2010 Ford Escape Hybrid Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Message center Entertainment Systems AM/FM stereo with CD/MP3 Auxiliary input jack (Line in) USB port Satellite radio information Navigation system SYNC Climate Controls Dual automatic temperature control...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes AdvanceTrac Transmission operation Reverse sensing system Rear-view camera system Roadside Emergencies Getting roadside assistance...
Page 4: Introduction
For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com •...
Page 5 Introduction Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment.
Page 6 Introduction Do not add friction modifier compounds or special break-in oils since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage. HYBRID OPERATION This hybrid vehicle combines electric and gasoline propulsion without compromise, to provide breakthrough performance and efficiency.
Page 7 Introduction Stopping: The gas engine may shut off to conserve fuel as you come to a stop. Restarting the vehicle is not required. Simply step on the accelerator when you are ready to drive. Transmission Operation: Due to the technologically advanced, electronically-controlled Continuously Variable Transaxle (eCVT) you will not feel shift changes like those of a non-hybrid vehicle.
Page 8 Introduction Engine: The engine speed in your hybrid is not directly tied to your vehicle speed. Your vehicle’s engine and transmission are designed to deliver the power you need at the most efficient engine speed. During heavy accelerations, your hybrid may reach high engine speeds (up to 6000 RPM).
Page 9 Introduction Additional Tips: • Do not carry extra loads • Be mindful of adding external accessories that may increase aerodynamic drag • Observe posted speed limits • Perform all scheduled maintenance • There is no need to wait for your engine to “warm up”. The vehicle is ready to drive immediately after starting Refer to Essentials of good fuel economy in the Maintenance and Specifications chapter for more fuel saving tips.
Page 10 Introduction Question Answer After I start my car in the There are several reasons the engine morning, why does it take a stays on for an extended amount of time long time before the engine when it is first started. One common shuts down? reason is to ensure that the emissions components are warm enough to...
Page 11 Introduction Question Answer What is the fan noise I hear The fan noise comes from two fans from the rear of my hybrid? located inside the high voltage battery. These fans turn on when the battery requires cooling air. The fan speed, and associated noise level, will change according to both the amount of cooling required and the speed of the vehicle to...
Page 12 Do not use this vehicle for snowplowing. Your vehicle is not equipped with a snowplowing package. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package.
Page 13 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 14 Introduction may seek to access the information independently of Ford Motor Company and Ford of Canada. To the extent that any law pertaining to Event Data Recording applies to SYNC or its features, please note the following: Once 911 Assist (if equipped)
Page 15 Introduction WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 16 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
Page 17 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 18: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
Page 19 Instrument Cluster WARNING: Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Brake system warning light: To confirm the brake system warning light is functional, it will BRAKE momentarily illuminate when the ignition is turned to the on position...
Page 20 Instrument Cluster Safety belt: Reminds you to fasten your safety belt. A Belt-Minder chime will also sound to remind you to fasten your safety belt. Refer to the Seating and Safety Restraints chapter to activate/deactivate the Belt-Minder chime feature. Stop safely hazard warning: Indicates hybrid component fault/failure that will cause the vehicle to shutdown, fail to start or...
Page 21 Instrument Cluster High engine or high motor electronic coolant temperature: Illuminates when the engine coolant or motor electronics coolant temperature is high. The message center displays HIGH ENGINE TEMPERATURE / HIGH MOTOR TEMPERATURE when the engine coolant or motor electronics are overheating.
Page 22 Instrument Cluster Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter). Speed control: Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged.
Page 23: Gauges
Instrument Cluster HEV engine off reminder chime: Sounds for 10 seconds when the PRNDL is in the P (Park) position and the Driver’s door is ajar (open) while ignition is on. Always turn your ignition key to off and remove key before leaving your vehicle.
Page 24 Instrument Cluster Battery gauge: Provides information about the vehicle’s energy usage. • ASSIST — Battery provides extra power to boost the vehicle’s acceleration. • CHARGE — Storing extra energy in the battery when coasting or slowing down. Odometer: Registers the total miles (kilometers) of the vehicle.
Page 25: Message Center
Instrument Cluster MESSAGE CENTER Your vehicle’s message center is capable of monitoring many vehicle systems and will alert you to potential vehicle problems and various conditions with an informational message followed by a long indicator chime. The message center display is located in the instrument cluster. Info Press the INFO button repeatedly to cycle through the following features:...
Page 26 Instrument Cluster AVG MPG (L/100km) Average fuel economy displays your average fuel economy in miles/gallon or liters/100 km. If you calculate your average fuel economy by dividing distance traveled by gallons of fuel used (liters of fuel used by 100 kilometers traveled), your figure may be different than displayed for the following reasons: •...
Page 27 Instrument Cluster System check and vehicle feature customization Press the SETUP button repeatedly to cycle the message center through the following features: PRESS RESET FOR ENGLISH When entering the setup menu and a non-English language has been selected, this message will be displayed to change back to English. Press the RESET button to change back to English.
Page 28 Instrument Cluster 2. Press and hold the RESET button for two seconds and release to reset the oil life to 100%. Note: To change oil life 100% miles value from 7,500 miles (12,000 km) or 12 months to another value, proceed to Step 3. 3.
Page 29 Instrument Cluster RESET FOR CALIBRATION For more information on the compass and compass set up, refer to Electronic compass in the Driver Controls chapter. LANGUAGE = ENGLISH / SPANISH / FRENCH Allows you to choose which language the message center will display in. Selectable languages are English, Spanish, or French.
Page 30 Instrument Cluster STOP SAFELY NOW — Displayed when the stop safety hazard warning lamp is illuminated. This indicates a hybrid component fault/failure that will cause the vehicle to shut down, fail to start or enter into limited operating mode. Note: If the vehicle is still running, it may soon shut down without further warning and should be stopped safely.
Page 31 Instrument Cluster CHECK FUEL FILL INLET — Displayed when the fuel fill inlet may not be properly closed. Refer to Easy Fuel™ “no cap” fuel system in the Maintenance and Specifications chapter. BRAKE FLUID LEVEL LOW — Indicates the brake fluid level is low and the brake system should be inspected immediately.
Page 32 Instrument Cluster VEHICLE NEAR TOP SPEED — Displayed when a MyKey™ is in use and the MyKey speed limit is on and the vehicle speed is approaching 80 mph (130 km/h). Refer to MyKey™ in the Locks and Security chapter for more information. TOP SPEED MYKEY SETTING —...
Page 33 Instrument Cluster SPACE FOUND PULL FORWARD (if equipped) — May display when using the active park assist system. See Active park assist in the Driving chapter for more information. SPACE FOUND STOP (if equipped) — May display when using the active park assist system.
Page 34: Entertainment Systems
AM/FM/single CD/MP3 satellite compatible sound system WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 35 Entertainment Systems AM/FM Radio / VOL (Power/Volume): Press to turn the radio on/off. Turn the knob to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a nominal listening level when the ignition is turned back on.
Page 36 Entertainment Systems To activate the autoset feature: Press MENU repeatedly until AUTO PRESET ON/OFF appears in the display. Use SEEK/TRACK turn AUTO PRESET to ON, and either wait five seconds for the search to initiate or press OK to immediately initiate the search. If you press another control within those five seconds, the search will not initiate;...
Page 37 Entertainment Systems Play/Pause: Press to play/pause a track when playing a SEEK/TRACK: Press SEEK/TRACK to access the previous/next track. CAT (Category) / FOLD (Folder): In MP3 mode only– Press CAT/FOLD and then press SEEK/TRACK to access the previous/next folder. SCAN: Press for a brief sampling of all tracks on the current disc or MP3 folder.
Page 38 Entertainment Systems SHUFFLE: Press SHUFFLE to turn on and off and begin/stop random play. The system will only shuffle the disc currently playing. Satellite Radio Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. SIRIUS: Press to access satellite radio mode, if equipped.
Page 39 Entertainment Systems MEMORY PRESETS (0–9): There are 30 available presets, 10 each for SAT1, SAT2 and SAT3. To save satellite channels in your memory presets, tune to the desired channel then press and hold a memory preset number (0–9) until sound returns.
Page 40 Entertainment Systems an audible prompt. Press OK while SONG ALERT is in the display and the system will take you to the channel playing the desired song. You can save up to 20 song titles. If you attempt to save more than 20 titles, the display will read REPLACE SONG? Press OK to access the saved titles and press to cycle through the saved titles.
Page 41 Entertainment Systems b. CHANGE PIN: Press OK when CHANGE PIN is displayed. The display will read ENTER OLD PIN. Enter your current (old) PIN number and when the system accepts your entry it will display ENTER NEW PIN. Enter your new four-digit PIN and the system will save the new PIN and PIN SAVED will display.
Page 42: Auxiliary Input Jack (Line In)
Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 43 Entertainment Systems Your vehicle is equipped with an Auxiliary Input Jack (AIJ). The Auxiliary Input Jack provides a way to connect your portable music player to the in-vehicle audio system. This allows the audio from a portable music player to be played through the vehicle speakers with high fidelity.
Page 44: Usb Port
USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 45 Entertainment Systems Your vehicle may be equipped with a USB port located on the instrument panel. This feature allows you to plug in media playing devices, memory sticks, and also to charge devices if they support this feature. For further information on this feature, refer to Accessing and using your USB port in the SYNC supplement or Navigation System...
Page 46 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch...
Page 47 Entertainment Systems CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels.
Page 48: Satellite Radio Information
Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
Page 49 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 50 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. This than two seconds to message should produce audio for the disappear shortly. selected channel. SAT FAULT Internal module or If this message does not system failure present. clear within a short period of time, or with an ignition key cycle,...
Page 51: Navigation System
Entertainment Systems Radio Display Condition Action Required NO TEXT Category information Category information not not available. available at this time on this channel. The system is working properly. NO SIGNAL Loss of signal from You are in a location that the SIRIUS satellite is blocking the SIRIUS or SIRIUS tower to...
Page 52: Climate Controls
Climate Controls DUAL AUTOMATIC TEMPERATURE CONTROL 1. AUTO/Driver temperature: Press to engage full automatic operation. The system will automatically determine fan speed, airflow distribution, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature. Turn to increase/decrease the temperature on the driver side of the vehicle.
Page 53 Climate Controls : Press to activate/deactivate the climate control system. Power/ When the system is off, outside air is shut out. Press + or – manually increase/decrease the fan speed. The manual fan speed setting will appear on the left side of the display. Press AUTO to return to full automatic control.
Page 54 Climate Controls Recirculated air: Press to activate/deactivate air recirculation in the vehicle. Recirculated air may reduce the amount of time needed to cool down the interior of the vehicle, may reduce the energy needed to keep the interior of the vehicle cool, and may also help reduce undesired outside odors from reaching the interior of the vehicle.
Page 55: Manual Operation
Climate Controls • To improve the A/C cool down, drive with the windows slightly open for 2-3 minutes after start up or until the vehicle has been “aired out.” During extreme high ambient temperatures when idling stationary for extended periods of time in gear, it is recommended to run the A/C in the MAX A/C position, reduce blower fan speed from the highest setting and put the vehicle’s transmission into the P (Park) gear position to continue to receive cool air from your A/C system.
Page 56: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice. The vehicle must be on to operate the rear window defroster. Press to turn the rear window defroster on.
Page 57: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position turn on the headlamps. Rotate back to to turn the headlamps off. Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 58 Lights 2. Rotate the headlamp control to the autolamp position. 3. Rotate the headlamp control to the off position. 4. Turn the key to the on position. 5. Turn the key back to the off position. 6. Turn the headlamp control to the autolamp position (the headlights should turn on).
Page 59 Lights Flash-to-pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the lowbeam headlamps on with a reduced output. To activate: • the ignition must be in the on position. • the headlamp control must be in the off , parking lamps or autolamp position.
Page 60 Lights switch from the full dim position to the full dome/on position to reset. This will ensure that your displays are visible under all lighting conditions. AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident, the alignment of your headlamps should be checked by your authorized dealer.
Page 61: Turn Signal Control
Lights 5. Locate the vertical adjuster on the headlamp, then turn the adjuster either clockwise (to adjust up) or counterclockwise (to adjust down) aligning the upper edge of the light pattern to the horizontal line. 6. Move the opaque cloth to cover the right-hand headlamp and repeat Steps 4 and 5 for the left-hand headlamp.
Page 62 Lights The map lamp controls (without moon roof) are located on the dome lamp. Press the button on either side of each map lamp to illuminate the lamps. Press the button again to turn off the lamps. For models equipped with a moon roof, the map lamps are located on the moon roof control panel.
Page 63: Bulb Replacement
Lights Ambient lighting (if equipped) Illuminates footwells, cupholders, the console bin and the console tray with a choice of several colors. The ambient lighting control switch is located on the floor console. To activate, press and release the control to cycle through the color choices plus the off state.
Page 64 Lights Take your vehicle to dealer for service if any of the above conditions of unacceptable moisture are present. Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E”...
Page 65 Lights Replacing headlamp bulbs 1. Make sure that the headlamp control is in the off position. 2. Open the hood. 3. Reach over the front bolster. 4. Remove the bulb by turning it counterclockwise and then pulling it straight out. 5.
Page 66 Lights 5. Carefully pull the bulb out of the socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly and rotate clockwise. Replacing front sidemarker bulbs For bulb replacement, see your authorized dealer. Replacing tail/stop/turn/sidemarker/backup lamp bulbs The tail/stop/turn/sidemarker/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other.
Page 67 Lights Replacing license plate lamp bulbs 1. Make sure the headlamp switch is in the off position. 2. Depress the lever and carefully pry the license plate lamp assembly (located above the license plate) from the liftgate. 3. Rotate the bulb socket counterclockwise and remove from lamp assembly.
Page 68 Lights 3. Pull the bulb straight out of the socket and push in the new bulb. To complete installation, follow the removal procedure in reverse order. Replacing fog lamp bulbs (if equipped) 1. Make sure the fog lamp switch is in the off position.
Page 69: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Press the end of the stalk: •...
Page 70: Steering Wheel Adjustment
Driver Controls Rear window wiper/washer controls For rear wiper operation, rotate the rear window wiper and washer control to the desired position. Select: 2 — Normal speed operation of rear wiper. 1 — Intermittent operation of rear wiper. O (off) — Rear wiper and washer off. For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position.
Page 71 Driver Controls ILLUMINATED VISOR MIRROR Lift the mirror cover to turn on the visor mirror lamps. Slide-on-rod feature The visor will slide back and forth on the rod for increased sunlight coverage. Rotate the visor towards the side window and extend it rearward for additional sunlight coverage.
Page 72 Driver Controls Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. 2. Turn ignition to the on position. 3. Start the engine. 7 8 9 1011 4. Press the SETUP control to select the Update Zone function and display the current ZONE XX in the center stack display.
Page 73 Driver Controls 2. To calibrate, press and hold the RESET control for approximately ten seconds until CAL appears. Release the control. 3. Slowly drive the vehicle in a circle (less than 3 mph [5 km/h]) until the CAL display changes to the direction value.
Page 74 Driver Controls The tray and inside bin can be removed to open up space to fit a laptop computer, MP3 players, CDs or handbags. To remove, open the console lid and pull the bin straight up and out from the console housing.
Page 75 Driver Controls To have full capacity usage of your power point, the engine is required to be running to avoid unintentional discharge of the battery. To prevent the battery from being discharged: • do not use the power point longer than necessary when the engine is not running, •...
Page 76: Power Windows
Driver Controls defeat the safety protection design provided by the cap and twist tab. It will also cause the power point to overload due to powering multiple devices that can reach beyond the 150W load limit. The power point can switch to a fault mode when it is overloaded, overheated, or shorted.
Page 77 Driver Controls One-touch down (AUTO) Allows the driver’s window to open fully without holding the control down. Press the switch completely down to the second detent and release quickly. The window will open fully. Momentarily press the switch to any position to stop the window operation.
Page 78: Mirrors
Driver Controls The mirror will automatically return to the normal state whenever the vehicle is placed in R (Reverse) to ensure a bright clear view when backing up. Do not block the sensors on the front and back of the interior rear view mirror since this may impair proper mirror performance.
Page 79: Speed Control
Driver Controls Fold-away mirrors Fold the side mirrors in carefully when driving through a narrow space, like an automatic car wash. Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.
Page 80 Driver Controls Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release 2. Accelerate to the desired speed. 3. Press the SET + control and release it.
Page 81 Driver Controls Resuming a set speed Press the RES control and release it. This will automatically return the vehicle to the previously set speed. Increasing speed while using speed control There are three ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control.
Page 82 Driver Controls Turning off speed control There are two ways to turn off the speed control: • Press the OFF control. • Turn off the ignition. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. STEERING WHEEL CONTROLS These controls allow you to operate some audio control features.
Page 83 Driver Controls In any mode: • Press VOL + or VOL - to adjust the volume. Navigation system hands-free control features (if equipped) Press and hold control briefly until the voice icon appears on the navigation display to use the voice command feature.
Page 84: Moon Roof
Driver Controls Navigation system/SYNC hands-free control features (if equipped) Press control briefly until the voice icon appears on the Navigation display to use the voice command feature. Press to activate phone mode or answer a phone call. Press and hold to exit phone mode or end a call.
Page 85 Driver Controls Bounce-back: When an obstacle has been detected in the moon roof opening as the moon roof is closing, the moon roof will automatically open and stop at a prescribed position. This is known as “bounce-back”. If the ignition is turned off (without accessory delay being active) during bounce-back, the moon roof will move until the bounce-back position is reached.
Page 86 Driver Controls Car2U Home Automation System (if equipped) The Car2U Home Automation System is a universal transmitter located in the driver’s visor that includes two primary features – a garage door opener and a platform for remote activation of devices within the home.
Page 87 Driver Controls • Fixed code garage door openers were produced prior to 1996. Fixed code uses the same coded signal every time. It is manually programmed by setting DIP switches for a unique personal code. If you do not know if your garage door opener is a rolling code or fixed code device, open your garage door opener’s remote control battery...
Page 88 Driver Controls 2. Go to the garage to locate the garage door opener motor and its “learn” button. You may need a ladder to reach the unit and you may need to remove the unit’s cover or light lens to locate the “learn” button.
Page 89 Driver Controls the Erasing the Car2U Home Automation System buttons procedure and then programming all of the devices being used. Fixed code programming Note: Do not program the Car2U system with the vehicle in the garage. Make sure that your key is on and engine off while programming the transmitter.
Page 90 Driver Controls 3. To input these positions into the Car2U system, simultaneously press all three Car2U system buttons for a few seconds and then release to put the device into programming mode. The indicator lights will blink slowly. Within 2.5 minutes enter your corresponding DIP switch settings from left to right into your Car2U system by pressing and releasing the buttons corresponding to the settings you circled.
Page 91 Driver Controls To erase programming on the Car2U system (individual buttons cannot be erased), use the following procedure: 1. Firmly press the two outside Car2U system buttons simultaneously for approximately 20 seconds until the indicator lights begin to blink rapidly. The indicator lights are located directly above the buttons.
Page 92 Driver Controls Do not open the liftgate or liftgate window in a garage or other enclosed area with a low ceiling. If the liftgate window is raised and the liftgate is also opened, both liftgate and window could be damaged against a low ceiling.
Page 93 Your vehicle may be equipped with factory-installed crossbars. Ford Genuine Accessory crossbars, designed specifically for your vehicle, are also recommended for use with your roof rack system.
Page 94 Driver Controls To remove the cross-bar assembly (if equipped) from the roof rack side rails: 1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable). 2. Slide the cross-bar to the end of the rail. 3. Use a long, flat object to depress the tongue in the endcaps on both sides of the cross-bar.
Page 95 Driver Controls To reinstall the cross-bar assembly (if equipped) to the roof rack side rails: 1. Ensure that both cross-bar assemblies are installed with the F (front) arrow facing towards the front of the vehicle. 2. Use a long, flat object to press the tongue in the endcaps on both sides of the cross-bar.
Page 96: Locks And Security
Locks and Security KEYS Your vehicle is equipped with two Integrated Keyhead Transmitters (IKTs). The key blade functions as a programmed key which starts the vehicle and unlocks/locks all the doors. The transmitter portion functions as the remote entry transmitter. Your IKTs are programmed to your vehicle;...
Page 97 Locks and Security MYKEY (IF EQUIPPED) The MyKey™ feature allows you to program a restricted driving mode to promote good driving habits. All but one of the keys programmed to the vehicle can be activated as a MyKey™. The key will remain restricted until MyKey™...
Page 98 Locks and Security 2. Press and release the RESET button. HOLD RESET TO CONFIRM MYKEY will be displayed. 3. Press and hold the RESET button for two seconds until MARK THIS AS RESTRICTED is displayed. 4. Wait until KEY RESTRICTED AT NEXT START is displayed. MyKey™...
Page 99 MyKey™ is not compatible with non-Ford approved aftermarket remote start systems. If you choose to install a remote start system please see your authorized dealer for a Ford approved remote start system. When using a Ford-approved remote start system, the default settings will recognize the remote start system as an additional admin key with its associated privileges.
Page 100 Locks and Security status menus will include the remote start system as an additional key in the total count. See the Check MyKey™ system status section. Note: For all vehicles with remote start installed, it is possible to program all original vehicle keys as MyKeys™, in which case, you will need to use your remote start system to reset all MyKeys™...
Page 101: Locks
Locks and Security Condition Potential Causes • Purchase a new key from your authorized Lost the only admin dealer • For programming spare keys, refer to the Lost any key Programming spare keys section in this chapter. • Vehicle has a remote start system that is I accidentally programmed all keys recognized as an admin key.
Page 102 Locks and Security Door key unlocking/locking Unlocking the doors Turn the key in the door cylinder to unlock the driver’s door only. All other doors will remain locked. Locking the doors Turn the key in the door cylinder to lock the driver’s door only. Autolock The autolock feature will lock all the doors, liftgate and liftgate window when:...
Page 103 Locks and Security 1. The ignition must be off to begin sequence. 2. Turn the ignition to the on position. 3. Press the power door unlock control three times. 4. Turn the ignition from the on to the off position. 5.
Page 104 Locks and Security • the driver door is opened within 10 minutes of the ignition being transitioned to the off or accessory position. Note: The doors will not autounlock if the vehicle has been electronically locked before the driver door is opened. Deactivating/activating autounlock Your vehicle comes with the autounlock feature activated.
Page 105 Locks and Security 3. Enter factory–set 5–digit entry code. 4. Press and hold the 3 • 4. While holding the 3 • 4, press and release the 7 • 8. While still holding the 3 • 4, press and release the 7 • 8 a second time.
Page 106 Locks and Security the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 107 Locks and Security The battery saver feature will turn off the interior lamps 10 minutes after the ignition is turned to the off position. One step door unlocking If the one step door unlocking feature is activated, press and release once to unlock all of the doors, the liftgate and liftgate glass.
Page 108 Locks and Security Note: The panic alarm will only operate when the ignition is in the off position. Replacing the battery The integrated keyhead transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. To replace the battery: 1. Twist a thin coin in the slot of the IKT near the key ring in order to remove the battery cover.
Page 109 Locks and Security Illuminated entry The interior lamps, parking lamps and puddle lamps (if equipped) illuminate when the Integrated Keyhead Transmitter or the keyless entry system keypad is used to unlock the door(s). The illuminated entry system will turn off the lights if: •...
Page 110 Locks and Security 2. Within five seconds press the 1 • 2 on the keypad. The doors will lock and then unlock to confirm that the system is in programming mode. 3. Enter your personal 5–digit code. Each number must be entered within five seconds of each other.
Page 111: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 112 Locks and Security Anti-theft indicator The anti-theft indicator is located in the instrument panel cluster. • When the ignition is in the off position, the indicator will flash once every two seconds to indicate the SecuriLock system is functioning as a theft deterrent.
Page 113 Locks and Security programmed to your vehicle; only four of these eight keys can be IKTs with remote entry functionality. If your IKTs or standard SecuriLock coded keys are lost or stolen and you don’t have an extra coded key, you will need to have your vehicle towed to an authorized dealer.
Page 114 Locks and Security 4. After three seconds but within 10 seconds of turning the ignition to the 1 (off) position, insert the second previously coded key into the ignition. 5. Turn the ignition from the 1 (off) position to the 3 (on) position. Keep the ignition in the 3 (on) position for at least three seconds, but no more than 10 seconds.
Page 115: Seating And Safety Restraints
Seating and Safety Restraints FRONT SEATS WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 116 Seating and Safety Restraints To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint.
Page 117 Seating and Safety Restraints To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint.
Page 118 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Adjusting the front manual seat (if equipped) Lift handle to move seat forward or backward. Pull lever up to adjust seatback. Adjusting the front power seat (if equipped) WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving.
Page 119 Seating and Safety Restraints WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. WARNING: Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the passenger sensing system, resulting in serious injury or death in a crash.
Page 120 Seating and Safety Restraints Press the control to move the seat forward, backward, up or down. Heated seats (if equipped) WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater.
Page 121 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, the driver and passenger occupants should not sit in and/or operate the vehicle, until the head restraint is placed in its proper position. The driver should never adjust the head restraint while the vehicle is in motion.
Page 122 Seating and Safety Restraints Properly adjust the head restraint so that the top of the head restraint is even with the top of your head and positioned as close as possible to the back of your head. For occupants of extremely tall stature, adjust the head restraint to its full up position.
Page 123 Seating and Safety Restraints To reinstall the adjustable head restraint, do the following: 1. Insert the two stems into the guide sleeve collars. 2. Push the head restraint down until it locks. Properly adjust the head restraint so that the top of the head restraint is even with the top of your head and positioned as close as possible to the back of your head.
Page 124 Seating and Safety Restraints 3. Flip seat forward. Attach the safety belt web snap button to the quarter trim panel snap button. This will ensure that safety belt does not get caught by staying out of the seat back folding path.
Page 125 Seating and Safety Restraints 5. Rotate seatback down into load floor position. Returning the second row seats to upright position 1. Pull seatback up and into upright position making sure seatback locks into place and the red seat unlatched indicator on release paddle is not visible.
Page 126 Seating and Safety Restraints WARNING: Make sure safety belt buckle heads are through elastic holders on seat backs. Safety belt buckles may break if they are trapped underneath the seatback as the seatback is rotated down. WARNING: Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.
Page 127: Safety Restraints
Seating and Safety Restraints To install the second row cushion 1. Push the cushion to the inboard side of the vehicle. 2. Make sure that the hinges are locked into place. SAFETY RESTRAINTS Personal Safety System™ The Personal Safety System™ provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of airbag-related injuries.
Page 128 Seating and Safety Restraints conditions. A collection of crash and occupant sensors provides information to the Restraints control module (RCM). During a crash, the RCM may activate the safety belt pretensioners and/or either one or both stages of the dual-stage airbag supplemental restraints based on crash severity and occupant conditions.
Page 129 Seating and Safety Restraints occupant is not properly restrained by safety belts or child safety seats and they move forward during pre-crash braking. The most effective way to reduce the risk of unnecessary injuries is to make sure all occupants are properly restrained.
Page 130 Seating and Safety Restraints increase the effectiveness of the safety belts. In frontal collisions, the safety belt pretensioners can be activated alone or, if the collision is of sufficient severity, together with the front airbags. Safety belt energy management retractors The front and rear outboard safety belt energy management retractors allow webbing to be pulled out of the retractor in a gradual and controlled manner in response to the occupant’s forward momentum.
Page 131 Seating and Safety Restraints WARNING: To reduce the risk of injury, make sure children sit where they can be properly restrained. WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.
Page 132 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 133 Seating and Safety Restraints (8 km/h) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers. Automatic locking mode When to use the automatic locking mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt.
Page 134 Seating and Safety Restraints How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. WARNING: After any vehicle collision, the safety belt systems at all seating positions (except the driver position, which doesn’t have this feature) must be checked by an authorized dealer to verify that the automatic locking retractor feature for child seats is still...
Page 135 Seating and Safety Restraints Safety belt pretensioner Your vehicle is equipped with safety belt pretensioners at the driver and front passenger seating positions. The safety belt pretensioners activate during frontal collisions, and in side collisions and rollovers. A safety belt pretensioner is a device which tightens the webbing of the lap and shoulder belts in such a way that they fit more snugly against the body.
Page 136 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1 minute and the warning switch is turned to the on chime sounds 6 seconds. position...
Page 137 Seating and Safety Restraints If... Then... The driver’s and front The Belt-Minder feature will not passenger’s safety belts are activate. buckled before the ignition switch is turned to the on position or less than 1-2 minutes have elapsed since the ignition switch has been turned to on...
Page 138 3 of 4 fatal crashes occur within 25 miles (40 km) of home. Belts are uncomfortable Your Ford safety belts are designed to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 139 Seating and Safety Restraints Reasons given... Consider... I have an airbag Airbags offer greater protection when used with safety belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. I’d rather be thrown clear Not a good idea. People who are ejected are 40 times more likely to DIE.
Page 140 Seating and Safety Restraints WARNING: While the design allows you to deactivate your Belt-Minder , this system is designed to improve your chances of being safely belted and surviving an accident. We recommend you leave the Belt-Minder system activated for yourself and others who may use the vehicle.
Page 141: Airbags
Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag.
Page 142 Seating and Safety Restraints WARNING: Never place your arm over the airbag module as a deploying airbag can result in serious arm fractures or other injuries. To properly position yourself away from the airbag: • Move your seat to the rear as far as you can while still reaching the pedals comfortably.
Page 143 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 144 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder or sodium compounds which may irritate the skin and eyes, but none of the residue is toxic.
Page 145 Seating and Safety Restraints impact sensors, the system wiring, the airbag system readiness light, the airbag back up power and the airbag ignitors). WARNING: Several air bag system components get hot after inflation. Do not touch them after inflation. WARNING: If the airbag has deployed, the airbag will not function again and must be replaced immediately.
Page 146 Seating and Safety Restraints The front passenger sensing system uses a passenger airbag off or pass airbag off indicator which will illuminate and stay lit to remind you that the front passenger frontal airbag is off. The indicator lamp is located in the center stack of the instrument panel just above the air vents.
Page 147 Seating and Safety Restraints • If the indicator lamp remains lit even after this, the person should be advised to ride in the rear seat. Pass Airbag Off Occupant Passenger Airbag Indicator Lamp Empty seat Unlit Disabled Small child in child Disabled safety seat or booster Small child with safety...
Page 148 Seating and Safety Restraints Pass Airbag Off Objects Passenger Airbag Indicator Lamp Small (i.e. three-ring Unlit Disabled binder, small purse, bottled water) Medium (i.e. heavy Disabled briefcase, fully packed luggage) Empty seat, or small Disabled to medium object with safety belt buckled If you think that the status of the passenger airbag off indicator lamp is incorrect, check for the following: •...
Page 149 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance chapter of this Owner’s Guide.
Page 150 Seating and Safety Restraints A difficulty with the system is indicated by one or more of the following: • The readiness light will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is turned on. •...
Page 151 Seating and Safety Restraints How does the side airbag system work? The design and development of the side airbag system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 152 Seating and Safety Restraints WARNING: Several airbag system components get hot after inflation. Do not touch them after inflation. WARNING: If the side airbag has deployed, the airbag will not function again. The side airbag system (including the seat) must be inspected and serviced by an authorized dealer.
Page 153 Seating and Safety Restraints Safety Canopy System WARNING: Do not place objects or mount equipment on or near the headliner at the siderail that may come into contact with a deploying Safety Canopy . Failure to follow these instructions may increase the risk of personal injury in the event of a collision.
Page 154 Seating and Safety Restraints How does the Safety Canopy System work? The design and development of the Safety Canopy System included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 155 Seating and Safety Restraints The Safety Canopy System is designed to active when the vehicle sustains lateral deceleration sufficient to cause the RCM to initiate Safety Canopy inflation or when a certain likelihood of a rollover event is detected by the rollover sensor. The Safety Canopy is mounted to roof side-rail sheet metal, behind the headliner, above the first and second row seats.
Page 156: Child Restraints
Seating and Safety Restraints • The readiness light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and/or light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your authorized dealer immediately.
Page 157 Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 158 Seating and Safety Restraints Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Infants or Children weighing 40 lb (18 kg) or Use a child safety toddlers less (generally age four or younger) seat (sometimes called an infant carrier, convertible seat, or toddler seat).
Page 159 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by “X” LATCH LATCH Safety Safety Safety (lower (lower belt belt and belt Restraint Child anchors anchors LATCH only Type Weight only) (lower tether...
Page 160 Seating and Safety Restraints WARNING: Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by the vehicle manufacturer.
Page 161 Seating and Safety Restraints training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
Page 162 Seating and Safety Restraints Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat all the way back.
Page 163 Seating and Safety Restraints Perform the following steps when installing the child seat with combination lap/shoulder belts: Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 1.
Page 164 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 165 There should be no more than one inch (2.5 cm) of movement for proper installation. 11. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) to make certain the child restraint is properly installed.
Page 166 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 167 Seating and Safety Restraints WARNING: Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain safety belt buckle assemblies and/or LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be properly restrained.
Page 168 Seating and Safety Restraints Combining safety belt and LATCH lower anchors for attaching child safety seats When used in combination, either the safety belt or the LATCH lower anchors may be attached first, provided a proper installation is achieved. Attach the tether strap afterward, if included with the child seat. Refer to Recommendations for attaching child safety restraints for children in this chapter.
Page 169 If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Child booster seats The belt-positioning booster (booster seat) is used to improve the fit of the vehicle safety belt.
Page 170 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that vehicle lap/shoulder safety belts fit better.
Page 171 Seating and Safety Restraints • Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? Types of booster seats There are generally two types of belt-positioning booster seats: backless and high back.
Page 172 Seating and Safety Restraints Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 173 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 174: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 175 Tires, Wheels and Loading conventional two-wheel drive vehicle cannot. The 4WD system is active all the time and requires no input from the operator. For 4WD vehicles, a spare tire of a different size other that the tire provided should never be used. A dissimilar spare tire size (other than the spare tire provided) or major dissimilar tire sized between the front and rear axles could cause the 4WD system to stop functioning and default to front wheel drive.
Page 176: Tire Information
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 177 Tires, Wheels and Loading government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄ ) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices, and differences in road characteristics and climate.
Page 178: Tire Inflation
Tires, Wheels and Loading • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture. Also referred to as DOT code. • Inflation pressure: A measure of the amount of air in a tire. •...
Page 179 Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 180 Tires, Wheels and Loading To check the pressure in your tire(s): 1. Make sure the tires are cool, meaning they are not hot from driving even a mile. If you are checking tire pressure when the tire is hot, (i.e. driven more than 1 mile [1.6 km]), never “bleed”...
Page 181 Tires, Wheels and Loading the valve stem. Inspect the tire sidewalls for cracking, cuts, bruises and other signs of damage or excessive wear. If internal damage to the tire is suspected, have the tire demounted and inspected in case it needs to be repaired or replaced.
Page 182 B-Pillar or edge of the driver’s door. If this information is not found on these labels then you should consult your Ford dealer. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 183 The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System. If the TPMS indicator is flashing, your TPMS is malfunctioning. Your replacement tire might be incompatible with your TPMS, or some component of the TPMS may be damaged.
Page 184 Tires, Wheels and Loading • Avoid fast starts, stops and turns • Avoid potholes and objects on the road • Do not run over curbs or hit the tire against a curb when parking WARNING: If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires;...
Page 185 Tires, Wheels and Loading Tire rotation Rotating your tires at the recommended interval (as indicated in the scheduled maintenance information that comes with your vehicle) will help your tires wear more evenly, providing better tire performance and longer tire life. •...
Page 186 Tires, Wheels and Loading • Rear-wheel drive (RWD) vehicles/Four-wheel drive (4WD)/All-wheel drive (AWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 187 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 188 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
Page 189 Tires, Wheels and Loading 11. Maximum Load: Indicates the maximum load in kilograms and pounds that can be carried by the tire. Refer to the Safety Compliance Certification Label, which is located on the B-Pillar or the edge of the driver’s door, for the correct tire pressure for your vehicle.
Page 190 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below. Note: Tire Quality Grades do not apply to this type of tire. 1.
Page 191 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 192: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 193 Tires, Wheels and Loading following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: The Tire Pressure Monitoring System is NOT a substitute for manually checking tire pressure.
Page 194 Tires, Wheels and Loading To restore the full functionality of the Tire Pressure Monitoring System, have the damaged road wheel/tire repaired and remounted on your vehicle. For additional information, refer to Changing tires with TPMS in this section. When you believe your system is not operating properly The main function of the Tire Pressure Monitoring System is to warn you when your tires need air.
Page 195 Tires, Wheels and Loading Low Tire Pressure Possible Customer Action Required Warning Light cause Flashing Warning Spare tire in Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.
Page 196 SNOW TIRES AND CABLES WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 197: Vehicle Loading
Tires, Wheels and Loading VEHICLE LOADING – WITH AND WITHOUT A TRAILER This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 198 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 199 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 200 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 201 Tires, Wheels and Loading • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury.
Page 202 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 203 Tires, Wheels and Loading WARNING: Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lb.”...
Page 204: Trailer Towing
Tires, Wheels and Loading to transport the cement to your home? If you and your friend each weigh 220 lb. (99 kg), the calculation would be: 1400 - (2 x 220) - (12 x 100) = 1400 - 440 - 1200 = - 240 lb. No, you do not have enough cargo capacity to carry that much weight.
Page 205 Tires, Wheels and Loading Follow these guidelines to ensure safe towing procedure: • Do not tow a trailer until your vehicle has been driven at least 1,000 miles (1,600 km). • Refer to the instructions included with towing accessories for the proper installation and adjustment specifications.
Page 206 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Engine Maximum Trailer Weight Maximum GCWR - lb Range - lb frontal area of (kg) (kg) trailer - ft 2.5L 5040 (2286) 1000 (454) 24 (2.2) Notes: For high altitude operation, reduce GCW by 2% per 1000 ft. (300 m) elevation.
Page 207 Tires, Wheels and Loading Safety chains Always connect the trailer’s safety chains to the hook retainers on the vehicle. To connect the trailer’s safety chains, cross the chains under the trailer tongue and allow slack for turning corners. If you use a rental trailer, follow the instructions that the rental agency gives to you.
Page 208 Tires, Wheels and Loading • Anticipate stops and brake gradually. • Do not exceed the GCWR rating or transmission damage may occur. Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your scheduled maintenance information for more information.
Page 209: Recreational Towing
Tires, Wheels and Loading Exceeding these limits may allow water to enter vehicle components: • causing internal damage to the components. • affecting driveability, emissions and reliability. Replace the rear axle lubricant any time the axle has been submerged in water.
Page 210: Driving
Driving STARTING Positions of the ignition 1. Off— locks the gearshift lever and allows key removal. 2. Accessory— allows the electrical accessories such as the radio to operate while the vehicle is not running. 3. On— all electrical circuits operational and warning lights will illuminate.
Page 211 Driving Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked.
Page 212 Driving 3. Turn the key to 3 (on) without turning the key to 4 (start). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights. Starting the vehicle 1.
Page 213 Driving Note: After starting the vehicle, the engine may stop running to conserve fuel after it is warmed-up and the high voltage battery is sufficiently charged. Note: If the vehicle does not start, put the gearshift lever into P (Park), turn the ignition off, then attempt to start the vehicle again.
Page 214 Driving WARNING: To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. Prior to using the engine block heater, follow these recommendations for proper and safe operation: • For your safety, use an outdoor extension cord that is product certified by Underwriter’s Laboratory (UL) or Canadian Standards Association (CSA).
Page 215: Brakes
Driving How to use the engine block heater Ensure the receptacle terminals are clean and dry prior to use. To clean them, use a dry cloth. Depending on the type of factory installed equipment, your engine block heater will use .4 to 1.0 kilowatt-hours of energy per hour of use. Your factory installed block heater system does not have a thermostat;...
Page 216 Driving Using ABS When hard braking is required, apply continuous force on the brake pedal; do not pump the brake pedal since this will reduce the effectiveness of the ABS and will increase your vehicle’s stopping distance. The ABS will be activated immediately, allowing you to retain steering control during hard braking and on slippery surfaces.
Page 217 Driving Regenerative braking does not take the place of the standard friction brakes; it only assists them. Regenerative braking has also been designed to interact with the anti-lock brake system (ABS). Regenerative braking is disabled when the ABS is activated or the battery is fully charged. Parking brake Apply the parking brake whenever the vehicle is parked.
Page 218: Advancetrac
Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. ADVANCETRAC WITH ROLL STABILITY CONTROL™ (RSC ) STABILITY ENHANCEMENT SYSTEM WARNING: Vehicle modifications involving braking system, aftermarket roof racks, suspension, steering system, tire construction and/or wheel/tire size may change the handling characteristics of the vehicle and may adversely affect the the...
Page 219 Driving WARNING: If a failure has been detected within the AdvanceTrac with RSC system, the “sliding car” icon will illuminate steadily. Verify that the AdvanceTrac with RSC system is not manually disabled (press the AdvanceTrac with RSC button located on the center of the instrument panel). If the “sliding car” icon still illuminates steadily, have the system serviced by an authorized dealer immediately.
Page 220 Driving When AdvanceTrac with RSC performs a normal system self-check, some drivers may notice a rumble, grunting, or grinding noise after startup and when driving off. When an event occurs that activates AdvanceTrac with RSC you may experience the following: •...
Page 221 Driving or avoiding objects in the roadway. The ESC system operates by applying brakes to one or more of the wheels individually and, if necessary, reducing engine power if the system detects that the vehicle is about to skid or slide laterally. During ESC events the “sliding car”...
Page 222 Driving AdvanceTrac with RSC button. Full features of the AdvanceTrac with RSC system can be restored by pressing the AdvanceTrac with RSC button again or by turning off and restarting the engine. If you switch off the traction control, the “sliding car” icon will illuminate steadily.
Page 223 Driving • improper steering alignment. A high crown in the road or high crosswinds may also make the steering seem to wander/pull. PREPARING TO DRIVE WARNING: Utility vehicles have a significantly higher rollover rate than other types of vehicles. WARNING: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 224 Driving blown or the vehicle’s brake lamps are not operating properly. Refer to Fuses and relays in the Roadside Emergencies chapter. If the fuse is not blown, perform the following procedure: 1. Apply the parking brake. 2. Using a screwdriver or similar tool, carefully pry out the small Brake Transmission Shift Interlock (BTSI) cover cap located to the...
Page 225: Transmission Operation
Driving AUTOMATIC TRANSMISSION OPERATION Understanding the gearshift positions of the electronically-controlled Continuously Variable Transmission (eCVT) P (Park) This position locks the transmission and prevents the front wheels from turning. To put your vehicle in gear: 1. Start the engine 2. Release the parking brake 3.
Page 226: Reverse Sensing System
Driving D (Drive) The normal driving position for the best fuel economy. L (Low) • Provides maximum engine braking. • The transmission may be shifted into L (Low) at any vehicle speed. WARNING: When parking, do not use the gearshift in place of the parking brake.
Page 227 Driving WARNING: To help avoid personal injury, always use caution when in reverse and when using the RSS. WARNING: This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 228: Rear-View Camera System
Driving Note: If the system cannot be turned off, refer to MyKey™ in the Locks and Security chapter for more information. Keep the RSS sensors (located on the rear bumper/fascia) free from snow, ice and large accumulations of dirt (do not clean the sensors with sharp objects).
Page 229 Driving Image delay if displayed through the rearview mirror: When shifting out of R (Reverse) and into any other gear, the image in the rearview mirror will remain on for a few seconds before it shuts off to assist in parking or trailer hookup. Image delay if displayed through the Navigation screen: After shifting out of R (Reverse) and into any gear other than P (Park), the image in the navigation screen will remain until the vehicle speed...
Page 230 Driving Night time and dark area use At night time or in dark areas, the camera relies on the reverse lamp lighting to produce an image. Therefore it is necessary that both reverse lamps are operating in order to get a clear image in the dark. If either of the lamps are not operating, stop using the camera, at least in the dark, until the lamp(s) are replaced and functioning.
Page 231 Driving Automatic search for parking space To start, press the APA control switch located on the instrument panel. The message center will display ACTIVE PARK SEARCHING. To designate what side of the street to search on, use the turn signal. The arrow symbols >>...
Page 232 Driving Automatic steering into parking space Automatic steering is activated when you stop the vehicle, remove your hands from the steering wheel and select R (Reverse) gear. Be sure the steering wheel motion is not obstructed by any objects. The vehicle will steer itself from this point on as you follow the instructions in the message center to safely move the vehicle reverse and forward in the space.
Page 233 Driving APA finished When active park assist has completed the automated steering, the message center displays ACTIVE PARK FINISHED followed by a chime. The driver is responsible to assess and correct as necessary the final parking position and put the vehicle in P (Park). The system can also be deactivated at any time by the following: •...
Page 234 Driving The system should not be used if: • a foreign object (i.e. bike rack, trailer, etc.) is attached to the front or rear of the vehicle or at another location close to the sensors. • the front bumper or side sensors are damaged (i.e. in a collision) or obstructed by a foreign object (i.e.
Page 235 Driving • The vehicles or objects bordering the space may not be positioned appropriately. • The vehicle was pulled further up from the parking space than usual while driving by the space. APA performs best when you drive the same distance past the entire length of the parking space whenever parking your vehicle.
Page 236 Driving Driving with blind spot mirrors Before a lane change, check the main mirror first, then check the blind spot mirror. If no vehicles are present in the blind spot mirror and the traffic in the adjacent lane is at a safe distance, signal that you are going to change lanes.
Page 237 Driving Driving off-road with truck and utility vehicles 4WD vehicles are specially equipped for driving on sand, snow, mud and rough terrain and have operating characteristics that are somewhat different from conventional vehicles, both on and off the road. How your vehicle differs from other vehicles Truck and utility vehicles can differ from some other vehicles.
Page 238 Driving • It often may be less risky to strike small objects, such as highway reflectors, with minor damage to your vehicle rather than attempt a sudden return to the pavement which could cause the vehicle to slide sideways out of control or roll over. Remember, your safety and the safety of others should be your primary concern.
Page 239 Driving Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency. Excessive steering will result in less vehicle control, not more.
Page 240 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 241 Driving slopes or hills. A danger lies in losing traction, slipping sideways and possibly rolling over. Whenever driving on a hill, determine beforehand the route you will use. Do not drive over the crest of a hill without seeing what conditions are on the other side. Do not drive in reverse over a hill without the aid of an observer.
Page 242 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 243 Driving DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).
Page 244: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 245 Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles (56 km). To obtain reimbursement information, U.S.
Page 246: Hazard Flasher Control
Roadside Emergencies HAZARD FLASHER CONTROL The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Press in the flasher control and all front and rear direction signals will flash.
Page 247 Roadside Emergencies The fuel pump shut-off switch is located in the front passenger’s footwell, behind a flip-up cover. The high voltage shut-off switch is located in the cargo area on the passenger side of the vehicle in the jack compartment, behind the jack access door.
Page 248: Fuses And Relays
Roadside Emergencies If you see or smell fuel, do not reset the fuel pump shut-off or try to start your vehicle; you could injure yourself or others. Have all the passengers get out of the vehicle and call the local fire department or a towing service.
Page 249 Roadside Emergencies COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses — — — Brown — — Natural Black Black Passenger compartment fuse panel The fuse panel is located on the right-hand side of the center console, by the instrument panel.
Page 250 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Protected Circuits Location Rating 110V inverter Brake on/off switch SYNC module Moon roof Brake-shift i nterlock (BSI), Passenger compartment fuse panel, Keypad illumination Turn signals, Stop lamps Low beam headlamps (left) Low beam headlamps (right) Interior lights Backlighting...
Page 251 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Ignition switch Radio Instrument panel cluster Not used (spare) Restraints control module Rear video camera module Not used (spare) Not used (spare) Four wheel drive, Electronic power assist steering (EPAS), 110V inverter module, Park aid module, Active park assist module Passive anti-theft system (PATS)
Page 252 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. WARNING: Always disconnect the low voltage (underhood) battery before servicing high current fuses. WARNING: To reduce risk of electrical shock, always replace the cover to the power distribution box before reconnecting the low voltage (underhood) battery or refilling fluid reservoirs.
Page 253 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 20A** Rear power point 40A** Electric vacuum pump 10A* Powertrain control module (PCM) – keep alive power, PCM relay, Transmission control module, Canister vent — Not used 15A* Liftgate latch Traction battery control module 50A** Brake control module 30A**...
Page 254 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 10A* PCM (general powertrain components malfunction indicator lamp), Heater pump relay, Motor electronics coolant pump relay, Electronic A/C compressor 15A* Universal exhaust gas oxygen (UEGO) sensor, PCM – emission related powertrain components malfunction indicator lamp 15A* PCM power...
Page 255 Roadside Emergencies Auxiliary relay box The relay box is located in the engine compartment on the radiator support bracket. Fuse/Relay Fuse amp Description location rating Relay — Electric vacuum pump (solid state) — Not used — Not used — Not used Vacuum pump monitor —...
Page 256: Changing Tires
Roadside Emergencies CHANGING A FLAT TIRE If you get a flat tire while driving: • do not brake heavily. • gradually decrease the vehicle’s speed. • hold the steering wheel firmly. • slowly move to a safe place on the side of the road. Your vehicle may be equipped with a conventional spare tire that is different in one or more of the following: type, brand, size, speed rating and tread design.
Page 257 Roadside Emergencies and type as the road tires and wheels that were originally provided by Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired. A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that...
Page 258 Roadside Emergencies The usage of a full-size dissimilar spare tire/wheel can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability •...
Page 259 Roadside Emergencies Removing the jack and tools The jack and tools are located in the right rear of the cargo area behind an access panel. To remove jack from vehicle: 1. Release the thumbscrew on the bracket. 2. Release the retention clip on the upper part of the jack bracket.
Page 260 Roadside Emergencies Removing the spare tire or spare tire and tether (if equipped) 1. Insert the lug wrench through the access hole in the rear bumper. 2. Turn the handle counterclockwise and lower the spare tire until it can be slid rearward and the cable is slack.
Page 261 Roadside Emergencies 6. If not replacing the spare or flat tire to the underbody storage area, raise winch up into the installed position. 7. Use the attached fastener strap (2) to tie the tether end to the winch actuator shaft (if equipped). Tire change procedure WARNING: When one of the front wheels is off the ground, the transmission alone will not prevent the vehicle from moving or...
Page 262 Roadside Emergencies 2. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Before placing the jack under the vehicle, NOTE the jack locations: • Front View shown from rear of front tire. Position the jack directly below the protruding bolt.
Page 263 Roadside Emergencies • Rear View shown from forward of rear tire. Position the jack directly below the stud on the rear trailing arm. 3. Position the jack according to the guides and turn the jack handle clockwise until the tire is a maximum of 1 inch (25 mm) off the ground.
Page 264 Roadside Emergencies Never use the differentials as a jacking point. WARNING: To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 265 Roadside Emergencies Reinstall the jack and tools in the cargo area. To replace the jack in the vehicle, • guide the jack bottom first in the trim opening and position in the bracket (3), • secure the retention clip on the upper part of the jack (2), and •...
Page 266: Wheel Lug Nut Torque
(tire rotation, changing a flat tire, wheel removal, etc.). Bolt size Wheel lug nut torque* ft-lb N•m M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners.
Page 267 Roadside Emergencies WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel. Ensure that any fasteners that attach the rotor to the hub are secured so they do not interfere with the mounting surfaces of the wheel.
Page 268: Jump Starting
Roadside Emergencies JUMP STARTING (LOW VOLTAGE [UNDERHOOD] BATTERY ONLY) WARNING: The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. WARNING: Batteries contain sulfuric acid which can burn skin, eyes and clothing, if contacted.
Page 269 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 270 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 271 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 272 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 273: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. On FWD vehicles, if your vehicle is to be towed from the front, ensure proper wheel lift equipment is used to raise the front wheels off the ground.
Page 274 Roadside Emergencies Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. If the vehicle is towed by other means or incorrectly, vehicle damage may occur.
Page 275: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 276 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final...
Page 277 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step...
Page 278 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 279 CAMVAP decisions are fast, fair, and final as the arbitrator’s award is binding to both you and Ford of Canada. CAMVAP services are available in all territories and provinces. For more information, without charge or obligation, call your CAMVAP Provincial Administrator directly at 1-800-207-0685.
Page 280 If you are in another foreign country, contact the nearest authorized dealer. If the authorized dealer employees cannot help you, they can direct you to the nearest Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S.
Page 281: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 282: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 283 Cleaning WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area.
Page 284 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 285 Cleaning PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
Page 286 Cleaning INSTRUMENT PANEL/INTERIOR TRIM AND CLUSTER LENS Clean the instrument panel, interior trim areas and cluster lens with a clean, damp, white cotton cloth, then use a clean and dry white cotton cloth to dry these areas. • Avoid cleaners or polishes that increase the gloss of the upper portion of the instrument panel.
Page 287 Cleaning • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14). In Canada, use Motorcraft Multi-Purpose Cleaner (CXC-101). • If a ring forms on the fabric after spot cleaning, clean the entire area immediately (but do not oversaturate) or the ring will set.
Page 288 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 289: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide/Customer Information Guide to find out which parts and services are covered.
Page 290 Maintenance and Specifications 1. High voltage connector shield 2. Service disconnect 3. High voltage battery case...
Page 291 Maintenance and Specifications Working with the engine off 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Turn off the engine and remove the key. 3. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on 1.
Page 292: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 1. Engine coolant reservoir 2. Motor/Electronics (M/E) coolant reservoir 3. Engine oil filler cap 4. Brake fluid reservoir 5. Power distribution box 6. Low voltage (underhood) battery 7. Engine air filter assembly 8.
Page 293 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 294 Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper blade and arm away from the glass. 2. Squeeze the locking tabs to release the blade from the arm and pull the blade away from the arm to remove it. 3.
Page 295: Engine Oil
Maintenance and Specifications Changing rear window wiper blade The rear wiper arm is designed without a service position. This reduces the risk of damage to the blade in an automatic car wash. To replace the wiper blade: 1. Grab the wiper arm with one hand close to the arm/blade joint and pull it as far away from the glass as possible.
Page 296 Maintenance and Specifications 5. Locate and carefully remove the engine oil level dipstick. 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is within the lower and upper holes/lines, the oil level is acceptable.
Page 297 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine and engine’s warranty, use Motorcraft SAE 5W-20 or an equivalent SAE 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 298: Battery
Maintenance and Specifications It is recommended you use the appropriate Motorcraft oil filter or another with equivalent performance for your engine application. LOW VOLTAGE (UNDERHOOD) BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service.
Page 299 Maintenance and Specifications WARNING: Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.
Page 300: Engine Coolant And Motor/Electronics Coolant
Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE Low and high voltage battery – storage Your vehicle must be started and run for a minimum of 10 minutes once a month in order to maintain the high voltage battery charge.
Page 301 Maintenance and Specifications Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance information. The coolant concentration should be maintained at 50/50 coolant and distilled water, which equates to a freeze point of -34°F (-36°C).
Page 302 Maintenance and Specifications Checking motor/electronics (M/E) coolant The M/E coolant reservoir is located behind the engine coolant reservoir. Refer to the following engine coolant sections for all information, instructions and warnings related to cooling systems. The two systems use the same coolant and operate similarly, with the Motor and Electronics system generally operating at a lower temperature...
Page 303 Maintenance and Specifications If the engine coolant has not been checked at the recommended interval, the engine coolant reservoir may become low or empty. If the reservoir is low or empty, add engine coolant to the reservoir. Refer to Adding engine coolant in this chapter.
Page 304 Maintenance and Specifications • Do not use alcohol, methanol, brine or any engine coolants mixed with alcohol or methanol antifreeze (coolant). Alcohol and other liquids can cause engine damage from overheating or freezing. • Do not add extra inhibitors or additives to the coolant. These can be harmful and compromise the corrosion protection of the engine coolant.
Page 305 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
Page 306: Fuel Information
Maintenance and Specifications • NEVER decrease the coolant concentration below 40%. Decreased engine coolant concentrations below 40% will decrease the corrosion/freeze protection characteristics of the engine coolant and may cause engine damage. • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate protection at the temperatures in which you drive.
Page 307 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before refueling your vehicle. • Always turn off the vehicle before refueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 308 Maintenance and Specifications Refueling WARNING: Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 309 Maintenance and Specifications fuel filler nozzle. This allows residual fuel to drain back into the fuel tank and not spill onto the vehicle. Note: A fuel spillage concern may occur if overfilling the fuel tank. Do not overfill the tank to the point that the fuel is able to bypass the fuel filler nozzle.
Page 310 Maintenance and Specifications Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based additives. Note: Use of any fuel other than those recommended may cause powertrain damage, a loss of vehicle performance, and repairs may not be covered under warranty.
Page 311 Maintenance and Specifications Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 312 Maintenance and Specifications When filling the vehicle’s fuel tank from a portable fuel container, use the funnel included with the vehicle. 1. Locate the white plastic funnel. It is attached to the inside of the rear passenger side cargo compartment access door.
Page 313 Maintenance and Specifications Filling the tank When the fuel gauge indicates empty, there is still a small reserve of fuel in the fuel system. When refueling your vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank.
Page 314 Maintenance and Specifications the highway. This is contrary to conventional vehicles. However, many of the same actions that improve fuel economy in a conventional vehicle will also improve fuel economy in this vehicle. Give consideration to the lists that follow and you may be able to improve your fuel economy.
Page 315 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine...
Page 316 Maintenance and Specifications WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the service engine soon indicator, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power could indicate that the emission control...
Page 317 Maintenance and Specifications 4. Driving through deep water—the electrical system may be wet. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel, properly closing the fuel fill inlet or letting the electrical system dry out. After three driving cycles without these or any other temporary malfunctions present, the service engine soon indicator should stay off the next time the engine is started.
Page 318 Maintenance and Specifications The OBD-II system is designed to check the emission control system during normal driving. A complete check may take several days. If the vehicle is not ready for I/M testing, the following driving cycle consisting of mixed city and highway driving may be performed: 15 minutes of steady driving on an expressway/highway followed by 20 minutes of stop-and-go driving with at least four 30-second idle periods.
Page 319: Air Filter(S)
Maintenance and Specifications TRANSMISSION FLUID Checking electronically-controlled Continuously Variable Transmission (eCVT) The eCVT does not have an underhood transmission fluid dipstick. Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. It is designed to be filled for life. However, the fluid level should be checked if the transmission is not working properly, or if you notice some sign of fluid leakage.
Page 320: Part Numbers
Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
Page 321: Maintenance Product Specifications And Capacities
Maintenance and Specifications...
Page 322 Maintenance and Specifications...
Page 323 Maintenance and Specifications...
Page 324: Engine Data
Maintenance and Specifications ENGINE DATA Engine 2.5L I4 engine Cubic inches Required fuel 87 octane Firing order 1-3-4-2 Ignition system Coil on plug Spark plug gap 0.049–0.053 inch (1.25–1.35mm) Compression ratio 12.3:1 Engine drivebelt routing HIGH VOLTAGE BATTERY DATA High Voltage Battery Battery chemistry Nickel metal hydride Nominal voltage...
Page 325 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
Page 326 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint Devices and their location 3. Make, vehicle line, series, body type 4. Engine type 5.
Page 327: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 328 Accessories Peace of mind Keyless entry keypad Wheel locks For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).
Page 329: Scheduled Maintenance Guide
Your Ford or Lincoln Mercury dealer, or Ford or Lincoln Mercury Quality Care Center has factory trained technicians who can perform the required maintenance using genuine Ford parts. They are committed to meeting your service needs and to assuring your continuing satisfaction.
Page 330 Lincoln Mercury dealership for all your vehicle’s needs. Get the most from your service and maintenance visits There are a lot of reasons why visiting your Ford or Lincoln Mercury Dealership for all your service needs is a great way to help keep your vehicle running great.
Page 331 With factory-trained technicians, and one-stop service from routine maintenance like oil changes and tire rotations to repairs like brake service, check out the value your Ford and Lincoln Mercury dealers can offer. WHICH MAINTENANCE SCHEDULE SHOULD YOU FOLLOW?
Page 332 In order to keep your vehicle running right, it is important that you have the systems on your vehicle checked regularly. This can help identify any potential issue before there are any problems. Ford Motor Company suggests the following multi-point inspection to be performed at every scheduled maintenance as the way to ensure your vehicle keeps running right.
Page 333: Normal Scheduled Maintenance And Log
ADDITIONAL INFORMATION AVAILABLE ON THE WEB AT WWW.GENUINESERVICE.COM OR WWW.FORD.CA To learn more about the importance of routine and dealer-performed maintenance on your vehicle, please visit the Ford Customer Service website. You’ll also find important warranty information, customer assistance, technical expertise, frequently asked questions and much more.
Page 334 Scheduled Maintenance Guide U.S. AND CANADIAN SCHEDULE 5,000 miles (8,000 km) ❑ Inspect tires for wear and measure tread depth ❑ EALER ALIDATION Rotate tires RO#: P&A C ILEAGE 10,000 miles (16,000 km) ❑ Change engine oil and replace oil filter ❑...
Page 335 Scheduled Maintenance Guide 30,000 miles (48,000 km) ❑ Change engine oil and replace oil filter ❑ EALER ALIDATION Inspect tires for wear and measure tread depth ❑ Rotate tires ❑ Inspect wheel ends for end play and noise ❑ Replace engine air filter RO#: P&A C ILEAGE...
Page 336 Scheduled Maintenance Guide 60,000 miles (96,000 km) ❑ Change engine oil and replace oil filter ❑ Inspect tires for wear and measure tread depth ❑ Rotate tires EALER ALIDATION ❑ Inspect wheel ends for end play and noise ❑ Inspect brake pads, shoes, rotors, drums, brake lines and hoses and parking brake ❑...
Page 337 Scheduled Maintenance Guide 90,000 miles (144,000 km) ❑ Change engine oil and replace oil filter ❑ EALER ALIDATION Inspect tires for wear and measure tread depth ❑ Rotate tires ❑ Inspect wheel ends for end play and noise ❑ Replace engine air filter RO#: P&A C ILEAGE...
Page 338 Scheduled Maintenance Guide 120,000 miles (192,000 km) ❑ Change engine oil and replace oil filter ❑ Inspect tires for wear and measure tread depth ❑ Rotate tires EALER ALIDATION ❑ Inspect wheel ends for end play and noise ❑ Inspect brake pads, shoes, rotors, drums, brake lines and hoses and parking brake ❑...
Page 339: Special Operating Conditions And Log
Scheduled Maintenance Guide 150,000 miles (240,000 km) ❑ Change engine oil and replace oil filter ❑ Inspect tires for wear and measure tread depth EALER ALIDATION ❑ Rotate tires ❑ Inspect wheel ends for end play and noise ❑ Replace engine air filter ❑...
Page 340 Scheduled Maintenance Guide Operating in dusty conditions such as unpaved or dusty roads Every 5,000 miles, 6 months or Change engine oil and replace filter 200 hours of engine operation (whichever comes first) Inspect tires and rotate Inspect wheel ends for end play and noise As required Replace cabin air filter, if equipped Replace engine air filter Off-road operation...
Page 341 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
Page 342 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
Page 343 Scheduled Maintenance Guide Engine Coolant Change Record ❑ 6 years or 100,000 miles (160,000 km) (whichever comes first) - change engine coolant and Motor/electrical coolant. Refer to Maintenance product specifications and capacities in the Maintenance and Specifications chapter for the proper coolant type.
Page 344 Scheduled Maintenance Guide Current mileage goes here => Dealer Stamp Add 50,000 miles to the current miles + 50,000 Next change due at this mileage => Today’s date goes here => Add 3 years + 00 / 00 / 03 Date of next change =>...
Page 345: Ford Extended Service Plan
FORD ESP EXTENDED SERVICE PLANS More than 30 million Ford, Lincoln, and Mercury owners have discovered the powerful protection of Ford ESP. It is the only extended service plan backed by Ford Motor Company, and provides “peace of mind” protection beyond the New Vehicle Limited Warranty coverage.
Page 346 Ford ESP Can Quickly Pay for Itself One service bill – the cost of parts and labor – can easily exceed the price of your Ford ESP Service Contract. With Ford ESP, you minimize your risk for unexpected repair bills and rising repair costs.
Page 347 Ford Extended Service Plan...
Page 348: Index
Index Auxiliary power point ....74 Axle Accessory delay ......77 lubricant specifications ..321 Active Park Assist .....230 refill capacities ......321 AdvanceTrac ......218 Air cleaner filter ....319–320 Air conditioning Battery ........298 automatic temperature control system ......52 acid, treating emergencies ..298 jumping a disabled battery ..268 Airbag supplemental restraint maintenance-free ....298 system ......141, 150, 153...
Page 349 Cruise control refill capacities ......321 (see Speed control) ....79 service points ....292–293 Customer Assistance ....244 Engine block heater ....213 Ford Extended Service Plan ......345 Engine oil ........295 Getting assistance outside the checking and adding ....295 U.S. and Canada .....279 dipstick ........295 Getting roadside assistance ...244...
Page 350 Index recommendations ....297 refill capacities ......321 Garage door opener ....85 specifications ......321 Gas cap (see Fuel cap) ....308 Event data recording ....13 Gas mileage Exhaust fumes ......213 (see Fuel economy) ....312 Gauges .........23 Fleet MyKey programming ..97 Hazard flashers ......246 Fluid capacities ......321 Headlamps ........57 Fog lamps ........58...
Page 351 Index Luggage rack .......93 Jump-starting your vehicle ..268 Manual transmission fluid capacities ......321 lubricant specifications ..321 Keyless entry system autolock ......102–103 Message center ......25 keypad ........109 english/metric button ....29 locking and unlocking system check button ....29 warning messages .....29 doors ........110 programming entry code ..109 Mirrors ........77–78 automatic dimming rearview...
Page 352 Index Power distribution box Safety defects, reporting ..281 (see Fuses) .......252 Safety restraints ....127, 130, Power door locks ......101 132–135 Belt-Minder ......136 Power mirrors ......78 extension assembly ....135 Power point .........74 for adults ......132–134 for children ......156 Power steering ......222 Occupant Classification Sensor ........128 Power Windows ......76...
Page 353 Index Special notice recreational towing ....209 ambulance conversions ....12 trailer towing ......204 utility-type vehicles ....12 wrecker ........273 Specification chart, Transmission ......225 lubricants ........321 brake-shift interlock (BSI) ..223 Speed control ......79 fluid, checking and adding (automatic) ......319 Starting your vehicle ..210–212 fluid, refill capacities ....321 jump starting ......268 lubricant specifications ..321...

This manual is also suitable for:

Automobile

Ford 2010 Escape Hybrid Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Scheduled Maintenance Guide

Ford Extended Service Plan

Index

Quick Links

Table of Contents

Related Manuals for Ford 2010 Escape Hybrid

Summary of Contents for Ford 2010 Escape Hybrid

This manual is also suitable for:

Table of Contents
