Specifications Of Electrical Parts - Toshiba RAV-SM406BT-E Service Manual

Concealed Duct Type
No.
1 Fan motor (SM406BT / SM456BT / SM566BT)
2 Fan motor (SM806BT)
3 Fan motor (SM1106BT / SM1406BT / SM1606BT)
4 Thermo. Sensor (TA-sensor)
5 Heat exchanger sensor (TCJ-sensor)
6 Heat exchanger sensor (TC-sensor)
7 Float switch
8 Drain pump motor
9 Reactor

4. SPECIFICATIONS OF ELECTRICAL PARTS

Parts name Type
ICF-340W150-2
ICF-340W150-1
ICF-340W250-1
328mm
Ø6mm, 1000mm
Ø6mm, 1000mm
FS-0218-102
MDP-1401
CH-49-Z-T
– 20 –
Specifications
Output (Rated) 150W, 220-240V
Output (Rated) 150W, 220-240V
Output (Rated) 250W, 220-240V
10kΩ at 25˚C
10kΩ at 25˚C
10kΩ at 25˚C
14mH, 4A
