3. The installation plate must be installed
using the appropriate anchoring
hardware and/or fastener for the wall
surface application.
4. Drill holes and mount the fan onto the
bracket by fitting and tightening the
thumbscrew to the corresponding hole
of the plate.
5. CAREFULLY check fan for proper
mounting.
OPERATING INSTRUCTIONS
(See Fig. 2 & 3)
1. Pull the RIGHT Control CORD down for
the required fan speed: "0" for "OFF", "1"
for Low Speed, "2" for Intermediate
Speed, "3" for High Speed.
2. To start or stop the fan head oscillation,
pull the LEFT CONTROL CORD down.
NOTE: CAREFULLY PULL ON FAN
CORD CONTROLS. EXCESSIVE
FORCE MAY DAMAGE FAN AND MAY
CREATE AN ELECTRICAL HAZARD.
3. To adjust the fan head, loosen the
thumbscrew and move to the desired
angle. Then firmly tighten the
LEARNING MORE
For a wealth of information about your fan and other Bionaire
website at www.bionaire.com.
THIS PRODUCT IS MANUFACTURED TO COMPLY WITH
THE E.E.C. DIRECTIVES 2006/95/EC AND 2004/108/EC.
Waste electrical products should not be disposed of with house-
hold waste. Please recycle where facilities exist. Check on the
following website for further recycling and WEEE information:
www.bionaire.com.
Please see warranty card for warranty information.
© 2009 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights
reserved. Manufactured by Sunbeam Products, Inc. doing business as Jarden Consumer
Solutions, 2381 Executive Center Drive, Boca Raton, Florida 33431 U.S.A. Distributed
by Jarden Consumer Solutions of India Private Limited, Unit Number B-204, Universal
Business Park Off Saki Vihar Road, Chandivli Farm Road Andheri (E), Mumbai 400-072,
India. Telephone : 1-800-102-6300
Printed in PRC
SPR-110409
thumbscrew. The fan may be moved up
and down, but not left to right.
NOTE: THE FAN SHOULD BE FULLY
ASSEMBLED ON THE WALL BEFORE
MAKING THIS ADJUSTMENT.
OTHERWISE THE FAN HEAD WILL
NOT HOLD INTO POSITION.
CAUTION: The fan should be
switched off when making this
adjustment
CLEANING
1. Switch off and unplug the power cord
before assembling or disassembling
and cleaning.
2. Plastic parts should be cleaned using
mild detergent and a damp cloth or
sponge.
CAUTION: Do not use harsh
detergents, chemical cleaners or
solvents as they may damage the
surface finish of the plastic
components. Also, do not immerse
in liquids.
NOTE: Unit must be unplugged for
it to be fully off.
products, visit our
®
138037
DUAL BLADE
WALL FAN
MODEL# BDWLF1609-IN
INSTRUCTION MANUAL
Read instructions before operating. Retain for future reference.
