in R (Reverse) and the ignition is on.
Page 236 Driving Driving with blind spot mirrors Before a lane change, check the main mirror first, then check the blind spot mirror. If no vehicles are present in the blind spot mirror and the traffic in the adjacent lane is at a safe distance, signal that you are going to change lanes.
Page 237 Driving Note: Your AWD vehicle is not intended for severe off-road use. The AWD feature gives your vehicle some limited off-road capabilities in which driving surfaces are relatively level, obstruction-free and otherwise similar to normal on-road driving conditions. Operating your vehicle under other than those conditions could subject the vehicle to excessive stress which might result in damage which is not covered under your warranty.
Page 238 Driving If your vehicle is equipped with AdvanceTrac with Roll Stability Control™, it may be beneficial to disengage the AdvanceTrac with Roll Stability Control™ system while attempting to rock the vehicle. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 239 Driving AWD Systems (if equipped) With AWD, the vehicle uses all four wheels to power the vehicle. This increases traction, enabling you to drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot. Sand When driving over sand, try to keep all four wheels on the most solid area of the trail.
Page 240 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 241 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
Page 242 Any modifications to a vehicle that raise the center of gravity can make it more likely the vehicle will rollover as a result of a loss of control. Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder or luggage racks).
Page 243: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 244: Hazard Flasher Control
Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles. To obtain reimbursement information, U.S.
Page 245: Fuel Pump Shut-Off Switch
Roadside Emergencies FUEL PUMP SHUT-OFF SWITCH This device stops the electric fuel pump from sending fuel to the engine when your vehicle has had a substantial jolt. After an accident, if the engine cranks but does not start, this switch may have been activated.
Page 246 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 247 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Protected Circuits Location Rating Not used (Spare) Not used (Spare) SYNC Driver front smart window Keypad illumination, 2nd row seat, Tire Pressure Monitoring System (TPMS), Brake Shift Interlock (BSI), Smart junction box (SJB) Turn signals Low beam headlamps (left)
Page 248 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Backlighting, Puddle lamps, Ambient lighting All wheel drive 7.5A Power mirror switch, Driver side power seat memory, Driver seat module – Keep alive power (KA) Satellite radio Power liftgate module Climate control Not used (Spare) All power lock motor feeds, Liftgate release...
Page 249 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating PATS transceiver Climate control Subwoofer/Amp (Audiophile radio) Radio Not used (Spare) Delayed accessory function for radio and lock switch illumination, Ambient lighting Not used (Spare) Rear wiper logic Customer accessory feed Front wiper logic, Climate control relay feed 7.5A...
Page 250 Roadside Emergencies The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Not used — Blower motor relay — Not used — Not used 40A** Cooling fan (vehicles with trailer tow) 60A** Cooling fan (vehicles without trailer tow) 40A** Cooling fan (trailer tow only)
Page 251 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 30A** Front heated seats 20A** Cigar lighter/Power point 20A** Panoramic moon roof — Fuel pump diode — Powertrain control module (PCM) relay 7.5A* PCM – Keep alive power (KA) —...
Page 252: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 10A* Trailer tow right stop/turn lamp — Trailer tow right stop/turn lamp relay — Run/Start relay 10A* PCM ISPR 10A* ABS Run/Start — Not used Fuel pump relay coil 30A** SPDJB Run/Start —...
Page 253: Dissimilar Spare Tire/Wheel Information
Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 254 Roadside Emergencies • Load the vehicle beyond maximum vehicle load rating listed on the Safety Compliance Label • Tow a trailer • Use snow chains on the end of the vehicle with the dissimilar spare tire • Use more than one dissimilar spare tire at a time •...
Page 255 Roadside Emergencies When driving with the full-size dissimilar spare tire/wheel additional caution should be given to: • Towing a trailer • Driving vehicles equipped with a camper body • Driving vehicles with a load on the cargo rack Drive cautiously when using a full-size dissimilar spare tire/wheel and seek service as soon as possible.
Page 256 Roadside Emergencies Tire change procedure WARNING: When one of the front wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the vehicle is in P (Park). WARNING: To help prevent the vehicle from moving when you change a tire, be sure to place the transmission in P (Park), set the parking brake and block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire...
Page 257 Roadside Emergencies WARNING: To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 258: Wheel Lug Nut Torque
20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 259: Jump Starting
Roadside Emergencies Note: Inspect the wheel pilot hole prior to installation. If there is visible corrosion in wheel pilot hole, remove loose particles by wiping with clean rag and apply grease. Apply grease only to the wheel pilot hole surface by smearing a “dime” (1 square cm) sized glob of grease around the wheel pilot surface (1) with end of finger.
Page 260 Roadside Emergencies 4. Check all battery terminals and remove any excessive corrosion before you attach the battery cables. Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect from any electrical surges.
Page 261 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 262 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 263 Roadside Emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery.
Page 264: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. On FWD vehicles, if your vehicle is to be towed from the front, ensure proper wheel lift equipment is used to raise the front wheels off the ground.
Page 265 If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 266: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 267 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final...
Page 268 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step...
Page 269 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 270 United States and Canada, provided by a network of more than 4,600 participating authorized dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this...
Page 271 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 272: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 273: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 274 Cleaning WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area.
Page 275 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 276 Cleaning vehicle’s glass or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, water repellent coatings, tree sap, or other organic contamination; these contaminants may cause squeaking or chatter noise from the blades, and streaking and smearing of the windshield.
Page 277 Cleaning • Be certain to wash or wipe your hands clean if you have been in contact with certain products such as insect repellent and suntan lotion in order to avoid possible damage to the interior painted surfaces. • Do not use household or glass cleaners as these may damage the finish of the instrument panel, interior trim and cluster lens.
Page 278 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 279 Cleaning Motorcraft Custom Vinyl Protectant (ZC-40-A) Motorcraft Dash and Vinyl Cleaner (ZC-38-A) Motorcraft Deluxe Leather and Vinyl Cleaner (U.S. only) (ZC-11-A) Motorcraft Leather Care Kit (U.S. only) (ZC-11-D) Motorcraft Detail Wash (ZC-3-A) Motorcraft Dusting Cloth (ZC-24) Motorcraft Engine Shampoo and Degreaser (U.S. only) (ZC-20) Motorcraft Engine Shampoo (Canada only) (CXC-66-A) Motorcraft Multi-Purpose Cleaner (Canada only) (CXC-101) Motorcraft Premium Glass Cleaner (Canada only) (CXC-100)
Page 280: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide/Customer Information Guide to find out which parts and services are covered.
Page 281 Maintenance and Specifications Working with the engine on 1. Set the parking brake and shift to P (Park). 2. Block the wheels. WARNING: To reduce the risk of vehicle damage and/or personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 282: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 1. Engine coolant reservoir 2. Power steering fluid reservoir 3. Brake fluid reservoir 4. Battery 5. Power distribution box 6. Air filter assembly 7. Transmission fluid dipstick 8. Engine oil dipstick 9.
Page 283 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16-A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 284 Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Press the lock tab to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 285: Engine Oil
Maintenance and Specifications 4. Attach the new wiper to the wiper arm and press it into place until a click is heard. If you find this procedure too difficult, please see your dealer. ENGINE OIL Checking the engine oil Refer to the scheduled maintenance information for the appropriate intervals for checking the engine oil.
Page 286 Maintenance and Specifications • If the oil level is within this range, the oil level is acceptable. DO NOT ADD OIL. • If the oil level is below this mark, engine oil must be added to raise the level within the normal operating range.
Page 287 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance information. Ford production and Motorcraft replacement oil filters are designed for added engine protection and long life. If a replacement oil filter is used...
Page 288: Battery
Maintenance and Specifications that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced. It is recommended you use the appropriate Motorcraft oil filter or another with equivalent performance for your engine application. BATTERY...
Page 289 Maintenance and Specifications WARNING: When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 290: Engine Coolant
Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock and radio settings must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 291 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the FULL COLD level or within the COLD FILL RANGE as listed on the engine coolant reservoir (depending upon application).
Page 292 Maintenance and Specifications Note: Do not use stop leak pellets or cooling system sealants/additives as they can cause damage to the engine cooling and/or heating systems. This damage would not be covered under your vehicle’s warranty. • A large amount of water without engine coolant may be added, in case of emergency, to reach a vehicle service location.
Page 293 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
Page 294 Maintenance and Specifications • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate freeze protection at the temperatures in which you drive in the winter months. If you drive in extremely hot climates: •...
Page 295: Fuel Information
Maintenance and Specifications Continued operation will increase the engine temperature: • The engine will completely shut down. • Steering and braking effort will increase. Once the engine temperature cools, the engine can be re-started. Take your vehicle to an authorized dealer as soon as possible to minimize engine damage.
Page 296 Maintenance and Specifications WARNING: The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. WARNING: If you do not use the proper fuel filler cap, excessive vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in...
Page 297 Maintenance and Specifications clothing and wash skin thoroughly with soap and water. Repeated or prolonged skin contact with fuel liquid or vapor causes skin irritation. • Be particularly careful if you are taking “Antabuse” or other forms of disulfiram for the treatment of alcoholism. Breathing gasoline vapors, or skin contact could cause an adverse reaction.
Page 298 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford, Motorcraft or other certified fuel filler cap is not used. WARNING: The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 299 Maintenance and Specifications WARNING: If you do not use the proper fuel filler cap, excessive vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in personal injury. Choosing the right fuel Use only UNLEADED fuel or UNLEADED fuel blended with a maximum of 10% ethanol.
Page 300 Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 301 Maintenance and Specifications possible. Fuel expense, frequency of fill-ups or fuel gauge readings are NOT accurate as a measure of fuel economy. We do not recommend taking fuel economy measurements during the first 1,000 miles (1,600 km) of driving (engine break-in period). You will get a more accurate measurement after 2,000 miles–3,000 miles (3,000 km–5,000 km).
Page 302 Maintenance and Specifications 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading. 4. Subtract your initial odometer reading from the current odometer reading. 5. Follow one of the simple calculations in order to determine fuel economy: Calculation 1: Divide total miles traveled by total gallons used.
Page 303 Maintenance and Specifications • Resting your foot on the brake pedal while driving may reduce fuel economy. • Combine errands and minimize stop-and-go driving. Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy.
Page 304 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 305 Maintenance and Specifications it from working. Information about your vehicle’s emission system is on the Vehicle Emission Control Information Decal located on or near the engine. This decal also lists engine displacement. Please consult your Warranty Guide/Customer Information Guide for complete emission warranty information.
Page 306 Maintenance and Specifications Readiness for Inspection/Maintenance (I/M) testing Some state/provincial and local governments may have Inspection/Maintenance (I/M) programs to inspect the emission control equipment on your vehicle. Failure to pass this inspection could prevent you from getting a vehicle registration. Your vehicle may not pass the I/M test if the service engine soon indicator is on or not working properly (bulb is burned out), or if the OBD-II system has determined...
Page 307 Maintenance and Specifications 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C). 2. While the engine idles, turn the steering wheel left and right several times.
Page 308 Maintenance and Specifications consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage. Automatic transmission fluid expands when warmed. To obtain an accurate fluid check, drive the vehicle until it is warmed up (approximately 20 miles [30 km]).
Page 309 Maintenance and Specifications High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 310: Air Filter(S)
Maintenance and Specifications AIR FILTER Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the air filter element listed. Refer to Motorcraft part numbers in this chapter. WARNING: To reduce the risk of vehicle damage and/or personal burn injuries do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 311: Part Numbers
PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 312: Maintenance Product Specifications And Capacities
Maintenance and Specifications...
Page 313 Maintenance and Specifications...
Page 314 Maintenance and Specifications...
Page 315: Engine Data
Maintenance and Specifications ENGINE DATA Engine 3.5L-DOHC V6 engine Cubic inches Required fuel 87 octane Firing order 1–4–2–5–3–6 Spark plug gap 0.050–0.057 inch (1.29–1.45 mm) Ignition system Coil on plug Compression ratio 10.3:1 Engine drivebelt routing 1. Short drivebelt is on first pulley groove closest to engine. 2.
Page 316 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
Page 317 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint System 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6.
Page 318: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 319 Accessories Peace of mind Remote start Vehicle security systems Wheel locks For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).
Page 320: Index
Index Accessory delay ......72 Battery ........287 acid, treating emergencies ..287 AdvanceTrac ......223 jumping a disabled battery ..258 Air cleaner filter ....309–310 maintenance-free ....287 Air conditioning ......51 replacement, specifications ...310 Airbag supplemental restraint servicing ........287 system ....148–149, 157, 160 Belt-Minder ......144 and child safety seats ....150 description ....149, 157, 160 Blind Spot Spotter Mirror ..234...
Page 321 ....287 lubrication specifications ..311 Cupholder(s) ......133 refill capacities ......311 Customer Assistance ....242 service points ....281–282 Ford Extended starting after a collision ..244 Service Plan ......269 Engine block heater ....219 Getting assistance outside the U.S. and Canada .....269...
Page 322 Index change oil soon warning, message center .......284 Gas cap (see Fuel cap) ....297 checking and adding ....284 dipstick ........284 Gas mileage filter, specifications ..286, 310 (see Fuel economy) ....299 recommendations ....286 Gauges .........17 refill capacities ......311 specifications ......311 Event data recording ....7 Hazard flashers ......243 Exhaust fumes ......219 Head restraints ......131...
Page 323 Index cluster ........12 Locks lighting up panel autolock ........104 and interior .......58 childproof ........108 doors ........104 Lubricant specifications ...311 Lug nuts ........257 Jack ..........251 positioning .......251 Lumbar support, seats .....125 storage ........251 Jump-starting your vehicle ..258 Message center .....84–86 english/metric button ....90 system check button ....90 Keyless entry system warning messages .....92...
Page 324 Index Passenger Occupant Safety defects, reporting ..271 Classification Sensor ....136 Safety restraints ....134, 137, Power distribution box 139–142 (see Fuses) .......248 Belt-Minder ......144 Power door locks ......104 extension assembly ....143 Power liftgate ......96 for adults ......139–141 for children ......164 Power mirrors ......74 Occupant Classification Power point .........69 Sensor ........136...
Page 325 Index Spark plugs, trailer towing ......210 specifications .....310, 314 wrecker ........263 Specification chart, Transmission ......228 lubricants ........311 brake-shift interlock (BSI) ..228 Speed control ......75 fluid, checking and adding Starting your vehicle ..216–218 (automatic) ......306 jump starting ......258 fluid, refill capacities ....311 Steering wheel lubricant specifications ..311 controls ........77...

This manual is also suitable for:

2009 edge

Ford Automobile Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Related Manuals for Ford Automobile

Summary of Contents for Ford Automobile

This manual is also suitable for:

Table of Contents
