Lismore
Boiler Solid Fuel Stove
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot
working surfaces while in use or until the appliance has thoroughly cooled.
When using the boiler stove in situations where children, aged and/or infirm persons are present a fire-
guard must be used to prevent accidental contact with the stove. The fireguard should be
manufactured in accordance with BS 8423:2002.

Advertisement

Table of Contents
loading

Related Manuals for Stanley Lismore

Summary of Contents for Stanley Lismore

  • Page 1 Lismore Boiler Solid Fuel Stove INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE NO. General ............... 3 Handling .
  • Page 3 TABLE OF CONTENTS PAGE NO. 37. Glass Cleaning ..............16 38.

  • Page 4: General

    1:2007 Design, Installation and Commissioning of When installing, operating and maintaining your chimneys. BS EN 14336:2004: Heating Systems in Lismore Stove respect basic standards of fire safety. Buildings. Installation & Commissioning of Water Read these instructions carefully before commenc- Based Heating Systems.

  • Page 5: Flue Pipes

    FLuE EXIT (TOP & REAR) 2300 Fig.1 The stove is designed to allow the chimney be cleaned through the stove. If the chimney cannot be cleaned through the stove it is necessary to provide a soot box/access door in the flue for cleaning. See Fig.1A for recommended locations.

  • Page 6: Chimney

    Alternatively the calculation procedure given in EN Fig.3 13384-1 may be used as the basis for deciding whether a particular chimney design will provide suf- ficient draught. The outlet from the chimney should be above the roof of the building in accordance with the provisions of Building Regulations Approved Document J.

  • Page 7: Ventilation & Combustion Air Requirements

    Approved Document J (see also combustion air sup- Where such an installation exists, a test for spillage ply). should be made with the fan or fans and other appli- ances using air in operation at full rate, (i.e.extrac- Adequate provision e.g. easily accessible soot door tion fans, tumble dryers) with all external doors and or doors must be provided for sweeping the chimney windows closed.

  • Page 8: Heat Recovery Ventilation (Hrv)

    HRV may create a pressure less than There are several conditions to be considered in atmospheric, this slow pressure will effect the flue selecting a location for your Stanley Lismore Stove. pressure which is required to safely evacuate the products of combustion from the stove.

  • Page 9: Flue & Water Pipe Locations

    Fig.5 Thermostat Knob Flue Outlet Fig.6 4 Water Pipe Outlets Water Pipe Inlet Primary Air Inlet Fig.7 FLuE & WATER PIPE LOCATIONS Flue outlet to suit 152mm (6”) internal diameter flue pipe. Water outlets 25mm (1”) B.S.P. TECHNICAL DATA WOOD MANuFACTuRED SMOKELESS FuEL Room...

  • Page 10: Plumbing

    SPECIFICATION Fig.8 Fig.8a Note: Dimensions stated are in millimetres unless otherwise stated and may be subject to a slight +/- variation. PLuMBING GRAVITY CIRCuIT REGuLATIONS The gravity circuit consists of the domestic hot water The plumbing must be in accordance with all tank of 135 litres indirect cylinder, fixed in an upright relevant regulations and practices.

  • Page 11: Injector Tee

    There must be no gate valves on this circuit and it system probably in the roof space at the expansion must have an expansion pipe exhausting to tank. atmosphere. Cylinder and pipe work should be lagged to minimise heat loss. In the unlikely event that the appliance is not oper- ating in freezing conditions the water must be This diagram illustrates the basic principal of water...

  • Page 12: Important Notes

    16. Avoid contact with the appliance when in use as stove reaches very high operating temperatures. 17. This appliance should be regularly maintained by a competent service engineer. Use only replacement parts recommended by Stanley. Making unauthorised modifications, or using unautho- rised parts will invalidate your guarantee and may cause damage or injury.

  • Page 13: Lighting

    LIGHTING Before lighting the stove check with the installer that the installation work and commissioning checks described in the installation instructions have been carried out correctly and that the chimney has been swept clean, is sound and free from any obstructions.

  • Page 14: Operating Instructions

    THERMOSTAT OPERATION OPERATING INSTRuCTIONS Fig.12 RECOMMENDED FuELS All fuels should be stored under cover and kept as dry as possible prior to use. This appliance has been tested using seasoned wood logs and manufactured briquetted smokeless fuel (Ancit) for closed appliances, sized between 20g and 140g.

  • Page 15: De-Ashing

    Fig.15 The secondary air control knob may be hot when the appliance is in use. The ashpan handle is a com- bined operating tool and can be used to operate this knob or use the glove provided. To open the sec- ondary air, locate the knob under the base on the right of the stove.

  • Page 16: Changing Grate Orientation

    For best combustion of wood it is best to use a flat grate so that it can build up a bed of ash as it burns. The grate on the Lismore Stove can be changed from a coal setting to wood burning setting.

  • Page 17: Vitreous Enamel Cleaning

    Fig. 20 VITREOuS ENAMEL CLEANING General cleaning must be carried out when the stove is cool. If this stove is finished in a high gloss vitreous enamel, to keep the enamel in the best condition observe the following tips: 1. Wipe over daily with a soapy damp cloth, followed by a polish with a clean dry duster.

  • Page 18: Exploded View

    ASH DOOR - B00616AZZ 29. DOOR CATCH - V00985AXX 10. DOOR GLASS CLIP - F00003AXX 30. DAMPER ROD - V00988AXX 11. LISMORE BOILER - F01067AXX 31. RIDDLING ROD - V00989AXX 12. RIDDLING LINK - F01068AXX 32. FRONT STRIP - V00990AXX 13.

  • Page 19: Installation Check List

    INSTALLATION CHECK LIST Tick Flue System 1. Minimum Flue Height of 4.6 metres (15 feet). 2. Appliance should be connected to a minimum of 1.8 metres (6 feet) of 150mm (6”) flue pipe with a horizontal run not exceeding 300mm (12”). 3.
  • Page 20 Manufactured by Waterford Stanley Ltd., Unit 210, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315 Item No: N00524AXX DP111101...
