12. Secure both guards firmly by fitting and
tightening the guard locking screw/nut.
13. Remove the plastic screw from the base
(turning counter-clockwise). Then affix
motor assembly to base hole until
snapped. Tighten screw to the base.
OPERATING INSTRUCTIONS
(See Fig. 2 & 3)
1. Operate the relevant push button for
the required fan speed. "0" for "OFF",
"1" for Low Speed, "2" for Intermediate
Speed and "3" for High Speed.
2. To make the fan head oscillate, push the
oscillation knob DOWN. To stop the
oscillation, pull the oscillation knob UP.
3. Adjust the tilt of the fan head to the
desired angle by pushing gently up or
down on the fan guard.
CAUTION: The fan should be switched
off when making this adjustment.
Please note that the head will not latch
into the low or mid position until the
guard and blade are fitted to the motor.
LEARNING MORE
For a wealth of information about your fan and other Bionaire
website at www.bionaire.com.
THIS PRODUCT IS MANUFACTURED TO COMPLY WITH THE E.E.C.
DIRECTIVES 2006/95/EC AND 2004/108/EC.
Waste electrical products should not be disposed of with house-
hold waste. Please recycle where facilities exist. Check on the
following website for further recycling and WEEE information:
www.bionaire.com.
Please see warranty card for warranty information.
© 2009 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights
reserved. Manufactured by Sunbeam Products, Inc. doing business as Jarden Consumer
Solutions, 2381 Executive Center Drive, Boca Raton, Florida 33431 U.S.A. Distributed
by Jarden Consumer Solutions of India Private Limited, Unit Number B-204, Universal
Business Park Off Saki Vihar Road, Chandivli Farm Road Andheri (E), Mumbai 400-072,
India. Telephone : 1-800-102-6300
Printed in PRC
SPR-110409
4. To adjust the height of the pedestal fan,
loosen the height adjustment mechanism.
Carefully raise or lower the fan and firmly
re-tighten the height adjustment
mechanism.
CAUTION: The fan should be switched
off when making this adjustment.
CLEANING
1. Switch off and unplug the power cord
before assembling or disassembling and
cleaning.
2. Plastic parts should be cleaned using
mild detergent and a damp cloth or
sponge.
CAUTION: Do not use harsh
detergents, chemical cleaners,
gasoline or solvents as they may
damage the surface finish of the
plastic components. Also, do not
immerse in liquids.
NOTE: Unit must be unplugged for
it to be fully off.
products, visit our
®
138034
DUAL BLADE

STAND FAN

MODEL# BDSF1609-IN
INSTRUCTION MANUAL
Read instructions before operating. Retain for future reference.
pure indoor living
