WARNING!
For Outdoor Use Only.
WARNING!
Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing
this equipment.
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Notice to Installer: Leave these instructions with the gas patio heater owner for future reference.
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278
Fax: (705)725-2564 email: care@nac.on.ca web site: www.napoleongrills.com
BELLAGIO COMMERCIAL GAS PATIO HEATER
Do not try to light this appliance without
reading the "LIGHTING" instructions section of
this manual.
Do not store or use gasoline or other flam-
mable liquids or vapors in the vicinity of this
or any other appliance. An L.P. cylinder not
connected for use must not be stored in the
vicinity of this or any other appliance. If the
information in these instructions is not fol-
lowed exactly, a fire or explosion may result,
causing property damage, personal injury or
death.
Napoleon Appliance Corp.,
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
PTH31GT
WARNING
N415-0219 AUG 27/09
Advertisement
Table of Contents
Related Manuals for Napoleon PTH31GT
Summary of Contents for Napoleon PTH31GT
- Page 1 APPLY SERIAL NUMBER LABEL FROM CARTON Serial No. XXXXXX000000 MODEL NO. BELLAGIO COMMERCIAL GAS PATIO HEATER PTH31GT WARNING Do not try to light this appliance without DANGER reading the “LIGHTING” instructions section of IF YOU SMELL GAS: this manual.
-
Page 2: Conditions And Limitations
NAPOLEON products are designed with superior components and materials, and are assem- bled by trained craftsmen who take great pride in their work. Every component has been thoroughly inspected by a qualified technician before packaging and shipping to ensure that you, the customer, receive the quality product you expect from NAPOLEON. -
Page 3: Safe Operating Practices
WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating this gas patio heater. Safe Operating Practices • Read the entire instruction manual before operating the patio heater. •... -
Page 4: General Information
General Information This gas heater is certified under Canadian and American national standards, CSA 2.37a – 2008 and ANSI Z83.26a - 2008 respectively for outdoor patio heaters and must be installed to conform with local codes. When an appliance is for connection to a fixed piping system, the installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2. - Page 5 Propane Cylinder Installation: Set cylinder into hole in bottom shelf. Tighten strap over cylinder to secure it in place. Loop Strapping through slots in bottom shelf and secure over top of propane tank as illustrated Cylinder Connection: Ensure the gas regulator hose is kink free. Remove the cap from the cylinder fuel valve.
- Page 6 Leak Testing Instructions WARNING! A leak test must be performed annually and each time a cylinder is hooked up or if a part of the gas system is replaced. WARNING! Never use an open flame to check for gas leaks. Be certain no sparks or open flames are in the area while you check for leaks.
-
Page 7: Lighting Instructions
Lighting Instructions WARNING! Never use the heater while it is raining, the glass tube could crack or break causing serious injury. WARNING! Ensure burner controls are in the off position. Slowly turn on the gas supply valve. 1. Turn burner control to ‘LIGHT’ position. - Page 8 Operating The Patio Heater Initial Lighting: When lit for the first time, the patio heater emits a slight odor. This is a normal temporary condition caused by the “burn-in” of internal paints and lubricants used in the manufacturing process and does not occur again.
-
Page 9: Maintenance / Cleaning Instructions
Maintenance / Cleaning Instructions This patio heater must be thoroughly inspected and serviced annually by a qualified service person. WARNING! Always wear protective gloves and safety glasses when cleaning your patio heater. WARNING! To avoid the possibility of burns, maintenance should be done only when the patio heater is cool. -
Page 10: Troubleshooting
Troubleshooting Problem Possible Causes Solution Low heat / Low flame when For propane - improper lighting procedure. Ensure lighting procedure is followed valve turned to high. carefully. The valve must be in the off position when the tank valve is turned on. Turn tank on slowly to allow pressure to equalize. -
Page 11: Getting Started
CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly. - Page 12 7 X (M5 X 8mm) Disassemble the control box (2) from the plate cover (7) and the middle plate (1) by removing the (M5 x 8mm) screws (17). These parts were assembled at the factory to protect the parts during shipping. Désassemblez le boîtier de contrôle (2) et le couvercle de plaque (7) de la plaque centrale (1) en retirant les vis (M5 x 8 mm) (17).
- Page 13 16 X (M5 X 8) Assemble the four upper supports (5) to the lower supports (4) using the (M5 x 8mm) screws (17). The upper plate (6) is then assembled to the upper supports (5) using the (M5 x 8mm) screws (17). Fixez les quatre pattes supérieures (5) aux pattes inférieures (4), à...
- Page 14 3 X (M5 X 8) Install an AA battery (20) into the control box. Assemble the control box (2) onto the bottom of the middle plate (1) using the (M5 x 8mm) screws (17). Note : The control knob is to face to the front of the heater where the magnet is installed in the middle plate.
- Page 15 Carefully install the glass tube (8) by lifting up and inserting through the center hole in the upper plate (6). Ensure the black silicone ring is attached to the lower edge of the glass tube as To aid in installation place black illustrated.
- Page 16 12 X (M5 X 8) Attach the three side panels (15) to the heater using the (M5 x 8mm) screws (17). Note : Do not cover the front side where the control knob is. Fixez les trois panneaux latéraux (15) sur le chauffe-patio, à...
- Page 17 Propane Only – Proper Hose Connection Propane Seulement - Branchement Adéquat Du Boyau WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. AVERTISSEMENT! Assurez-vous que le boyau ne touche à aucune surface à haute température sinon il risque de fondre, de provoquer une fuite et causer un feu.
- Page 18 Leak Testing Instructions WARNING! A leak test must be performed annually and each time a cylinder is hooked up or if a part of the gas system is replaced. WARNING! Never use an open flame to check for gas leaks. Be certain no sparks or open flames are in the area while you check for leaks.
-
Page 19: Parts List
Parts List Item # Description/Part # Picture Comments Middle Plate - LH230-1-3-0 Control Box Assy - LH200-30 Preassembled in the Middle Includes: Plate Burner LP - LH100-3-8-0 Burner NAT - LH200-3A-8-0 Pilot LP - LH100-3-7A-0 Pilot NAT - LH200-3A-7-0 Valve Assy LP - LH200-3-2-0 Valve Assy NAT - LH200-3A-2-0 Pilot Tube - LH200-3-4-0 Igniter - LH100-3-10... - Page 20 Parts List Item # Description/Part # Picture Comments Tube Connectors - LH200-8 Upper Protective Guards LH230-7 Fixing Brackets - LH100-10 Side Panel - LH230-11A Front Panel - LH230-12-3-0 A chain is preassembled in this panel Screw M5 x 8mm Preassembled in relative parts Knob - LH100-12-1 Chain - LH100-12-2-0...
