- Page 1 User's Manual MOD-16PRO/16H 16P SERIES WIRELESS MICROPHONE SYSTEM www.altoproaudio.com Version 1.0 Oct. 2006 English...
- Page 2 SAFETY RELATED SYMBOLS External Connection CAUTION The external wiring connected to the out- RISK OF ELECTRIC SHOCK DO NOT OPEN put hazardous live terminals requires The symbol is used to indicate that some installation by an instructed person, or hazardous live terminals are involved the use of ready-made leads or cords.
- Page 3 Servicing instructions. Do not install near any heat Refer all servicing to qualified personnel. To sources such as radiators, heat registers, stoves, or other apparatus (including am- reduce the risk of electric shock, do not perform any servicing other than that contained in the plifiers) that produce heat.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction ..............Features ...............3 Control Elements ............4 Operation ..............8 Modelling Technology for Wireless Microphones ..11 6. -
Page 5: Introduction
1. Introduction LTO MOD-16 wireless systems have been designed for Vocalists, Presenters and performing Musicians. These wireless systems are based on a sophisticated and innovative PLL circuit but, at the same time, are worry-free and easy to use. Large back lighted displays are available both on the Receiver and the Transmitters and simple Menus allow for a large number of functions such as Frequency Select, Sensitivity, Muting, etc. - Page 6 Type: Dynamic Mic. Frequency response: 50Hz~16kHz( 3dB) Impedance: 300 20% at 1kHz Sensitivity: -71dB 3dB Direction: Omni-directional MOD-16P A bodypack transmitter with belt clip. The MOD-16P transmitter will come with either: 1.A cable to be connected to an electric guitar or bass 2.A Lavalier Microphone.
-
Page 7: Features
HM-38, Condenser microphone LM-10, Clip microphone Preset impedance: 600ohm; Preset impedance: 680ohm; Freq. response: 80-12KHz; Freq. response: 50-12KHz; Sensitivity: -68dB+/-3dB at 1KHz; Sensitivity: -65dB 3dB at 1KHz Directional: Uni-directional; Directional: 12 180mm Weight: 52g (0.12Ib) 0.47" 7.1") Weight: 22g(0.049Ib) 2. Features FEATURES OF MOD-16PRO, PLL UHF DIVERSITY RECEIVER The friendly User Interface including two digit displays and intuitive MENU system for easy operation. -
Page 8: Control Elements
3. Control Elements: Ok, enough with numbers. Let's start to familiarize with your MOD-16 System. First of all, the MOD-16PRO Receiver: 3.1 MOD-16PRO, PLL UHF Diversity Receiver FRONT PANEL Power Switch: We are afraid you can not use the MOD-16R if you don't switch the Power ON! UP/DOWN Keys: You can adjust the right values through these two keys... - Page 9 Volume Control: This knob sets the audio signal level outputted through the balanced and unbalanced output jacks on the rear panel. Turn the knob clockwise fully for the max volume, and turn the knob counterclockwise fully for the min volume. Antenna Input Sockets: Includes 2 antennas to secure the Diversity function.
- Page 10 Front Grill: This spring steel mesh grill will protect the microphone capsule during a live performance. Especially made for heavy metal players, alcohol, drugs, etc.. LCD Display: This nice blue LCD will indicate the current operation status. CH/ON Key: If you press this key for a few seconds your Transmitter will switch ON and OFF.
- Page 11 3.3 MOD-16P, Body Pack Transmitter LCD display: This nice blue LCD will indicate the current operation status. CH-ON Key: If you press this key for a few seconds your Transmitter will switch ON and OFF. Once you have switched the unit ON, just press this key again slightly and you can edit various parameters such as CHANNEL, GROUP , RF POWER LEVEL and LOCK/UNLOCK.
-
Page 12: Operation
Belt Clip: It is a detachable belt clip for easy carry during the live applications. Antenna: It is a flexible antenna. To get effective transmission, never cover the antenna with hand, clothes, etc during the operation, and always position the transmitter nearby the receiver. - Page 13 4.2 For the MOD-16H/16P transmitters And now that you know how to operate your Mod16PRO Receiver, let's learn how to use the MOD-16 Transmitters. The following instructions apply both to the handheld version and to the bodypack version. There are 2 keys on the Transmitter labelled CH/ON and SELECT. Press the CH/ON key for a few seconds and the transmitter will be powered ON.
- Page 14 - RF Output Power Select Your Transmitter can operate on three different levels of output power. These are different form the Handheld Model and the Bodypack model. For the Handheld model the levels are - PL 0, the output power is 5dBm; - PL 1, the output power is 10dBm;...
-
Page 15: Modelling Technology For Wireless Microphones
Transmitter will mute any audio signal going to the Receiver. Press SELECT again for a few seconds and you will UNMUTE the Transmitter. Note: Why Alto Transmitters come with 100 different frequencies? Not because you will need to use 100 different microphones at the same time. It is unlikely that you will use more than 8 systems at the same time so why 100 frequencies? This depends mainly of Countries regulations. - Page 16 microphone capsules for their wireless systems but this flexibility is far behind the wide choice of tones or "models", as we call them at LTO. In fact, a specific model of wireless microphone may be used by a male vocalist or female vocalist during a live performance, by a Priest in a church service, by a speaker during a seminar, by and aerobics teacher during a training lesson, by a DJ, by a choir, by an announcer, by an auction director, we...
- Page 17 MODEL 5: DE-ESSER- The name tells everything. Use it to de-emphasize the sibilants, like the letter sound 's', for example, from your vocals. MODEL 6: VINTAGE RADIO- Old tube based Receivers made the Announcer voice sound like... yeah, we call it Vintage. Try it for a smooth satin voice. Ideally used for speech, but we found some other neat applications in the studio as well! MODEL 7: MID-WARMTH, a moderate voice enhancement making use of Bass enhancer.
-
Page 18: Technical Specifications
6. Technical Specifications MODEL MOD-16PRO Multi-channels, up to 100 frequency presets for Channel each frequency bands Frequency band UHF 470-900 MHz Dependent on applicable country regulations Receiver type PLL UHF SYNTHESIZED Frequency response 50 Hz-15KHz ( 3dB) Frequency stability 0.005% (-10 -50 ) 1KHZ 0.8% T.H.D. - Page 19 MODEL MOD-16H MOD-16P SPECIFICATION Oscillation mode PLL UHF SYNTHESIZED UHF 470-900 MHz Carrier frequency band Dependent on applicable country regulations Frequency response 50 Hz-15KHz ( 3dB) Frequency stability 0.005% (-10 ~ 50 ) T.H.D. 1KHz<0.8% Modulation mode FM (F3E) RF output power 5-50mW(adjustable 3 bands) Dynamic 100dB...
-
Page 20: Annex
7. ANNEX 7.1 Frequency Band Selection Most countries closely regulate the radio frequencies used in the transmission of wireless information. These regulations state which devices can use which frequencies, and help to limit the amount of RF(radio frequency)interference in all wireless communications. To be flexible enough to operate worldwide, MOD-16PRO Wireless receivers are available in a number of models, each with a unique frequency range. -
Page 22: Warranty
