Outdoor Heat Pump
User's Information/Installation Instructions
Two Stage R-410A Split System
These units have been designed and tested for capacity and effi ciency in accordance with A.R.I.
Standards. Split System Heat Pump units are designed for use with a wide variety of fossil fuel
furnaces, electric furnaces, air handlers, and evaporator coil combinations equipped with variable
speed in blowers.
These instructions are primarily intended to assist qualifi ed individuals experienced in the proper
installation of heating and/or air conditioning appliances. Some local codes require licensed instal-
lation/service personnel for this type of equipment. Read all instructions carefully before starting
the installation.
USER'S INFORMATION
Read this owner information to become familiar with the capabilities and use of your appliance.
Keep this with literature on other appliances where you have easy access to it in the future. If a
problem occurs, check the instructions and follow recommendations given. If these suggestions
don't eliminate your problem, call your servicing contractor. NOTE: For this type of equipment to
function as intended for maximum effi ciency and adequate capacity, a two stage cooling/heating
thermostat is required. See unit wiring diagram.
Heat Pump Principle of Operation
WINTER HEATING
1. Outdoor air enters heat pump.
2. Cold, heat-transfer section (outdoor coil)
extracts heat from outdoor air as refrigerant
evaporates from a liquid to a gas.
3. Refrigerant, compressed to a hot gas by
heat pump, carries the heat to the hot heat-
transfer section (indoor coil).
4. Hot, heat-transfer section (indoor coil)
releases the heat to indoor air as refrigerant
condenses from a gas to a liquid.
5. Air handler circulates the heat throughout
the home.
6. Refrigerant returns to outdoor coil and
evaporates once again to absorb more
heat.
IMPORTANT
SUMMER COOLING
1. Indoor air enters the air handler section.
2. Cold, heat-transfer section (indoor coil)
extracts heat from indoor air as refrigerant
evaporates from a liquid to a cold gas.
3. Refrigerant, drawn to heat pump and
compressed to a hot gas by heat pump,
carries the heat outdoors.
4. Hot, heat-transfer section (outdoor coil)
releases the heat as refrigerant condenses
from a gas to a liquid.
5. Heat pump (outdoor fan) discharges the
heat to outside air.
6. Refrigerant returns to indoor coil and
evaporates once again to absorb more
heat.

Advertisement

Table of Contents
loading

Summary of Contents for Nordyne Two Stage R-410A Split System

  • Page 1 Outdoor Heat Pump User’s Information/Installation Instructions Two Stage R-410A Split System These units have been designed and tested for capacity and effi ciency in accordance with A.R.I. Standards. Split System Heat Pump units are designed for use with a wide variety of fossil fuel furnaces, electric furnaces, air handlers, and evaporator coil combinations equipped with variable speed in blowers.
  • Page 2: Operating Instructions

    OPERATING INSTRUCTIONS 2. Set the thermostat temperature to the desired temperature level using the TO OPERATE YOUR HEAT PUMP temperature selector. Please refer to the separate detailed thermostat user’s FOR COOLING — manual for complete instructions regarding thermostat programming. The outdoor unit 1.
  • Page 3 The continuous indoor blower operation can be and ice on the heat transfer coil. This is obtained with the thermostat system switch set normal, and the unit will periodically defrost in any position, including OFF. itself. These units employ Adaptive Demand Defrost Feature that monitors ambient and The continuous indoor blower operation is coil temperatures and regulate defrost...
  • Page 4: General Information

    Read Your Warranty and gaseous refrigerant under pressure. Installation and servicing of this equipment Please read the separate warranty document should be accomplished by qualifi ed, trained completely. It contains valuable information personnel thoroughly familiar with this type of about your system. equipment.
  • Page 5: Installing The Outdoor Unit

    of the equipment. The system must be wired and during system operation. Tubing should be kept provided with circuit protection in accordance clean of foreign debris during installation. Every with local building codes and the National effort should be made by the installer to ensure Electrical Code.
  • Page 6: Startup And Checkout

    circuits must be wired in strict accordance with Electrical Code” (ANSI/NFPA 70) and with applicable local codes having jurisdiction. current provisions of the National Electrical Code (ANSI/NFPA 70), with applicable local Thermostat connections should be made in codes having jurisdiction, and the installation accordance with the instructions supplied with instructions provided with the equipment.
  • Page 7 NOTE: Jumper W1 and W2 Thermostat together for G R W2 C E O Y1 W1 W3 shorter staging time. See table 2 Stat O Y1 Y/Y2 Air Handler Heat Pump OD Section Typical 2-Stage Cooling Heat Pump with Optional Outdoor Thermostat and Variable Speed Air Handler Typical 2-Stage Heat Pump System Connection...
  • Page 8 back to AUTO. Blower will operate at a decreased Comfort Alert Diagnostics — The Comfort speed on continuous fan. Alert diagnostics module is a breakthrough innovation for troubleshooting heat pump and 2-Speed Outdoor Fan Motor (Select air conditioning system failures. The module Models) —...
  • Page 9 When constant 24 VAC (R) wire) is not present Heating — If provided with heating equipment, in the outdoor unit, use one of the spare wires lower the thermostat setpoint temperature to the in the thermostat cable to bring power to the lowest obtainable setting and set the thermostat module.
  • Page 10 Status LED Status LED Description Status LED Troubleshooting Information Green “POWER” Module has power Supply voltage is present at module terminals 1. Compressor protector is open Red “TRIP” Thermostat demand signal Y is present, but the • Check for high head pressure compressor is not •...
  • Page 11 Status LED Status LED Description Status LED Troubleshooting Information 1. Outdoor unit power disconnect is open Yellow “ALERT” Open Circuit 2. Compressor circuit breaker or fuse(s) is open Flash Code 5 3. Compressor contactor has failed open • Check compressor contactor wiring and connectors •...
  • Page 12 Miswired Module Indication Recommended Troubleshooting Action Green LED is not on, Determine if both R and C module terminals are module does not power up connected. Verify voltage is present at module’s R and C terminals. Review 24VAC Power W iring (page 4) for R and C wiring.
  • Page 13: Adjustment Of Refrigerant Charge

    Note: If the “Y2” thermostat input is energized Procedure for charging an R-410A (on a 2-stage system), the second stage will unit in AC mode at outdoor tempera- come on. tures above 65F. If the above steps will not initiate a defrost, replace With the system operating at steady-state, the defrost board.
  • Page 14: Cooling Charging Charts

    Cooling Charging Charts Remove refrigerent when above curve Add refrigerent when below curve 95 100 105 110 115 120 125 Liquid Temperature (F) 2 Ton System Cooling Charging Chart Remove refrigerent when above curve Add refrigerent when below curve 100 105 110 115 120 125 Liquid Temperature (F) 3 Ton System Cooling Charging Chart...
  • Page 15 Cooling Charging Charts (continued) Remove refrigerent when above curve Add refrigerent when below curve 100 105 110 115 120 125 Liquid Temperature (F) 4 Ton System Cooling Charging Chart Remove refrigerent when above curve Add refrigerent when below curve 100 105 110 115 120 125 Liquid Temperature (F) 5 Ton System Cooling Charging Chart...
  • Page 16: Heating Charging Chart

    Heating Charging Chart Remove refrigerant when above curve Add refrigerant when above curve Liquid Temperature F INSTALLER: PLEASE LEAVE THESE INSTALLATION INSTRUCTIONS WITH THE HOMEOWNER. ¢708868b¤ 7088680 7088680 Specifi cations and illustrations subject to change without notice and without incurring obligations. Printed in U.S.A.
