Accessories

Parts and Accessories available
for the Explorer SE:
10" Slimline FBS Coil
8" FBS Coil With Lower Shaft
10" Coil Skidplate
8" Coil Skidplate
Sealed 1600mA/H NiMH Battery Pack
Sealed 1800mA/H NiMH Battery Pack
'AA' Housing Battery Pack
Mains Charger
12V Car Charger
Koss UR-30 Headphones
RPG Headphones
Carbon Fibre Lower Shaft
Tall Man Lower Shaft
Armrest
Armrest Strap with Buckles
Coil Nut & Bolt (pk of 5)
Coil washers (pk of 10)
Control Box Cover
Detector Carry Bag
Instruction Manual
Minelab Cap
Minelab Polo Shirt
Minelab Sleeveless Body Warmer
Minelab Trash Bag
Recharging NiMH Battery Pack
with the Car Charger:
1 Remove battery pack (pg. 10).
2 Insert the car charger plug into the
accessories socket of your vehicle.
3 Insert the car charger plug into the
socket at the tapered end of the battery
pack. A small light on the car charger
illuminates indicating that the car
charger is in operation.
4 Leave for 18 hours to fully recharge.
If the battery was not completely
discharged, the charging time will be
shorter.
The car charger is provided with a 3AG
2Amp fast blow fuse for short circuit
protection. This can be accessed by
unscrewing the tip of the accessories plug.
Some vehicles will need the ignition to be
switched on to 'accessories' for power to be
supplied to the charger.
Charging the battery beyond full capacity
will not damage the NiMH battery pack,
but it could gradually discharge your car
battery.

Technical Specifications

Length Unextended 43 Inches (1100mm)
Length Extended 55 Inches (1358mm)
Shipping Weight 3 lb 7 oz (1700g) Excluding Batteries
Coil 10.5 inches (264mm). "Double D" Waterproof
Audio Output Internal Speaker and Headphones
Headphone Input 1/4 Inch (6.3mm) 100 Ω Stereo Jack
Transmission Full Band Spectrum. Simultaneous Frequency
Transmission ranging from 1.5kHz –100kHz
Ground Rejection Auto Ground Compensation –
Advanced Digital Filtering
Discrimination Smartfind™ Two-Dimensional Discrimination
Visual Display 64 x 128 Pixel Liquid Crystal Display (LCD)
Control Panel
Batteries 12V
Patents US 4890064, US 5537041, US 5506506
Custom Select Discrimination Yes
Learn Function (Accept/Reject) Yes
Saved Discrimination Patterns 6
Edit Function Yes
Auto Noise Cancel (Scanning) Yes
Manual Noise Cancel Yes
User Saved Settings Current, User A, User B
Response Normal, Long, Smooth, Pitch Hold
Recovery Selectable (Fast & Deep)
